Ivy Biomedical Systems 7600 User manual

Part No. 2718-55-16
OPERATION MANUAL
© 2017 IVY Biomedical Systems Inc. All Rights Reserved.
Part No. 3232-00-16 Rev.12 EN
Cardiac Trigger Monitor
Model 7600/7800
Model 7800 shown

TABLE OF CONTENTS
Model 7600/7800 Operation Manual i
TABLE OF CONTENTS
1.0 USER RESPONSIBILITY ..........................................................................................................................1
2.0 MANUAL REVISION HISTORY ..............................................................................................................2
3.0 WARRANTY................................................................................................................................................3
4.0 INTRODUCTION ........................................................................................................................................4
5.0 SAFETY ........................................................................................................................................................5
5.1 Electrical .........................................................................................................................................5
5.2 Explosion.........................................................................................................................................6
5.3 Patient Connections........................................................................................................................6
5.4 MRI..................................................................................................................................................7
5.5 Pacemakers.....................................................................................................................................7
5.6 Electrosurgery Protection..............................................................................................................7
5.7 Defibrillation Protection................................................................................................................7
5.8 Signal Amplitude............................................................................................................................7
5.9 EMC ................................................................................................................................................7
5.10 Accessories ......................................................................................................................................8
5.11 Description of Symbols Used.......................................................................................................11
6.0 MONITOR DESCRIPTION......................................................................................................................12
6.1 Intended Use .................................................................................................................................13
6.2 Patient Population........................................................................................................................13
6.3 Contraindications.........................................................................................................................13
6.4 Classification (in accordance with ANSI/AAMI ES60601-1:2005)..........................................13
6.5 Controls and Indicators ...............................................................................................................14
6.6 Display...........................................................................................................................................15
6.7 Alarm Messages............................................................................................................................15
6.8 Programmable Touch Keys.........................................................................................................15
6.9 Menu Structure.............................................................................................................................16
6.10 Rear Panel.....................................................................................................................................17
6.11 Fuse Ratings..................................................................................................................................17
6.12 Rear Panel Description ................................................................................................................18
7.0 MONITOR SETUP ....................................................................................................................................19
7.1 Monitor Installation.....................................................................................................................19
7.2 To Set Up the Instrument for Operation....................................................................................19
7.3 Setting the Date and Time ...........................................................................................................20
7.4 Setting the QRS and Alarm Volume...........................................................................................20
7.5 Setting the Alarm Limits..............................................................................................................20
7.6 Setting the Trace Speed ...............................................................................................................20
7.7 Default Settings.............................................................................................................................21
8.0 SYNCHRONIZED OUTPUT (TRIGGER)..............................................................................................22
8.1 The Synch Pulse............................................................................................................................22
8.2 Trigger Mark................................................................................................................................22
8.3 Polarity Lock (P-Lock) ................................................................................................................22

TABLE OF CONTENTS
ii Model 7600/7800 Operation Manual
9.0 ECG MONITORING.................................................................................................................................23
9.1 Safety Considerations...................................................................................................................23
9.2 Patient Connections......................................................................................................................24
9.3 ECG Electrodes ............................................................................................................................25
9.4 Impedance Measurement (Model 7800 Only)............................................................................26
9.5 ECG Waveform Amplitude (Size)...............................................................................................27
9.6 ECG Notch Filter..........................................................................................................................27
9.7 Lead Selection...............................................................................................................................28
9.8 Low Signal Message.....................................................................................................................29
9.9 Pacemaker.....................................................................................................................................29
9.10 Alarm Limits.................................................................................................................................30
10.0 SYSTEM INTERLOCK OPERATION .................................................................................................31
10.1 X-Ray Status Messages (Model 7800 Only)................................................................................31
11.0 ECG DATA STORAGE AND TRANSFER...........................................................................................32
11.1 ECG Data Transfer Using the USB Port (Model 7800 Only)...................................................32
11.2 USB Port........................................................................................................................................32
12.0 RECORDER OPERATION ...................................................................................................................33
12.1 Changing Paper............................................................................................................................33
12.2 Recorder Modes............................................................................................................................34
12.3 Recorder Speed.............................................................................................................................35
12.4 Sample Printouts ..........................................................................................................................35
13.0 ALARM MESSAGES ..............................................................................................................................36
13.1 Reminder Signals..........................................................................................................................36
13.2 Patient Alarms..............................................................................................................................36
13.3 Technical Alarms..........................................................................................................................37
13.4 Informatory Messages..................................................................................................................37
14.0 MONITOR TESTING..............................................................................................................................38
14.1 Internal Test..................................................................................................................................38
14.2 ECG Simulator.............................................................................................................................38
15.0 TROUBLESHOOTING...........................................................................................................................40
16.0 MAINTENANCE AND CLEANING......................................................................................................41
16.1 The Monitor..................................................................................................................................41
16.2 Patient Cables...............................................................................................................................41
16.3 Preventive Maintenance...............................................................................................................41
17.0 ACCESSORIES........................................................................................................................................42
18.0 DISPOSAL ................................................................................................................................................43
18.1 WEEE Directive 2012/19/EU.......................................................................................................43
18.2 RoHS Directive 2011/65/EU.........................................................................................................43
18.3 Standard of the Electronics Industry of the People’s Republic of China SJ/T11363-2006....43
19.0 SPECIFICATIONS ..................................................................................................................................44

