iSystem MPC5 /SPC5 Series User manual

MPC5xxx/SPC5 Galvanic Isolation Adapter
User Manual
V1.0

This document and all documents accompanying it are copyrighted by iSYSTEM AG and all rights are
reserved. Duplication of these documents is allowed for personal use. In all other cases, written consent
from iSYSTEM is required.
iSYSTEM AG. All rights reserved.
All trademarks are property of their respective owners.
iSYSTEM is an ISO 9001 certified company.
www.isystem.com

Contents
MPC5xxx/SPC5 14-pin 2.54mm Galvanic Isolation Adapter
Package content ...................................................................................................................................... 5
Specifications ........................................................................................................................................... 6
Device overview ....................................................................................................................................... 7
Connecting procedure ............................................................................................................................. 9
Accessories ............................................................................................................................................. 10
User Notes .............................................................................................................................................. 11

MPC5xxx/SPC5 14-pin 2.54mm Galvanic Isolation
Adapter
Galvanic isolation is used where two electric circuits must communicate, but their grounds
may be at different potentials. It is an effective method of breaking ground loops between the
two circuits. Galvanic isolation is also used for safety, preventing accidental current from
reaching ground through a person's body.
iSYSTEM Galvanic Isolation Adapters provide a basic isolation that withstands high voltages.
To prevent injury to personnel when dealing with potentially hazardous voltages it is
mandatory to have a second protection measure in place, in case the first insulation barrier
fails. This is termed double or, reinforced isolation. How should a double isolation be
implemented depends on the use-case or application setup.
It is a user's responsibility to check local safety related directives valid for his company
and country to make sure all requirements are met.
MPC5xxx / SPC5 14-pin 2.54mm Galvanic Isolation Adapter is used to electrically isolate:
· iSYSTEM iC5700 BlueBox in conjunction with
· 14-pin 2.54 mm MPC5xxx Debug Adapter (Ordering code IC50150) from the embedded
target.
Find more information on www.isystem.com or contact [e-mail]. To reach
for technical support please visit www.isystem.com/support.

Package content
MPC5xxx / SPC5 14-pin 2.54 mm Galvanic Isolation Adapter is delivered with the following
components:
MPC5xxx / SPC5 14-pin
2.54 mm
Galvanic Isolation Adapter
USB-C Power supply
Ribbon cable
Ordering code:
IEA-GI-MPC
Ordering code:
IT5V2AUSBC-PS
Ordering code:
IA14PIN14PIN254-10
User Manual

Specifications
GENERAL
Operating temperature
10°C to 40°C
Storage temperature
-10°C to 60°C
MECHANICAL
Size
65 x 40 x 19 mm
Weight
approx. 55 g
ELECTRICAL
Isolation Type
Basic
Isolation Ratings
1kVrms
VIORM
560Vpeak
DEBUG TOOL SIDE
Supply Voltage
5V (via attached power supply)
Max Supply Current
50mA
TARGET SIDE
Supply Voltage
3V - 5V (via VREF)
Max Supply Current
50mA

Device overview
The top face of the Galvanic Isolation Adapter features:
A – DEBUG TOOL connector.
B – TARGET connector.
C– LED lights indicate power supply status.
If LEDs on the Galvanic Isolation Adapter are OFF, immediately turn everything OFF!
The side face of the Galvanic Isolation Adapter features:
D – USB-C Power supply socket (PWR).
Use only original iSYSTEM USB-C Power supply for powering and connecting with the
Galvanic Isolation Adapter, otherwise the primary functionality of the Galvanic Isolation
Adapter would be counteracted.

Pinout
The following pinout is valid on the target side:
Signal
Direction
Signal
Description
Signal
Pin
Pin
Signal
Signal
Description
Signal
Direction
O
JTAG
TDI
1
2
GND
Ground
I
JTAG
TDO
3
4
GND
Ground
O
JTAG
TCK
5
6
GND
Ground
O
Nexus Event
Input
nEVTI(EVTI0)
7
8
PORST
Power On
Reset
IO
I/O
Reset
nRESET
9
10
TMS
JTAG
O
I
Reference
Voltage
Vref
11
12
GND
Ground
Not Connected
NC
13
14
JCOMP
JTAG TRST
(optional)
O
14-pin MPC5xxx & SPC5 target pinout

Connecting procedure
Do not use a Grounding wire between the BlueBox and the embedded target since it
would counteract the primary functionality of the Galvanic Isolation Adapter!
1. Make sure your hardware is powered OFF.
· Embedded Target
· BlueBox
· Galvanic Isolation Adapter
2. Connect a Debug Adapter to the BlueBox. Refer to the BlueBox User Manual for more details
on connecting the Debug Adapter.
3. Connect the Debug Adapter to the Galvanic Isolation Adapter.
4. Connect 1:1 Ribbon cable which is delivered along this package to the Galvanic Isolation
Adapter.
5. Connect 1:1 Ribbon cable to the embedded target.
6. Connect BlueBox, Galvanic Isolation Adapter and Target to the power supply.
Use only original iSYSTEM USB-C Power supply for powering and connecting with the
Galvanic Isolation Adapter, otherwise the primary functionality of the Galvanic Isolation
Adapter would be counteracted.
7. Power ON the hardware in the following order:
· BlueBox
· Galvanic Isolation Adapter
· Target
If LEDs on the Galvanic Isolation Adapter are OFF, immediately turn everything OFF!

Accessories
Ordering Code
Description
IC57000
iC5700 BlueBox
IC50150
14-pin 2.54mm MPC5xxx Debug Adapter
Please refer to the iC5700 BlueBox User Manual for all current iC5700 Accessories.
Find more information on www.isystem.com or contact [e-mail]. To reach
for technical support please visit www.isystem.com/support.

User Notes
This page is intentionally left blank.
