ITW Dynatec DM55 DynaDrum Guide

Adhesive Application Solutions | ISO 9001 certified
DM55 DynaDrum Bulk Adhesive Melter
With Piston Pump & Controller V6 Touch Panel Rev.2.19
Technical Documentation, No. 21-18, Rev.2.19
ITW Dynatec
An Illinois Tool Works Company
www.itwdynatec.com

ITW Dynatec
Information about this manual
Page 2 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
Information about this manual
Read all instructions before operating this equipment!
It is the customer’s responsibility to have all operators and service
personnel read and understand this information. Contact your ITW
Dynatec customer service representative for additional copies.
ITW Dynatec Service Parts and Technical Service:
AMERICAS EUROPE, MIDDLE
EAST & AFRICA
ASIA PACIFIC
ITW Dynatec
31 Volunteer Drive
Hendersonville, TN 37075
USA
Tel. [phone]
[e-mail]
[e-mail]
ITW Dynatec
Industriestrasse 28
40822 Mettmann
Germany
Tel. [phone]
[e-mail]
[e-mail]
ITW Dynatec
NO. 2 Anzhi Street,
SIP, Suzhou, 215122
China
Tel. [phone]
[e-mail]
[e-mail]
ITW Dynatec
Tsukimura Building 5th Floor
26-11, Nishikamata 7-chome
Ota-ku, Tokyo 144-0051,
Japan
Tel. [phone]
[e-mail]
[e-mail]
NOTICE:
Please be sure to include the serial number of your application
system each time you order replacement parts and/or supplies. This
will enable us to send you the correct items that you need.
Note: Most common screws, nuts and washers called out in the
manual are not for sale and they can be obtained locally at your
hardware Store. Specialty fasteners are available by contacting ITW
Dynatec’s Customer Service.

Index
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 3
Index
Information about this manual ................................................2
Index ..........................................................................................3
Chapter 1 Declaration of Conformity......................................7
Chapter 2 Safety Instructions .................................................9
General Considerations ............................................................................................................ 9
Warning Labels ......................................................................................................................... 9
Safety Symbols in this Manual ................................................................................................ 10
Safe Installation and Operation ............................................................................................... 10
Explosion/ Fire Hazard ............................................................................................................ 11
Choice of Adhesive ................................................................................................................. 11
Special Safety Considerations When Using Reactive HMPUR Adhesives ............................ 11
Eye Protection & Protective Clothing ...................................................................................... 13
Electrical .................................................................................................................................. 13
Lockout/ Tagout ...................................................................................................................... 13
High Temperatures ................................................................................................................. 14
High Pressure ......................................................................................................................... 14
Protective Covers .................................................................................................................... 14
Servicing, maintenance ........................................................................................................... 15
Secure transport ...................................................................................................................... 15
Treatment for Burns from Hot Melt Adhesives ........................................................................ 16
Measures in case of fire .......................................................................................................... 16
Keep attention to environmental protection standards ........................................................... 17
Chapter 3 Description and Technical Specs .......................19
3.1 Applicable Safety Regulations ...................................................................... 19
Intended Use ........................................................................................................................... 19
Unintended Use, Examples..................................................................................................... 19
Residual Risks ........................................................................................................................ 20
Technical changes .................................................................................................................. 20
Using foreign components ...................................................................................................... 20
Setting-up operation ................................................................................................................ 20
3.2 Description .................................................................................................... 21
Two-Hand-Control-Buttons (Left & Right-Confirm-Buttons) .................................................... 22
System Status Lights .............................................................................................................. 22
Mechanical High-Temperature Protection .............................................................................. 22
RTD Sensors ........................................................................................................................... 22
3.3 Specifications................................................................................................ 23
3.4 Model Designation Guide ............................................................................. 26
Chapter 4 Installation .............................................................27
4.1 Conditions for set-up and mounting .............................................................. 27
4.2 Installation .................................................................................................... 28
4.3 Quality of compressed Air ............................................................................. 29
Chapter 5 Setting-up Operation, Daily Operation ...............31
5.1 Advices for the setting-up operation ............................................................. 31

