J D Williams Levanto Lounger User manual

IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
Levanto Lounger
Assembly Instructions
Product size: W62.5xD197xH63cm
1/6

Levanto Lounger
Assembly Instructions
Before you start
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
Warnings
Dos
See enclosed instructions for assembly, safety and care
information
Failure to follow the warnings could result in serious
injury.
Handle heavy parts with care.
Ensure that this product is fully assembled as illustrated
before use.
This product should only be used on firm, level ground.
Keep small parts out of reach of children.
Do not stand or climb onto this product.
This product is intended for domestic use only.
Furniture can be dangerous if incorrectly used. No
liability will be accepted for damage or injury caused by
incorrect use of this product.
Do not use scourer, abrasives, washing powders,
chemical cleaners or any other substances containing
abrasives since these substances can damage the
product, including the glass panel.
Never tilt the lounger during use.
Do not use power tools to construct this product.
Do not use this product if parts are missing, damaged
or worn.
Do not stand or climb onto the product and do not use
it as a ladder, as this could lead to it unbalancing and
overturning.
Never drag furniture when moving it, always lift it.
Number of people required for assembly.
Dos
25 minutes
Time to assemble
Tools required
Tips:
Do Not fully tighten bolts before all
components are connected.
Only fully tighten once you are satisfied
with the alignment of all components.
Do not overtighten bolts.
When you are ready to start, make sure that you have the
right tools, plenty of space and a clean, dry area for assembly .
Remove all packaging and banding and place the components
carefully on suitable surfaces to prevent damaging or
scratching them.
Check the pack and make sure you have all of the parts listed.
Check all screws and bolts are tightened and inspect regularly.
We recommend the use of furniture covers to protect your
product when not in use.
Two people
This product is suitable for all year outdoor use. Cushions
should not be left out in wet weather or overnight.
PLEASE NOTE all cushions should always be stored indoors
after use. THE CUSHIONS ARE NOT WATERPROOF.
We recommended the use of furniture covers to protect your
furniture when not in use. During severe weather conditions,
please move your furniture inside.
To prolong the life of the product we recommend that during
severely bad weather and during the winter months, it is stored
in a cool, dry place.
Before storage, ensure that the product is clean and dry.
To clean, wipe down with a sponge and warm soapy water and
wipe with a clean, dry cloth.
Cushions should be cleaned following the care instruction
on the label.
2/6

Assembly Instructions
Components，fixtures & fittings（not actual size）
Parts List
Levanto Lounger
3/6
A
Part
No. Diagram Qty Part No. Diagram Qty
G
H
I
B
C
D
E
1 PC 10 PCS
4 PCS
1 PC
2 PCS
2 PCS
1 PC
1 PC
F1 PC
J
K
L
M
16 PCS
2 PCS
1 PC
1 PC
M6x15mm
M6x30mm
M6x35mm
M6
M6x4mm

Assembly Instructions
Levanto Lounger
Note: All Bolt Head Caps and Nut Caps should not be attached before finally
tightening all Bolts with the Allen Key.
Only tighten all bolts when you are satisfied with the alignment of all components.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Step One
Fasten the supporting tube (Part C) with the front of the armrest tube (Part A
and B) by bolts (Part G) and washers (Part J).
Step Two
Fasten seat part (Part D) with front leg (Part E)
by bolts (Part G) and washers (Part J).
Please ensure the screws are tightend
completely.
4/6
A
B
C
G
J
D
E
G
J
J
G

Assembly Instructions
Levanto Lounger
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Step Three
Fasten seat part (Part D) with the
front of armrest (Part A and B)
by bolts (Part H) and washers
(Part J). Fasten the seat part
and the supporting tube (Part
C) with the rest of the armrest
by bolts (Part H and G) and
washers(Part J).
Step Four
Fasten back part(Part F)
with seat part (Part D) by
bolts (Part I) and washers
(Part J and K). Please ensure
the screws are tightened
completely.
5/6
H
J
A
B
D
Step Five
Put the seat cushion(Part L) on the seat part and connect the sticky strap.
L
F
I
J
K
J
H
J
G
C

Assembly Instructions
Levanto Lounger
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Warning
One: The backrest of the lounger should not be sat during normal use.
6/6
the backrest
Two: The first step of the adjustable position should not be used during
normal use.
the first step