USER RESPONSIBILITY
Model 7600/7800 Operation Manual 1
1.0 USER RESPONSIBILITY
This product will perform in conformity with the description contained in this Operation Manual and accompanying
labels and/or inserts, when assembled, operated, maintained and repaired in accordance with the instructions
provided. This product must be checked periodically. A defective Product should not be used. Parts that are broken,
missing, plainly worn, distorted or contaminated should be replaced immediately. Should such repair or replacement
become necessary, Ivy Biomedical Systems, Inc. recommends that a telephone call or written request for service
advice be made to Ivy Biomedical Systems, Inc.’s Service Department. This product or any of its parts should not be
repaired other than in accordance with instructions provided by Ivy Biomedical Systems, Inc.’s trained personnel.
The product must not be altered without the prior written approval of Ivy Biomedical Systems, Inc.’s Quality
Assurance Department. The user of this Product shall have the sole responsibility for any malfunction which results
from improper use, faulty maintenance, improper repair, damage or alteration by anyone other than Ivy Biomedical
Systems, Inc.
CAUTION: US Federal law restricts this device to sale by or on the order of a licensed medical practitioner.
Ivy Biomedical Systems, Inc.
11 Business Park Drive
Branford, Connecticut 06405 USA
[phone] [phone] FAX [phone]
www.ivybiomedical.com e-mail: [e-mail]

MANUAL REVISION HISTORY
_____________________________________________________________________________
2 Model 7600/7800 Operation Manual
2.0 MANUAL REVISION HISTORY
Revision
Date
Description
00
August 11, 2011
Initial Release of Model 7600 Operation Manual
01
March 13, 2012
Changed title to Model 7600/7800 Operation Manual.
Added model 7800 description, specifications etc. to
Operation Manual.
02
May 7, 2012
Revised Operation Manual to comply with IEC 60601-1 3rd
edition.
03
June 4, 2012
Added Patient Population and Contraindications statements
to Monitor Description section of the Operation Manual.
04
June 5, 2012
Revised Power/Standby symbol and added IPX1 statement.
05
September 28, 2012
Added warning statement regarding reducing the
possibility of a tripping hazard to the Monitor Setup section
of the Operation Manual.
06
January 31, 2013
Increased Operating Environment and Storage
Environment Temperature Range.
07
November 20, 2013
Updated China RoHS table and Warning and Caution
symbols.
08
December 9, 2013
Corrected typographical errors in sections 7.3 and 7.4.
09
March 9, 2015
Updated EMC Guidance and Manufacturer’s Declaration
on pages 8, 9 and 10. Added EAC symbol to User
Responsibility section on page 1. Updated all references to
WEEE Directive to 2012/19/EU. Revised all references to
fuse rating and type to T .5A, 250V.
10
September 2, 2015
Revised all references to fuse rating and type to T 0.5AL,
250V.
11
June 8, 2016
Revised sections 6.10 and 6.12.
12
March 1, 2017
Revised section 19.0 to include additional regulatory
standards.

