iSport W227 User manual

HEART RATE BELT
compatible with:
INSTRUCTIONS FOR USE
ISPORT
FITNESS
TRACKER
STRAVA Runtastic PRO Runkeeper Adidas
MiCoach 60beat Endomondo Wahoo Utility ETC

1
SAFETY INFORMATION
... regarding the instructions for use
Read the instructions for use and the following safety information thor-
oughly before putting the device to use. Keep these instructions for use
for future reference.
... regarding children
WARNING! Danger of strangulation and asphyxiation! Do not allow
children to play with the device. Keep the device, particularly the chest
belt and packaging materials out of reach of children.
WARNING! Risk of being swallowed! Keep the device, in particular the
battery compartment cover and the battery out of reach of children.
These appliances can be used by children of 8 years and upwards and
persons with impaired physical, sensory or mental abilities, or insuf-
been instructed in the proper use of the appliance and understand the
risks involved.
Cleaning and user maintenance must not be carried out by children
without supervision.

2
... regarding correct use
The device is only intended for private use. It is not designed for com-
mercial use.
If you have been diagnosed with a heart disease, have a cardiac pace-
consulting your medical practitioner.
Do not use the device to check the frequency of a cardiac pacemaker.
Consult your medical practitioner before starting a training program.
... regarding the battery
WARNING! Risk of explosion and injury!
Do not take batteries apart!
Do not use force on batteries or deform them!
Do not recharge batteries!
Do not short circuit batteries. Do not store batteries together with
conductive metallic objects.
Protect batteries from high temperatures! Do not throw batteries on
WARNING! React correctly in case of emergency:
If a battery has been swallowed, seek medical advice immediately!
-
ous amounts of clean water and seek medical advice immediately!

3
Preparing the chest belt for wear
1. Unpack the device. The package must contain the following:
- 1 transmitter module with battery inserted
- 1 elastic chest belt
- 1 instructions for use
Info: Contact your dealer immediately if any transport damage is found.
2. First clip the chest belt into one side of transmitter module.
3. Put the chest belt on as shown below. Now clip the loose end of the chest belt into the other side of
transmitter module.
4.
and have a good skin contact.
5.
The transmitter module automatically transmits pulse data via Bluetooth® as soon as both sensor surfaces
make contact with the skin.

4
Activating the chest belt and App
The standard Bluetooth® protocol is used by this chest belt.
This makes it compatible with various Apps of iOS and Android:
- Apple:
- Android: Smart phones that support Google-Android-Version 4.3 and Bluetooth® 4.0
- Apps:
1. Activate the Bluetooth® function on the smartphone.
2. Start the App (see above). Info: Observe the conditions of use for the App:
Depending upon the APP, it may be necessary to pay to update the APP for using the heart rate
logging.
3. Open the settings in the APP and follow the instructions given to use the chest belt with the APP.
The chest belt is now connected to the APP via Bluetooth®.
Info: If you are unable to activate the chest belt and APP, tap the Bluetooth® icon on the display of your
smartphone, close an existing Bluetooth® connection and try to set up a new connection.
4.
- actual heart rate logging, max. heart rate,
- logging the number of steps taken, distance covered,
- calories burnt, activity duration, etc..
5. Now start your training schedule. Carry the smartphone as close as possible the transmitter module.
Info: We recommend carrying the smartphone in a breast pocket or pouch.
CAUTION! Protect the device from exposure to dirt, direct sunlight and extremely high or low tempera-
tures.
Info: The device is also compatible to all heart rate watches that communicate via 5.3 kHz (e.g. Polar,
Timex, SUUNTO, etc.). However, the distance between the transmitter module and heart rate watch must
not exceed 80 cm for this type of data transmission. If this distance is exceeded, signal transmission will
be unreliable.
Info:
heavy currents) can cause interference to heart rate watches. This can cause erroneous measurements.

5
Replacing the battery
CAUTION! Remove weak or discharged batteries immediately from the battery compartment, otherwise
they can leak and cause damage to the device! Remove the battery if you are not going to use the device
for a period of 3 months or more.
CAUTION! Make sure that the battery is inserted correctly,
observe the polarity! Only insert a type CR2032 lithium battery.
CAUTION! Make sure that the sealing ring in the battery compartment is seated correctly when inserting
the battery. If it is not seated correctly, the device will no longer be water resistant and can be damaged.
Cleaning the device
CAUTION! Never use paint thinners (solvent-based agents), alcohol or petrol to clean the device. Do not
wash the transmitter module or chest belt in a washing machine.
It is recommended to always clean the transmitter module as follows after use:
1. Disconnect the transmitter module from the chest belt.
2. Wipe the transmitter module dry.
3. Wash the chest belt by hand in a mild detergent solution at max. 30 °C.
4. Then rinse the chest belt out thoroughly and allow it to dry fully.
Disposal
The device and its battery must not be disposed of as household waste.
Dispose of the device and battery separately in accordance with the local environmental regula-
tions.
+

6
Troubleshooting
If the heart rate is not displayed or the app and chest belt cannot be paired, please make sure of the
following:
- Is your Smartphone equipped with Bluetooth® 4.0/-Smart?
Older versions are not supported!
- The chest belt can only be connected with one of the apps previously specied.
The app must support Bluetooth® 4.0/-Smart connection .
- No PIN is required to connect Smartphone and chest belt via Bluetooth® .
If the heart rate is still
not displayed, check the
following:
Technical data
Battery 1 x CR2032
Chest belt adjustment range 60 - 105 cm
Weight Transmitter module (without battery): 42 g
Weight, chest belt: 13 g
Compatible smartphones Apple: iPhone 4S and newer, iPad 3 and newer,
Android: Smartphones that support Google-Android-
Version 4.3 and Bluetooth® 4.0
Compatible Apps e. g.
iSport Fitness Tracker, Strava, Runtastic Pro, Runkeeper,
Compatible heart rate monitors e. g. Polar, Timex, SUUNTO etc.
Bluetooth® signal SMART
Range via Bluetooth® SMART max. 10 m
Range via 5.3 kHz (open signal) max. 80 cm
Subject to technical changes as part of constant product development.
Is the distance between the chest best and Smartphone too
far? (The maximum distance must be less than 10 m.)
Does the App in use support heart rate measurement?
Were the contacts moistened?
Does the transmitter module properly t to the body?
Is the battery in the transmitter module discharged?

FCC Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
