iSystem Aurora MPC5 Series User manual

MPC5xxx/SPC5 Galvanic Isolation Adapter
User Manual
V1.2
November 2022

This document and all documents accompanying it are copyrighted by iSYSTEM AG and all rights are
reserved. Duplication of these documents is allowed for personal use. In all other cases, written consent
from iSYSTEM is required.
iSYSTEM AG. All rights reserved.
All trademarks are property of their respective owners.
www.isystem.com

Contents
MPC5xxx/SPC5 14-pin 2.54mm Galvanic Isolation Adapter
Package content ...................................................................................................................................... 5
Specifications ........................................................................................................................................... 6
Device overview ....................................................................................................................................... 7
Connecting procedure ............................................................................................................................. 9
Accessories ............................................................................................................................................. 10
User Notes .............................................................................................................................................. 11

MPC5xxx/SPC5 14-pin 2.54mm Galvanic Isolation
Adapter
Galvanic isolation is used where two electric circuits must communicate, but their grounds
may be at different potentials. It is an effective method of breaking ground loops between the
two circuits. Galvanic isolation is also used for safety, preventing accidental current from
reaching ground through a person's body.
iSYSTEM Galvanic Isolation Adapters provide a basic isolation that withstands high voltages.
To prevent injury to personnel when dealing with potentially hazardous voltages it is
mandatory to have a second protection measure in place, in case the first insulation barrier
fails. This is termed double or, reinforced isolation. How should a double isolation be
implemented depends on the use-case or application setup.
It is your responsibility to check the local safety directives applicable to your company
and country to ensure that all requirements are met.
MPC5xxx / SPC5 14-pin 2.54 mm Galvanic Isolation Adapter is used to electrically isolate:
· iSYSTEM iC5700 BlueBox in conjunction with
o14-pin 2.54 mm MPC5xxx Debug Adapter (Ordering code IC50150) or
oMPC5x/SPC5x Aurora Active Probe MPC5x/SPC5x Aurora Active Probe (Ordering code
IC57150) + 14-pin 2.54 mm JTAG Converter (Ordering code IASAM34MPCPIN14)
from the embedded target.
Find more information on www.isystem.com or contact [e-mail]. To reach
for technical support, please visit www.isystem.com/support.

Package content
MPC5xxx / SPC5 14-pin 2.54 mm Galvanic Isolation Adapter is delivered with the following
components:
MPC5xxx / SPC5 14-pin 2.54
mm
Galvanic Isolation Adapter
USB-C Power supply
Ribbon cable
Ordering code:
IEA-GI-MPC
Ordering code:
IT5V2AUSBC-PS
Ordering code:
IA14PIN14PIN254-10
User Manual

Specifications
GENERAL
Operating temperature
10°C to 40°C
Storage temperature
-10°C to 60°C
MECHANICAL
Size
65 x 40 x 19 mm
Weight
approx. 55 g
ELECTRICAL
Isolation Type
Basic
Isolation Ratings
1 kVrms
VIORM *
560 V peak
DEBUG TOOL SIDE
Supply Voltage
5 V (via attached power supply)
Max Supply Current
50 mA
TARGET SIDE
Supply Voltage
3 V - 5 V (via VREF)
Max Supply Current
50 mA
PERFORMANCE
JTAG
Up to 50 MHz
VIORM is defined as the maximum repetitive peak voltage that the isolator can
withstand.
Make sure that the target side provides a reference voltage (VREF) for the adapter to
work properly.

Device overview
The top face of the Galvanic Isolation Adapter features:
A – DEBUG TOOL connector.
B – TARGET connector.
C– LED lights indicate power supply status.
If LEDs on the GI Adapter are OFF, immediately turn everything OFF!
The side face of the Galvanic Isolation Adapter features:
D – USB-C Power supply socket (PWR).
Use only original iSYSTEM USB-C Power supply for powering and connecting with the GI
Adapter, otherwise the primary functionality of the GI Adapter would be counteracted.

Pinout
The following pinout is valid on the target side:
Signal
Direction
Signal Description
Signal
Pin
Pin
Signal
Signal Description
Signal
Direction
O
JTAG
TDI
1
2
GND
Ground
I
JTAG
TDO
3
4
GND
Ground
O
JTAG
TCK
5
6
GND
Ground
O
Nexus Event Input
nEVTI(EVTI0)
7
8
PORST
Power On Reset
I/O
I/O
Reset
nRESET
9
10
TMS
JTAG
O
I
Reference Voltage
Vref
11
12
GND
Ground
Not Connected
NC
13
14
JCOMP
JTAG TRST (optional)
O
14-pin MPC5xxx & SPC5 target pinout

Connecting procedure
Do not use a Grounding wire between the BlueBox and the embedded target since it
would counteract the primary functionality of the Galvanic Isolation (GI) Adapter!
1. Make sure your hardware is powered OFF.
· Embedded Target
· BlueBox
· GI Adapter
2. Connect a Debug Adapter to the BlueBox. Refer to the BlueBox User Manual for more details
on connecting the Debug Adapter.
3. Connect the Debug Adapter to the GI Adapter.
4. Connect 1:1 Ribbon cable which is delivered along this package to the GI Adapter.
5. Connect 1:1 Ribbon cable to the embedded target.
6. Connect BlueBox, GI Adapter and Target to the power supply.
Use only original iSYSTEM USB-C Power supply for powering and connecting with the GI
Adapter, otherwise the primary functionality of the GI Adapter would be counteracted.
7. Power ON the hardware in the following order:
· BlueBox
· GI Adapter
· Target
If LEDs on the GI Adapter are OFF, immediately turn everything OFF!

Accessories
Ordering Code
Description
IC57000
iC5700 BlueBox
IC57150
MPC5x/SPC5x Aurora Active Probe
IC50150
14-pin 2.54 mm MPC5xxx Debug Adapter
IASAM34MPCPIN14
14-pin 2.54 mm JTAG Adapter
Please refer to the iC5700 BlueBox User Manual for all current iC5700 Accessories.
Find more information on www.isystem.com or contact [e-mail]. To reach
for technical support, please visit www.isystem.com/support.
