ITT neo-dyn 100p User manual

NEO-DYN
MODELS 100P, 101P, 110P, 180P, 200P, 201P
ADJUSTABLE PRESSURE SWITCHES;
MODEL 160P
ADJUSTABLE DIFFERENTIAL PRESSURE SWITCHES,
ENCLOSURE 3X FOR WEATHERPROOF APPLICATIONS
INSTALLATION AND
OPERATION MANUAL
PN 610-0008 Rev E

Enclosure 3X Pressure Switches Page i
Manual No. 610-0008 REV E
Neo-Dyn®
28150 Industry Drive
Valencia, CA 91355
Tel: [phone]
Fax: [phone]
World Wide Web: www.neodyn.com
©Copyright 2002
ITT Industries
Important Information
The product warranty applicable to this ITT Neo-Dyn®instrument is as stated on page the last
page of this manual.
Should any after-delivery problems arise, please contact ITT Neo-Dyn’s Customer Service
using the information above. Our normal business hours are weekdays, 7:00 am to 3:30 PM,
Pacific Time.
Before installing this Pressure Switch, become familiar with the installation and adjustment
instructions in Chapters 2 and 3
WARNING Indicates a hazard which can cause severe personal injury, death, or substantial
property damage if the warning is ignored.
CAUTION Indicates a hazard which will or can cause minor personal injury or property damage if the
caution is ignored.
NOTE Indicates additional information about a particular item necessary to the operation of the unit.
This document contains proprietary information, which is the property of Neo-Dyn®, a unit of
ITT industries. This document may not be reproduced, either in part or in full, without the
consent of ITT industries.

Enclosure 3X Pressure Switches Page ii
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION............................................................................................................1
CUSTOMER SERVICE....................................................................................................................2
OTHER CONFIGURATIONS..........................................................................................................2
CHAPTER 2 INSTALLATION.............................................................................................................3
MOUNTING .....................................................................................................................................3
PROCESS CONNECTIONS.............................................................................................................4
PROCESS MEDIA............................................................................................................................4
POTENTIALLY EXPLOSIVE ATMOSPHERES (HAZARDOUS LOCATIONS) ......................4
ELECTRICAL CONNECTIONS......................................................................................................5
CHAPTER 3 ADJUSTMENTS AFTER INSTALLATION..................................................................6
SETPOINT ADJUSTMENT.............................................................................................................6
CHAPTER 4 TROUBLESHOOTING...................................................................................................7
CHAPTER 5 SPECIFICATIONS..........................................................................................................8
WARRANTY INFORMATION..........................................................................................................14

Enclosure 3X Pressure Switches Page 1
CHAPTER
1
INTRODUCTION
The Neo-Dyn®Enclosure 3X Switches described in this manual are weather-proof,
electromechanical sensing devices designed for a wide range of applications in pneumatic
and hydraulic systems up to 10,000 psig. Models 100P, 101P, 110P, 200P, and 201P are
gauge pressure switches, Model 180P is a vacuum switch, and Model 160P is a differential
pressure switch.
The most common wetted materials of these pressure and vacuum switches include a
polyimide (Kapton) sensing diaphragm, nitrile O-ring, and aluminum alloy or corrosion
resistant steel (CRES) pressure port. CRES diaphragms and all-welded constructions are
also available in some models for corrosive pressure media and are standard on the
temperature switches.
Setpoint adjustments are easily made through the adjustable range by turning an
adjustment nut located inside the housing. On Models 101P and 201P this adjustment is
external.
The standard configuration of these switches will switch up to 15 amp at up to 250 VAC
in a single-pole configuration, and up to 11 amp at up to 250 VAC in a double-pole
configuration. When ordered with M Option, the switch is rated for currents to one amp,
but its bifurcated gold contacts will reliably switch currents in the milliampere and
microampere ranges.
These switches have CE Mark, and they all have weatherproof enclosures with IP66
ingress protection and that meet the requirements of NEMA 3. 3R, 3S, 4, 4X and 13. The
internal switch elements are UL and CSA recognized components.

