Hoshizaki KM-1301SAH-E User manual

ISSUED: October 29, 2008






STACKABLE CRESCENT CUBER
GESTAPELTE EISMASCHINE FÜR SICHELFÖRMIGE EISWÜRFEL
PRODUCTOR DE FORMAS DE HIELO APILADO
DISTRIBUTEUR EMPILE DE CUBELETS EN DEMI-LUNE
CUBETTATRICE A MEZZALUNA IMPILABILE
GESTAPELDE HALVE-MAANVORMIGE IJSMACHINE
FOR QUALIFIED INSTALLER ONLY
NUR FÜR QUALIFIZIERTE INSTALLATEURE
EXCLUSIVAMENTE PARA INSTALADORES AUTORIZADOS
DESTINE UNIQUEMENT A L’INSTALLATEUR QUALIFIE
PER L’USO ESCLUSIVO DA PARTE DI INSTALLATORI ESPERTI
UITSLUITEND VOOR BEVOEGDE INSTALLATEURS


HOSHIZAKI

91A7DG11A

2

5) Check that the refrigerant lines do not rub or touch
lines or other surfaces, and that the fan blade turns
freely.
6) Check that the compressor is snug on all mounting
pads.
7) See the nameplate on the rear panel, and check
that your voltage supplied corresponds with the
voltage specied on the nameplate.
8) Remove the shipping tapes securing the cube
guide.


1. In order to carry out safe and proper
installation of the product, please read this
booklet carefully beforehand and follow the
instructions contained within.
2. On completion of the installation, start the
icemaker to check for any abnormalities,
and instruct the user on how to use and
maintain the icemaker in accordance with the
Instruction Manual.
3. This booklet should be handed over to the
user after the installation and be preserved
by the user together with the Instruction
Manual for any further consultation that may
be necessary.

The installation must be carried out by
qualied personnel, in accordance with current
regulations, according to the manufacturer’s
instructions.


Children should not be allowed in reach of the
packaging elements (plastic bags and expanded
polystyrene) as they are potential sources of
danger.

Remove shipping carton, tape, and packing
material. If packing material is left in the
icemaker, it will not work properly.
Note: This icemaker needs a storage bin. The
recommended storage bin is Hoshizaki Ice
Storage Bin, Model B-800 series.
1) After removing the packing material, make sure
that the icemaker is in good condition. If in doubt,
please do not use the equipment but apply
to professionally qualied personnel. See the
instruction sheet attached to the storage bin for its
unpacking and installation guidelines.
2) Remove the panels to prevent damage when
installing the icemaker. (See "2. How to Remove
Panels.")
3) Remove the package containing the accessories
from the compressor compartment.
4) Remove the protective plastic lm from the panels.
If the icemaker is exposed to the sun or to heat,
remove the lm after the icemaker cools.

a) Front Panel: Remove the two screws. Lift up and
pull towards you.
b) Top Panel: Remove the two screws, and then lift
off.
c) Side Panel (R): Remove the screw. Pull slightly
towards you, and take off.
d) Insulation Panel: Remove the thumbscrew. Lift up
slightly, and pull towards you.

3



1. This icemaker is not intended for outdoor
use. Normal operating ambient temperature
should be within +7°C to +40°C. Normal
operating water temperature should be within
+7°C to +35°C. Operation of the icemaker,
for extended periods, outside of these normal
temperature ranges may affect production
capacity.
2. The icemaker should not be located next to
ovens, grills, or other high heat producing
equipment.
3. The location should provide a rm and level
foundation for the equipment.
4. Allow 15 cm clearance at rear, sides, and
top for proper air circulation and ease of
maintenance and/or service should they be
required.
5. This appliance is not suitable for installation
in an area where a water jet could be used
and where dripping is not allowed.
6. Do not place anything in front of the louver.
7. This icemaker will not work at subfreezing
temperatures. To prevent damage to the
water supply line, drain the icemaker when
air temperature is below zero.

• The installation must be carried out by qualied
personnel, in accordance with current regulations,
according to the manufacturer’s instruction.
• Incorrect installation can cause harm to people,
animals, the icemaker, or the installation location, for
which the manufacturer cannot be held responsible.
1) Unpack the storage bin and attach the four
adjustable legs provided (bin accessory) to the
bottom of the storage bin.
2) Position the storage bin in the selected permanent
location.
3) Place the icemaker on top of the storage bin taking
care not to damage the bin top sealing gasket.
4) Secure the icemaker to the storage bin using the
two mounting brackets and the bolts provided. See
Fig. 2.

