ITR MUPASZ 710 plus User manual

Bay control unit
User manual
Document version:
05i00
Update:
2015-01-22
energetyka.itr.org.pl

We reserve the right to modify the device.
Tele- and Radio Research Institute
ICT and Electronics Centre
03-450 Warsaw, ul. Ratuszowa 11
tel./faks: + 48 22 619 73 14
e-mail: [e-mail]
www: energetyka.org.pl

User manual
IU_M710P_MANUAL_05i00_ENG Strona 3 z 36
Contents:
1. General ..................................................................................................................................4
1.1. Designated use.......................................................................................................................4
1.2. Features.................................................................................................................................5
1.3. Functionality and accessories .................................................................................................8
2. User interface.......................................................................................................................10
2.1. Front panel........................................................................................................................... 10
2.1.1. Control keyboard.......................................................................................................... 11
2.1.2. Signal diodes ................................................................................................................11
3. Operation manual ................................................................................................................12
3.1. Window ...............................................................................................................................12
3.2. Menu ...................................................................................................................................13
3.3. Bay view............................................................................................................................... 14
3.4. Diode description .................................................................................................................15
3.5. Event log .............................................................................................................................. 15
3.6. Measurements ..................................................................................................................... 16
3.7. Alarms –cancelling the signaling ..........................................................................................17
3.8. Control mode .......................................................................................................................18
3.8.1. Selection of control mode.............................................................................................18
3.8.2. User commands............................................................................................................18
3.8.3. Switches....................................................................................................................... 19
3.9. Management........................................................................................................................20
3.9.1. Settings ........................................................................................................................20
3.9.2. Supervision...................................................................................................................23
3.9.3. Configuration ............................................................................................................... 24
3.10. Identification........................................................................................................................26
3.11. Extensions............................................................................................................................26
3.11.1. AI >>> - Autonomous independent overcurrent protection ...........................................26
3.11.2. DAR –Fault recorder.....................................................................................................26
3.11.3. CDAR - Criterion recorder .............................................................................................27
3.11.4. PQA –Power Quality Analyzer ......................................................................................27
3.11.5. SLOG –System Log ....................................................................................................... 27
3.11.6. UPS –Uninterruptible Power Supply............................................................................. 28
3.11.7. RPS –Redundant Power Supply ....................................................................................28
3.12. Diagnostic ............................................................................................................................28
3.12.1. SC - Self-check .............................................................................................................. 28
3.12.2. MAC - Manual Algorithms Check................................................................................... 29
3.12.3. CBD - Circuit Breaker Diagnostics .................................................................................. 29
3.13. Autotest ...............................................................................................................................29
3.13.1. CCT - Cumulated Current Test.......................................................................................29
3.13.2. CBCT - Circuit Breaker Control Test ...............................................................................30
3.13.3. HVT - High Voltage Test ................................................................................................30
3.13.4. PAT - Protection and Automation Test ..........................................................................30
4. Description of communication interfaces..............................................................................31
4.1. Modem RS-485 (2-wire/ 4-wire connection) ......................................................................... 31
4.2. Modem 2 x RS-485 ...............................................................................................................33
4.3. Twisted Pair RJ Ethernet Modem ..........................................................................................34
4.4. ST Optical Fibre ....................................................................................................................34
5. Remarks of manufacturer .....................................................................................................35
5.1. Maintenance, inspections, repairs ........................................................................................35
5.2. Storage and transport...........................................................................................................35
5.3. Place of installation ..............................................................................................................35
5.4. Disposal................................................................................................................................36
5.5. Guarantee............................................................................................................................36
5.6. Service .................................................................................................................................36