Enclosure 3X Pressure Switches Page 2
Figure 1. Models 100P, 101P, 110P, 160P, 180P,
200P, 201P: Enclosure 3X Adjustable Pressure Switches
Pressure Port Configurations Vary with Model and Range
Hidden lines indicate mounting holes under the cover (see Mounting in Chapter 2).
Chapter 5 contains complete specifications for these Adjustable Pressure Switches.
CUSTOMER SERVICE
If you have any questions about these Pressure and Temperature Switches that are not
covered in this manual, you can contact Neo-Dyn®or our representatives in several ways.
The Neo-Dyn®customer service phone number is [phone]. Our customer service
department is open from 7:00 am to 3:30 p.m. Pacific Time.
Our Internet site is www.neodyn.com; it includes lists of sales representatives and
distributors.
OTHER CONFIGURATIONS
WARNING The models described in this manual are also available in special and factory-set
configurations. For these units, follow the installation and operating instructions herein,
except adhere to the pressure and electrical limits marked on the units.
ADJUSTMENT
KNOB,
MODELS
101P, 201P PRESSURE
PORT
CONDUIT FITTING, 1/2-14 NPT FEMALE
ALTERNATE LOCATION (SEE BELOW)
CONDUIT FITTING
1/2-14 NPT FEMALE
STANDARD LOCATION
(SEE BELOW)
HOUSING COVER 4X COVER SCREW
LOW-PRESSURE PORT, MODELS 152P, 160P
VACUUM PORT, MODEL 180P
1/4-18 NPT FEMALE

Enclosure 3X Pressure Switches Page 3
CHAPTER
2
INSTALLATION
Installation of these Neo-Dyn®Enclosure 3X pressure switches is straightforward.
However, they must be installed by a qualified electrician, in compliance with all local
and national electrical codes.
WARNING Electrical hazard
WARNING Do not make electrical connections while power is on.
WARNING Always check for multiple circuits.
WARNING Always make sure grounding is adequate.
WARNING Do not remove switch while under pressure.
MOUNTING
The Pressure Switch can be mounted directly to the process connection if there is no
significant vibration and the fluid lines are capable of supporting the weight. It can also
be attached to a flat surface, such as a wall or panel, using .250 in. diameter or M6
socket-head cap screws through the mounting holes that are accessed by removing the
housing cover; allow .5 in. (12.7 mm) screw length above the mounting surface. These
holes are located on two corners of a 2.72 inch (6.91 cm) square, or 3.85 inches (9.77 cm)
apart on a 45° diagonal. Do not over tighten the screws when replacing the cover.
Note that on certain models and ranges the housing of the pressure fitting has a large
outside diameter that extends below the mounting surface, requiring either a cutout in that
surface, or having the pressure fitting overhang an edge. These models are 100P and
101P, Range 1; 110P; 142P; 152P; 160P; and 180P

Enclosure 3X Pressure Switches Page 4
PROCESS CONNECTIONS
The process connections are:
Models 160P and 180P, both ports: ¼” - 18 NPT female standard. On Model 180P, the
vacuum port is on the side of the round housing, and the normal pressure port must be left
open to the atmosphere, which serves as the reference pressure.
All other pressure switches:
Wetted Material 1: ¼” - 18 NPT female standard
Wetted Materials 4-9: ½” - 14 NPT female standard
In addition, some models can be ordered with Option E (7/16”-20 SAE port); refer to
Table 7.
When installing the Pressure Switch, always:
Make sure that the unit and your system have matching threads.
Use the wrench flats provided.
Seal all joints with pipe joint sealing compound.
CAUTION Avoid excessive torque on all threaded connections.
WARNING Do not exceed the marked maximum operating pressure in normal operation.
The marked Proof Pressure is provided to give the maximum allowable pressure without
causing permanent damage to the pressure switch in the event of an over-pressure
condition. Set pressure relief/safety valves below this setting.
PROCESS MEDIA
Process media must be compatible with the wetted materials listed in Chapter 5.
Compatibility is defined by an “A” rating in the Chemical Resistance Guide for Metals
and Alloys, the Chemical Resistance Guide for Plastics, and the Chemical Resistance
Guide for Elastomers, all published by Compass Publications, and available from the
National Association of Corrosion Engineers (NACE), Houston, Texas; telephone 281
228 6200.

