ISTCONTROL IRD4M User manual

Installation Guide
V.1.0.0 English
IRD4M
Smart Mobile ID Reader
1

Contents
Safety instructions ___________________________________________________________________ 3
Introduction _________________________________________________________________________ 5
Components ________________________________________________________________________ 5
Name of each part __________________________________________________________________ 5
Cables and connectors ______________________________________________________________ 6
Installation __________________________________________________________________________ 7
Product specifications________________________________________________________________ 8
Dimensions _________________________________________________________________________ 9
FCC compliance information __________________________________________________________ 10
EU Declaration of Conformity (CE)_____________________________________________________ 10
2

Warning
Noncompliance of instructions could lead to serious injury or death.
Installation
Do not install the product in a place with direct sunlight, moisture, dust, or soot.
• A fire or electric shock may occur.
Do not install the product in a place with heat from an electric heater.
• A fire or electric shock may occur due to overheating.
Install the product in a dry place.
• Otherwise, a product damage or electric shock may occur due to moisture.
Install the product in a place with no electromagnetic interference.
• Otherwise, a product damage or electric shock may occur.
The user should not install or repair the product independently.
• A fire, electric shock, or personal injury may occur.
• If the product has been damaged due to independent installation or repair of the product by the user, free A/S
service will not
be provided.
Operation
Do not allow liquids such as water, beverages, or chemicals get into the product.
• A fire, electric shock, or product damage may occur.
Caution
Noncompliance of instructions could lead to minor injury or product damage.
Installation
Do not install the power supply cable in a place where people pass by.
• Product damage or physical injury may occur.
Do not install the product near a highly magnetic object such as a magnet, TV, (especially CRT) monitor, or speaker.
• A product failure may occur.
If installing the product outside where the product is completely exposed, it is recommended to install the product
together with
the enclosure.
Keep the minimum separation distances between the devices when install multiple devices.
• Otherwise, RF performance affects to the other device, the devices may not operate normally.
Operation
Do not drop the product or apply an impact to the product.
• A product failure may occur.
When cleaning the product, wipe the product with a soft and dry cloth and no water, benzene or alcohol.
• Otherwise, a product failure may occur.
Safety instructions
Observe the following instructions to use the product safely and prevent any risk of injury or
property damage.
3

LED Indicator
Components
Wall Bracket Screw x 2
Name of each Part
IRD4M Wall Bracket Screw x 2
LED Icon indicator
Tamper Sensor
RFID card
authentication
unit
Cable
Introduction
4

PIN
English 한국어
Color 색상
1PWR +VDCRed 빨간색
2 PWR GND Black 검은색
3 WG DO Green 초록색
4 WGD1 White 흰색
5 485 TRXA Yellow(Gray Stripe) 노란색 (회색띠)
6 485 TRXB White (Gray stripe) 흰색 (회색띠)
7 RED LED Brown 갈색
8 GRN LED Orange 주황색
9 BUZZER Yellow 노란색
10 TAMPER Violet 보라색
11 EXT IN1 SKY 하늘색
12 EXT IN2 Blue 파랑색
13 EXT IN3 Pink 분홍색
14 EXT IN4 Gray 회색
Cables and
connections
5

Installation
1. Determine the correct position to install the bracket. Fix the bracket firmly using fixing
screws through the bracket to the position where IRD4M will be installed.
500mm
Wall
Distance
Wall Thickness
Wall Thickness Distance
100mm 460mm
120mm 460mm
150mm 400mm
6

2. Put the reader on top of the bracket and slightly to the right side of bracket and slide it
from right to left inserting the comb pattern side of the bracket into the groove on the back
of the reader.
3. Press the reader firmly toward the wall until you hear click sound.
7

Product Specification
Base Part
Number
Input
Voltage (VDC)
Current
Operation
Temperature Cable Length
Standby AVG Max AVG Peak
IRD4M 12V 250mA 300mA 400mA -20℃ ~ 60℃
Wiegand : 22 AWG (150m)
24 AWG (90m)
RS-485 : 4 AWG (1,200m)
24 AWG (500m)
8
•Controls LED through LED Control- RED LED, GRN LED Input.
•BUZZER Control – Controls the buzzer output through the buzzer input (Yellow).
•Optical Tamper - Once activated, and when the mounting plate is removed, the optical Tamper
is activated.
•Icon LED Control – Controls the four icon LED through EXT IN 1~4 line.
•Using the integrated Wiegand version, when the integrated Wiegand version Firmware of DNX
control is applied, also the door contact sensor signal and the Exit button signal line is
connected to EXT IN 3(pink) and EXT IN 4(gray) line of the reader. it delivers to DNX control
through the communication between the door contact signal ad the lock status signal.

9
Dimensions
128mm
20mm
86mm
60mm
99mm

• Bluetooth Transmit Power: 2.1dBm
• Bluetooth Frequency: 2402~2480 MHz
• NFC Frequency: 13.56 MHz
• RFID Frequency: 13.56 MHz
For more information, contact us at the following contact information.
ISTCONTROL, Inc.
Access Control & Integrated Solution Provider
1203, 37, Maebongsan-ro, Mapo-gu, Seoul, Republic of Korea 03909
TEL: 82+ 070-4194-1993
Website : www.istcontrol.com
Email: [email protected]
10
FCC compliance information
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
Modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment
under FCC rules.
FCC Caution
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
FCC ID : 2AZS5IRD4M
EU Declaration of Conformity (CE)
This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU.
Hereby, ISTCONTROL declares that this product is in compliance with the essential requirements and other
relevant provisions of Radio Equipment
Directive (RED) 2014/53/EU.
