iWantit IPBTB16 User manual

instruction manual
IPBTB16
wireless speaker
IPBTB16_IB_160308.indd 1 30/03/2016 14:24

IPBTB16_IB_160308.indd 2 30/03/2016 14:24

Contents
safety warnings........................................................... 4
unpacking .................................................................... 7
product overview ....................................................... 8
main unit............................................................................ 8
- top view .............................................................................8
- side view ............................................................................8
charging the unit........................................................ 9
Bluetooth® operation ..............................................10
disconnect the Bluetooth® ........................................10
general operation.....................................................11
switching the unit on and o ..................................11
pause and resume playback ....................................11
adjusting the volume ..................................................11
skip the track ..................................................................11
receiving and ending calls.........................................12
calling back the last number dialled......................12
AUX IN operation...................................................... 13
maintenance..............................................................13
cleaning the unit...........................................................13
hints and tips.............................................................14
specications.............................................................15
IPBTB16_IB_160308.indd 3 30/03/2016 14:24

4
• Read all the instructions carefully before using the
unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you are in
any doubt about it working normally, or if it is
damaged in any way - switch o and consult your
dealer.
Location of Unit
• The unit must be placed on a at stable surface
and should not be subjected to vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
Temperature
• Avoid extreme degrees of temperature, either hot
or cold. Place the unit well away from heat sources
such as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked ame on
the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects lled with
liquids, such as vases, should be placed on the
unit. Do not operate the unit with wet hands, near
water or other liquid.
• If you spill any liquid into the unit, it can cause
serious damage. Switch it o immediately.
Withdraw the mains plug and consult your dealer.
safety warnings
IPBTB16_IB_160308.indd 4 30/03/2016 14:24

5
Ventilation
• To prevent the risk of electric shock or re hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase,
built-in cabinet or in another conned space.
Ensure the unit is well ventilated.
Safety
• In the interests of safety and to avoid unnecessary
energy consumption, never leave the unit
switched on while unattended for long periods of
time, e.g. overnight, while on holiday or while out
of the house. Switch it o.
Interference
• Do not place the unit on or near appliances which
may cause electromagnetic interference. If you do,
it may adversely aect the operating performance
of the unit, and cause a distorted sound.
Batteries
• Please dispose of batteries correctly by following
the guidance in this manual.
Supervision
• Children should be supervised to ensure that they
do not play with the unit.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a fatal
electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
IPBTB16_IB_160308.indd 5 30/03/2016 14:24

6
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-
serviceable parts. Please leave all maintenance
work to qualied personnel.
• Do not open any xed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from any devide and
switch o before cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
IPBTB16_IB_160308.indd 6 30/03/2016 14:24

7
Thank you for purchasing your new iWantit
wireless speaker.
We recommend that you spend some time reading this
instruction manual in order that you fully understand
all the operational features it oers. You will also nd
some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and
keep this instruction manual for
future reference.
unpacking
Remove all items from the packaging. Retain the
packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
Main Unit
USB cable 3.5 mm to 3.5 mm Stereo
Audio Cable
If items are missing or damaged, please contact
Partmaster (UK only).
Tel: [phone] for assistance.
IPBTB16_IB_160308.indd 7 30/03/2016 14:24

8
product overview
main unit
top view
side view
1. STANDBY Button
2. VOLUME DOWN/SKIP Button
3. VOLUME UP/ SKIP Button
4. PLAY/PAUSE/TALK Button
5. DC-IN 5V 1A Socket
6. AUX IN Socket
1
5
6
24 3
IPBTB16_IB_160308.indd 8 30/03/2016 14:24

9
charging the unit
This Unit has a built-in rechargeable Lithium battery.
• To charge the unit, open the ap then connect
the USB cable to the DC-IN 5V 1A Socket on
the side of the unit and plug into a powered USB
socket e.g. a computer.
• While charging, the battery indicator on the
STANDBY button will light up red.
• When fully charged the indicator will light up
green.
• When the unit is less than 10% battery life, it will
say ‘Battery is low’ every 30 seconds.
• Battery life approx. 10 hours at moderate listening
level.
It takes 4 hours (approx.)
to fully charge the battery.
To Save battery life, please
switch o the unit. Do not
over charge the battery as
it may shorten its life.
IPBTB16_IB_160308.indd 9 30/03/2016 14:24

10
Bluetooth® operation
1. Activate Bluetooth® on the device to be connected
to the unit.
2. Press and hold the STANDBY button to switch
the unit on. It will say “Powering on”and the blue
indicator lights will ash quickly. The unit is now in
pairing mode.
3. “iWantit IPBTB16”will appear on the list of
Bluetooth® devices select this. Type in the
password “0000” if requested. It will say “Paired”
once it has connected. The blue indicator will now
light up.
disconnect the Bluetooth®
1. Press and hold the PLAY/PAUSE/TALK button
to disconnect your unit, will say“Ready to pair”
If you are trying to pair your speaker to a mobile device
and your mobile device shows the message ‘Failed to
connect and password is incorrect’, then switch the
unit o, wait 1 minute then switch the unit back on. Try
pairing again.
IPBTB16_IB_160308.indd 10 30/03/2016 14:24

