Programat®P710
Short Instructions | Kurzanleitung | Mode d’emploi : l’essentiel
Istruzioni d’uso – versione ridotta | Guía rápida | Guia Rápido

Dear Customer
Thank you for having purchased the Programat®P710. In order to render the setting-up and the initial use of the furnace as easy as
possible, we have prepared these short instructions.
These short instructions replace by no means the detailed Operating Instructions. We therefore kindly ask
you to thoroughly read the Operating Instructions and follow the notes contained therein.
Enjoy working with the Programat P710.
english
Programat®P710
Short Instructions

1 1
2
3
1 2
4
5
A
C
E
B
D
F
1. Installation
Remove the furnace components from their packaging and place the
unit on a suitable table. Please observe the instructions on the outer
packaging. Make sure the voltage indicated on the rating plate com-
plies with the local power supply. If this is not the case, the furnace
must not be connected.
AMounting the cooling tray
Remove both screws for the cooling tray (1) and the transport protection of
the infrared camera.
BPlace the cooling tray (2) on the frame plate (3).
Make sure that the cooling tray is correctly positioned on the
frame plate.
CSecure the cooling tray with the two screws (1).
DPlacing the firing plate
The firing plate (4) can now be placed on the firing plate holder (5).
EMounting the furnace head
The furnace head is best mounted with the back of the furnace pointing
towards the user. Lift the furnace head with both hands as shown in the
picture and place it on the furnace head mounting.
Mount the furnace head as shown in the picture until you feel
it click into place. Make sure that neither the firing plate nor the
insulation is damaged during the mounting of the furnace head.
F
1 1

1
2
76
8
9
10
12
11 14
13
G
I
K
H
J
Establishing the connections
Connect the cables of the furnace head with the furnace base.
Proceed as follows:
- Connect vacuum hose (6).
- Insert the thermocouple plug (7). (Make sure that the polarity of
the plug is correct.)
- Insert the heater plug (8).
Insert the heater plug into the specified connector. Secure the heater plug by
rotating it by 45°.
Closing the protective cover
When all cables are correctly connected to the base, close the
cover (9) to protect the connections until you feel it click into place.
Mounting the connection cover
The connection cover (10) can now be mounted and secured with the
screws.
The furnace may only be used with the protective cover closed
and the connection cover mounted!
Establishing additional connections
Power connection
Make sure that the voltage indicated on the rating plate complies with the
local power supply. Subsequently, connect the power cord (11) with the
power socket of the Programat (12).
Connecting the vacuum pump
Connect the vacuum pump plug (13) with the vacuum pump socket (14). We
recommend using only the VP4 vacuum pump from Ivoclar Vivadent, since
this pump is especially coordinated with the furnace. If other pumps are used,
please observe and do not exceed the indicated maximum power consumption.
G
H
I
J
K
english

2. User interface
The Programat P710 has a wide-screen colour display. The keypad and the touch
screen allow user-friendly handling. By tapping slightly with your fingertips
on the touch screen, the buttons are activated and the furnace performs the
requested function.
Keypad:
Home
Returning to “Home” screen (main menu)
Power-saving key
This key activates the power-saving function.
Open furnace head
Close furnace head
START (Start LED)
Starts the selected program. The green LED indicates that a
program is running. If the program is paused (1 x STOP), the
Start LED flashes until renewed pressing of START results in the
program being resumed.
STOP
A running program can be paused by pressing the STOP key and
terminated by pressing the key twice. Movement of the furnace
head can be stopped at any time by pressing STOP. Acoustic
signals can be turned off by pressing the STOP key.
Program key
Pressing once: The currently selected program is
displayed.
Pressing twice:
The program selection via number entry is accessed.
IRT key
With this key, the infrared image of the object can be
displayed during the closing process.
Digital Shade Assistant key
With this key, the Digital Shade Assistant (DSA) can be
started and closed.
Phone key
– If the furnace is not yet connected to a mobile phone,
pressing this key results in the Bluetooth settings being
displayed.
– If the furnace is already connected to a mobile phone,
pressing this key results in the mobile phone menu being
displayed.
– During an active phone call, this key can be used to fade
the mobile phone screen in or out.

