Itm TD1316F User manual

TABLE OF CONTENTS
2
Safety Information ............................................................................................... 3
Package Contents ............................................................................................... 8
Preparation .......................................................................................................... 8
Assembly Instructions .......................................................................................... 9
Operating Instructions ........................................................................................ 11
Care and Maintenance ....................................................................................... 12
Troubleshooting .................................................................................................. 13
Replacement Parts List ...................................................................................... 14
TRADEMASTER
Magnetic Base Drilling Machines
Tools and Machinery
AIR

2
INTRODUCTION
Thank you for purchasing this drill press.
This machine has been designed for drilling large or small holes in metal, wood and
plastic
etc. Before attempting to use this product, please read this manual thoroughly
and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and
that of others around you, and you can look forward to your purchase giving you
long
and satisfactory service.
2
IMPORTANT
Please read all of the safety and operating instructions carefully before using this
product. Please pay particular attention to all sections of these instructions that
display warning symbols and notices.
WARNING: THIS SYMBOL IS USED THROUGHOUT THE
INSTRUCTIONS WHENEVER THERE IS A RISK OF PERSONAL
INJURY. ENSURE THAT THESE WARNINGS ARE READ AND
UNDERSTOOD AT ALL TIMES.
GENERAL SAFETY RULES
WARNING: WHEN USING ELECTRIC TOOLS, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE
RISK OF FIRE, ELECTRIC SHOCK AND PERSONNAL INJURY
INCLUDING THE FOLLOWING. READ ALL THESE INSTRUCTIONS
BEFORE ATTEMPTING TO OPERATE THIS PRODUCT AND SAVE
THESE INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY IN THE WORKPLACE
1. ALWAYS ensure that air can circulate around the machine and that the air
vents are unobstructed.
2. ALWAYS keep work area clean & tidy. Cluttered work areas and benches
invite accidents.
3. NEVER over-reach. Keep proper footing and balance at all times.
4. NEVER store equipment in a wet/damp environment or expose to rain.
5. KEEP other people especially children) that are not involved in the work, away
from the tool or extension cable and keep them away from the work area.
6. NEVER operate a machine when under the influence of alcohol, drugs or
medication.

3
7. ALWAYS ensure the workplace is well lit. Ensure that lighting is placed so that
you will not be working in your own shadow.
8. Do not use tools in the presence of flammable liquids or gasses.
9. Stay alert, watch what you are doing, use common sense and do not operate
the tool when you are tired.
CARE OF POWER TOOLS
1. Read this manual carefully and understand the machines applications and
limitations as well as the specific potential hazards relevant to it.
2. ALWAYS keep guards in place and in working order. A guard or other part tha
t
is damaged should be properly repaired or replaced by an authorized service
agent, unless otherwise indicated in this instruction manual.
3. Remove any adjusting keys or wrenches before starting. Form the habit of
checking to ensure that keys, wrenches and tools are removed from the
machine.
4. Don’t force the machine and use the correct tool. It will do the job better
and safer, at the rate for which it was intended.
5. ALWAYS disconnect the machine from the power supply before carrying out
any servicing or changing any accessories.
6. Before further use of the tool, it should be carefully checked to determine
that it will operate properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts,
mounting or other condition that may affect its operation.
7. Have defective switches repaired by an authorized service agent. Do not
use a tool if the switch does not turn it on and off.
8. ALWAYS check for any damage or any condition that could affect the
operation of the machine. Damaged parts should be properly repaired.
9. NEVER remove the cover panel unless the machine is disconnected from the
power supply, and never use the machine with cover panels removed.
10. Have your tool repaired by a qualified person. This tool complies with the
relevant safety rules. Repairs should only be carried out by qualified persons
using original spare parts, otherwise this may result in considerable danger
to the user.
11. NEVER use this product for any other purpose than that described in this
booklet.
12. NEVER abuse the power cable by yanking the cable to disconnect it from the
socket. Keep the cable away from heat, oil or sharp edges.
13. Guard against electric shock. Avoid body contact with earthed or grounded
surfaces.
14. If the tool should be used outdoors, use only extension cables intended for
outdoor use and marked accordingly.
15. Avoid accidental starting by making sure the power switch is offbefore
plugging in the power cable.

