J.Burrows TYPHOON JBSTEALBK User manual

TYPHOON GAMING HIGH BACK CHAIR
Weight capacity: 120kgs
1/11
ASSEMBLY INSTRUCTIONS
This design and instruction booklet is subject to copyright.
www.officeworks.com.au
For spare parts or hardware call [phone] or email [email protected]
1CTN
JBSTEALBK/JBSTEALBL/JBSTEALRD/JBSTEALWH

30
2/11
Officeworks Ltd. | 236-262 East Boundary Road | Bentleigh East VIC 3165 | AUSTRALIA
• Please check you have all hardware before assembly.
• If you are missing any hardware, please contact Kyvas on [phone] or email
[email protected]
• Please ensure you have the name of the item, required hardware part and quantity.
• Please retain your receipt as proof of purchase to validate your warranty.
.
NOTE
• Do not tighten screws before all screws are in the right place.
• Do not use this product unless all bolts, screws and knobs are firmly secured.
• Check that all bolts, screws and knobs are securely tightened at least every 4 months.
CAUTION
• If parts are missing, broken, damaged or worn stop using the product until all repairs
are made using manufacturer authorised parts.
• Failure to follow these warnings could result in serious injury
WARNING
• CHILDREN MUST BE SUPERVISED.
DANGER
[phone]
Assembly Video
•To view an assembly video,go to https://www.officeworks.com.au
•Search the product by item code or name:
•Click on the icon to watch the video.

3/11
A
x5 x1 x1 x1
x1 x1 x1 x2
x1
x1
x1
x1
x1 x1x1 x1
B C D
E F G H-L / H-R
I
MN O P
J K L
Q(M8x22mm) (M5 x 10mm) R
x 4 x 1x 16 x 6
S T

4/11
Note: Attach Armrests (H) to the Seat Cushion (G) using 4 x Screws (Q) with Allen Key (T).
Tighten the screws.
D
C
B
A
Q
4 Pcs
M8x22mm Bolt
used to complete
this step.
H-R
G
Q
T
H-L
Note:Turn the Star Base (B) upside down. Push the Castors (A) firmly into hole at the end of each leg.
Turn the Star Base (B) upright and insert Gas Lift (C) into the center hole of Star Base (B).
Place cover (D) over the Gas Lift (C).
FRONT

5/11
Note: Align the Seat Plate (E) so the FRONT of the Seat Plate matches the FRONT label on the
bottom of the Seat Cushion (G).
Tighten the screws with Allen Key (T).
Note: Attach the Angle Adjuster (I) and Connector (J) to Seat Cushion (G) using 4 x Screws (Q)
by Allen Key (T).
Remark: Angle Adjuster (I) should be attached to the right side of the Seat Cushion (G).Connector (J)
should be attached to the left side of the Seat Cushion (G).
Q
4 Pcs
M8x22mm Bolt
used to complete
this step.
Q
4 Pcs
M8x22mm Bolt
used to complete
this step.
G
G
E
Q
T
TQ
I
J
FRONT

6/11
Note: Place the Plastic Cover (K) & (L) on Seat Cushion (G) using 4 x Screws (R) with Allen Key (T).
Remark: Plastic Cover (K) should be placed to the right side of the Seat Cushion (G).
Plastic Cover (L) should be placed to the left side of the Seat Cushion (G).
Note: Using 2 x Screws (Q) through upper holes of Bracket to attach Back cushion (F).
Tighten the screws with Allen Key (T).
6
F
Q
2 Pcs
M8x22mm Bolt
used to complete
this step.
QT
R
4 Pcs
M5x10mm Bolt
used to complete
this step.
R
G
K
L
T
Warning : DO NOT adjust/ touch the backrest lever before
the backrest has been securely fastened to bracket. Doing
so will cause the bracket to spring forward and may
cause harm. Keep hands clear of the recline mechanism
until the backrest has been assembled.
Bracket
Bracket Recline Lever

Note: Using 2 x Screws (Q) through lower holes of Bracket to attach Back cushion (F).
Tighten the screws.
Note: Place the Plastic Cover (M) on the upper Angle Adjuster (I) using 2 x Screws (R)
with Allen Key (T).
Place the Plastic Cover (N) on the upper Connector (J) using 2 x Screws (R) with Allen Wrench (T).
7/11
Q
2 Pcs
M8x22mm Bolt
used to complete
this step.
7
8
Tighten the screws.
R
2 Pcs
M5x10mm Bolt
used to complete
this step.
RT
F
QT
F
N
M

Note: Place assembled Seat Cushion (G) on the Gas Lift (C). Push down firmly until connection
is secure.
8/11
S
G
C
Note: Press the Plastic Caps (S) into the Plastic Cover to cover the screws.
9
10

Note: Headrest cushion - Place the strap through the holes at the top of the backrest. Fasten the clips by
pushing together.
Your Typhoon Gaming High Back Chair is now complete and ready for use.
IMPORTANT NOTE: Periodically check and re-tighten screws
9/11
11
O
P
12
Lumbar cushion – Place the bottom straps through the gap between the seat and back rest. Feed
the top straps through the holes at the top of the backrest. Fasten the clips by pushing together.

10/11
Thank you for your purchase. Please retain your receipt to validate warranty.
If you would like to know more about our furniture products, please visit www.officeworks.com.au
• Wipe with a damp cloth and mild soap. Wipe dry
immediately with an absorbent dry cloth.
•Treat spills immediately with an absorbent cloth by
blotting the spill.
• Do not use detergents, solvents or abrasive cleaners.
• Keep away and protect from direct sunlight and heat.
•Avoid contact with skin, in particular during high
temperatures and humidity.
• Clean, check and tighten all parts regularly.
Care Instructions

11/11
TYPHOON GAMING HIGH BACK CHAIR
- To increase chair height pull
lever upward while lifting body
weight slightly off the seat.
- Release lever at desired height.
- To lower chair height sit fully into
the chair and pull lever upward.
- Release lever at desired height.
Your feet should be resting flat on
the floor.
Chair Height Adjustment
Adjustable Tilt Tension Control
-Turn continuously to adjust how
quickly chair tilts back & forth.
Note: if adjusting while sitting in chair:
Turn knob left to tighten tension
Turn knob right to loosen tension
- Sitting in the chair pull the lever up.
Move your upper body fore and aft to
a comfortable position.
When comfortable lock the position
by pushing the lever down.
Back Tilt
- Pull lever out to unlock & allow chair
to tilt back & forth
- Push lever to lock.Chair will have slight
movement in locked position
Chair Tilt
- Pull lever up whilst moving the
arm up or down. Release lever
at desired height.
Arm Height Adjust
Functionality
