ISYGLT CC-03-SL-USB User manual

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
1
Technical Data / Instruction Manual
CC-03-SL-USB
Article no. 80016022
Compact Controller slim-line with USB interface

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
2
1. Notes on documentation
These instructions are intended for qualified personnel who are
familiar with the assembly, installation and operation of the ISYGLT
system. It is essential that you read these operating instructions
through before commissioning and keep them accessible for further
use.
SEEBACHER cannot accept any liability for damage or malfunctions
resulting from failure to observe these instructions.
1.1. Retention of documents
These instructions and all other applicable documents are part
of the product. They must be handed over to the device operator.
The operator will store the documents so that they can be made
available if necessary.
1.2. Symbols used
Observe the following safety and other instructions in the manual:
Handling instruction
The hand indicates that you should carry out an act.
Danger!
Immediate danger to life!
Attention!
General notes, useful information and special features
Directory of Content
1. Notes on documentation
1.1. Retention of documents
1.2. Symbols used
2. Safety instructions
2.1. Intended usage
2.2. Predictable mishandling
2.3. Safe handling
2.4. Qualification of staff
2.5. Changes to the product
2.6. Use of spare parts and additional equipment
2.7. Liability notes
3. Warranty
4. Declaration of Conformity
5. Service address
6. Maintenance / Care / Disposal
7. Storage
8. Assembly
9. Product description
10. Technical Data
10.1. Pin assignment
11. Wiring diagram

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
3
The module is designed for cabinet installation on a 35mm DIN
rail according to EN 60715 in corresponding standard housings.
Extreme environmental conditions impair the function of the pro-
duct.
• Protect module from shocks
• Use module indoors only
• Protect module from humidity
In addition to these safety instructions, you must also observe
the special safety instructions listed in the individual chapters for
the individual acts.
2.4. Qualification of staff
Assembly, commissioning, operation, maintenance, decommis-
sioning and disposal may only be carried out by qualified staff.
Work on electrical parts may only be carried out by a trained
electrician in accordance with the applicable regulations and
directives. Other activities in connection with the ISYGLT module,
such as assembly and installation of system components with
tested standard plug connections, as well as operation and con-
figuration of the ISYGLT module may only be carried out by trai-
ned staff.
2.5. Changes to the product
Unauthorized modifications to the ISYGLT module which are not
described in this or the other applicable instructions can lead to
malfunctions and are prohibited for safety reasons.
2.6. Use of spare parts and additional equipment
The module may be damaged if unsuitable spare parts and addi-
tional equipment are used. Only use original spare parts and
additional equipment from the manufacturer.
2.7. Liability notes
SEEBACHER accepts no liability or warranty whatsoever for
damage and consequential damage caused by non-compliance
with the technical regulations, instructions and recommendati-
ons. SEEBACHER shall not be liable for any costs or damage
incurred by the user or third parties as a result of the use of this
equipment, in particular improper use of the equipment, misuse
or malfunction of the connection, malfunction of the equipment
or connected devices.
SEEBACHER accepts no liability for printing errors.
2. Safety instructions
Observe the following general safety instructions when installing
and commissioning the device:
Assembly and installation of the ISYGLT module may only be carried
out by a qualified electrician. Other activities in connection with the
ISYGLT module, such as assembly and installation of system com-
ponents with tested standard plug connections, as well as operation
and configuration of the ISYGLT module may only be carried out by
trained staff.
Observe the electrical installation regulations of the country in which
the device is installed and operated as well as its national accident
prevention regulations. In addition, observe internal company regu-
lations (work, operating and safety regulations).
Before working on the ISYGLT module system, it must be
disconnected from the power supply and secured against
being switched on again. After completion of the assembly,
installation and maintenance work, an electrical check must
be carried out! Check all protective conductor connections
and the voltages at all connection plugs as well as at each
individual module slot.
2.1. Intended usage
The module is exclusively suitable for regulation (control) in con-
nection with ISYGLT system components. Any other use is not
intended. The limit values stated in the technical data must not be
exceeded under any circumstances. This applies in particular to
the permissible ambient temperature range and the permissible
IP protection type. For applications with a higher required IP pro-
tection type, the ISYGLT module must be installed in a housing
or a cabinet with a higher IP protection type.
2.2. Predictable mishandling
The module must not be used in the following cases in particular:
•explosive area
When operating in explosive areas, sparking can lead to defla-
gration, fire or explosions.
2.3. Safe handling
This module corresponds to the state of the art and the recog-
nised safety regulations. Each device is tested for function and
safety before delivery.
Only operate this module in perfect condition in accordance with
the operating instructions, the applicable regulations and directi-
ves of the country in which the device is installed and operated,
and the applicable safety and accident prevention regulations.