WARRANTY
Model 7600/7800 Operation Manual 3
3.0 WARRANTY
All products manufactured by Ivy Biomedical Systems, Inc. under normal use, are warranted to be free from defects
in material and workmanship and to operate within published specifications, for a period of 13 months from date of
original shipment.
All accessories such as patient cables and lead wires, supplied by Ivy Biomedical Systems, Inc. under normal use,
are warranted to be free from defects in material and workmanship and to operate within published specifications, for
a period of 90 days from date of original shipment.
If an examination by Ivy Biomedical Systems, Inc. discloses such product(s) or component part(s) to have been
defective, then Ivy’s obligation is limited at Ivy’s option, to repair or replacement.
When a product or products need to be returned to the manufacturer for repair or examination, contact service
personnel at Ivy Biomedical Systems to obtain a Return Material Authorization number (RMA #) and the correct
packing instructions:
Service / Tech Support:
Telephone: [phone] or [phone]
Fax: [phone]
E-mail: [e-mail]
All products being returned for warranty repair shall be shipped prepaid to:
Ivy Biomedical Systems, Inc
Attn: Service Department
11 Business Park Drive
Branford, CT 06405 USA
Ivy will send the shipment of the repaired or replacement product to customer at Ivy’s expense.

INTRODUCTION
4 Model 7600/7800 Operation Manual
4.0 INTRODUCTION
This manual provides information on the correct use of the Model 7600/7800 Cardiac Trigger monitor. It is up to the
user to ensure that any applicable regulations regarding the installation and operation of the monitor are observed.
The Model 7600/7800 is ME EQUIPMENT (Medical Electrical Equipment) that is intended to monitor patients
under medical supervision. The Model 7600/7800 monitor must be operated by trained and qualified medical
personnel only.
Using This Manual
We recommend that you read this manual before operating the equipment. This manual is written to include all
options. If your monitor does not include all options, menu selections and display data for those options will not
appear on your monitor.
Use the Monitor Description section for general descriptions of controls and displays. For details on the use of each
option, refer to the section of the manual dealing with the appropriate option.
Boldface type is used in text to refer to the labeling on user controls. Brackets [ ] surround menu selections used
with the programmable touch keys.
Manufacturer’s Responsibility
The manufacturer of this equipment is responsible for the effects on safety, reliability, and performance of the
equipment only if:
•Assembly operations, extensions, re-adjustments, or repairs are carried out by persons authorized by the
manufacturer
•The electrical installation complies with all applicable regulations
•The equipment is used in accordance with the instructions in this manual
Incorrect operation or failure of the user to maintain the monitor in accordance with proper maintenance procedures
relieves the manufacturer or his agent from all responsibility for consequent non-compliance, damage, or injury.
Ivy Biomedical Systems, Inc.
11 Business Park Drive
Branford, Connecticut 06405
[phone] or [phone]
Fax [phone]
E-mail: [e-mail]
This manual explains how to set up and use the Model 7600/7800. Important safety information is located
throughout the manual where appropriate. READ THE ENTIRE SAFETY INFORMATION SECTION BEFORE
YOU OPERATE THE MONITOR.

SAFETY
Model 7600/7800 Operation Manual 5
5.0 SAFETY
5.1 Electrical
This product is intended to be operated from a mains power source of 100-120V~ or 200-230V~, 50/60 Hz and a
maximum ac power consumption of 45VA.
WARNING: To avoid risk of electric shock, this equipment must only be connected to a supply mains with
protective earth. Connect the monitor only to a three-wire, grounded, hospital grade receptacle. The three-conductor
plug must be inserted into a properly wired three-wire receptacle; if a three-wire receptacle is not available, a
qualified electrician must install one in accordance with the governing electric code.
WARNING: Do not under any circumstances remove grounding conductor from the power plug.
WARNING: The power cable supplied with this equipment provides for this protection. Do not attempt to
defeat this protection by modifying the cable or by using ungrounded adapters or extension cables. The power cord
and plug must be intact and undamaged. To disconnect the equipment from the mains power; unplug the power
cord.
WARNING: Do not connect to an electrical outlet controlled by a wall switch or dimmer.
WARNING: If there is any doubt about the integrity of the protective ground conductor arrangement, do not
operate the monitor until the ac power source protective conductor is fully functional.
WARNING: For power interruptions exceeding 30 seconds, the monitor must be turned on manually by
pressing the Power On/Standby switch. When monitor power is restored, the monitor will return to manufacturer's
DEFAULT settings. (An option is available which will allow monitor to use the last used or STORED settings.)
WARNING: To avoid unacceptable RISK caused by power interruptions, connect the monitor to an
appropriate medical-grade uninterruptable power source (UPS).
WARNING: Do not place the monitor in any position that may cause it to fall on the patient. Do not lift the
monitor by the power supply cord or patient cable.
WARNING: Carefully route monitor cables (patient cables, power cords, etc.) to reduce the possibility of a
tripping hazard.
WARNING: Do not position the monitor in a way that would cause difficulty to the operator to disconnect it
from the power source.
WARNING: Electric shock hazard! Do not remove covers or panels. Refer service to trained and
qualified service personnel.

