itam PT-7200 User manual

For sale and use in :
AT, BE, BG, CH, CY, CZ, DE, DK, EE, ES, FI, FR,
GB, GR, HU, IE, IT, LT, LU, NL, NO, PL, PT, RO,
SE, SI, SK
PT-7200 UHF / VHF
Handfunkgerät
Handheld Transceiver
Bedienungsanleitung
Manual
Manuale d’uso
TEAM Electronic GmbH
Bolongarostrasse 88; D-65929 Frankfurt am Main, Germany
phone ++49 / 69 / 300 950 0 - fax ++49 / 69 / 31 43 82
www.team-electronic.de - [email protected]
WEEE - Reg. Nr. DE 91930360 8 ( EAR ), 50635 ( ERA )
GRS-Nr. 10001374
DSD 2617305, ARA 2284
manual_pt-7200_2.qxp 22.07.2008 14:52 Seite 1

22 23
Dear Customer,
we thank you for the purchase of the PT-7200. Please read this instruc-
tion manual carefully before using the PT-7200 for the first time. You will
learn about the different features and functions of your new handheld
transceiver.
The use of commercial frequencies requires a licence. For more informa-
tion about the regulations, fees and applications contact your local gov-
ernment agency in charge of telecommunication.
We recommend, to get the radio programmed by an authorized TEAM
dealer. The radio has to be programmed according to the restrictions of
the individual licence of the user.
Safety
It is important that the user is aware of and understands hazards com-
mon to the operation of any transceivers.
Warning!
Turn off your transceiver prior to entering any area with a potentially
explosive atmosphere (where the air contains gas, dust and smog,
etc.), e.g. gasoline service stations.
Precautions in Use
Please follow the instructions to avoid fire, bodily injury and damage of
the transceiver.
It is recommended not to exceed the maximal times for transmission
(1 minute) and reception (4 minutes) since these operation tasks gen-
erate heat. Too much heat may cause damage.
Please do not disassemble or assemble the transceiver under any cir-
cumstances.
Please do not expose the transceiver to direct sunlight for a long time;
do not place the transceiver near any heating devices, either.
Please do not put the transceiver in extremely dusty or moist places;
do not place it on unstable surfaces, either.
If the transceiver emits smoke or strange odors, turn it off, remove the
battery from the transceiver and immediately contact your authorized,
local TEAM Electronic dealer.
Contents page
1 Unpacking and Checking 23
1.1 Supplied Accessories 23
2 Preparation 23
2.1 Battery Info 24 - 26
2.2 Battery Care Tips 26 - 27
2.3 Battery Recycling and Disposing 27
2.4 Charging the Battery 27
3 Accessories 28
3.1 Installing/Removing the Battery Pack 28
3.2 Installing the Antenna 28
3.3 Installing the Belt Clip 28
3.4 Installing the Dust Cover 28
3.5 Connecting the Accessory 28
4 Getting Acquainted 29
4.1 Radio Overview 29
5 Basic Operation 30
6 Programmable Dual Keys 30 - 34
Annunciation Type Selection 31
Whisper 31
Talkaround 31
Call 1 / 2 / 3 / 4 31
Lone Work 32
Emergency Call Cancel Call 32
Scan 32
Noise Channel Delete 32
Call Forward 32
High / Low Power 32
Squelch Adjust 33
Monitor Momentary 33
Monitor 33
Squelch Off Momentary 33
Squelch Off 33
Lock Keyboard 33
Compander 33
Scrambler 33
Battery Check 33
Rental Time Check 33 - 34
7 Auxiliary Functions 34
7.1 Vox 34
7.2 Wire Clone Mode - 34
7.3 Time-Out-Timer 35
7.4 Power Save 35
7.5 Low Battery Level Alert 35
7.6 CTCSS / DCS 35
7.7 5-Tone Selective Calling 36
7.8 DTMF 36
8 Specification 37
9 Programmed Settings 38 - 41
GB GB
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 23