User manual
Strona 4 z 36 IU_M710P_MANUAL_05i00_ENG
1. General
1.1. Designated use
MUPASZ 710 plus is designated for operation as a multi-function bay control device in MV grids,
with grounded or insulated neutral point, and in compensated grids.
Fig. 1.1.1 The view of MUPASZ 710 plus.
The device can work in grids with frequency 50 or 60 Hz.
The MUPASZ 710 plus bay controller may have up to 8 bay types (profiles) implemented
which may be freely modified and adapted to the user’s requirements. Logic function
simulator is included. The user may also redesign implemented bay views and usage of 16
three-colour signaling diodes.
MUPASZ 710 plus works with ELF application used to design individual bay operation logic,
parameterization of protections, to configuration, to read measurements and events, and
to control device operation in service mode.
The regular 36 months warranty period may be extended to 60 or 120 months.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 5 z 36
1.2. Features
Operation in
capacitor battery bay
incoming-outgoing feeder
generator bay
line bay
busbar coupling bay
measurement bay
motor bay
transformer bay
feeder bay
Connector types
circuit breaker
contactor
load switch
disconnecting switch
disconnecting-earthing switch
truck
earthing switch
short-circuiting switch
Control
local/remote: user interface, transmission, binary inputs
switches: open, close, insertion, withdrawal
cancelling:
failures AW - TRIP
signaling UP - ALARM
lock - LOCK
binary and analog outputs
user commands
Automatic functions
AACF –Automatic Active Component Forcing
ACCB –Automatic Connection of Capacitor Battery
CBF - Circuit Breaker Failure
AUFLS - Automatic Under Frequency Load Shedding
ARF - Automatic Reclosing Function
ATC - Automatic Transfer Control
Synchrocheck v1 –external synchronizer
Synchrocheck v2 - integrated synchronizer
BPF - Busbar Protection Function
Protections
current protection: I>, I>>, I>IDMT, dI>, dI>>, I2f>, I<
autonomous current protection: AI>>>
zero-sequence overcurrent protection: I0>, I0>IDMT, I0>dir, Y0 >
voltage protection: U<, U>, U2>, U0>
frequency protection: f>, f<, df/dt
motor protection: ItR >, ItA >, ItU >, NfR >, ItS >, U123, Cos φ, Θm> , Rwir <
power protection: P>, P<0
technological protection: Tech
temperature protection: Temp
special protections: Harm, Arc

User manual
Strona 6 z 36 IU_M710P_MANUAL_05i00_ENG
Options of protections
operation based on RMS or 1-harmonic
directional action
operation in CBF mode
operation in BPF mode
cooperation with ARF
voltage stabilization
frequency stabilization
harmonic stabilization
acceleration/deceleration of protection action
Measurements
current: I1, I2, I3, I0
voltage: U1, U2, U3, U12, U32, U13, U0
frequency: f
power: P, Q, S, cos φ
energy: EC+, EB+, EC- , EB-
angle between current signals and voltage signals
temperature: Θm (calculated from thermal model), Temp 1…6 (PT100)
diagnostics: THD (up to 40 harm), Tp (bay working time), Σ I (cumulated current )
resistance: Rrotor, Rhvt
Measurements, set two
current: 2.I1, 2.I2, 2.I3
voltage: 2.U1, 2.U2, 2.U3, 2.U12, 2.U32, 2.U13
frequency: 2.f
Diagnostic
SC - Selfcheck
voltage: supply, reference, battery
memory: program and data
correctness of internal module-to-module communication
calibration factors of measurement channels;
device set points
MAC - Manual Algorithm Check
CBD - Circuit Breaker Diagnostics
Autotest
CCT - Cumulated Current Test
CBCT - Circuit Breaker Control Test
HVT - High Voltage Test
PAT - Protection and Automation Test
Extensions
AI >>> - Autonomous independent overcurrent protection
DAR –Fault recorder
CDAR –Criterion recorder
PQA –Power Quality Analyzer
SLOG –System Log
RPS –Redundant Power Supply
UPS –Uninterruptible Power Supply

User manual
IU_M710P_MANUAL_05i00_ENG Strona 7 z 36
User interface
three languages: Polish, English, Russian
up to 12 users
colour display 320 × 240 pixels
7 signal diodes: Emergency trip, Alarm, Lock, Local, Remote, Power supply, Device failure
16 freely configurable tricolour diodes
configuration of displayed measurements and event counters
bay view editing - over 120 elements of synoptic available: switches, electrical symbols, lines, nodes,
texts, measurements, clock, states of binary inputs and outputs, events, messages, signaling
operational states
Other functions
4 sets of set points
event log capacity 1000 events
filtering of events displayed
system log
each defined event has 16 bit counter assigned
power outputs (relay-semiconductor type)
auto-logging
editing selected texts, e.g. names of protections, connectors and signal diodes
algorithm operational status registers
user registers for free assignment of analog-digital signals