SAFETY
6 Model 7600/7800 Operation Manual
WARNING: Disconnect the monitor from its power source when serviced. Refer service to trained and
qualified service personnel.
WARNING: All replaceable parts should be replaced by trained and qualified service personnel.
WARNING: To avoid electrical shock, disconnect the monitor from its power source before changing fuses.
Replace fuse only with same rating and type: T 0.5AL, 250V.
WARNING: Do not clean monitor while it is plugged into a power source.
WARNING: If unit is accidentally wet, immediately disconnect the monitor from its power source.
Discontinue use until dry and then test unit for proper operation before reuse on a patient.
WARNING: This unit uses a common isolation path for the ECG leads and Electrodes. Do not allow the
ECG leads and/or Electrodes to come in contact with other conductive parts including earth ground. Do not connect
any non-isolated accessories to the ECG input when connected to a patient, as this may compromise the safety of the
unit. When attached to other devices, ensure that the total chassis leakage currents of all units do not exceed 300
μA.
WARNING: The synchronized output pulse is not designed to synchronize a defibrillator discharge or a
cardioversion procedure.
WARNING: To ensure proper monitor ventilation, do not use the monitor without the bottom cover feet or
the optional bottom cover mounting plate.
WARNING: Do not modify this equipment without authorization of the manufacturer.
5.2 Explosion
WARNING: Explosion hazard! Do not use this equipment in the presence of flammable anesthetics or
other flammable substance in combination with air, oxygen-enriched environment or nitrous oxide.
5.3 Patient Connections
Patient connections are electrically isolated. For all connections use isolated probes. Don’t let patient connections
contact other conductive parts, including earth ground. See instructions for patient connections in this manual.
Carefully route patient cables to reduce the possibility of patient entanglement or strangulation.
Leakage current is limited internally by this monitor to less than 10 μA. However, always consider cumulative
leakage current that can be caused by other equipment used on the patient at the same time as this monitor.
To ensure that the leakage current protection remains within the specifications, use only the patient cables specified
in this manual. This monitor is supplied with protected lead wires. Do not use cables and leads with unprotected