24 25
1 Unpacking and Checking
Unpack the transceiver set carefully. We recommend that you identify
the listed items before discarding the packing material. If any items are
missing or have been damaged during shipment, please contact the
dealer immediately.
1.1 Supplied Accessories
1 x Antenna 1 x Belt clip 1 x Dust cover
1 x Screw 1 x Battery 1 x Charger
1 x Power adapter 1 x User's Manual 1 x Hand strap
2 Preparation
2.1 Battery Precautions
CAUTION
1) Do not attempt to charge a fully charged battery pack. Doing so,
may shorten the lifetime of the battery pack or the battery pack may
get damaged.
2) Upon completion of charging process, disconnect the battery pack
from the charger. If the charger power is reset (turned ON after
being turned OFF), recharging will start again and the battery pack
will be overcharged.
3) Do not use the transceiver while charging the battery pack. We re-
commend you switch the transceiver power OFF during charging.
4) Do not expose the battery pack to heat or fire.
5) Never attempt to remove the casing from the battery pack.
DANGER!
1) Do not disassemble or reconstruct the battery pack!
The battery pack has a safety function and protection circuit to avoid
danger. If they suffer serious damage, the battery may generate
heat or smoke, rupture, or burst into flame.
2) Do not short-circuit the battery!
Do not join the + and - terminals using any form of metal (such as a
paperclip or wire). Do not carry or store the battery pack in contain-
ers holding metal objects (such as wires, chain-necklace or hair-
pins). If the battery pack is short-circuited, excessive current will
flow and the battery may generate heat or smoke, rupture, or burst
into flame. It will also cause metal object to heat up.
3) Do not apply heat to the battery!
If the insulator is melted, the gas release vent or safety function is
damaged, or the electrolyte is ignited, the battery may generate
heat or smoke, rupture, or burst into flame.
4) Do not place the battery near fires, stoves, or other heat sources!
If the polymer separator melts due to high temperature, an internal
short-circuit may occur in the individual cells and the battery may
generate heat or smoke, rupture, or burst into flame.
5) Do not immerse the battery in water or get it wet by other means!
If the battery's protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke, rup-
ture, or burst into flame.
6) Do not charge the battery near fires or under direct sunlight!
If the battery's protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke, rup-
ture, or burst into flame.
7) Use only the specified charger and observe charging require-
ments!
If the battery is charged in unspecified conditions (under high tem-
perature over the regulated value, excessive high voltage or cur-
rent over regulated value, or with a remodeled charger), it may
overcharge or an abnormal chemical reaction may occur. The bat-
tery may generate heat or smoke, or burst into flame.
8) Do not pierce or strike the battery with any object or step on it!
This may break or deform the battery, causing a short circuit. The
battery may generate heat or smoke, rupture, or burst into flame.
9) Do not jar or throw the battery!
An impact may cause the battery to leak, generate heat or smoke,
rupture, and/or burst into flame. If the battery's protection circuit is
damaged, the battery may charge at an abnormal current (or volt-
age), and an abnormal chemical reaction may occur. The battery
may generate heat or smoke, rupture, or burst into flame.
10) Do not use the battery pack if it is damaged in any way!
The battery may generate heat or smoke, rupture, or burst into
flame.
11) Do not solder directly onto the battery!
If the insulator is melted or the gas release vent or safety function
is damaged, the battery may generate heat or smoke, rupture, or
burst into flame.
12) Do not reverse the battery polarity (and terminals)!
When charging a reversed battery, an abnormal chemical reaction
may occur. In some cases, an unexpected large amount of current
may flow upon discharging. The battery may generate heat or
smoke, rupture, or burst into flame.
13) Do not reverse-charge or reverse-connect the battery!
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating equip-
ment, do not force it; check the polarity of the battery. If the battery
GB GB
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 25

