Ivation IVANSICE05 User manual

PORTABLE
ICE MAKER
USER GUIDE
IVANSICE05
Thank you for purchasing the Ivation Portable Ice Maker. This User Guide is intended to
provide you with guidelines to ensure that operation of this product is safe and does not
pose risk to the user. Any use that does not conform to the guidelines described in this
User Guide may void the limited warranty.
Please read all directions before using the product and retain this guide for reference. This
product is intended for household use only.
This product is covered by a limited one-year warranty. Coverage is subject to limits and
exclusions. See warranty for details.
TABLE OF CONTENTS
2 Safety Precautions
3 Box Contents
3 Parts
3 Control Panel
3 Installation
3-4 Operation
4 Care and Maintenance
4-5 Troubleshooting
6 Specifications

Safety Precautions
• Read all safety precautions listed at the beginning of this manual.
• It is recommended to use a dedicated circuit for this ice maker.
• Do not use receptacles that can be turned o by a switch or pull chain.
• Do not connect or disconnect the electric plug with wet hands.
• Never clean the ice maker with flammable liquids. The fumes can create a fire hazard or
explosion risk.
• Do not store gasoline or other flammable vapors/liquids in the vicinity of this or any
other appliance.
• Do not attempt to repair or replace any part of the ice maker unless specifically
recommended by the manufacturer. All other servicing should be referred to a
qualified technician.
• Never install or operate the unit in an enclosed area, such as a closed cabinet. Choose a
well- ventilated area with temperatures between 50°F and 100°F. The unit MUST be
installed in an area protected from the elements, e.g., wind, rain, water spray or drips.
• Do not place the unit next to ovens, grills or other sources of high heat.
• The ice maker must be installed with the electrical in accordance with state and
local code.
• Do not bend or pinch the power supply cord.
• The unit must be on a level surface in order to work properly.
• Check for leaks after water is added.
• Never allow children to operate or play with the ice maker.
• When using the ice maker for the first time (or after a period of inactivity), it is
recommended to discard the first two batches of ice to ensure machine is
thoroughly clean.
• Never tilt the ice maker more than 45 degrees.
• If the ice maker has not been used for a long time, clean thoroughly before use. Follow
instructions provided for cleaning and sanitizing.
• Do not leave any solution inside the unit after cleaning.
• Make sure the plug is accessible after installation.
• Do not use this appliance for anything other than its intended purpose.
• Do not touch the evaporator by hand when the unit is operating.
• Use only drinking water with this product.
• If the supply cord is damaged, it must be replaced by the manufacturer, a service agent
or similarly qualified person in order to avoid a hazard.
• The ice maker is equipped with a 3-prong grounding plug. To minimize possible shock
hazard, the cord must be plugged into a mating 3-pronged and grounding-type wall
receptacle. Do not cut or remove the ground prong. If a mating wall receptacle is not
available, it is the responsibility of the customer to have a properly grounded 3-prong
wall receptacle installed by a certified electrician.
2

Box Contents
Portable ice maker
Ice bucket
Ice scraper
Power cord
User guide
Parts
1. Ice bucket
2. Ice shovel
3. Window
4. Control panel
5. Drain plug
6. Power socket
7. Air outlet
Control Panel
A.Add water indicator
B. Power button
C. Ice full indicator
Installation
Before connecting the power, allow unit to stand upright for at least 24 hours to allow the
refrigerant to settle.
1. Remove all packaging materials before setting up the ice maker.
2. Place the unit on a sturdy and level surface that can support the ice maker’s full weight
with water and ice.
3. This unit must be placed in a well ventilated area with temperature between 50°F and
100°F, with at least 7 inches of space around the back and sides for proper air circulation.
4. Do not place the unit next to ovens, grills or other high heat sources.
NOTE: For the unit’s longevity, it is recommended to use only filtered or purified water. This
will prevent mineral build-up in the unit.
Operation
When using the ice maker for the first time (or after a period of inactivity), it is recommended to
discard the first two batches of ice to ensure machine is thoroughly clean.
1. Connect the ice maker to a grounded outlet.
2. Open the front cover and remove the ice bucket.
3. Pour water into the reservoir. Do not fill past the max capacity mark.
3