SAFETY
Model 7600/7800 Operation Manual 7
lead wires having exposed conductors at the cable end. Unprotected lead wires and cables may pose an
unreasonable risk of adverse health consequences or death.
Line isolation monitor transients may resemble actual cardiac waveforms and thus inhibit heart rate alarms. To
minimize this problem, ensure proper electrode placement and cable arrangement.
If an alarm condition occurs while the alarms are set to off, neither visual nor audio alarms will be present.
5.4 MRI
The Model 7600/7800 should not be used within the magnetic field during Magnetic Resonance Imaging.
5.5 Pacemakers
WARNING – PACEMAKER PATIENTS:Rate meters might continue to count the pacemaker rate during
occurrences of cardiac arrest or some arrhythmias. Do not rely entirely on rate meter ALARM SIGNALS. Keep
pacemaker PATIENTS under close surveillance. See the SPECIFICATIONS section in this manual for disclosure of
the pacemaker pulse rejection capabilities of this instrument. AV sequential pacemaker pulse rejection has not been
evaluated; do not rely on pacemaker rejection with patients with dual chamber pacemakers.
5.6 Electrosurgery Protection
This equipment is protected against electrosurgery potentials. To avoid the potential of electrosurgery burns at
monitoring sites, ensure proper connection of the electrosurgery return circuit as described by the manufacturer’s
instructions. If improperly connected, some electrosurgery units might allow energy to return through the ECG
electrodes.
5.7 Defibrillation Protection
This equipment is protected up to 360 J defibrillator discharge.The monitor is internally protected to limit current
through the electrodes to prevent injury to the patient and damage to the equipment as long as the defibrillator is
used in conformance with the manufacturer’s instructions. Use only Ivy specified accessories (see Accessories).
5.8 Signal Amplitude
WARNING: The minimum patient physiological “R-wave” signal amplitude is 0.5 mV.
The use of the Model 7600/7800, below the above amplitude value, may cause inaccurate results.
5.9 EMC
This equipment has been certified to be protected to emissions and immunity according to IEC-60601-1-2.
Electromagnetic Compatibility IEC 60601-1-2:2007
CAUTION: Medical Equipment needs special precautions regarding EMC and needs to be installed and put
into service according to the EMC information provided in the Operation Manual.
CAUTION: Portable and mobile RF communications equipment can affect medical electrical equipment.

SAFETY
8 Model 7600/7800 Operation Manual
WARNING: The Model 7600/7800 should not be used adjacent to or stacked with other equipment.
However, if adjacent or stacked use is necessary, the Model 7600/7800 should be observed to verify normal
operation in the configuration in which it will used.
5.10 Accessories
WARNING: The use of accessories other than those specified below may result in increased emissions or
decreased immunity of the equipment.
Ivy P/N Description
590432 Low Noise, Four Lead ECG Patient Cable, 10 ft. Long, Colors: White, Green, Red, Black
590433 Set of Four Shielded Lead Wires, 24 Inches Long, Colors: White, Green, Red, Black
590435 Set of Four Radiotranslucent Lead Wires, 30 Inches Long, Colors: White, Green, Red, Black
590442 Set of Four Radiotranslucent Lead Wires, 36 Inches Long, Colors: White, Green, Red, Black
590446 Low Noise, Four Lead ECG Patient Cable, 10 ft. Long, IEC Colors: Red, Black, Green, Yellow
590447 Set of Four Shielded Lead Wires, 24 Inches Long, IEC Colors: Red, Black, Green, Yellow
590451 Set of Four Radiotranslucent Lead Wires, 30 Inches Long, IEC Colors: Red, Black, Green, Yellow
590452 Set of Four Radiotranslucent Lead Wires, 36 Inches Long, IEC Colors: Red, Black, Green, Yellow
590436 Radiotranslucent ECG electrodes, Box of 40 (10 pouches of 4 electrodes)
Guidance and manufacturer’s declaration – Electromagnetic emissions
The Model 7600/7800 monitor is intended for use in the electromagnetic environment specified
below. The customer or the user of the Model 7600/7800 should ensure that it is used in such an
environment.
Emissions test
Compliance
Electromagnetic environment - guidance
RF emissions
CISPR 11 Radiated
Group 1
Class B
The Model 7600/7800 uses RF energy only for its
internal function. Therefore, their RF emissions are
very low and are not likely to cause any interference
in nearby electronic equipment.
RF emissions
CISPR 11 Conducted
Class B
The Model 7600/7800 is suitable for use in all
establishments other than domestic and those
directly connected to the public low-voltage power
supply network that supplies buildings used for
domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Class A

SAFETY
Model 7600/7800 Operation Manual 9
Guidance and manufacturer’s declaration – Electromagnetic immunity
The Model 7600/7800 monitor is intended for use in the electromagnetic environment specified
below. The customer or the user of the Model 7600/7800 should ensure that it is used in such an
environment.
Immunity test
IEC 60601 test
level
Compliance level
Electromagnetic environment –
guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8kV air
±9 kV contact
±12kV air
Floors should be wood, concrete,
or ceramic tile. If floors are
covered with synthetic material,
the relative humidity should be at
least 30%.
Electrical fast
Transient/burst
IEC 61000-4-4
±2 kV for power
supply lines
±1 kV for
input/output lines
±3 kV for power
supply lines
±1.5 kV for
input/output lines
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
±1 kV differential
mode
±2 kV common
mode
±1.5 kV
differential mode
±3 kV common
mode
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage dips, short
interruptions, and
voltage variations
on power supply
input lines
IEC61000-4-11
<5 % U
T
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT) for
5 cycles
70 % UT
(30 % dip in UT) for
25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec cycle
<5 % U
T
(>95 % dip in UT)
for 0.5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec cycle
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the Model 7600/7800 requires
continued operation during power
mains interruptions, it is
recommended that the Model
7600/7800 be powered from an
uninterruptible power supply.
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
10 A/m
Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment.

