iWantit ISBT10013 User manual

wireless speaker with NFC
one-touch pairing
ISBT10013
instruction manual

Contents
safety warnings................................................................................................................................. 3
unpacking .......................................................................................................................................... 5
product overview ............................................................................................................................. 6
main unit ....................................................................................................................................................................... 6
- front view ........................................................................................................................................................................... 6
- top view .............................................................................................................................................................................. 6
- rear view ............................................................................................................................................................................. 6
remote control ............................................................................................................................................................ 7
remove the insulating strip from the remote control ............................................................... 8
battery replacement for the remote control............................................................................... 8
remote control operation range.................................................................................................... 9
power source..................................................................................................................................... 9
mains power ................................................................................................................................................................ 9
general operation........................................................................................................................... 10
switching on / o the unit.....................................................................................................................................10
selecting modes .......................................................................................................................................................10
adjusting the volume..............................................................................................................................................10
adjusting the sound eect....................................................................................................................................10
Bluetooth® operation .................................................................................................................... 11
NFC operation ................................................................................................................................. 12
Connecting an NFC device with one already connected ..........................................................................12
iPod / iPhone / iPad operation ..................................................................................................... 13
charging your iPod / iPhone / iPad ....................................................................................................................13
AUX IN operation............................................................................................................................ 14
maintenance.................................................................................................................................... 14
cleaning the unit ......................................................................................................................................................14
hints and tips................................................................................................................................... 15
specications................................................................................................................................... 15

3
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit onto a
third party make sure to include this manual.
• Check that the voltage marked on the rating
label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way - switch o,
withdraw the mains plug and consult your
dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases,
should be placed on the unit. Do not operate
the unit with wet hands, near water or other
liquid.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or re
hazard due to overheating, ensure that
curtains and other materials do not obstruct
the ventilation vents.
• Do not install or place this unit in a bookcase,
built-in cabinet or in another conned space.
Ensure the unit is well ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
during a lightning storm.
• In the interests of safety and to avoid
unnecessary energy consumption, never
leave the unit switched on while unattended
for long periods of time, e.g. overnight, while
on holiday or while out of the house. Switch
it o and disconnect the mains adapter from
the mains socket.
Mains Cable
• Make sure the unit is not resting on top of
the mains cable, as the weight of the unit
may damage the mains cable and create a
safety hazard.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the operating performance of the unit,
and cause a distorted picture or sound.
Batteries
• Batteries used in the unit are easily
swallowed by young children and this is
dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the unit. Seek
medical advice if you believe a cell has been
swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
Supervision
• Children should be supervised to ensure
that they do not play with the unit and the
remote control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.
safety warnings

4
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure
that may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains
socket before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.

5
Thank you for purchasing your new iWantit wireless speaker with NFC one-touch pairing.
We recommend that you spend some time reading this instruction manual in order that you fully
understand all the operational features it oers. You will also nd some hints and tips to help you
resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for
future reference.
unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit Remote Control
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.

6
product overview
main unit
front view
top view
1. IR Sensor
2. Subwoofer speaker
3. Speakers
1. BLUETOOTH MODE Indicator
2. IPHONE/IPOD/IPAD Mode Indicator
3. AUX IN Mode Indicator (bright)
STANDBY Mode Indicator (Dim)
4. STANDBY/SOURCE Button
• Press and hold to switch the unit
to standby mode.
• Press to switch the unit on if in
standby mode.
• Press to toggle between Bluetooth,
iPhone/iPod/iPad and AUX IN Modes.
5. PLAY/PAUSE Button
Press to start or pause the playback in
iPhone/iPod/iPad and Bluetooth modes.
6. VOLUME +/ Buttons
To adjust the volume
2
3
1
654
1 2 3
rear view
1. USB Port
For connection of iPhone/iPod/
iPad for playback and charging of
mobile device.
2. AUX IN Socket
3. MAINS CABLE
4. POWER ON/OFF Button
41 32
If the unit is idle for
approximately 20 mins, it
will automatically switch
to standby mode.