4. Replace the ice bucket and close the front cover.
5. Press the power button to the ON position. The “L” light will illuminate, then the ice making
process will begin.
Notes:
• As soon as the ice bucket is full, the ICE FULL indicator on the control panel will illuminate and
the ice maker will stop automatically. Ice production resumes once ice has been removed from
the bucket.
• If there is not enough water in the ice maker, the ADD WATER indicator will illuminate and ice
maker will stop operation. Add more water, then press the power switch to the ON position to
start the machine.
• If any error or failure occurs, the ADD WATER and ICE FULL indicators will flash together and
ice production will stop. Please refer to Troubleshooting page of this user guide.
• Switch o the ice maker and disconnect it from the power supply when not in use.
• If the unit is powered o for any reason, wait at least 5 minutes before powering it back on.
This is to protect the compressor.
Care and Maintenance
Periodic cleaning and proper maintenance will ensure eciency, performance, and extend unit’s
life span.
• Always turn o and disconnect power supply before cleaning.
• Never use solvent-based cleaning agents, which may leave harmful residues.
• DO NOT wash the main unit, instead wipe the exterior with a damp cloth.
• Dry the interior and exterior with a soft cloth.
• Check the drain plug regularly for leaks.
• If there is a strange taste, the ice maker must be cleaned.
• After cleaning, run the ice maker two times before using the ice.
Troubleshooting
If the unit appears to be malfunctioning, wait for the unit to stop automatically. The issue may be
solved by referring to the table below. However, do not open to check or repair the unit unless
instructed to do so.
Note:
The “L” light keeps flash when unit is powered on, this will happen when the compressor is running.
The ice maker has a self-checking feature. Any error will be displayed in the control panel with
“ADD WATER” and “ICE FULL” lights flashing together.
4
Pro
bl
em Poss
ibl
e Causes So
l
ut
i
on
The unit does
not operate. Power is not being supplied. Check your local power source.
A household fuse or
circuit breaker has
been tripped.
The detachable
power cord is not
connected properly.
Make sure the power cord is
connected firmly to the unit
and plugged correctly into
the power outlet.

5
Pro
bl
em Poss
ibl
e Causes So
l
ut
i
on
“Add Water”
indicator
illuminates.
The water reservoir
is almost or
completely empty.
Add water not exceeding
the water full mark and the
ice maker will re-start
automatically.
“Ice Full”
indicator
illuminates.
The ice bucket is
full. Remove ice from ice storage bucket.
Ice cubes stick
together. Ice making cycle is too long. Press the power button to turn o the unit, then press
it again to turn on the unit.
Select the SMALL ice size.
Water temperature
in the water
reservoir is too low.
Replace water in the water
reservoir. Water
temperature between 45°F
and 90°F is recommended.
The ice making
cycle seems
normal but no
ice is made.
Ambient
temperature or
water temperature
in the water
reservoir is too high.
Operate the ice maker in
room temperature below
90°F. Water temperature
between 45°F and 90°F is
recommended.
There is refrigerant
leakage. Call an authorized technician to repair.
Pipe in the cooling
system is blocked. Call an authorized technician to repair.
“Add Water”
and “Ice Full”
indicator are
both blinking.
Ice is stuck in the
ice making box. Press the power button to turn o the unit. Remove the
ice cubes in the ice making
box. Press Power button
again to restart.
Mechanical failure If both indicators remain
blinking after removing ice
cubes and restarting, unplug
the ice maker for 2 minutes
and plug in the unit again.
Components may
be damaged Call an authorized technician to repair.

6
Specifications
Ice making capacity: 22 lbs. / 24h (10kg/24h)
Ice storage: 2 lbs. (900g)
Water tank capacity: 3 pints (1.6L)
Rated voltage/frequency: 115V/60Hz
Rated current: 0.9A
Input power: 120W
Shock protection grade: I
Refrigerant: R600a/26g
Insulation layer: EPS
Machine size: 9.5" x 13.5" x 12" (249 x 345 x 308mm)
Net weight: 22 lbs. (10kg)
Customer Service
[e-mail]
866-849-3049
Distributed by
C&A Marketing, Inc.
114 Tived Lane East
Edison, NJ 08837 USA
Europe: C&A Europe
167 Hermitage Road
Crusader Industrial Estate
London N4 1LZ
United Kingdom
[email protected]
Made in China
Ivation and the Ivation logo are registered
trademarks of C&A Holdings, LLC in the U.S.
©2018 All rights reserved