SAFETY
10 Model 7600/7800 Operation Manual
Guidance and manufacturer’s declaration – Electromagnetic immunity
The Model 7600/7800 monitor is intended for use in the electromagnetic environment specified
below. The customer or the user of the Model 7600/7800 should ensure that it is used in such an
environment.
Immunity test
IEC 60601 test
level
Compliance
level
Electromagnetic environment – guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2.5 GHz
5 Vrms
10 V/m
Portable and mobile RF communications
equipment should be used no closer to any
part of the Model 7600/7800, including
cables, than the recommended separation
distance calculated from the equation
applicable to the frequency of the
transmitter.
Recommended separation distance
d= 1.2 p
d= 1.2 p80 MHz to 800 MHz
d= 2.3 p 800 MHz to 2.5 GHz
Where pis the maximum output power
rating of the transmitter in watts (W)
according to the transmitter manufacturer
and dis the recommended separation
distance in meters (m).
Field strengths from fixed RF transmitters,
as determined by an electromagnetic site
survey a, should be less than the compliance
level in each frequency range b
Interference may occur in the vicinity of the
equipment marked with the following
symbol:
NOTE 1 – At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 – These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects, and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile
radios, amateur radios, AM and FM radio broadcast, and TV broadcast cannot be predicted theoretically with accuracy. To
assess the electromagnetic environment due to fixed RF transmitters, and electromagnetic site survey should be considered.
If the measured field strength in the location in which the Model 7600/7800 is used exceeds the applicable RF compliance
level above, the Model 7600/7800 should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as re-orienting or relocating the Model 7600/7800.
b
Over the frequency range 150 KHz to 80 MHz, field strengths should be less than 3 V/m.

SAFETY
Model 7600/7800 Operation Manual 11
5.11 Description of Symbols Used
Consult instructions for use Warning
Type CF Applied Part,
Defibrillator proof Caution
Equipotential ground connector RoHS Compliant
Fuse type / rating Output Signal
Protective earth (Ground) Input Signal
Earth (Ground) Input / Output Signal
Power On/Standby Manufacturer
Date of Manufacture Alarm Mute
WEEE Compliant
∼
Alternating Current
Electric shock hazard: Do not remove covers or panels. Refer service to qualified service personnel.

MONITOR DESCRIPTION
12 Model 7600/7800 Operation Manual
6.0 MONITOR DESCRIPTION
The Model 7600/7800 is an easy-to-use Cardiac Trigger Monitor that features a bright color touch screen LCD
display. The Model 7600/7800 displays two simultaneous ECG vectors and the patient’s heart rate. The Trigger
ECG vector (top ECG waveform) can be selected from Leads I, II III or Auto. The Second ECG vector (bottom
ECG waveform) can be selected from Leads I, II or III. In addition, high and low heart rate alarm limits can be
adjusted to bracket the patient’s heart rate so that a violation of these limits produces an audible and visual
indication of the violation. The Model 7600/7800 color display includes dual ECG traces, large heart rate numbers
and alphanumeric characters for other data, alarm messages, menus and user information.
•The Model 7600/7800 monitor is intended primarily for use on patients in applications requiring precision
R-wave synchronization such as timed imaging studies.
•The Model 7600/7800 includes an AUTO lead select feature (Trigger lead only). When selected, this
feature will determine which lead (I, II or III) provides the best quality ECG signal and, thus, a more
reliable cardiac trigger.
•The Model 7600/7800 has an electrically isolated RS-232 micro-D connector that provides two-way
communications between the monitor and the external console for the transfer of ECG data.
•The Model 7600/7800 is available with different options; not all options are included in all monitors. An
optional integral recorder is available. Set up of recorder functions is made through the monitor touch screen
menus.
•The Model 7600/7800 is suitable for use in presence of electrosurgery.
•The Model 7600/7800 is not intended for use with any other physiological monitoring unit.
•The Model 7600/7800 is restricted to use on one patient at a time.
Model 7800 Only:
•The Model 7800 has special hardware and software that allows for the measurement of skin to electrode
impedance.
•The Model 7800 provides two Ethernet channels from a single RJ45 connector. The first channel provides
two way communications between the monitor and the CT console for the transfer of ECG data, trigger
timing data and the receipt of patient identification information. The second channel provides ECG data to
the CT Gantry display. These functions will only operate when the Model 7800 is electrically connected to
a CT console and CT gantry capable of displaying ECG data.
•The Model 7800 has a USB drive that allows the operator to store and retrieve ECG data on a USB
memory stick device.
•The Model 7800 has an Auxiliary 9-pin D-subminiature connector that provides a customized interface for
specific installations.