11
general operation
switching the unit on and o
• To turn on the unit, press and hold the STANDBY
button for 3 seconds. The unit will say “ Powering
ON” and the blue indicator lights will ash.
• To turn o the unit, press and hold the STANDBY
button for 5 seconds. The unit will say “Powering
o”The blue indicator lights will switch o.
pause and resume playback
• In Bluetooth® mode, press the PLAY/PAUSE/TALK
Button on the top surface of unit to pause
playback. Press the PLAY/PAUSE/TALK Button
on the top surface of unit to resume playback.
adjusting the volume
• Press the VOLUME DOWN/SKIP or VOLUME UP/
SKIP Button to decrease or increase the volume.
Each button press will increase or decrease the
volume one step at a time.
You can only adjust the volume level from the unit or
the Auxillary device independently, so you may need to
adjust both.
skip the track
• Press and hold the VOLUME DOWN/SKIP or
VOLUME UP/ SKIP Button to skip the next/
previous track.
Your unit will automatically switch o if not paired and
left idle for 5 minutes.
IPBTB16_IB_160308.indd 11 30/03/2016 14:24

12
receiving and ending calls
When there is an incoming call, the unit will pause the
playback and ring to alert.
• To answer a call, press the PLAY/PAUSE/TALK
Button.
• To end a call, press the PLAY/PAUSE/TALK
Button again.
• To reject a call, press and hold the PLAY/PAUSE/
TALK Button. Press the PLAY/PAUSE/TALK
again to resume playback.
calling back the last number dialled
You can call back the last number that you dialled on
your phone.
• Press the PLAY/PAUSE/TALK twice. Your phone
will now call the last number that you answered.
IPBTB16_IB_160308.indd 12 30/03/2016 14:24

13
AUX IN operation
Use a 3.5mm AUX IN cable (not included) to connect
your audio device through the AUX IN socket at the
rear of the unit.
Use the controls on your auxiliary device to play music.
You can only adjust the volume level from the unit or
the Auxillary device independently, so you may need
to adjust both.
Ensure to unplug the unit from the USB socket of a
computer or any external devices before cleaning.
maintenance
cleaning the unit
• To clean the unit, wipe the case with a slightly
moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol,
ammonia or abrasives.
• Do not spray aerosol at or near the unit.
IPBTB16_IB_160308.indd 13 30/03/2016 14:24

14
hints and tips
If a problem does occur, it may often be due to
something very minor. The following table contains
various tips.
Problem Cause / Solution
No Power • Make sure that the unit is fully
charged.
No
response in
AUX mode
• Ensure that the unit is fully
charged.
• Ensure that all the required cables
are securely connected.
• Ensure that the unit is switched on.
• Press the PLAY/PAUSE/TALK
Button to resume sound if the unit
is muted.
• Check the volume level of the unit
and the Bluetooth®/Aux device.
• While answering a call with the
unit via Bluetooth® connection,
end the call to resume playback in
AUX IN mode.
Bluetooth
Can’t
connect
• Ensure that the Bluetooth®
function is activated on your
Bluetooth® device.
• The unit and Bluetooth® device are
to far apart they must be within
10m of each other.
• Ensure that another Bluetooth®
device is not connected with
the unit. If so, disconnect the
Bluetooth® device with the unit.
No Sound • Ensure that the unit is switch on.
• You may need to adjust the
volume level on the unit and your
Bluetooth®/Aux device.
IPBTB16_IB_160308.indd 14 30/03/2016 14:24

15
specications
Model IPBTB16
Unit output power 2 x 3W (RMS)
Bluetooth Bluetooth® 4.0
Battery life 10 hours (approx.)
DC-IN 5V, 1A
Dimensions Approx. 170(L) x 52(W) x
60(H) mm
Weight 390g
Features and specications are subject to change
without prior notice.
For general information about this appliance
and handy hints and tips, please visit
www.knowhow.com/knowledgebank or
call 0344 5611234.
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct
to your door the very next day. Visit www.partmaster.
co.uk or call 0344 800 3456
(UK customers only)
Calls charged at National Rate.
IPBTB16_IB_160308.indd 15 30/03/2016 14:24

IB-IPBTB16-160330V1
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
The symbol on the product or its
packaging indicates that this product
must not be disposed of with your
other household waste. Instead, it is
your responsibility to dispose of your
waste equipment by handing it over
to a designated collection point for
the recycling of waste electrical and
electronic equipment. The separate
collection and recycling of your waste
equipment at the time of disposal will
help conserve natural resources and
ensure that it is recycled in a manner
that protects human health and the
environment.
For more information about where you
can drop o your waste for recycling,
please contact your local authority, or
where you purchased your product.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by DSG Retail Limited is under license.
Other trademarks and trade names are those of their
respective owners and all rights are acknowledged.
IPBTB16_IB_160308.indd 16 30/03/2016 14:24