Before operating the icemaker, the bin control
thermostat must be installed correctly.
5) Install the bin control thermostat as follows. See
Fig. 3a and 3b.
(a) Remove the bafe from the bin.
(b) Remove the tie securing the bin control
thermostat assembly. Remove the
two thumbscrews.
(c) Remove the bin control thermostat assembly
from the shipping hook by lifting it up and
shifting it to the right. Lower the thermostat
extension bracket (stainless) with the
thermostat bulb attachment and thermostat
bulb through the hole located at the bottom
of the icemaker. Next, lower the thermostat
bracket (plastic) through the hole.


Bin Control
Thermostat
Assembly
Shipping
Hook
Thermostat
Bracket
(plastic)
Tie
Thermostat
Bulb
Attachment
and
Thermostat
Bulb
Thumbscrews
Thermostat
Extension
Bracket
(stainless)
Hole
Wall
Plug
Receptacle
Thumbscrews
Hook
Bushing
Icemaker
Mounting Brackets
Bolts
Bin

4

(d) Make sure the left side and bottom of the
assembly are ush against the wall and base
panel.
(e) Secure the assembly into place with the
thumbscrews (unless you are installing
a second unit). (See "5. Stacking Two
Icemakers.")
(f) Insert the plug into the receptacle on the
assembly until it locks into place.
(g) Remove the two screws from the lower part of
the thermostat bracket (plastic) and use them
to attach the thermostat extension bracket
(stainless) to the thermostat bracket (plastic).
6) Level the icemaker and storage bin in both the
left-to-right and front-to-rear directions. Adjust the
storage bin legs to make the icemaker level.
7) Replace the panels and bafe in their correct
positions (unless you are installing a second unit).
(See "5. Stacking Two Icemakers.")

1) See "4. Installation" for the lower unit installation.
2) Remove the top panel and the top insulation of the
lower unit. The top panel and the top insulation of
the lower unit are not required when installing the
second icemaker.
3) Unpack the second icemaker (upper unit), and
remove the shipping carton, tape, and packing
material.
4) Remove the panels of the second icemaker.
5) Stack the upper unit on top of the lower unit.
6) Secure the upper unit to the lower unit using the
two mounting brackets and the bolts provided.


7) Remove the tie securing the upper unit's bin control
thermostat assembly.
8) Remove the bin control thermostat assembly from
the shipping hook by lifting it up and shifting it to
the right.
9) Remove the thermostat bulb attachment of the
upper unit from the thermostat extension bracket
(stainless).
10) Carefully remove the thermostat bulb from the
thermostat bulb attachment of the upper unit.
11) Carefully route the thermostat bulb and capillary
tubing of the upper unit through the bottom hole of
the upper unit. Remove the bushing from the lower
bin control thermostat assembly. Route the bulb
and tubing through the hole in the assembly and
down into the bin. Reattach the bushing.
12) Secure the lower bin control thermostat assembly
in place with the thumbscrews.
13) Carefully insert the thermostat bulb back into the
thermostat bulb attachment.
14) Secure the thermostat bulb attachment of the upper
unit to the thermostat bulb attachment of the lower
unit with the screws of the upper unit.
15) Insert the plug of the upper unit into the receptacle
of the upper unit's bin control thermostat assembly
until it locks into place.
16) Replace the panels and bafe in their correct
positions.
Thermostat Bracket
(plastic)
Thermostat Extension Bracket
(stainless)
Mounting
Brackets
Bolts
Bin
Icemaker
(Upper
Unit)
Icemaker
(Lower
Unit)
Mounting
Brackets

5

Thermostat
Capillary Tubing
Thermostat Extension
Bracket (stainless)
Thermostat Bulb
Attachment
Removed from
Upper Unit
Thermostat Bulb
Attachment of
Lower Unit Thermostat Bulb