26 27
pack is reverse-connected to the charger, it will be reverse-charged
and an abnormal chemical reaction may occur. The battery may gen-
erate heat or smoke, rupture, or burst into flame.
14) Do not touch a ruptured and leaking battery!
If the electrolyte liquid from the battery gets into your eyes, wash your
eyes out with fresh water as soon as possible, without rubbing your
eyes. Go to the hospital immediately. If left untreated, it may cause
eye-problems.
WARNING
1) Do not charge the battery for longer than the specified time!
If the battery pack has not finished charging even after the regulat-
ed time has passed, stop the charging process. The battery may
generate heat or smoke, rupture, or burst into flame.
2) Do not place the battery pack into a microwave or highpressure
container!
The battery may generate heat or smoke, rupture, or burst into
flame.
3) Keep ruptured and leaking battery packs away from fire!
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte leaking
from battery can easily catch on fire and cause the battery to gen-
erate smoke or burst into flame.
4) Do not use an abnormal battery!
If the battery pack emits a bad odor, appears to have different color-
ing, is deformed, or seems abnormal for any other reason, remove it
from the charger or operating equipment and do not use it. The bat-
tery may generate heat or smoke, rupture, or burst into flame.
2.2 Battery Care Tips
The transceiver is equipped with a TEAM Li-Poly battery pack. The
following tips help you to get the best battery performance and pro-
loged battery life.
1) Charge the new battery pack continuously for 4~5 hours before its
initial using, which ensures the maximum battery capacity and best
performance in using.
2) Do not attempt to charge the TEAM battery pack in any other charg-
er than the one included in the scope of delivery.
3) The battery pack can be charged while in the transceiver, and to
ensure it is fully charged it's recommended to charge the battery
pack with the transceiver turned off.
4) The ideal temperature to store the battery pack is 25 (room tem-
perature). Charging the battery pack at a low temperature (below
0°C) will cause electrolyte leakage and damage to the battery pack.
5) Charging the battery pack at a high temperature (above 35 °C ) will
cause decrease in battery discharge capacity and affect the trans-
ceiver performance.
6) The new or used battery should be stored in a cool and dry place.
7) If recharge the battery pack after long storage, you should
charge it continuously for 4~5 hours.
8) Do not leave the transceiver and the battery in the charger when
not charging. Overlong charging will shorten the battery life.
(Please do not use the charger as the transceiver's mounting
bracket.)
2.3 Battery Recycling and Disposing
After the battery life expires, the Li-Poly battery pack has to be recy-
cled. Please , however, the recycling facilities are not available every-
where. TEAM goes in for the recycling of all the rechargeable batter-
ies. For more details please contact your local TEAM distributor.
2.4 Charging the Battery
A new battery, or a battery with low power level needs to be
charged completely.
Left LED - Red The battery is in the state of charging.
Middle LED - Green The battery is fully charged or the battery
is not inserted properly into the charger.
Right LED - Yellow The battery temperature is abnormal or the
battery is defect.
1) Connect the power adapter with the battery charger. Plug the
adapter into an AC wall outlet and the indicator turns green.
2) Place the battery or transceiver into the charger slot. The indicator
turns red or flashes, then the charger gets in the state of charging
automatically. Charging time depends on battery capacity. When
battery is fully charged the middle LED turns green.
Notes:
1) The battery is not fully charged in the factory.
Before the initial use, please charge the new battery continu-
ously for 4~5 hours.
2) The charger will stop charging and the left, red LED will go off.
If the charger detects a damaged battery or if the temperature
of the battery is too high, then the right LED will light yellow.
3) The charger detects if the battery is fully charged and stops
charging.
4) Partly charged battery packs will be discharged first, before
charging process starts.
GB GB
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 27