4
ADDITIONAL SAFETY RULES FOR DRILL PRESSES
CAUTION: AS WITH ALL MACHINERY, THERE ARE CERTAIN
HAZARDS INVOLVED WITH THEIR OPERATION AND USE.
EXERCISING RESPECT AND CAUTION WILL CONSIDERABLY LESSEN
THE RISK OF PERSONAL INJURY. HOWEVER, IF NORMAL SAFETY
PRECAUTIONS ARE OVERLOOKED, OR IGNORED, PERSONAL INJURY
TO THE OPERATOR, OR DAMAGE TO PROPERTY MAY RESULT.
1. IMPORTANT: You should not operate this machine unless you are
thoroughly familiar with drilling machines and drilling techniques. If there is
any doubt whatsoever you should consult a qualified person.
2. NEVER operate the machine until it is completely assembled and you have
read and understood this entire manual.
3. ALWAYS use clamps or a drill vice bolted to the table, to hold the work. It
should never be held with bare hands.
4. ALWAYS shut offthe power & remove drill bit before leaving the machine.
5. ALWAYS make all adjustments with the power off.
6. ALWAYS use the correct drilling speeds for the drill size and the type of
material being drilled.
7. NEVER leave the drill unattended whilst it is running. Turn the machine OFF
and do not leave until it has come to a complete stop.
8. ALWAYS remove and store the drill bits when you have finished work.
9. NEVER attempt to drill into a workpiece that does not have a flat surface
unless a suitable support is used.
10. ALWAYS stop the drill before removing workpieces, work supports or swarf
from the table.
11. Keep drills sharp and clean for best and safest performance. Follow
instructions for changing accessories.
12. Adjust the table or depth stop to avoid drilling into the table surface.
13. ALWAYS be sure that the drill bit is securely locked in the chuck.
14. NEVER assemble or set up any work on the table while the drill is running.
15. ALWAYS ensure the table lock is tight before starting the drill.
16. Keep handles dry, clean and free from oil and grease.
17. ALWAYS keep hands and fingers away from the drill bit.
WARNING: DUST GENERATED FROM CERTAIN MATERIALS CAN BE
HAZARDOUS TO YOUR HEALTH. ALWAYS OPERATE THE DRILL IN A
WELL-VENTILATED AREA. USE A DUST COLLECTION SYSTEM IF
POSSIBLE.
WARNING: THE USE OF ANY ACCESSORY OR ATTACHMENT OTHER
THAN ONE RECOMMENDED IN THIS INSTRUCTION MANUAL MAY
PRESENT A RISK OF PERSONNAL INJURY.

5
PROTECTIVE CLOTHING
1. Dress properly, loose clothing or other jewellery may get caught in moving
parts. Non-slip footwear is recommended.
2. ALWAYS wear safety glasses. (Everyday glasses are not safety glasses.)
3. Wear a face mask if drilling into any material which produces dust.
ELECTRICAL CONNECTIONS
WARNING! Read these electrical safety instructions thoroughly
before connecting the product to the mains supply.
Before switching the product on, make sure that the voltage of your electricity
supply is the same as that indicated on the rating plate. Connecting it to any
other power source may cause damage.
This product may be fitted with a non-rewireable plug. If it is necessary to change
the fuse in the plug, the fuse cover must be refitted. If the fuse cover becomes
lost or damaged, the plug must not be used until a suitable replacement is
obtained.
If the plug has to be changed because it is not suitable for your socket or due to
damage, it should be cut offand a replacement fitted by a qualified electrician.
The old plug must be disposed of safely as insertion into a mains socket could
cause an electrical hazard.

19
TROUBLE SHOOTING
PROBLEM
PROBABLE CAUSE
REMEDY
Noisy
operation
(under load).
a. Incorrect belt tension.
b. Dry spindle.
c. Loose pulley.
d. Loose belt.
e. Worn bearing.
a. Adjust tension.
b. Remove spindle and quill
assembly and lubricate.
c. Tighten pulley.
d. Adjust belt tension.
e. Replace bearing.
Excessive drill
wobble.
a. Loose chuck.
b. Worn spindle or bearing.
c. Worn chuck.
d. Bent drill bit.
a. Tighten by pressing chuck down
on to a block of wood against
the table.
b. Replace spindle shaft or bearing.
c. Replace chuck.
d. Renew drill bit.
Motor won’t
start.
a. Power supply.
b. Motor connection.
c. Switch connection faulty.
d. Faulty switch.
e. Motor windings burned.
f. Pulley cover not closed.
g. Micro switch on cover
not operating.***
a. Check power cord/fuse.
b. Check motor connections.
c. Check switch connections.
d. Replace switch.
e. Replace motor.
f. Close pulley cover.
g. Check operation of micro switch,
and renew/adjust as necessary.
Drill binds in
workpiece.
a. Excessive feed pressure.
b. Loose belt.
c. Loose drill.
d. Incorrect bit speed.
e. Drill angles incorrect
for type of material.
a. Apply less pressure.
b. Check belt tension.
c. Tighten drill with key.
d. Adjust the drill speed
reasonably.
e. Consult a technical manual
dealing with materials, drills and
cutting angles, and sharpen drill
accordingly.
Drill bit burns
or smokes.
a. Incorrect speed.
b. Swarf isnt discharging.
c. Dull drill or not proper.
clearance for material.
d. Needs coolant.
e. Excessive feed pressure
a. Adjust drill speed accordingly.
b. Clean drill.
c. Check sharpness & taper.
d. Use coolant whilst drilling.
e. Apply less pressure.
Table difficult
to raise.
a. Needs lubrication.
b. Table lock tightened.
a. Lubricate with light oil.
b. Loosen clamp.

1:1S
图样标记 重 量
共 张 第 张
数 量
5
6
8
15
16
19
20
22
27 26
24
25
30 31 32 33 34 35 36
37
38 39
40 12 42
43
44
45
48
56
58
59
60
61
62
63
64
65
77
76
75
78
88
89
90
91
92
93
96
94
97
98
100
99
101
102
103
104
74
29 17
54 55
68
73
9
49
7
47
57
(38)
(27) (38)
28
85 84
83 82
81 80 79 18
86
87
41
10
13
11
14
50
51
52
53
1
2
3
4