User manual
Strona 8 z 36 IU_M710P_MANUAL_05i00_ENG
1.3. Functionality and accessories
Profile
Logic - Used to edit operational logic of the device, utilizes: protections, automatic functions, logic
gates, comparators, timers, flip-flops, registers, event blocks, etc. Available via ELF program.
Simulator - Used to carry out simulations of designed logic and preview analog-digital signals in the
profile schematics. Forcing of input signals and measurement values can be carried out using data
saved in COMTRADE format. Available via ELF program.
Bay view –Allows editing graphic representation of bay schematics, visible in the device, via ELF
program.
Freely programmable diodes - 16 freely programmable tricolour diodes. The Elf program allows their
editing: assignment of functions to be signaled, signaling order, description, colours and display
mode.
Set points - Used to preview and edit parameters: nominal values, protections, automatic functions,
control and monitoring systems, autodiagnostics; grouped into sets of set points.
Texts - Used to preview texts predefined in the device, in supported languages, and to edit editable
texts. Available via ELF program.
Selected counters - Used to configure Selected Event Counters window.
Selected measurements - Used to configure Selected Measurements window.
Selected MODBUS records - Used to map MODBUS registers.
Monitoring
Configuration - Used to preview and edit configuration parameters of the device, i.a. system clock,
communication ports, user interface.
Log - Used to preview events logged in the device.
Event counters - Each event defined in the device has a16-bit counter assigned. Used to preview
their values in Event Counter window.
States - Used to preview system states, digital inputs and outputs, signal diodes, communication
ports, user login information.
Measurements - Used to preview measurements, along with their status.
UM –User Manager controls and identifies users access to functions of the device.
RALG - Algorithm register - used to preview, in textual and graphical form, of algorithm operating
states, of e.g. protections, automatic functions, switches.
Service - Group of service parameters available to users with service privilege.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 9 z 36
Extensions
AI>>> - Autonomous independent overcurrent protection protects objects against consequences of
short-circuits in the absence of device supply voltage.
DAR - Fault recorder used to record analog-digital signals with sampling frequency 2 kHz.
CDAR - Criterion recorder used to record analog-digital signals with sampling frequency 50 Hz.
PQA - Power quality analyzer used to assess the quality of energy at the protected facility.
SLOG - System log. Stores time-and-date stamped device operation logs i.a. user logging, last
modification of set points, control commands.
UPS - Ensures sustaining full functionality of the device for 60 s following voltage decay or up to
200 s with display backlight off.
RPS -The solution that allows installation of two independent power supply units in the bay
controller, making up redundant power supply system.
Diagnostic
SC –Self check, monitoring of internal states of the device.
MAC –Manual algorithm check simulates measurement values and allows verification of correct
operation of an algorithm.
CBD - Circuit breaker diagnostics is used to determine critical parameters of circuit breaker/contactor
during its operation.
Autotest
CCT - Cumulated Current Test monitors the value of cumulated current for each phase.
CBCT - Circuit Breaker Control Test monitors the integrity of coil control circuits and auxiliary voltage.
HVT - High Voltage Test monitors the condition of cable insulation, using high voltage, before
energizing the cable.
PAT - Protections and Automatic Functions Test verifies correct operation of protections and
automatic functions, using external testing systems.
Accessories
Communication and arc detection fibre optic cables, sealing caps, fixing elements, hardware access
key, grounding copper braid, mini USB cable.
Accessories available for MUPASZ devices can be found on the website energetyka.itr.org.pl.
Availability of individual elements varies by device family and technical specification.

User manual
Strona 10 z 36 IU_M710P_MANUAL_05i00_ENG
2. User interface
2.1. Front panel
The front panel hosts:
320x240 pixel backlit graphic display;
control keyboard of the device;
LED signal diodes;
USB service port for communication with ELF software tool.
Fig. 2.1.1 Front panel
1) Freely programmable diodes; diode descriptions on graphic display.
2) Colour graphic 320x240 pixels display.
3) Emergency opening signalization cancelling key - TRIP.
4) Alarm cancelling key - UP .
5) Active circuit breaker lock cancelling key - LOCK.
6) Menu navigation keys.
7) Context keys.
8) Control key –OPEN.
9) Control key –CLOSE.
10) USB mini B service connection port.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 11 z 36
2.1.1. Control keyboard
Control keyboard of the device has 12 navigation, function, control and context keys. Navigation and context
keys are used to navigate around the display MENU and to review and edit parameters.
Table 2.1.1 Control keyboard
Przycisk
Opis
navigation key - UP arrow
navigation key - DOWN arrow
navigation/function key ESC - cancel/return
navigation/function key OK - acceptance
function key, function description is displayed
function key TRIP used to cancel signalization of emergency opening of the main switch
function key ALARM used to cancel UP signalization of bay damage
function key LOCK used to cancel active locks
function key CLOSE used to issue the „close” command to the main switch
function key OPEN used to issue the „open” command to the main switch
The function keys OPEN and CLOSE allow issuing commands to the main switch. The “open”
command is always executable. For the „close” command to be executed the Local or Local and remote mode
must be active. Additionally, access to the „close” command may be restricted for some users (see Part 3.9.2.1
User Manager).
2.1.2. Signal diodes
In addition to graphic display and control keyboard, device front panel has 23 signal LEDs, 16 of them are
programmable. They signal the most important states of device operation, resulting from operation of
algorithms, or existing situation, such as establishing a lock, emergency CB opening, ALARM signalization (UP-
bay damage), local or remote control mode.
Table 2.1.2 Meanings of predefined diodes
Diode
Color
Meaning
green
Signals feeding of correct supply voltage to the device Continuous light.
red
Signals action of SC Self Check mechanism. Continuous light.
TRIP
red
Signals opening of the CB caused by tripping of protection set to
disconnection or disconnection with lock. Continuous light.
ALARM
yellow
Signals protection tripping the signalization. Flashing/continuous light.
LOCK
yellow
Signals that the device is locked following activation of any lock.
Continuous light.
L
yellow
Signals the possibility of local control. Continuous light.
R
yellow
Signals the possibility of remote control. Continuous light.