This icemaker requires an earth that meets the
national and local electrical code requirements.
To prevent possible severe electrical shock to
individuals or extensive damage to equipment,
install a proper earth wire to the icemaker. Turn
off the power supply before any maintenance,
repairs, or cleaning is undertaken.
• This icemaker must have a separate power supply
or receptacle of proper capacity. See the nameplate.
It is recommended that this icemaker be the only
electrical device on its power supply circuit.
• Stacked icemakers should each have a separate
receptacle, but they must all be connected in parallel
to the same single phase supply or circuit with
sufcient ampacity.
• The opening for the power supply connection is
22.2 mm diameter to t a conduit.
• If a power cord is used to provide electricity to
the icemaker in place of the permanent (conduit)
connection, a gland should be installed at the
22.2 mm power supply connection. This gland should
be of the correct size for the power supply cord being
installed. The size of the conductors of this power
supply cord should be suitable for the electrical
consumption of this icemaker.
As the colours of the wires in the terminal box of this
appliance may not correspond with eld supplied
wiring or with the markings identifying the terminals in
your power supply receptacle, proceed as follows:
The wire which is coloured Green-and-Yellow must
be connected to the terminal in the receptacle which
is marked with the letter E or by the symbol or
coloured Green or Green-and-Yellow. The wire which
is coloured Blue must be connected to the terminal
which is marked with the letter "N" or coloured Black.
The wire which is coloured Brown must be connected
to the terminal which is marked with the letter L or
coloured Red.
• Usually an electrical permit and services of a licensed
electrician are required.

6




To prevent damage to the pump assembly, do
not operate the icemaker when the water supply
is off, or if the pressure is below .7 bar. Do not
run the icemaker until the proper water pressure
is reached.
• Only potable water should be used for the icemaker
supply.
• Connection to the water services should be done by a
professionally qualied person.
• Water supply inlet is 1/2" female pipe thread (FPT).
• A water supply line shut-off valve and drain valve
should be installed. A ball valve is recommended for
the shut-off valve. A type of valve other than a ball
valve should not have a minimum opening smaller
than the water supply line ID as this can cause a
reduced water ow rate which can lead to poor
harvest performance and/or freeze up. A minimum
of 13 mm OD copper tubing is recommended for the
water supply lines.
• Water supply pressure should be a minimum of .7 bar
and a maximum of 8 bar. If the pressure exceeds 8
bar, the use of a pressure reducing valve is required.
Do NOT throttle back the supply tap.
• Drain outlet for icemaker dump and storage bin is 3/4"
FPT. The drain for condensation is a 10 mm ID pipe.
The icemaker drain and the condenser drain piping
connections must be made separately from the bin
drain. The sump drain should be vented to insure an
adequate ow rate during the harvest cycle. (See
Fig. 6).
• Do NOT use solder type ttings as the application of
heat to the icemaker/bin may result in damage to the
internal connections.
• The drains must have 2 cm fall per 30 cm on
horizontal runs to get a good ow.
• The drains should not be piped directly to the sewer
system. An air gap of a minimum of 5 vertical cm
should be between the end of the drain pipe from
the icemaker or the ice bin and the oor drain. (See
Fig. 6).
• This icemaker should be installed in accordance with
applicable national, provincial, and local regulations.


7



1. This icemaker is designed to produce edible
ice. To keep the icemaker sanitary:
• Wash your hands before removing ice.
• Use the plastic scoop provided (accessory).
• Keep the scoop clean. Clean it by using a
neutral cleaner and rinsing thoroughly.
• The storage bin is for ice use only. Do not
store anything else in the bin.
• Close the door after removing ice to
prevent entrance of dirt, dust, or insects
into the storage bin.
2. The use of any electrical equipment involves
the observance of some fundamental rules.
In particular:
• Instances of high humidity and moisture
increase the risk of electrical short circuits
and potential electrical shocks. If in doubt,
disconnect the icemaker.
• Do not use the icemaker when you have
bare feet.
• Do not pull the power cord in order to
disconnect the icemaker from the feed
network.
• This appliance is not suitable for
unsupervised use by young children or
aged or inrm persons.
3. All parts are factory-adjusted. Improper
adjustments may result in failure.
4. If the unit is turned off, wait for at least
3 minutes before restarting the icemaker to
prevent damage to the compressor.
5. Do not operate the unit in the "WASH"
position without water in the water tank. This
will cause damage to the water pump seal.
1) Open the water supply line shut-off valve.
2) Remove the front panel.
3) Move the control switch, on the control box, to the
"ICE" position.
4) Replace the front panel in its correct position.
5) Turn on the power supply and allow the water
tank to ll with water and the icemaker to operate
for a total of 10 minutes. (See "9. Operation" for
Sequence of Operation).
6) Check the water supply and drain connections for
water leaks.
7) Turn off the power supply, and remove the front
panel.
8) Remove the insulation panel. Remove the cap
located on the front bottom part of the ice dropping
hole. Drain the water tank to ush any loose debris.
See Fig. 7.