Enclosure 3X Pressure Switches Page 5
ELECTRICAL CONNECTIONS
An internal terminal block is standard, with a green screw for attaching the ground wire. See
See Figure 2 and
Figure 3
WARNING All field wiring must comply with requirements of the NEC or applicable local or
national electrical codes, including wire gauges and insulation temperature ratings.
Conduit seals may be required.
Figure 2. Form C and CC Schematics Shown Below the Decreasing Setpoint
NOTE: The direction of increasing pressure shown above represents the direction of
increasing vacuum on Model 180P.
Figure 3. Form Z Schematic Shown Below the Decreasing Setpoint.
NOTE: The direction of increasing pressure shown above represents the direction of
increasing vacuum on Model 180P.
RED NC1
BRN C1
BLU NO1
BLK NC2
YEL C2
VIO NO2
GRN
SCREW
RED NC1
BRN C1
FORM CC FORM C
GRN
SCREW
NC BLK
GRN
SCREW
NO VIO
RED NC
BLU NO

Enclosure 3X Pressure Switches Page 6
CHAPTER
3
ADJUSTMENTS AFTER INSTALLATION
The factory-set setpoint or adjustable setpoint range is marked on the nameplate of the
switch. This section describes the adjustments needed after an Adjustable Pressure
Switch has been properly installed.
SETPOINT ADJUSTMENT
Disconnect the electrical power. Check for multiple circuits.
Disconnect the electrical power. Check for multiple circuits.
1. On all models except 101P and 201P, loosen the screws on the housing cover, and move it
aside.
2. Check the setpoints per paragraphs 4 and 0 below for precise adjustments.
3. The adjustment nut can be rotated by hand or with an open-end wrench or similar tool (use a
screwdriver on Models 101P and 201P, or turn the knob by hand if a knob is included). The
range scale is intended to be used only as an approximate guide; it indicates the increasing
setpoint.
4. To check the increasing setpoint, connect a pressure source and a calibrated pressure gauge or
transducer to the pressure port and slowly apply increasing pressure (or vacuum on Model
180P) until the switch actuates. Actuation can be noted by listening to the audible snap of the
Belleville spring, or with an ohmmeter across the appropriate terminals in the terminal block.
5. If you want to check the decreasing setpoint, slowly decrease the pressure or vacuum after
the switch has actuated and note the value at which the audible snap or an ohmmeter indicates
deactuation. Deadband may be calculated if desired by subtracting the decreasing setpoint
reading from the increasing setpoint reading.
CAUTION 6. On all models except 101P and 201P, replace the cover by moving it back into
position over the top of the housing and tightening the screws until the cover is snug
against its gasket. Do not overtighten, as this could damage the gasket.

Enclosure 3X Pressure Switches Page 7
CHAPTER
4
TROUBLESHOOTING
In-service problems are unlikely, but the following paragraphs suggest ways to verify any
problems that might arise:
1. Pressure Switch Leaks
If a leak is suspected, isolate the pressure switch from the rest of the system. Connect
the switch and a calibrated pressure gauge downstream from a pressure source and
shutoff valve. Apply normal system pressure, isolate the gauge and Pressure Switch
from the pressure source with the shutoff valve for at least one minute, and check for
leaks as evidenced by a drop in the gauge reading.
If a leak is verified, return the unit for repair. Contact ITT directly, or your local sales
representative or distributor (see www.neodyn.com for a contact list).
2. Failure to Switch
If application of pressure or vacuum 10% greater than the adjusted setpoint fails to
produce actuation, first check for contamination in the process connection, and verify
that the expected pressure is reaching the sensing diaphragm or piston.
If the Belleville spring can be heard to audibly snap, but an ohmmeter indicates no
electrical switching, the cause is probably stuck or burned switch contacts, or the
switch element has moved away from the position where it was synchronized with
the snap action. Return theunitfor repair.
If application of pressure or vacuum 10% greater than the adjusted setpoint fails to
produce an audible snap of the Belleville spring, there is probably a mechanical
failure or binding due to contamination. Return the unit for repair.
3. Calibration Shifts
If it is suspected that the setpoints have shifted, recheck them per paragraphs 4 and 0
of Chapter 3. If you verify unstable or drifting setpoints, return the unit for repair.

Enclosure 3X Pressure Switches Page 8
CHAPTER
5
SPECIFICATIONS
This section shows standard specifications and available options.
STANDARD
Interfaces
Weight: approximately 3 pounds (1.4 kg) each
Conduit Connection: ½” - 14 NPT male
Standard Pressure Port:
Wetted Material 1: ¼” - 18 NPT female
Wetted Materials 4-9: ½” - 14 NPT female
Models 160P (both ports) and 180P: ¼” - 18 NPT female
Listing Agency Approvals
All models: CE Mark with option X included
Internal switching elements are recognized components by both UL and CSA.