3. Operation
Turning the furnace on
Connect the power cord with the wall socket.
Switch the On/Off button to position «I».
After the self-test, the display shows the home screen. All functions of the Programat can
be selected from this screen. Click the HOME key in order to return to the home screen.
Selecting program sections
The furnace comprises multiple program sections
a. Programs for Ivoclar Vivadent materials
b. 500 individually programmable programs
Selecting the program group
The program sections are divided into program groups.
Each program group comprises 20 programs.
Selecting the program
Select the required program.
Loading the furnace
Open the furnace head by pressing the OPEN FURNACE HEAD key and
place the object to be fired with the firing tray in the furnace.
Programat Infrared Technology: Please read Chapter 6.3 of the Operating
Instructions carefully before using the furnace for the first time. The notes
regarding the Programat Infrared Technology must be observed!
Starting the program
Press the START key to start the program. The LED lights up green. You can see the progress in the firing curve. At the end of the program, the furnace
head opens automatically. As soon as the OSD lights up green, the furnace is available for the next program start.
A
A
B
C
D
E
english
BC
E
D
Program key
Pressing once: The currently selected program is
displayed.
Pressing twice:
The program selection via number entry is accessed.
IRT key
With this key, the infrared image of the object can be
displayed during the closing process.
Digital Shade Assistant key
With this key, the Digital Shade Assistant (DSA) can be
started and closed.
Phone key
– If the furnace is not yet connected to a mobile phone,
pressing this key results in the Bluetooth settings being
displayed.
– If the furnace is already connected to a mobile phone,
pressing this key results in the mobile phone menu being
displayed.
– During an active phone call, this key can be used to fade
the mobile phone screen in or out.

A
A
B
B
4. Editing the firing parameters
Parameters are set or edited in two steps.
Example: Setting the holding temperature
Press the [T] button.
Enter the desired holding temperature and confirm
by pressing the green button.
The holding temperature has been changed successfully. All parameters
shown in the firing curve can be changed / edited the same way.
Changing program options
By pressing the [Options] button, the menu for additional program options
opens.
Example: Open the write-protection program
Press the [Options] button.
Edit the desired option and return to the program view
by pressing the [Close] button.
By pressing the [Arrow] buttons, you can change between the individual
option pages.
Please refer to the Operating Instructions for more
detailed information.
A
A
B
B

Programat®P710
Kurzanleitung
deutsch
Sehr geehrter Kunde
Es freut uns, dass Sie sich für den Kauf des Programat®P710 entschieden haben. Um Ihnen die Inbetriebnahme und die erste Anwendung des Gerätes so
einfach wie möglich zu gestalten, haben wir diese Kurzanleitung verfasst.
Diese Kurzanleitung ersetzt keinesfalls die umfassende Bedienungsanleitung.
Wir bitten Sie daher, auch die Bedienungsanleitung genau durchzulesen und die Hinweise zu beachten.
Wir wünschen Ihnen viel Freude und Erfolg mit dem Gerät.

2
3
1 2
4
5
A
C
E
B
D
F
1. Installation
Gerätekomponenten aus der Verpackung nehmen und das Gerät auf
einen geeigneten Tisch stellen. Bitte beachten Sie die Anleitung auf
der Aussenverpackung. Prüfen Sie, ob die angegebene Spannung des
Typenschilds mit der vorhandenen Netzspannung übereinstimmt. Ist dies
nicht der Fall, darf das
Gerät nicht angeschlossen werden!
Montage der Brenngut-Ablageplatte
Entfernen Sie die zwei Befestigungsschrauben für die
Brenngutablageplatte (1) und den Transportschutz der Infrarotkamera.
Legen Sie nun die Brenngut-Ablageplatte (2) auf die Rahmenplatte (3).
Achten Sie dabei, dass die Brenngut-Ablageplatte korrekt auf der
Rahmenplatte aufliegt.
Sichern Sie nun die Brenngut-Ablageplatte mit den zwei Befestigungs-
schrauben (1).
Brenntisch auflegen
Der Brenntisch (4) kann nun auf die Brenntisch-Aufnahme (5) aufgelegt
werden.
Ofenkopf montieren
Der Ofenkopf kann am einfachsten montiert werden, wenn das Ofen-
Hinterteil zum Anwender zeigt. Heben Sie den Ofenkopf mit beiden Händen
wie auf dem Bild ersichtlich und setzen Sie ihn auf die Ofenkopfhalterung.
Die Ofenkopfhalterung wie auf dem Bild ersichtlich aufsetzen bis der
Ofenkopf spürbar einrastet. Achten Sie darauf, dass der Brenntisch
bzw. die Isolation durch die Ofenkopfmontage nicht beschädigt wird.
A
B
C
D
E
F
1 1