28 29
3 Accessories
3.1 Installing/Removing the Battery Pack
To install the battery pack:
1) Match the two bulges, located at the bottom of
the of the battery pack, with the corresponding holes at the rear
bottom of the transceiver;
2) Then firmly press the battery pack downwards
to lock it in place until a click is heard.
To remove the battery pack:
Push the latch with your thumb to unlock the battery
pack. Carefully remove the battery pack.
3.2 Installing the Antenna
Screw the antenna into the connector at the top of the
transceiver by holding the bottom of the antenna and turn-
ing it clockwise.
3.3 Installing the Belt Clip
Match the grooves of the belt clip with those on the rear
of the battery pack. Then press the belt clip downwards to
lock it in place.
3.4 Installing the Dust Cover over the Versatile Connector
When not using the optional Speaker/Microphone, use the dust
cover over the versatile connector with the supplied screw.
3.5 Installing the Optional Speaker / Microphone
The connection plugs of the PT-7200 accesssories have
a guide pin and a screw attached.
Position the guide pin, then ensure that the contacts of
connector and jack are in place. Next, thighten the screw.
Notes:
Only use the original TEAM accessories for the PT-7200.
Optional accessories, e.g. ear- / microphone, are not included in
the scope of delivery.
4 Getting Acquainted
4.1 Radio Overview
1 Antenna
2 LED Indicator
> Lights red in transmission mode;
> Lights green in reception mode;
>Flashes orange when receiving authorized DTMF and 5-Tone
signals.
> Flashes red when battery level is low. 3 Channel Selector
3 Rotary Channel Selector - select channel 1-16.
4 Power/Volume Switch
Turn clockwise to switch on the radio. Turn counterclockwise till
a click is heard to switch off the radio. Rotate to adjust the vol-
ume after turning on the radio.
5 Side Key 1
Programmable double-function key: Press short for acitivation of
first function and long for second function.
6 PTT (Push-to-talk)
To make a call, press and hold the PTT button, then speak into
the microphone with normal voice. Release the PTT button to
switch to reception mode.
7 Side Key 2
Programmable double-function key: Press short for acitivation of
first function and long for second function.
8 Top Key (Emergency Button)
Programmable double-function key: Press short for acitivation of
first function and long for second function. Recommended for
emergency functions.
9 Microphone/Speaker Jacks
For connection of accessory, programming cable and clone
cable.
GB GB
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 29

30 31
5 Basic Operation
Power On
Switch on the radio by turning the Power/Volume switch clockwise
until a click is heard. If programmed, a beep tone is audible and the
actual channel is announced.
Channel Selection
For setting the channel 1 - 16, rotate the channel selector. If voice
annunciation is activated, the actual channel is announced.
Transmission Mode
To transmit a signal, press PTT, and speak in normal voice with a
distance of 5 cm to microphone.
To transmit without pressing the PTT key, program the Vox func-
tion.
When transmitting a signal the LED lights red.
Reception Mode
By default, the radio is in reception mode. The LED lights green
when a signal is received.
6 Programmable Dual-Keys
Each of the three dual-keys can be programmed with a maximum
of two functions. Function 1 is triggered by pressing the key short-
ly. Function 2 is acitvated / deacitvated by the pressing the key
long. The required time period, for triggering function 2, can be pro-
grammed.
The assignment of the functions to the keys are programmed via
software. More information about programming the various func-
tions and their settings can be found in the manual of the software
T-UP10.
GB GB
Available Functions
None
Annunciation Type Selection
Whisper
Talkaround
Call 1 / 2 / 3 / 4
Lone Work
Emergency Call
Cancel Emergency Call
Scan
Noise Channel Delete
Call Forward
High / Low Power
Squelch Adjust
Monitor Momentary
Monitor
Squelch Off Momentary
Squelch Off
Lock Keyboard
Compander
Scrambler
Battery Check
Rental Time Check
None
No function assigned
Annunciation Type Selection
On / Off english voice annunciation
Programmable options: male / female either only channel or chan-
nel and functions.
Whisper
On / Off whisper mode
The microphone gain can be increased by a max. of 4 dB to allow
whispering in necessary situations.
The gain level for the internal and the external microphone can be
set differently.
Talkaround
On / Off talkaround repeater
When set up for repeater operation, all signal are directed to the
repeater. With the function Talkaround, repeater operation can be
deactivated and the direct communication with other radios within
the range of reception is possible.
Call 1/2/3/4
For each channel, a maximum of four selective calls can be pro-
grammed (Call 1/2/3/4). The call will be send by pressing the pro-
grammed dual-key.
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 31