Enclosure 3X Pressure Switches Page 9
Part Number
The part number contains information about which configurations and options are
included in your Adjustable Pressure Switch. To determine the pressure range, electrical
rating, and options, compare the part number of your unit with the information in Figure
4 and the following tables.
Figure 4. Part Number Breakdown
NOTE: Part number format varies for specials.
Wetted Materials
Table 1
No
Description
1
Aluminum alloy port, Teflon-coated polyimide (Kapton) diaphragm and nitrile
O-ring
1
Aluminum alloy port and piston, Teflon seal, Nitrile O-ring (only wetted
material available on Model 200P)
4
UNS S31600 CRES port, Teflon coated polyimide diaphragm and nitrile O-
ring
5
UNS S31600 CRES port and diaphragm, heliarc welded (Model 100P)
6
Hastelloy C port, Tantalum diaphragm, e-b welded (Model 100P)
7
Hastelloy C port and diaphragm (Model 100P)
9
Monel port and Inconel diaphragm, heliarc welded (Model 100P)

Enclosure 3X Pressure SwitchesPage 10
Pressure Ratings - Model 100P and 101P
Table 2
Part No
Range
No
Max
Operating
Pressure,
psig (bar)
Proof Pressure
PSIG (bar)
100P*1*3X
1
600 (41.37)
1000 (68.95)
100P*2*3X
2
3000 (206.9)
5000 (344.8)
100P*4*3X
4
3000 (206.9)
5000 (344.8)
100P*5*3X
5
3000 (206.9)
5000 (344.8)
100P*7*3X
7
3000 (206.9)
5000 (344.8)
100P*8*3X
8
3000 (206.9)
5000 (344.8)
Pressure Ratings - Model 110P
Table 3
Part No
Range
No
Max
Operating
Pressure,
psig (bar)
Proof Pressure
PSIG (bar)
110P*2*3X
2
300 (20.69)
500 (34.48)
110P*4*3X
4
300 (20.69)
500 (34.48)
Pressure Ratings - Model 180P
Table 4
Part No
Range
No
Max
Operating
Pressure,
psig (bar)
Proof Pressure
psig (bar)
180P*4*3X
4
225 (15.51)
350 (24.13)
Pressure Ratings - Model 200P and 201P
Table 5
Part No
Range
No
Max
Operating
Pressure,
psig (bar)
Proof Pressure
psig (bar)
200P12*3X
2
3000 (207)
4500 (310)
200P13*3X
3
7500 (517)
11250 (776)
200P16*3X
6
7500 (517)
11250 (776)
200P18*3X
8
10000 (690)
15000 (1034)
200P18*6EX
8
9500 (655)
15000 (1034)

Enclosure 3X Pressure SwitchesPage 11
Pressure Ratings - Model 160P
Table 6
Part No
Range
No
Max
Operating
Pressure,
psig (bar)
Proof Pressure
psig (bar)
160P*2*3X
2
300 (20.69)
500 (34.48) high / low;
200 (13.79) low / high
160P*4*3X
4
500 (34.48)
1000 (68.95) high / low;
400 (27.58) low / high
160P*6*3X
6
500 (34.48)
1000 (68.95) high / low;
400 (27.58) low / high
160P*7*3X
7
500 (34.48)
1000 (68.95) high / low;
400 (27.58) low / high