9) Replace the cap, insulation panel, and front panel
in their correct positions.
10) Clean the storage bin.
11) Turn on the power supply, and start the automatic
icemaking process.
12) Wait until a complete icemaking and harvest cycle
is completed.

1) With the front panel in place, remove the
thumbscrews along the upper edge of the storage
bin ice deector and allow it to pivot on the side
xings.
2) Hold some ice against the bin control bulb. The
icemaker should stop within 10 seconds.
3) Replace the thumbscrews and close the bin door.
4) Check that the icemaker re-starts.

8


The steps in the start-up/operation sequence are as
follows:
1) 1 Minute Fill Cycle
The unit always starts in the 1 minute ll cycle.
When power is applied to the unit, the water valve is
energized and the ll period begins. After 1 minute
the board checks for a closed oat switch. If the
oat switch is closed the harvest cycle begins. If
not, the unit will not start without adequate water in
the sump. This serves as a low water safety shut
off. The water valve will remain energized through
additional 1 minute cycles until sufcient water
enters the sump and the oat switch closes.
2) 1st Harvest Cycle
The compressor starts, hot gas valve opens, water
valve remains open, and harvest begins. As the
evaporator warms, the thermistor located on the
suction line checks for a 9°C temperature. When
9°C is reached, the harvest is turned over to the
adjustable control board harvest timer which is
factory set for normal conditions. This adjustment
can vary the harvest timer from 1 to 3 minutes. The
water valve closes and the pump motor runs for the
last 50 seconds of harvest.
3) Freeze Cycle
After the timer terminates the harvest cycle, the hot
gas valve closes, and the freeze cycle starts. For
the rst 5 minutes the control board will not accept a
signal from the oat switch. This 5 minute minimum
freeze acts as a short cycle protection. At the end of
5 minutes the oat switch assumes control. As ice
builds on the evaporator the water level in the sump
lowers. The freeze continues until the oat switch
opens and terminates ice production.
4) Harvest Pump Out
When the oat switch opens and signals the
completion of the freeze cycle, the harvest
cycle begins. The hot gas valve opens and the
compressor continues to run. The pump-out timer
starts counting the 10/20 second pump out.
The water pump stops for 15 seconds and reverses,
taking water from the bottom of the sump and
forcing pressure against the check valve seat
allowing water to go through the check valve and
down the drain. At the same time water ows
through the small tube to power ush the oat
switch. When the pump-out timer stops counting, the
pump-out is complete.
The control board allows for adjustment of pump-out
to occur every cycle, or every 2nd, 5th or 10th cycle.
5) Normal Harvest Cycle
The water valve opens to allow water to assist the
harvest. As the evaporator warms, the thermistor
reaches 9°C. The control board receives the
thermistor signal and starts the harvest timer. The
water valve closes and the pump motor runs for
the last 50 seconds of harvest. When the harvest
timer completes its countdown, the harvest cycle is
complete and the next freeze cycle starts.
The unit continues through 3), 4) and 5) sequence
until the bin control senses ice and shuts the unit
down.
Note: If the icemaker does not start or complete
a cycle of operation, contact your nearest
Hoshizaki Distributor for guidance.