MONITOR DESCRIPTION
Model 7600/7800 Operation Manual 13
6.1 Intended Use
The Ivy Biomedical Model 7000 Series Cardiac Trigger Monitors are simple-to-use instruments for monitoring ECG
and Heart Rate. They are designed for use in the ICU, CCU and operating room conditions. They can sound an
alarm when HR falls outside of preset limits. They provide an output pulse, synchronized to the R-wave for use in
applications requiring precision R-wave synchronization.
6.2 Patient Population
The Model 7000 Series Cardiac Trigger Monitor is intended to perform ECG monitoring and R-wave pulse
detection on adult, geriatric, pediatric and neonatal patients. R-Wave synchronization is typically used for gating
nuclear scanners, CT scanners, or other imaging devices.
6.3 Contraindications
The Model 7000 Series is limited to use by trained and qualified medical professionals. This device is not intended
for use as life support equipment or for performing cardiac diagnostics. The product is not intended for use in home
care monitoring or for use in an MRI environment.
6.4 Classification (in accordance with ANSI/AAMI ES60601-1:2005)
Protection against electric shock: Class 1.
Degree of protection against electric shock: Type CF applied part. Defibrillator proof: ECG
Degree of protection against harmful ingress of water: Ordinary Equipment IPX1 per IEC-60529
Methods of Maintenance and Cleaning: See Maintenance and Cleaning section of this manual
Degree of safety of application in the presence of a Equipment not suitable for use in the presence of a
flammable anesthetic mixture with air or oxygen flammable anesthetic mixture
or nitrous oxide:
Mode of operation: Continuous

MONITOR DESCRIPTION
14 Model 7600/7800 Operation Manual
6.5 Controls and Indicators
Basic Keys
When the monitor is plugged into an ac power source, the Power On/Standby switch, when
pressed, provides power to the monitor’s electronic circuits. Press this key again to disconnect
power from the monitor’s electronic circuits.
WARNING: To disconnect the monitor from mains power, unplug the ac power cord.
The Alarm Mute switch disables the audible alarms. Press this key again to return the alarms to
normal function.
Model 7800 shown
Programmable
Touch Keys
4-Lead ECG Simulator
RA, RL, LL, LA
Power On/Standby
Switch (Basic Key)
6-Pin ECG Patient
Cable Connector
Dual, Simultaneous
ECG Waveforms with
Lead Selection
Alarm Mute Switch
(Basic Key)
Mains Power
LED Indicator
Impedance
Readings in kΩ
(Model 7800 Only)
Measure Impedance
Touch Key
(Model 7800 Only)
Heart Rate (BPM)
XRAY Status
(Model 7800 Only)