ITW Dynatec
Index
Page 4 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
5.2 Setting-up operation, daily operation ............................................................ 33
Open/ Close the Main Panel Box Door ................................................................................... 33
To Turn Main Power On/Off .................................................................................................... 33
Operating Switches and Buttons ............................................................................................. 33
Procedure to Resume Production after Use of Emergency Stop ........................................... 34
Preparing a New Drum for melting .......................................................................................... 34
Pneumatic Controls ................................................................................................................. 34
Operator Adjustments ............................................................................................................. 36
Platen Position Sensor ............................................................................................................ 37
Bulk Melter Startup Procedure, Daily Operation ..................................................................... 38
Drum Change-Out ................................................................................................................... 42
5.3 Switching the unit off ..................................................................................... 44
Chapter 6 Controller V6 Touch .............................................45
6.1 Controller Set-Up .......................................................................................... 45
Helpful Tips for the User ......................................................................................................... 45
Temperature Control Functions in General ............................................................................. 45
Software & Hardware Versions ............................................................................................... 45
Defining DynaControl Temperature Control Terms ................................................................ 46
6.2 Program Your System's Parameters ............................................................ 48
Numeric Entry Keypad ............................................................................................................ 48
Alphabetic Entry Keypad ......................................................................................................... 49
Main Screen ............................................................................................................................ 50
Temperature Zones Set Screen .............................................................................................. 54
Zone On/Off Switch on the Numeric Entry Keypad ................................................................ 55
Pump Overview Screen .......................................................................................................... 56
Pump Control Screen/ Linear Line Speed .............................................................................. 58
Extended Pump Mode Settings Screen, Linear Line Speed, Pressure Control ..................... 60
Pump Control/ Pressure Control Screen ................................................................................. 62
Automatic Ramp Compensation at DM55 with Gear Pump .................................................... 64
Control Switch On/Off and Standby Switch ............................................................................ 66
Systems Screen ...................................................................................................................... 68
Settings Screen ....................................................................................................................... 70
Heating Priority Screen ........................................................................................................... 71
Zone Configuration Screen ..................................................................................................... 72
Zone Settings .......................................................................................................................... 73
Fieldbus Setup Screen ............................................................................................................ 75
General Settings Screen ......................................................................................................... 76
Temperature Settings .............................................................................................................. 76
Standby Settings ..................................................................................................................... 78
Drum Calibration ..................................................................................................................... 80
Level Control Settings ............................................................................................................. 82
Pressure Zero Calibration ....................................................................................................... 84
Customer Zone Names ........................................................................................................... 86
Support .................................................................................................................................... 88
Recipes Screen ....................................................................................................................... 89
Time & Scheduler Screen ....................................................................................................... 91
Log Book Screen ..................................................................................................................... 94
Security Screen ....................................................................................................................... 95
System Info Screen ................................................................................................................. 97
License Management Screen ................................................................................................. 98
Software Licenses ................................................................................................................... 99
Acknowledge Button ............................................................................................................. 100
Faults/ Alarms ....................................................................................................................... 101
Operator Response to Error Indication Alarms ..................................................................... 101
XIO Template Settings, Module #1 ....................................................................................... 102
6.3 Modules and Printed Circuit Boards (PCBs) ............................................... 103
V6 Base Module PN 115734 ................................................................................................. 104
V6 Temperature Module PN 115735 .................................................................................... 108