32 33
GB GB
Lone Work
On / Off Lone Work Function
Function secures workers in ciritical environments.
In determinably time intervals, a beep tone reminds the lone wor-
ker to give feedback to the controlling station by pressing any key
periodically. If no feedback is given, the radio switches to emergen-
cy mode.
Emergency Call
Switch on the emergency alarm.
This function can only be assigned to the orange-colored, top key
of the radio. The various settings of the emergency function are
explained in the manual of the software T-UP10.
Cancel Emergency Call
Turn off the emergency alarm
This function can only be assigned to the orange-colored, top key
of the radio.
Scan
On / Off Channel Scanning
Via software one of a maximum of sixteen scan lists can be assi-
gned to each channel.
Each scan list stores the selected channels that are to be scanned,
as well as two priority channels and a variety of scan settings.
When scanning is activated, all programmed channels are sear-
ched; in a ring system; for signals. By default, the LED blinks red,
while scanning is activated. If a signal is detected, the scan functi-
ons stops, the radio remains on this channel and the LED lights
green, until the signal ends. Then, scanning continous until anot-
her signal is detected
For each scan list, the individual parameters, e.g. hold time, can be
programmed.
Priority Channel
A maximum of two priority channels can be programmed for each
scan list.
The scan function stops immediately when a signal is present on
the programmed priority channels. The radio remains on the busy
channel until the signals ends.
Noise Channel Delete
On / Off Noise Blanker
Call Forward
On / Off Call Fowarding
H/L Power
Switches between Tx powers high and low if acitvated via software.
Squelch Adjust / Call Cancel
This function is only available with activated voice annunciation.
With each press of the assigned key, the programmed squelch
level ( 0 - 9) is increased by one. After level 9 is reached, the
adjustment jumps back to zero.
Monitor Momentary / Call Cancel
The actual channel is scanned for signals. If a signal is present, the
squelch is deactivated and the signal is audible. If no signal is pre-
sent, the squelch remains activated. The monitor function is only
activated as long as the assigned key is pressed.
Monitor / Call Cancel
Monitor function On / Off
Squelch Off Momentary
The squelch off function is only activated as long as the assigned
key is pressed.
When the squelch is turn off, all signals on the channel are audible
and a constant noise can be heard.
Squelch Off / Call Cancel Rauschunterdrückung Aus
Squelch On / Off
Lock Keyboard
Keylock On / Off
Locks the channel selector to avoid accidental channel change.
The PTT key and the dual-function keys are not affected by the
keylock function.
Compander
Compander On / Off
Improves weak signals
Scrambler
Scrambler On / Off
The scrambler distorts the signal, which cannot be understood by
radios that do not have the same scrambler function acitivated. To
be able to hear the scrambled signal in the original way, it must be
de-scrambled.
Battery Check
Tests the power level of the battery
This function is only available with activated voice annunciation.
The power level is described by the numbers 1 - 4, with number 1
indicating a low power level and number 4 indicating a high power
level.
Rental Time Check
Announces the remaining rental time
This function is only available with activated voice annunciation.
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 33

34 35
GB GB
The remaining rental time is annouced with the numbers 1 -4. Via
software three control times (Remaining Time 1/2/3) can be pro-
grammed
The remaing time between the start of the programmed rental time
and Remaining Time 1 is announced with the number 4. The time
between Remaining Time 1 and 2, is announced with the number
3, etc. Is the remaining beyond Remaining Time 3, number 1 is
announced.
7 Additional Functions
The following functions have to be programmed with the software
T-UP10. More information about the possible settings of these
functions can be found in the software manual.
7.1 VOX
With activated Vox function, voice-controlled transmission, without
PTT key operation, is possible.
There are various settings for this function, e.g. sensitivity, hold
time after end of signal, etc.
7.2 Wire Clone Mode
Data transfer from radio to radio via optional cable.
1. Turn both PT-7200 off.
2. Connect both radios via data transfer cable.
3. Set both radios to the same channel.
4. Turn the receiving radio on - the radio onto which the data should
be transferred.
5.At the transmitting radio, the one which data should be copied, hold
the two programmable dual key (above and below the PTT key)
while the radio is turned on.
The LED lights shortly orange and the command “clone” is
announced if the voice annunciation is activated.
6. At the transmitting radio, press the PTT key to start data transfer.
The LED starts to blink red.
At the receiving radio, the LED lights green.
After completion of the data transfer, a confirmation tone is
emmited at the transmitting radio.
7.3 Time-Out-Timer (TOT)
To avoid excessive occupation of a channel, the TOT function can
be set up.
The maximum transmit time (between 15 and 1200 seconds in 5
seconds-steps) can be programmed via software. When the maxi-
mum value is reached, transmission is stopped automatically and
an alarm tone is audible (default setting) until the PTT key is
released.
A warning tone, which annouces the soon end of the TOT limit can
be programmed.
7.4 Power Save Type
The Power Save Function reduces the power consumption. The
radio switches automatically into Power Save Mode when no
signal is received and the radio is not operated.
The sleep times can be adjusted (short, middle, long).
7.5 Low Battery Level
A low battery warn function can be programmed. Once the power
level falls below a certain level, the LED blinks red and the radio
omits some alarm tones.
Now, it is time to charge the battery pack.
7.6 CTCSS / DCS
With the CTCSS and DCS coding system, unwanted signals can
be filtered out. It is possible to make only those signals audible,
which are encoded with the same CTCSS / DCS code.
Signals that are not encoded with the same code will be not be
audible, although they are present and can be heard with the
squelch of or monitor function.
There are 52 CTCSS and 198 DCS codes available.
Attention:
The use of CTCSS and DCS codes does not guarantee privacy.
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 35