7
remote control
1. STANDBY Button
Switches the unit between on and
standby modes.
2. PLAY/PAUSE Button
Starts or pauses playback.
3. LEFT/RIGHT (SKIP ) Button
Returns to start of current track.
Moves to end of current track.
Moves backwards through current track
Moves forwards through current track
UP/DOWN Button
To select the options on the iPhone/
iPod/iPad menu screen.
ENTER Button
Conrms selection on the iPhone/iPod/
iPad menu screen.
4. MENU Button
Navigates through iPod/iPhone/
iPad menus.
5. SOURCE Button
Switches between Bluetooth,
iPhone/iPod/iPad and AUX IN modes.
The LED indicators indicate the
mode chosen.
6. TREBLE – / + Button
To adjust the treble level.
7. BASS – / + Button
To adjust the bass level.
8. MUTE Button
To mute and restore sound.
9. VOLUME – / + Button
To adjust the volume.
1
3
4
8
2
5
6
7
9

8
remove the insulating strip from the remote control
Remove the insulating plastic strip from the battery if the
battery is being used for the rst time. It is located at the
bottom back side of the remote control.
2. Pull out the battery holder and remove the old battery.
battery replacement for the remote control
The remote control requires a CR2025, 3V Lithium battery.
1. Slide and hold the battery release tab in the direction
of the arrow.
3. Replace with a new battery.
4. Insert the battery holder back into the remote control.
handling the battery
• Improper or incorrect use of batteries may cause corrosion or battery
leakage, which could cause re, personal injury or damage to property.
• Install the battery correctly by following the polarity (+ and –) indications
in the battery compartment.
• When the battery is exhausted, the remote control will not function.
• Only use the battery type indicated in this manual.
• Do not dispose of the used battery as domestic waste. Dispose of it in
accordance with the local regulations.
• Small button cell batteries such as the one used in the remote control
are easily swallowed by young children and this is dangerous. Keep loose
button cells away from young children and make sure that the battery
holder tray is secure in the remote control. Seek medical advice if you
believe a cell has been swallowed.

9
remote control operation range
Point the remote control at the unit no more than
5 metres from the remote control sensor and
within 60° of the front of the unit. The operating
distance may vary depending on the brightness
of the room.
30° 30°
Within about 5m
power source
mains power
This unit was designed to operate with
an AC 100-240V power supply. Connecting the
unit to any other power source may cause
damage to the unit.
1. Unwind the mains cable to its full length.
2. Connect the mains plug to a mains socket.
Make sure the mains plug is fully inserted
into the mains socket. Switch on at the
mains socket.
3. The unit is now connected and ready to use.
4. To switch the unit o completely, switch the
MAINS POWER switch to the OFF position
or withdraw the mains plug from the
mains socket.
handling the remote control
• Take care of your ngernails when you press and hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct sunlight or near sources
of excessive heat.
• Remove the battery from the remote control when not in use for a long
period of time, as it could cause corrosion or battery leakage and may
result in physical injury and/or property damage including re.

10
general operation
switching on / o the unit
• Ensure that the plug is switched on at the wall socket, then switch the POWER ON/OFF
switch at the rear of the unit to the ON position.
• To turn the unit on, either press the STANDBY button on the remote control or press
the STANDBY/SOURCE button on the unit. The standby mode indicator will light.
• To switch the unit to standby, either press the STANDBY button on the remote control
or press and hold the STANDBY/SOURCE button on the unit.
• To completely turn o the unit, switch the MAINS POWER switch at the rear of the unit
to the OFF position.
selecting modes
• On the unit, press the STANDBY/SOURCE button repeatedly to toggle between
Bluetooth,iPhone/iPod/iPad and AUX IN modes. The LED indicator next to the
selection will light up indicating the mode chosen.
• On the remote control, press the SOURCE button repeatedly to select either Bluetooth,
iPhone/iPod/iPad or AUX IN mode. The LED indicator next to the mode chosen will
light up.
• NFC mode is selected with the unit in standby or Bluetooth modes by placing an NFC
device close to (within 10mm) the unit’s NFC sensor.
adjusting the volume
• Press the VOLUME +/– buttons on the unit or remote control to adjust the volume.
• If you wish to switch the sound o, press the MUTE button on the remote control.
The LED indicator next to the mode in use will ash. Press the MUTE button again or
the VOLUME +/– button to resume normal listening.
adjusting the sound eect
• Press the BASS +/– button repeatedly on the remote control to adjust the bass level.
• Press the TREBLE +/– button repeatedly on the remote control to adjust the
treble level.
If the unit is idle for approximately 20 mins, it will automatically switch
to standby mode.