User manual
Strona 12 z 36 IU_M710P_MANUAL_05i00_ENG
3. Operation manual
The below show views may differ for different device specification.
3.1. Window
Fig. 3.1.1 Main window
In the main window of fig 3.1.1 there are presented elements shown in most user interface windows.
1) The upper line contains the window caption. i.e. the name of relevant branch or window the user is
watching at.
2) On the right hand side of the caption icons are located which inform about alarms, locks and emergency
CB opening.
3) Position of the cursor (line number) or number of the screen (e.g. in the Log) is located between the
header line and the scrollbar.
4) In the lower line functions of the context keys are displayed.
5) The central part of the display is used for presenting numbers, texts or graphic.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 13 z 36
3.2. Menu
The , and , keys are used to navigate around the device menu. In order to reach destination one
should navigate using the , keys. The key is used to accept entering the selected branch. The key
allows moving one level up in the menu tree.
For quick moving to selected windows or branches the context keys are used. Their current meaning id
displayed in the bottom line.
For example in order to move from the main window to the Logging window the following path should be
followed: Menu >Management > Monitoring > Logging or to use the Logging context key.
The context key in the main window are used for:
the left one –moving to the user Logging window,
the Middle one - moving to the parameter Configuration window,
the right one - moving to the Bay view window.
The right hand side context key is used for navigating through all widows listed in the main menu
starting from the Bay view window and ending in the Identification window.

User manual
Strona 14 z 36 IU_M710P_MANUAL_05i00_ENG
3.3. Bay view
Menu > Bay view
Bay view
ELF software tool allows configuration of the bay view,
customized to user’s needs. There is no need therefore to
visualize the whole bay, only its individual components,
such as state of the CB. Bear in mind, however, that
inserting in the bay view of e.g. earthing switch that is not
there in the actual bay, shall result in displaying it as not
monitored.
Control activates the mechanism of switch control.
Activation of this option marks the main switch.
Another switch may be selected with the , keys.
The switches which cannot be controlled may not be
selected and marked.
After selection of the required switch and pressing the
key the Control window opens in which required switching
operations may be selected from the list and confirmed
with the key.
After selection of the required operation it will be executed
or “not available” message displayed.
The switches may be operated also in the Switches window or by means of a User command.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 15 z 36
3.4. Diode description
Menu > Diode description
Diode description
Device MUPASZ 710 plus is fitted out with the set of freely
programmable signal LEDs installed on device front panel.
Diodes are configured by means of ELF program, in the tab
Logic; configuration consists in assigning a signal from the
system, algorithm or automatic function to specific LED.
Active state of the signal results in illumination of LED.
Descriptions of signalization diodes are defined by editing
the text assigned to given diode and are shown on the
display. The mark in front of the description text
corresponds with the diode colour illumination.
LED 1-8/9-16 –allows moving to the widow with
descriptions of the other diodes.
3.5. Event log
Menu > Event log
Event log
The Event log holds events generated in the device and
allows their viewing. Any recorded event is characterized
by:
1) type –see table below,
2) date and time –the events are tagged with 1 ms
resolution time tags,
3) descriptive text –displayed in one or two lines,
4) up to 5 parameters, e.g. current value at protection
stripping (the parameters may be accessed by selecting
the Details context key)
The logged events may be filtered for displaying in regard
of their types. Having selected the Filter context key a
window opens in which event types to be displayed may be
selected.
By means of the Select context key required positions
may be selected or deselected. After confirmation your
choice with the key and returning to the Event log
window only the event types selected in the Filter window
will be displayed.