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
4
6. Maintenance / Care / Disposal
The product is maintenance-free. It is sufficient from time to time to
remove any dust deposits. This may only be done in a power-free
state.
Disposal (European Union)
Do not dispose of product in household waste! Products with this
symbol
7. Storage
The product must be stored in a dry place, protected from dirt and
mechanical stress. After damp or dirty storage, the product may only
be operated after a condition check by an authorised electrician.
8. Assembly
(Only by certified electrician!)
Mount the product only when it is in a power-free state!
Switch off the power supply, check that there is no voltage, secure
against being switched on again!
The device may only be operated at voltages according to the tech-
nical data and loaded with the currents defined therein. Only use
suitable equipment (system modules).
Check that there are no loose parts in the product. If this is the case
and the presence of such parts is not explicitly described, do not
install or commission the product.
Only use suitable cables and fixing screws.
Assembly site
• The product can be installed in any position in a casing to be deter-
mined by the electrician (distribution box, switch cabinet). Observe
maximum ambient temperature!
Assembly steps
(Read completely before assembly!)
• Mount the device in a suitable casing.
• Make the electrical connections according to the wiring diagram.
• Congure the DIP switches according to your requirements.
• Only after a complete connection and a visual test by a qualied
electrician, the system may be put under voltage.
Seebacher GmbH
Marktstrasse 57
83646 Bad Tölz
GERMANY
Phone: [phone] / 77 77 6
Fax: [phone] / 77 77 2
www.seebacher.de
[e-mail]
5. Service address
4. Declaration of Conformity
The valid declaration of conformity for the module can be requested
from us free of charge by stating type and article no. as follows:
By phone: [phone]
By fax: [phone]
By mail: [e-mail]
3. Warranty
We provide warranty within the framework of the statutory provisi-
ons. These are limited to the intended use of the module and refer
to the repair or replacement of the ISYGLT module. Please send the
device with an attached error description to our company address
given below.
must be disposed of according to the EU directive WEEE 2012/19/
EU on waste electrical and electronic equipment at the local collec-
tion points for waste electrical and electronic equipment!

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
5
Inputs / outputs
• 1 relay output 230V 1500VA (max. 6,5A) hybrid technology with Triac-zero-voltage switch
• 8 inputs 24V for buttons
• 8 outputs for feedback
• 4 rotational potentiometer
• 1 RS-485 interface for the subnet BUS
• 1 USB Type-B interface for connection to the PC for programming
Connections
• 1 relay output 230V 6.5A
• 1 connection for subnet (BUS A and B, RS-485)
• 1 connection for operating voltage (Ub, 0V)
• 2 P-COM connections (subnet and operating voltage)
• 8 outputs (NPN minus switching against common “+(A)“)
• 8 inputs (on a common reference terminal “+(E)“)
• 1 connection USB Type-B for programming
9. Product description
The compact controller „slim line“ CC-03-SL-USB
is designed for performing smaller control tasks. On
the part of the hardware are 1 relay output in hybrid
technology, 4 potentiometers, 8 small-light control-
keys-circuit points and 8 small-light control-feedback
available. With these conditions, a large number of
small controllers can be realized. The ISYGLT con-
troller is freely programmable and expandable with
the available ISYGLT BUS components.
Function displays
• 1 ashing yellow LED „BUS“ indicates trouble-free data transfer on the ISYGLT BUS
• 1 ashing green LED „Betrieb“ indicates the processor function:
Steady ashing means „system ok, but no DCF-77 time detected“.
2x short ashing followed by a pause means „system ok and valid DCF-77 time detected“
• 1 red LED „Power“ indicates the operating voltage
Design
• light grey plastic housing, can be put on 35mm DIN rail, 6 HP

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
6
Type designation CC-03-SL-USB
Article no. 80016022
Operating voltage 12V to 35V DC
Current consumption 100mA at 24V + power for feedback outputs, max. 150mA = sum max. 250mA
Inputs (buttons) 24V DC, input current per input 5mA at 24V (only own voltage by bridge can be used!)
max. cable length: 50m
Outputs (feedbacks) 24V DC 0V switching, against internal + limited to 150mA, max. cable length: 50m
Relay output 230V 1500VA (max. 6.5A) with triac-zero-voltage switch
Isolation voltage 1000V (ISYGLT BUS / analog outputs)
Interface 1 RS-485 subnet BUS max. 5.6V limited by Z-diodes
Interface 2 USB 2.0 Type-B socket to connect a PC for programming
Program memory Program memory for user program:
24 KByte (EEPROM) programmable
Scene memory:
8 KByte (EEPROM) for light scenes, non-volatile (not expandable)
Weight 200g
Connection Screw terminals 2.5mm² pluggable, spring-type terminals 1.5mm² pluggable
Operating temperature -10°C to +50°C
Storage temperature -25°C to +70°C
Dimensions WxHxD 106x90x59mm (6 HP)
Humidity 0 to 85% relative humidity, not condensing
Protection class IP 30
CE mark Yes
10. Technical data
10.1. Pin assignment
Terminal Down left
@Ub Operating voltage
0V 0V Operating voltage
A BUS A (subnet RS-485)
B BUS B (subnet RS-485)
Socket Top left (under the cover)
USB typ-B Programming interface
Terminal Top right
Free
Free
A8 Hybrid relay output 230V 6.5A (coupled with feedback output A8)
A8 Hybrid relay output 230V 6.5A (coupled with feedback output A8)

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
7
Terminal Down right (front row)
+(E) +24V current-limited for inputs
E1 Input 1
E2 Input 2
E3 Input 3
E4 Input 4
E5 Input 5
E6 Input 6
E7 Input 7
E8 Input 8
Free
Free
Free
Terminal Down right (back row)
+(A) +24V current-limited for outputs
A1 Output 1
A2 Output 2
A3 Output 3
A4 Output 4
A5 Output 5
A6 Output 6
A7 Output 7
A8 Output 8
Free
Free
Free
View

Seebacher GmbH www.seebacher.de Phone: [phone] / 77 77 6
Marktstrasse 57, 83646 Bad Tölz [e-mail] Fax: [phone] / 77 77 2
8
11. Wiring diagram





 
 















 
 
 
                 
 
Misprints and technical changes reserved.