Enclosure 3X Pressure SwitchesPage 12
Weather Proof Ratings
Ingress protection IP66
Enclosure type 3, 3R, 3S, 4, 4X, 13 (NEMA)
Temperature Ranges for Pressure Media
Standard (Nitrile O-rings, -40°C (-40°F) to +121°C (+250°F) and Wetted Matl. 5-7, 9);
C Option (EPR O-rings): -40°C (-40°F) to +121°C (+250°F) and Wetted Matl. 5-7, 9);
B Option (Viton O-rings): -26°C (-15°F) to +121°C (+250°F) and Kalrez O-rings
Electrical and Ambient Temperature Ratings
Minimum ambient temperature is -40 °C (-40 °F), except with B Option and Kalrez O-
rings it is -26°C (-15°F)
Minimum ambient temperature is -40 °C (-40 °F), except with B Option and Kalrez O-
rings it is -26°C (-15°F)
Form C3X (SPDT):
15 amp @ 125 or 250 VAC , 1/8 HP @ 125 VAC,
¼ HP @ 250 VAC, to +70 °C (+158 °F) max;
5 amp resistive , 3 amp inductive @ 28 VDC; .5 amp resistive , .04 amp inductive @ 125
VDC to +85 °C (+186 °F) max.
Form CC3X (DPDT):
11 amp* and ¼ hp @ 125 or 250 VAC to +65 °C (+149 °F) max;
5 amp resistive , 3 amp inductive @ 28 VDC; .5 amp resistive @ 125 VDC to+85 °C
(+186 °F) max.
Form C3MX or CC3MX (SPDT or DPDT with M Option):
1 amp @ 125 VAC to +85 °C (+186 °F) max.
Form Z3X (SPDT):
15 amp @ 125 or 250 VAC , 1/4 HP @ 125 VAC,
1/2 HP @ 250 VAC, to +80 °C (+176 °F) max;
5 amp resistive , 3 amp inductive @ 28 VDC; 1 amp resistive , .5 amp inductive @ 125
VDC to +85 °C (+186 °F) max

Enclosure 3X Pressure SwitchesPage 13
OPTIONS
The available options for standard switches are listed below. These options can be
combined; every included option will be indicated in the part number of the unit.
Table 7
Option
Description
Available on Model
A
Epoxy-painted exterior
All
B
Viton O-Ring - Refer to
Wetted Materials
100P, 110P, 160P, 180P, 200P
C
EPR O-Ring - Refer to
Wetted Materials
100P, 110P, 160P, 180P, 200P
E
7/16 - 20 SAE Port
(Wetted Material 1 Only)
100P; 200P (except Range 8)
G
½-14 NPT Male Port
110P (Wetted Material 4 only)
M
Gold Electrical Contacts
For Extremely Low
Current Applications
All
K
Knob for external
adjustment
101P, 201P
R
72 inch (183 cm) leads
All
S
Corrosion-Resistant Steel
Diaphragm
100P;110P; 160P Ranges 2, 4;
180P Range 2; Wetted Material 4 Only
W
CRES exterior screws
100P, 110P, 200P, 201
Wetted Material 1 Only
(Standard on other wetted materials)
X
CE Mark
All

Enclosure 3X Pressure SwitchesPage 14
WARRANTY INFORMATION
A. Warranty:
ITT Industries (ITT) warrants that at the time of shipment, the products manufactured by
ITT Neo-Dyn®and sold hereunder, will be free from defects in material and
workmanship and will conform to the specifications furnished or approved by ITT.
B. Warranty Adjustment:
If any defect within this warranty appears, the Buyer shall notify ITT immediately.
ITT agrees to repair or furnish a replacement for, but not install, any product which,
within one (1) year from the date of shipment by ITT shall, upon test and examination by
ITT, prove defective within the above warranty.
No product will be accepted for return or replacement without the written authorization
of ITT. Upon such authorization, and in accordance with instructions by ITT, the product
will be returned with shipping charges prepaid by the Buyer. Replacements made under
this warranty will be shipped prepaid.
C. Exclusion from Warranty:
THE FOREGOING WARRANTY IS IN LIEUOF ANDEXCLUDES ALL OTHER
EXPRESSED OR IMPLIED WARRANTIES OFMERCHANTABILITY, OR FITNESS, OR
OTHERWISE.
Components manufactured by any supplier other than ITT shall bear only the warranty
made by the manufacturer of that product, and ITT assumes no responsibility for the
performance or reliability of the unit as a whole.
In no event shall ITT be liable for indirect, incidental or consequential damages nor shall
the liability of ITT arising in connection with any products sold hereunder (whether such
liability arises from a claim based on contract, warranty, tort or otherwise) exceed the
actual amount paid by Buyer to ITT for the products delivered hereunder.
The warranty does not extend to any product manufactured by ITT, which has been
subject to misuse, neglect, accident, improper installation, or to use in violation of
instructions furnished by ITT.
The warranty does not extend to or apply to any unit, which has been repaired or altered
at any place other than at ITT’s factory or service locations, by persons not expressly
approved by ITT.