MONITOR DESCRIPTION
Model 7600/7800 Operation Manual 15
6.6 Display
HEART RATE: Displayed in large numerals in beats per minute (BPM) on the upper part of the screen.
ECG: Dual simultaneous ECG waveforms are displayed across the screen moving from left to right. The trigger
ECG trace is displayed on the top and the second ECG trace is displayed on the bottom.
SETUP: Selections are made through the touch screen menus. Lead selects are displayed to the right of their
respective traces. Filter ON/OFF is displayed on the upper right hand corner of the display. Alarm limits are
displayed directly under the heart rate.
Impedance Measurement (Model 7800 Only): Displays the measured value of the impedance between the
patient’s skin and each individual ECG electrode (RA, LA, LL, RL). Impedance measurements are located at the
upper left hand corner of the display.
XRAY Status (Model 7800 Only): Displays the status of the CT Scanner X-ray. The XRAY status message is
located in the upper left hand corner of the display. Displayed messages are either: XRAY OFF, XRAY ON, or
XRAY DISCONNECT.
6.7 Alarm Messages
ALARM MUTE: A REMINDER SIGNAL indicating that the audible alarms have been turned
off.
Note: ALARM MUTE is equivalent to AUDIO OFF.
The following alarm indications are displayed in reverse video. Alarm indications appear on the center of the screen
and flash once per second.
LEAD OFF: A TECHNICAL ALARM indicating that a lead has become detached. The
LEAD OFF alarm message will appear within 1 second of detection.
CHECK LEAD: A TECHNICAL ALARM indicating that an imbalance between leads has been
detected. The CHECK LEAD alarm message will appear within 1 second of
detection.
HR HIGH: A PATIENT ALARM indicating that the high heart rate limit has been exceeded
for three seconds.
HR LOW: A PATIENT ALARM indicating that the low heart rate limit has been exceeded
for three seconds.
ASYSTOLE: A PATIENT ALARM indicating that the interval between heartbeats has
exceeded six seconds.
WARNING: The monitor powers on with audible alarms paused for 30 seconds. Other configuration options
are available upon request.
6.8 Programmable Touch Keys
Pressing a programmable touch key will display other menu levels or activate an appropriate function. Menu functions
are described in the Menu Structure.

MONITOR DESCRIPTION
16 Model 7600/7800 Operation Manual
6.9 Menu Structure
MEASURE
IMPEDANCE
MAIN MENU:
DISPLAY ECG OPTIONS FREEZE PRINT
MENU MENU MENU DIRECT
TRIGGER SIZE Date/Time QRS VOL
AUTO 10 MM/MV OFF
NEXT
SECOND FILTER
ALARM
VOL
LEAD I ON ↑ MEDIUM
SPEED P-LOCK ↓ REC MODE CLEAR
25 MM/SEC ON DIRECT MEMORY
Alarm
Limits
TEST PACER DET MODE COPY TO
MENU ON LOW ADULT USB DRIVE
MAIN MAIN ↑ MAIN MAIN
MENU MENU MENU MENU
↓
HIGH
SIM RATE ↑ USB
OFF MENU
↓
FINE TUNE
↓
FINE TUNE
↑
INTERNAL
TEST OFF
MAIN
MENU
KEY SELECTIONS
DISPLAY MENU OPTIONS MENU
Trigger: Lead I – II – III – AUTO QRS Volume: Off, Low, High
Second: Lead I – II – III Alarm Volume: Low, Medium, High
Speed: 25mm/s and 50mm/s Recorder Mode: Direct, Timed, Delay
Mode: Adult, Ped/Neo
ECG MENU
Size: 5, 10, 20, 40mm/mV
Filter: On, Off Model 7800 Only Selections:
P-Lock: On, Off Measure Impedance
Pacer Detect: On, Off USB Menu

MONITOR DESCRIPTION
Model 7600/7800 Operation Manual 17
6.10 Rear Panel
Model 7800 shown
6.11 Fuse Ratings
The fuses are located behind the cover of the power entry module. To replace the fuses, unplug the ac power cord.
Remove the power entry module cover and replace the fuse(s) only with same rating and type: T 0.5AL, 250V.
¼” Stereo Jack
ECG OUTPUT
9-Pin micro-D
RS-232
Fuses
(Behind Panel)
PEQ Ground
Power Entry Module
Mains Power Input
Serial Number
Label
RJ45 Connector
ETHERNET
(Model 7800 Only)
BNC Connector
SYNCHRONIZED
OUTPUT
9-pin D-subminiature
AUXILIARY
(Model 7800 Only)
4-Lead ECG Simulator
RA, RL, LL, LA