Index
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 5
Standard V6 Zone Table, Drum Unloader DM55 .................................................................. 109
V6 Power Module PN 823306 ............................................................................................... 110
V6 Motor Module PN 116823 ................................................................................................ 111
V6 Solid State Relay (SSR) Adapter PCB Assembly PN 118584 ........................................ 112
Optional V6 BUS Communications Module PN 118125 ....................................................... 113
V6 Extended I/O Module PN 117648 .................................................................................... 114
Optional Printed Circuit Boards ............................................................................................. 114
Chapter 7 Maintenance and Repair Notes .........................115
7.1 Security advices for maintenance and repair .............................................. 115
7.2 Maintenance plan ....................................................................................... 116
7.3 Piston Pump Oil Cavity ............................................................................... 117
7.4 Piston Pump Inlet Check Valve Cleaning ................................................... 117
7.5 Draining of Supply Air Filter/ Regulator ....................................................... 118
7.6 Clamshell Adjustments ............................................................................... 118
7.7 Special Maintenance for PUR Applications ................................................ 118
7.8 Piston Pump Assembly Replacement ......................................................... 119
7.9 Pump Disassembly ..................................................................................... 120
7.10 Platen Removal ........................................................................................ 122
7.11 Platen Seal Replacement ......................................................................... 123
7.12 Electrical Parts Replacement .................................................................... 127
Chapter 8 Troubleshooting .................................................129
8.1 Troubleshooting Notes ................................................................................ 129
8.2 Mechanical Troubleshooting Guide (for Piston Pump Models) ................... 131
8.3 Electrical Troubleshooting Guide ................................................................ 134
8.4 Heaters in Platen Core ............................................................................... 135
8.5 Heaters in Piston Pump .............................................................................. 136
8.6 RTD Sensors in Platen Core & Piston Pump .............................................. 136
8.7 Piston Pump Flow Diagram ........................................................................ 137
8.8 Motor Speed Control Drive ......................................................................... 138
8.9 Accessing, Programming and Monitoring Motor Control Parameters ......... 139
Chapter 9 Drawings and Bill of Materials...........................141
Notes ..................................................................................................................................... 141
Frame and Panel Box Assemblies ........................................................................................ 142
Platen and Connector Kit Assemblies ................................................................................... 144
Platen Vent Valve Assembly, PN 114295 ............................................................................. 146
Piston Pump Assembly, PN 114350 ..................................................................................... 147
Air Motor Assembly, PN 114314 ........................................................................................... 149
Piston Pump/ Air Motor Connection Replacement Parts ...................................................... 150
Remote Purge Kit, PN 116401 .............................................................................................. 151
Piston Pump Pneumatic Assembly, 5 PSI Air Inject, PN 823064 ......................................... 152
Air Injection Replacement Parts ............................................................................................ 154
Piston Pump Valve Assembly, PN 823066 ........................................................................... 155

ITW Dynatec
Index
Page 6 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
Junction Box Assembly, Piston Pump, PN 115945 .............................................................. 157
Chapter 10 Options & Accessories ....................................159
Level Control Kit without Heated Ball Valve & Actuator Option, PN 806573 ........................ 159
Heated 1” Ball Valve Option, PN 805732 .............................................................................. 159
Ball Valve Air Actuator Option, PN 806387 ........................................................................... 159
Pump Option ......................................................................................................................... 159
Full Clam Shell Option, PN 114126 ...................................................................................... 159
Vent Hood Option, PN 114367 ............................................................................................. 159
Pressure Transducer Kit PN 114717, Transducer only PN 811475 ..................................... 159
Pallet Spacer Option, PN 114725 ......................................................................................... 159
Purge Valve Heater Option, PN 115502 ............................................................................... 159
Platen Options ....................................................................................................................... 160
Platen Seal Options .............................................................................................................. 160
Platen Guard, PN 116967 ..................................................................................................... 160
Purge Valve Heater, PN 115502 ........................................................................................... 161
Pressure Transducer Kit, PN 114717 ................................................................................... 162
Drum-Present Sensor Kit, PN 114811 .................................................................................. 163
Cable Position Sensor Kit, PN 114812 ................................................................................. 164
Ball Valve Purge Kit, PN 114757 .......................................................................................... 165
Vertical Air Inject Valve, PN 116859 ..................................................................................... 166
Angled Air Inject, PN 117812 ................................................................................................ 167
Pressure Relief Assembly, 3 Position, PN 823034 ............................................................... 168
Pressure Relief Assembly, 2 Position, PN 823033 ............................................................... 169
Pressure Gauge Assembly, Easy Spin, PN 819685 ............................................................. 170
Optional V6 Communications Adapters/ PCBs: .................................................................... 170
Air Motor Rebuild Kits ........................................................................................................... 171
Chapter 11 Recommended Spare Part Lists......................173
Mechanical Parts ................................................................................................................... 173
Parts within the Controller Panel Box (240V, 400V or 480V) ............................................... 173
Parts for Piston Pump Models .............................................................................................. 174
Pneumatic Parts .................................................................................................................... 175
Miscellaneous ....................................................................................................................... 175
Chapter 12 Pneumatic Schematics.....................................177
Pneumatic Schematic, Piston Pump, 5 PSI Air Inject, PN 823079 ....................................... 177
Pressure Relief Assembly, 3 Position (optional), PN 823034 ............................................... 178
Pressure Relief Assembly, 2 Position (optional), PN 823033 ............................................... 178
Chapter 13 Electrical Schematics.......................................179
13.1 Bulk Melter DM55 240V ............................................................................ 179
Schematics, 240V, PN 823172 ............................................................................................. 179
13.2 Bulk Melter DM55 400V ............................................................................ 181
Schematics, 400V, PN 823173 ............................................................................................. 181
13.3 Bulk Melter DM55 480V ............................................................................ 183
Schematics, 480V, PN 823174 ............................................................................................. 183
Chapter 14 Appendix............................................................185
DynaControl V6 / Fieldbus Options ....................................................................................... 185
Revisions ............................................................................................................................... 186
Pressure Transducer

