Ivation IVALDH30PW User manual

70-Pint Energy Star
Dehumidifier
User Guide
IVALDH30PW
Thank you for purchasing the Ivation® 70-Pint Energy Star Dehumidifier.
This User Guide is intended to provide you with guidelines to ensure that
operation of this product is safe and does not pose risk to the user. Any
use that does not conform to the guidelines described in this User Guide
may void the limited warranty.
Please read all directions before using the product and retain this guide
for reference. This product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is
subject to limits and exclusions. See warranty for details.
Box contents
70-pint dehumidifier
User guide

Parts
1. Control panel
2. Air intake vent
3. Air filter
4. Water reservoir
5. Handle
6. Air outlet vent
7. Power cord band
8. Drain hose outlet
9. Power cord
10. Power plug
Control panel
2
5
6
7
8
9
10
1
2
3
4
11 12 14 13 17
25232122 24201918
15 16
11. Filter light reset button
12. Continuous (CONT.) mode button
13. Timer button
14. Fan (TURBO) button
15. Decrease button
16. Increase button
17. Power button
18. Clean filter light
19. Continuous mode light
20. Turbo speed fan light
21. Reservoir full light
22. Auto defrost light
23. On light
24. Off light
25. Digital display

Safety precautions
• Do not exceed the unit’s rated power.
• Do not pause the unit by turning off the power.
• Do not use a damaged or unspecified power cord.
• Do not modify the cord length or share the outlet with other appliances.
• Do not handle the plug with wet hands.
• Do not install the unit in a place where it may be exposed to
combustible gas.
• Do not place the unit near a heat source.
• Disconnect the power if unusual sounds, smells, or smoke, comes from
the unit.
• Never attempt to take apart or repair the unit.
• Before cleaning the unit, always turn off the power and unplug.
• Do not drink or use the water drained from the unit.
• Do not remove the water reservoir during operation.
• Do not place the unit in a place where it may become wet or damp.
• Always place the unit on a level, stable section of the floor.
• Do not cover the intake or exhaust vents with cloths or towels.
• Keep out of reach of children or pets.
• Do not use in areas where chemicals are handled.
• Never insert fingers or other foreign objects into the vents or openings.
• Do not place heavy objects on the power cord.
• Do not climb on or sit on the unit.
• Always insert the filters securely. Clean the filter once every two weeks.
• If water enters the unit, turn it off and disconnect the power. Contact a
qualified service technician.
Operation
Before turning the unit on, position it as
seen in the diagram. Be sure that you
place the unit in a room that is between
41°F (5°C) and 95°F (35°C).
Automatic features
AUTO SHUT OFF: The unit will
automatically shut off when
either the reservoir is full or
the set humidity is reached.
Wait 3 minutes before
resuming operation.
AUTO DEFROST: When frost builds up on the evaporator coils, the
compressor will cycle off and the fan will continue to run until the unit
has defrosted.
AUTO RESTART: If the power is cut unexpectedly, the unit will restart
with the previous settings when power resumes.
Manual features
COMFORT MODE: This mode will set the unit to automatically control
humidity between 45%-55% based on the temperature of the room. Note
that the humidity cannot be manually set while in this mode.
FILTER: When it is time to clean the filter, the clean filter light will turn on.
To reset the light after cleaning the filter, press the filter light reset button.
CONTINUOUS MODE: To set the dehumidifier to run constantly without a timer,
press the continuous mode button. The continuous mode light will turn on.
HUMIDITY CONTROL: Relative humidity can be adjusted in 5% increments. For
dryer air, press the minus button. For damper air, press the plus button. Note
that relative humidity can be set within a range of 35% to 85%.
TIMER: The timer can be set to indicate either when the dehumidifier will start
or when it will stop. To set a time, press the timer button until the desired timer
light turns on. Use the increase and decrease buttons to adjust the time in .5
hour increments up to 10 hours.
FAN: Press the fan button to switch between high and low fan speed. Note that
the higher fan speed will remove more moisture.
Removing collected water
Collected water can be removed in the following ways:
1. When the water reservoir is full, remove and empty it.
2. Continuous draining: water can be automatically emptied
into a floor drain by attaching the unit to a water hose
with a female threaded end (not included).
a. Remove the plastic cover from the drain
outlet of the unit and set aside.
b. Remove the water reservoir and insert
the hose through the drain outlet of the
unit, pressing it securely into the connector
on the front of the unit.
c. Tighten the adapter and the unit with two
screws (not included).
3
more than 40cm
more than 20cm
more than 20cm
more than 20cm
Drain hose
subassembly
Connector
Drain hose
Plastic cover

d. Install the female threaded end of the
water hose into the adapter, then lead
the water hose to the floor drain or a
suitable drainage facility.
Error codes
The following codes may appear on the LED display.
AS: humidity sensor error
ES: temperature sensor error
P2: the reservoir is full or not positioned correctly
If there is an error, follow the steps below:
1. Turn off the unit
2. Check for any obstructions
3. Restart the unit. If the malfunction is still present, turn off the unit and
unplug the power cord.
4. If the error persists, contact the manufacturer, its service agents or a
similar qualified person for service.
Care and maintenance
• Always turn the dehumidifier off and unplug before cleaning.
• The water reservoir should be washed with fresh water every few weeks.
• The air filter should be washed with clean water at least every 30 days.
• When storing the unit:
• After turning off the unit, wait one day before emptying the reservoir
• Clean the main unit, reservoir, and air filter
• Wrap the cord and bundle it with a band
• Cover the unit with a plastic bag
• Store the unit upright in a dry, well-ventilated place
Specifications
Rated power: 115V
Rated frequency: 60Hz
Rated current: 6.5 amps
Refrigerant: R410A/8.29oz./0.24kg
Moisture removal: 70 pints/day
EEV: 2.0L/kW.H
Design pressure:
High: 540PSIG/3.7MPa
Low: 300PSIG/2.1MPa
Water reservoir capacity: 16gal. (6L)
Customer service:
[email protected]om
866-849-3049
Troubleshooting
Problem
Unit does not start
The unit does not dry the air
as it should
The unit is making loud noises
Frost appears on the coils
Water is spilling on the floor
Solution/Explanation
Check that the unit is plugged in.
Check the house’s fuse/circuit breaker box.
The unit has reached its preset level or the
reservoir is full.
Reservoir is not in the correct position.
Allow the unit more time to remove the moisture.
Make sure that nothing is blocking the front or back
of the unit.
Select a lower humidity setting.
Check that all doors, windows, and other openings
are securely closed.
The room temperature is too low (below 41°F; 5°C).
There is another appliance producing water vapor
in the room.
The air filter is clogged.
The unit is tilted instead of upright.
The floor surface is not level.
This is normal. The unit has an auto defrost feature.
The hose connection may be loose.
The back drain plug is removed.
4
Water hose
Female
threaded
end
Distributed by
C&A Marketing, Inc.
114 Tived Lane East
Edison, NJ 08837 USA
Europe: C&A Europe
167 Hermitage Road
Crusader Industrial Estate
London N4 1LZ
United Kingdom
[email protected]
Made in China
Ivation and the Ivation logo are registered
trademarks of C&A Holdings, LLC in the U.S.
©2017 All rights reserved