11
Bluetooth® operation
1. Select BLUETOOTH mode by repeatedly pressing the STANDBY/SOURCE button
on the unit or SOURCE button on the remote control.
2. Activate Bluetooth on the device to be connected and select search mode.
3. “ISBT10013”will appear on the list of Bluetooth devices. Type in the password “0000”
if requested.
4. There will be a sound once the connection is complete.
5. In BLUETOOTH mode the PLAY/PAUSE, VOLUME +/– controls, MUTE button
and buttons can be controlled using the remote control. Use the controls on the
device for all other functions.
6. You must disconnect the Bluetooth device before it can be paired with another device.
There will be a sound to conrm the disconnection.
If you are trying to pair your speaker to a mobile device and your mobile
device shows the message‘ failed to connect and password is incorrect’, then
switch the unit o at the mains switch, wait 1 minute then switch the unit
back on. Try pairing again using bluetooth or NFC modes.

12
Distance between device
sensor and sensor area on unit
should be less than 10mm
Connecting an NFC device with one already connected
You can only connect one NFC device at a time. If an NFC device is already connected, the
connected device must be disconnected before you can connect another NFC device. This
is to prevent some from changing the music you are playing without your permission.
1. In the Bluetooth settings of the connected device select disconnect. The Bluetooth
device will now disconnect.
2. While the speaker is in Bluetooth mode touch the other NFC device against the NFC
sensor, the device will now connect.
NFC operation
NFC is a one touch way of pairing your NFC device via Bluetooth to your speaker.
1. The unit must be in STANDBY or Bluetooth mode to pair using NFC. Check your device
has NFC enabled.
2. Place the NFC sensor area on the device close to the unit’s NFC sensor area (it will work
best within 10mm). The unit will switch on and switch to Bluetooth mode, it will play
a sound to show it is connected via Bluetooth and the Bluetooth LED on the unit
will light up.
The rst time you use a device with NFC or if you have previously used it but un-paired it
you will be asked if you want to connect to the speaker. Conrm you want to connect.
3. Use the controls on the device to select and play music. In Bluetooth mode the PLAY/
PAUSE, VOLUME +/– controls, MUTE button and buttons on the device and remote
control can be used to control playback. Use the controls on the device for all other
functions.
4. To disconnect the device place it close to the NFC sensor area again. The device will
disconnect and your unit will remain in Bluetooth mode.
If its the rst time the NFC device has been used you will your HiFi you will be
asked if you want to connect. Conrm you want to connect.

13
iPod / iPhone / iPad operation
This unit can support the following iPhone/iPod/iPad models.
Type Support Model
iPhone • iPhone 6s Plus, 6s, 6 Plus and 6
• iPhone 5s, 5c and 5
iPod • iPod touch 5th, 6th and 7th generation
iPad • iPad Pro
• iPad Air and Air 2
• iPad mini, iPad mini 2, iPad mini 3 and iPad mini 4
• iPad 4th generation
1. Select IPHONE/IPOD/IPAD mode by repeatedly pressing the STANDBY/SOURCE
button on the unit or SOURCE button on the remote control.
2. Connect your iPhone/iPod/iPad to the unit using the USB socket on the back of unit.
3. Once connected, the unit will start playback automatically and also start charging the device.
4. Select your desired music and play the connected iPhone/iPod/iPad as usual.
You can use either the iPhone/iPod/iPad controls or the remote control.
• Press the PLAY/PAUSE button on the unit or remote control to start/pause playback.
• Press the buttons on the remote control to select the previous or next song.
To fast rewind or fast forward through a song press and hold either the or button.
• To view menus on the iPhone/iPod/iPad, press the MENU button on the remote
control, then use the UP/DOWN buttons to navigate through the dierent
menu options. Press the ENTER button to conrm a choice.
To control the menu operation of iPad series, iPhone series, iPod touch series
and iPod nano 6th generation, you need to enter the music menu on your
iPhone/iPod/iPad rst.
This manual provides the basic instructions of menu navigation on iPhone/iPod/
iPad. For advance operations, please refer to your iPhone/iPod/iPad instructions.
To avoid damaging your iPhone/iPod/iPad or the unit please take care when
inserting and removing the cable.
If you charge the iPhone/iPod/iPad while playing music, it may take
a longer time. 1st, 2nd & 3rd generation iPods cannot be charged.
charging your iPod / iPhone / iPad
1. You can automatically charge the iPhone/iPod/iPad through the unit when it is
connected by a USB cable.