Chapter 1
Declaration of Conformity
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 7
Chapter 1
Declaration of Conformity

ITW Dynatec
Chapter 1
Declaration of Conformity
Page 8 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
This page intentionally left blank.

Chapter 2
Safety Instructions
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 9
Chapter 2
Safety Instructions
General Considerations

All operators and service personnel must read and understand this manual
before operating or servicing equipment.

All maintenance and service on this equipment must be performed by trained
technicians.
Read and adhere to the manual!
1. Read and follow these instructions.
Failure to do this could result in severe personal injury or death.
2. Keep the binding rules for accident prevention valid for your country and the place of
installation. Also keep the approved qualified technical rules for safety-conscious and
professional work.
3. Additional safety instructions and/ or symbols are located throughout this manual.
They serve to warn maintenance personnel and operators about potentially hazardous
situations.
4. Inspect the machine for unsafe conditions daily and replace all worn or defective parts.
5. Keep work area uncluttered and well lit. Remove all material or things not needed for
the production from the workspace of the equipment!
6. All covers and guards must be in place before operating this equipment.
7. Subject to technical modifications without notice!
8. To ensure proper operation of the equipment, use specified electrical and/ or air
supply sources.
9. Do not attempt to alter the design of the equipment unless written approval is received
from ITW Dynatec.
10. Keep all manuals readily accessible at all times and refer to it often for the best
performance from your equipment.
Warning Labels
1. Read and obey all of the warning labels, signs and caution statements on the
equipment.
2. Do not remove or deface any of the warning labels, signs and caution statements on
the equipment.
3. Replace any warning labels, signs and caution statements which have been removed
or defaced. Replacements are available from ITW Dynatec.