User manual
Strona 16 z 36 IU_M710P_MANUAL_05i00_ENG
Table 3.5.1 Event types
Symbol
Event type
Description
Normal
Standard event type, such as user login.
Activation
Activation of an algorithm, e.g. protection
Alarm
Execution of algorithm, e.g. protection set to UP signalization - “UP
signalization” item selected in Options
Release
Deactivation of an algorithm, e.g. protection
Tripping
Execution of algorithm, e.g. protection set to opening of the main switch -
“Tripping” selected in Options
Lock
Execution of an algorithm, e.g. protection set to lock - “Lock” or “Temporary
lock” selected in Options
Executed
Execution of an algorithm, e.g. protection
3.6. Measurements
Menu > Measurements
Measurements
The resource stores and provides access to all
measurements carried out by the device. Measurements
have flags assigned to them that represent their state and
validity status (see table below).
By pressing the All / Selected keys either all available or
only user selected measurements will be displayed.
Pressing the Clearing key opens the window for clearing
counters, e.g. work time or energy counters.
Configuration of Selected measurements is also possible via the ELF software tool.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 17 z 36
Table 3.6.1 Flags of measurements
Symbol
Flags of measurements
Description
Infinity
Only used with measurements of resistance. Means opening in measured
circuit.
Above the range
Measured value exceeds upper measuring limit
Not available
No measurement, e.g. no measurement channel
Below the range
Measured value exceeds lower measuring limit
Unsure
Measurement value is calculated basing on incomplete information, e.g.
the power is calculated for two phase currents
3.7. Alarms –cancelling the signaling
Menu > Alarms
Alarms
MUPASZ 710 plus implements a series of switch bay
protection algorithms. In order to facilitate reading of
operating state of algorithms, the software of MUPASZ
710plus device is fitted with the function of displaying
aggregated information on states of all algorithms
implemented in the active profile.
In the Alarms window aggregated information on alarms,
locks and tripping is displayed.
The DELETE key deletes all signaling and displays
a relevant message.
If the cause of signaling is still active it will not be
cancelled. First the cause should be removed and then the
signaling cancelled.
Signaling may be selectively cancelled by means of the , , key.
An adequate User command on the logic scheme may be used to cancel signalization after adaptation.

User manual
Strona 18 z 36 IU_M710P_MANUAL_05i00_ENG
3.8. Control mode
3.8.1. Selection of control mode
Menu > Control > Selection of control
One of four control modes may be selected in the Selection
of control window:
Local –via device interface,
Remote –via communication system,
Local and remote –via device interface /
communication system,
Autonomous control –control without
participation of the device (CB is controlled by external
devices).
See chapter 3.9.1.1 Edition of parameters.
Before setting the control mode one should check if the intended mode is allowed in settings. - Menu >
Management > Settings > Settings X > Control group > Selection of control.
If in the bay operation logic scheme the control mode selection is done via binary inputs then selection
of the control mode via the user interface is disabled.
3.8.2. User commands
Menu > Control > User commands
ELF software tool allows the user to define own
commands which activate logic functions from the
device menu level.
Commands are configured by means of ELF program, in
the tab Logic; configuration consists in entering the
CMD_USER block and connecting its output signal to the
block of the function it is to activate. Selecting the
command from device menu shall activate the
instruction resulting from the logic.
User commands may be used to control the switches, cancel signaling, activation of algorithms or
execution of any user designed function present on the device logic scheme.

User manual
IU_M710P_MANUAL_05i00_ENG Strona 19 z 36
3.8.3. Switches
Menu > Control > Switches
In this window all switches included in the device active
profile and their states are displayed. After selection of a
particular switch and pressing the key the Control
window opens.
In case the selected switch is not intended for control
via the interface the message Lack of control is displayed.
If the selected operation is allowable it will be executed
and the Switches window will return. Additionally,
a relevant event will be logged in the Event log.
In order for the operation selected from the Switches submenu to be executed the control mode Local or
Local and remote must be selected.

User manual
Strona 20 z 36 IU_M710P_MANUAL_05i00_ENG
3.9. Management
3.9.1. Settings
Menu > Control > Settings
The Settings submenu allows selecting active bay type
(profile), active set of settings and reviewing and editing
parameters in one of four sets of settings.
Settings may be modified by a user with adequate
level of privileges (see chapter 3.9.2.1. User Manager).
Modified parameters are memorized in the set of settings being edited.
Menus of all sets of settings for a given profile are identical.
Algorithms of protections and automatic functions, control
and monitoring functions and nominal values are grouped
in separate menu branches.
After pressing the Factory context key all parameters in
a given set of settings may be restored to factory values.
The Cancel command opens again the window with
configuration of settings in the edited set. The Factory
command will be executed or information displayed that
the command cannot be executed. Additionally, a relevant
event will be logged in the Event log.