9


1) Is the icemaker level?
2) Is the icemaker in a site where the ambient
temperature is within +7°C to +40°C all year
around?
3) Is there at least a 15 cm clearance around the
icemaker for maintenance or service?
4) Have the shipping carton, tape, and packing
material been removed from the icemaker? Are
the cube guides in their correct position? Are the
separators properly attached to their holding clips?
See Fig. 7.
5) Have all electrical and piping connections been
made?
6) Has the power supply voltage been checked or
tested against the nameplate rating? And has a
proper earth been installed in the icemaker?
7) Are the water supply line shut-off valve and drain
valve installed? Has the water supply pressure
been checked to ensure a minimum of .7 bar and a
maximum of 8 bar?
Note: The icemaker may stop running when
the water supply is off, or if the pressure
is below .7 bar. When the proper water
pressure is reached, the icemaker
automatically starts running again.
8) Have the compressor hold-down bolts and
refrigerant lines been checked against vibration
and possible failure?
9) Has the bin control switch been checked for correct
operation?
10) Has the end user been given the instruction
manual, and instructed on how to operate the
icemaker and the importance of the recommended
periodic maintenance?
11) Has the end user been given the name and
telephone number of an authorized service agent?
12) Ensure all components, fasteners, and
thumbscrews are securely in place after
installation. Make sure that none have fallen into
the storage bin.

10

3) Die Packung mit dem Zubehör aus dem
Kompressorfach herausnehmen.
4) Die Kunststoffschutzfolie von der Maschine
abziehen. Wenn die Eismaschine Sonne
oder Wärme ausgesetzt ist, ist die Folie erst
abzuziehen, nachdem die Eismaschine abgekühlt
ist.
5) Überprüfen Sie, daß die Kühlmittelleitungen
nicht gegen andere Leitungen oder Oberächen
reiben oder diese berühren und daß sich der
Gebläseügel frei drehen kann.
6) Überprüfen Sie, daß der Kompressor fest auf den
Unterlagen sitzt.
7) Auf dem Typenschild auf der Rückseite überprüfen,
ob Ihre Netzspannung der Spannung entspricht,
die auf dem Typenschild angegeben ist.
8) Das Band abnehmen, mit dem die Würfelführung
für den Versand gesichert wird.



1. Damit das Gerät sicher und korrekt installiert
wird, ist zuerst dieses Handbuch sorgfältig
durchzulesen, und die darin enthaltenen
Anweisungen sind zu befolgen.
2. Im Anschluß an die Installation ist die
Eismaschine einzuschalten, um sie auf
Unregelmäßigkeiten beim Betrieb zu
überprüfen, und der Benutzer ist darin
zu unterweisen, wie die Eismaschine
entsprechend der Bedienungsanleitung zu
benutzen und instandzuhalten ist.
3. Dieses Handbuch ist dem Benutzer
nach der Installation zu übergeben und
ist vom Benutzer zusammen mit der
Bedienungsanleitung aufzubewahren, damit
beides bei Bedarf zu Rate gezogen werden
kann.

Die Installation ist von qualiziertem Personal
entsprechend den aktuellen Bestimmungen und
den Anweisungen des Herstellers auszuführen.


Kindern sollten keinen Zugang zum
Verpackungsmaterial (Kunststoffbeutel und
Polystyrol) haben, da dieses eine mögliche
Gefahrenquelle darstellt.

Versandkarton, Band und anderes
Verpackungsmaterial abnehmen. Wenn
Verpackungsmaterial in der Eismaschine
gelassen wird, arbeitet diese nicht richtig.
Anmerkung: Diese Eismaschine benötigt einen
Vorratsbehälter. Der empfohlene
Vorratsbehälter ist der HOSHIZAKI -
EISVORRATSBEHÄLTER, Modell Serie
B-800.
1) Nach Entfernung des Verpackungsmaterials
sollten Sie überprüfen, daß die Eismaschine in
gutem Zustand ist. Im Zweifelsfall sollten Sie das
Gerät nicht in Gebrauch nehmen, sondern sich an
qualizierte Fachkräfte wenden. Die Hinweise für
das Auspacken und die Installation nden sich im
Anleitungsblatt, das dem Vorratsbehälter beiliegt.
2) Die Platten abnehmen, um eine Beschädigung
während der Installation der Eismaschine
zu verhindern. (Siehe "2. ABNAHME DER
PLATTEN".)

a) Frontplatte: Die beiden Schrauben entfernen.
Anheben und nach vorne abziehen.
b) Obere Platte: Die beiden Schrauben entfernen,
dann abnehmen.
c) Seitenplatte (R): Die Schraube entfernen. Etwas
nach vorne ziehen und dann abnehmen.
d) Isolierplatte: Die Flügelschraube entfernen. Leicht
anheben und nach vorne abziehen.