ITW Dynatec
Chapter 2
Safety Instructions
Page 10 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
Safety Symbols in this Manual
1. DANGERS, WARNINGS and CAUTIONS are found throughout this manual.
DANGERS and WARNINGS mean that failure to observe the specific instructions may
cause injury to personnel.
2. CAUTIONS mean that failure to observe the specific instructions may damage the
equipment.
Safe Installation and Operation
Read and adhere to the manual!
1. Read this manual before applying electrical power to the equipment. Equipment may
be damaged by incorrect electrical connections.
2. To avoid possible failure of hoses, make sure all hoses are routed to avoid kinking,
tight radius turns (8” or less) and abrasive contact. Hot‐melt hoses should not have
prolonged contact with heat‐absorbing surfaces such as cold floors or metal troughs.
These heat‐absorbing surfaces can alter adhesive flow and cause incorrect
calibration. Hoses should never be covered with materials that prevent heat
dissipation, such as insulation or sheathing. Hoses should be spaced apart from each
other, not making direct contact.
3. Do not use adhesive that is dirty or that may be chemically contaminated. Doing so
can cause system clogging and pump damage.
4. When adhesive hand‐held applicators or other movable applicators are used, never
point them at yourself or at any other person. Never leave a hand‐held applicator's
trigger unlocked when not actually in use.
5. Never activate the heads, hand‐held applicators and/ or other application devices until
the adhesive's temperature is within the operating range. Severe damage could result
to internal parts and seals.
6. Always install the equipment on a flat surface.
7. Never attempt to lift or move the unit when there is molten adhesive in the system.
8. Promptly wipe up fluid spills to avoid potential slips or falls.
9. In case of an emergency or exceptional incident, press the emergency stop button in
order to stop the unit quickly.
10. Use the unit only as it is intended to.
11. Never let the unit run unattended.
12. Operate the unit only in a faultless and fully functional condition. Check and make
sure that all safety devices work in proper form!

Chapter 2
Safety Instructions
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 11
Explosion/ Fire Hazard
1. Never operate this unit in an explosive environment.
2. Use cleaning compounds recommended by ITW Dynatec or your adhesive supplier
only.
3. Flash points of cleaning compounds vary according to their composition, so consult
with your supplier to determine the maximum heating temperatures and safety
precautions.
Choice of Adhesive
Substance(s) being processed (e.g., melted, pumped, applied) by ITW equipment is at
the discretion of the user and beyond ITW Dynatec’s control. Any health effects or other
safety-related concerns arising from the melting of those particular substances (e.g.,
hazardous fumes) is the responsibility of the user to identify and mitigate.
DANGER HARMFUL FUMES
PUR adhesives emit fumes (MDI and TDI) that can be dangerous to anyone exposed to
them. These fumes cannot be detected by the sense of smell. ITW Dynatec strongly
recommends that a power‐vented exhaust hood or system be installed over any PUR
system.
Consult with your adhesive manufacturer for specifics about required ventilation. See
also the Special Considerations for Using Reactive HMPUR Adhesives section in this
chapter.
Because of the nature of PUR adhesives to strongly bond in the presence of moisture,
care must be taken to prevent them from curing inside ITW Dynatec equipment.
If PUR adhesive solidifies in a unit, the unit must be replaced. Always purge old PUR
adhesive from the system per your adhesive manufacturer's instructions and time table.
Special Safety Considerations When Using Reactive HMPUR Adhesives
Reactive hot melt PUR (HMPUR) adhesives are known for superior adhesion to
numerous substrates and their exceptional heat, cold and moisture-resistance qualities.
They are an excellent choice for the difficult-to-bond substrates used in a wide range of
environments. HMPUR adhesives chemically cross-link (i.e., cure or thermal-set) to reach
maximum bond strength, typically over a period of 24 to 48 hours after being exposed to
moisture and/or high temperatures.
The advantages of using HMPURs, however, come with special handling requirements.
The adhesive must remain sealed off from the environment and maintained at low
temperatures until it is dispensed, otherwise there is a risk that the adhesive will cross-
link within the glue application equipment, rendering it impervious to melting when it is re-
heated. Most importantly, when over-heated, many HMPURs release gases that can be
hazardous to humans. Therefore, adequate ventilation must be available to prevent injury
to personnel in the workspace. ITW Dynatec PN 114367 Vent Hood is required.
The following is a list of general operational considerations for the use of HMPURs in ITW
Dynatec equipment. In addition, it is important to contact your adhesive manufacturer to
discuss and verify precautions that must be implemented to prevent damage to
equipment and injury to personnel who are working with their products.
1. Assure the workspace has adequate ventilation.