14
AUX IN operation
1. Make sure the unit is disconnected at the
mains socket.
2. Use a 3.5mm AUX IN cable to connect your
audio device through the AUX IN socket at the
rear of the unit.
3. Connect the mains plug to the mains socket
and switch the POWER ON/OFF switch at the
rear of the unit to the ON position. The unit will
enter standby mode. The indicator light will
be on but dim to show the unit is in standby
mode.
4. Press the STANDBY button on the remote
control or the STANDBY/SOURCE button on
the unit to switch the unit on.
5. Select AUX IN mode by repeatedly pressing
the STANDBY/SOURCE button on the unit or
SOURCE button on the remote control. The
Aux In indicator will now light brighter to show
Aux mode is selected.
6. In AUX IN mode only the VOLUME +/– controls
and MUTE button can be controlled using the
remote control. Use the controls on the device
for all other functions.
maintenance
cleaning the unit
• To clean the unit, wipe the case with a slightly moist, lint-free cloth.
• Do not use any cleaning uids containing alcohol, ammonia or abrasives.
• Do not spray aerosol at or near the radio.
Ensure to unplug the unit from the mains socket before cleaning.
Standby mode and
Aux mode use the
same indicator.
Standby mode is dim.
Aux mode is bright.

15
specications
Model ISBT10013
AC power AC 230V ~50Hz
Unit output power 2 x 20W (L/R Speakers)
60W (Subwoofer)
Power consumption 130 W
Standby power consumption ≤ 0.5 W
Bluetooth compatibility 2.1EDR
Dimensions Approx. 450(L) x 195(W) x 185(H) mm
Features and specications are subject to change without prior notice.
If any anomaly is encountered, unplug the mains plug and reconnected again.
hints and tips
If a problem does occur, it may often be due to something very minor. The following table
contains various tips.
Problem Cause / Solution
Power
Unit does not turn on
or does not respond to
the remote control.
• Make sure the mains plug is connected to the mains socket
and switched on at the mains.
• Check that the remote control has a battery. The battery
may need to be replaced.
• Make sure that the power switch on the back of the unit is
switched to ON.
iPhone/iPod/iPad
The unit doesn’t play
les or doesn’t function
as expected.
• Make sure the function is set to iPhone/iPod/iPad mode.
• Make sure the iPhone/iPod/iPad is connected properly.
• Make sure the iPhone/iPod/iPad is switched on.
• Volume level may need increasing on the iPhone/iPod/iPad.
Remote Control
No functions or
short range.
• The battery may need to be replaced.
• Aim remote directly towards the remote sensor.
• Remove any objects that are between the remote control
and sensor.
NFC
Can’t connect
• Make sure the HiFi is in Standby or Bluetooth mode before
touching the devices together.
• Make sure another NFC device isn’t already connected. If so
disconnect the other device.

IB-ISBT10013-160303V4
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by DSG Retail Limited is as an Aliate under the License held
by DSG International Sourcing Ltd. Other trademarks and trade names are those of their
respective owners and all rights are acknowledged.
DSG Retail Ltd. (co. no. 504877)
1 Portal Way, London, W3 6RS, UK
Notes for battery disposal
The batteries used with this product contain chemicals that are harmful to the environment.
To preserve our environment, dispose of used batteries according to your local laws or
regulations. Do not dispose of batteries with normal household waste.
For more information, please contact the local authority or your retailer where you purchased
the product.
For general information about this appliance
and handy hints and tips, please visit
www.knowhow.com/knowledgebank or call 0344 5611234
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million spares and
accessories available we can deliver direct to your door the very
next day. Visit www.partmaster.co.uk or call 0344 800 3456
(UK customers only). Calls charged at National Rate.
The symbol on the product or its packaging indicates that this product must not
be disposed of with your other household waste. Instead, it is your responsibility
to dispose of your waste equipment by handing it over to a designated collection
point for the recycling of waste electrical and electronic equipment. The separate
collection and recycling of your waste equipment at the time of disposal will
help conserve natural resources and ensure that it is recycled in a manner that
protects human health and the environment.
For more information about where you can drop o your waste for recycling,
please contact your local authority, or where you purchased your product.
“Made for iPod,”“Made for iPhone,” and
“Made for iPad,”mean that an electronic
accessory has been designed to connect
specically to iPod, iPhone, or iPad,
respectively, and has been certied by the
developer to meet Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note that the use of this
accessory with iPod, iPhone or iPad may aect wireless performance.
iPad, iPhone, iPod, iPod classic, iPod nano, iPod shue, and iPod touch are trademarks of Apple
Inc., registered in the U.S. and other countries.
iPod, iPhone and iPad not included