36 37
GB GB
7.7 5-Tone Selective Calling
For 5-Tone Selective Calling, there are seven standards (CCIR1/2,
ZVEI1/2/3, EEA und EIA) and two user-defined formats available.
For the user-defined formats, the tone-frequency, -length and the
spaces between them can be defined.
A maximum of 32 encoder telegrams, composed of a maximum of
three 5-tone sequences, can be programmed.
A maximum of four individual and / or group encoding telegrams,
can be assigned.
A maximum of 16 telegrams can be decoded per channel.
For each encode-telegram, these commands are available: Gene-
ral, Incoming Emergency, Priority, Security Inquire, Emergency Exit,
Stun, Kill, Revive,Active, Clear Down, Silent Interrogate, ACK1 Rin-
ging, ACK1 Authorisation.
It can be programmed whether the signal is only audible at those
radios that are called or audible at all radios on the actual channel.
Furthermore, acknowledgement, if selected, can be manual or
automatic.
7.8 DTMF
ADTMF telegram consists a maximum of three sequences.ADTMF
sequence can be composed of max. 20 digits (0 - 9, A - D).
8 Specifications
PT-7200
Channel Number 16
Channel Separation 12,5 KHz / 20 kHz / 25 kHz
Modulation Type FM
Deviation narrow : 2.5 kHz / wide : 5 kHz
RX-Sensitivity narrow : 0.28 μV at 12.5 kHz /
wide: 0.75μV at 25 kHz
Audio Output Power 0.50 W at 8 Ohm with 10 % THD
Supply Voltage 6 - 8 V
Battery Pack Li-Poly, DC 7.2 V / 1700 mAh
Dimensions B/H/T: 56 x 120 x 35 mm
Weight 332 g (with antenna and battery pack)
Modell: PT-7200 VHF:
Frequency Range 136 - 174 MHz
TX Power max. 5 W
Modell: PT-7200 UHF:
Frequency Range 430 - 470 MHz
TX Power max. 4 W
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 37

38 39
GB GB
9 Programmed Settings
Model : Serial Number:
Hardware Version: MCU-Version :
Dual-Key Programming
Short Button (short press) Long Button (long press)
SK #1
SK #2
TK #3
Scan List Channels Prioritiy Channels
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Programmed Scan Lists
Channel Information
Chan nel TX
(MHz) RX
(MHz) TX
CTCSS/DCS RX
CTCSS/DCS Bandwidth
12.5/20/25kHz TX Power
High Scan List Personality
Template Beat Shift
1 2 3 4 5
6 7
8 9 10 11 12 13 14 15 16
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 39

40 41
GB GB
Personality Template
Personality Template Call 1 Key-
Telegram No. Call 2 Key
Telegram No. Call 3 Key-
Telegram No. Call 4 Key-
Telegram No. 5-Tone
Decode No. Com-
pander Scramble Vox Whisper Lone Work
1 2 3 4 5 6 7 8 9 10 11 12 13 14
15
16
Notes :
manual_pt-7200_2.qxp 22.07.2008 14:53 Seite 41