ITW Dynatec
Chapter 2
Safety Instructions
Page 12 DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19
2. Assure the entire adhesive delivery system is sealed from the environment to the
greatest extent possible to prevent moisture-related adhesive cross-linking.
3. Assure all air is evacuated from the adhesive delivery system as soon as possible
after it has been introduced (i.e., when changing hoses, replacing filters, changing
adhesive supplies, etc.) to prevent moisture-related cross-linking.
4. The ITW Dynatec equipment should not be left dormant (sealed at ambient
temperature) with PUR inside for longer than recommended by your adhesive
manufacturer. The ITW Dynatec system, especially applicators and nozzles, should be
thoroughly purged of adhesive using a PUR purge material if the system will be left
dormant for extended time periods.
5. HMPUR viscosity increases the longer it remains molten within a system and can
cross-link due to temperature exposure. Assure the molten adhesive does not sit
within the ITW Dynatec equipment at operating temperature for more than a
cumulative total of 2 to 4 hours. Utilization of the Temperature Standby feature will
ensure a temperature drop occurs automatically.
6. Turn off any gear pumps in the system if it will not be used for a period of five minutes
or more. Doing so will reduce potential glue degradation.
7. When using spray applicators, the nozzles must be thoroughly cleaned on a regular
basis to prevent the adhesive from cross-linking inside or on the surface of the air
passageways.
8. The adhesive applicators must be either fully sealed or thoroughly cleaned with PUR
purge material if the system is to be idle for more than two hours. Otherwise, HMPUR
adhesive present in the exposed orifices of the applicator could potentially cross-link,
clogging them.
9. Recommended adhesive application temperatures should never be exceeded. Higher
application temperatures may result in higher adhesive viscosities and thermal-related
cross-linking.
10. The use of air dryers such as ITW Dynatec PN 117944 or 117974 are recommended
in humid environments.
There are many advantages to using HMPURs. However, the proper handling of these
unique adhesives is imperative to assure success without damage to equipment or injury
to personnel. ITW Dynatec equipment has been engineered to minimize the effort
required to assure safe and proper handling of HMPURs.
ALLOWING PUR ADHESIVE TO CURE IN A UNIT OR ITS COMPONENTS VOIDS ITW
DYNATEC’S WARRANTY.
Please consult with your ITW Dynatec representative to discuss these topics in further
detail, if necessary.

Chapter 2
Safety Instructions
ITW Dynatec
DM55 DynaDrum PP V6, Manual No.21-18, Rev.2.19 Page 13
Eye Protection & Protective Clothing
WARNING
EYE PROTECTION & PROTECTIVE CLOTHING REQUIRED
1. It is very important that you PROTECT YOUR EYES when working around
hot melt adhesive equipment!
2. Wear a face shield conforming to ANSI Z87.1 or safety glasses with side
shields which conform to ANSI Z87.1 or EN166.
3. Failure to wear a face shield or safety glasses could result in severe eye
injury.
4. It is important to protect yourself from potential burns when working around hot melt
adhesive equipment.
5. Wear heat-resistant protective gloves and long-sleeved, protective clothing to prevent
burns that could result from contact with hot material or hot components.
6. Always wear steel-reinforced safety shoes.
Electrical
DANGER HIGH VOLTAGE
1. Dangerous voltages exist at several points in this equipment. To avoid personal injury,
do not touch exposed connections and components while input power is on.
2. Disconnect, lockout and tag external electrical power before removing protective
panels.
3. A secure connection to a reliable earth ground is essential for safe operation.
4. An electrical disconnect switch with lockout capability must be provided in the line
ahead of the unit. Wiring used to supply electrical power should be installed by a
qualified electrician.
5. Notify the maintenance personnel immediately, if cables are damaged. Provide for
exchanging the defective components immediately.
Lockout/ Tagout
Switch the unit voltage-free before working!
Main switch OFF!
1. Follow OSHA 1910.147 (Lockout/ Tagout Regulation) for equipment's lockout
procedures and other important lockout/tagout guidelines.
