Jäger Z62-H360.02S19W2/2V User manual
Manual
Z62-H360.02S19W2/2V
High Frequency Spindle
Pneumatic taper change
Item no. 10404084, Revision 002 ( 44 )
Identification of HF spindle
Spindle type
Pmax S6-60%
Item no. .... Serial no.
Rated rotation speed
Serial no.
Item no.
Power data
Spindle type
S1-100%
As we always ensure that our HF spindles are at the cutting edge of techno-
logical development, we reserve the right to make technical modifications
and variations from the exact design described in the manual.
The text in this manual has been compiled with the utmost care. However, Al-
fred Jäger GmbH cannot assume any legal responsibility or liability of any
kind for incorrect information and any consequences thereof.
Translations and reproductions – including of extracts – are prohibited with-
out the express written approval of Alfred Jäger GmbH.
Item no. 10404084, Revision 00 3 ( 44 )
Contents:
Translation of the original manual
1 Preliminary information 5
1.1 Purpose of the manual.......................................................5
1.2 Explanation of symbols used........................................... 5
2 Transport and packaging 6
2.1 Scope of supply of HF spindle.........................................6
2.1.1 Optional accessories..............................................6
2.1.2 Documentation supplied.....................................6
2.2 Packaging of HF spindle.................................................... 7
3 Designated use 7
3.1 Permissible types of machining...................................... 7
3.2 Permissible materials..........................................................7
4 Safety instructions 8
4.1 Safe working.......................................................................... 9
4.2 Shutdown of HF spindle..................................................10
4.3 Installation and maintenance........................................10
4.4 Modification and repair ...................................................10
4.5 Improper operation ..........................................................10
5 Technical description 11
5.1 Connections of HF spindle .............................................11
5.2 Electrical connection ........................................................12
5.3 Cooling ..................................................................................12
5.4 Sealing air .............................................................................13
5.5 Taper cleaning ....................................................................13
5.6 Pneumatic tool change....................................................13
5.7 Cylinder vent .......................................................................13
6 Technical Specifications 14
6.1 Dimensions ..........................................................................15
6.2 Technical data sheet (KL3702 , AC-Motor)................16
6.2.1 Performance Diagram........................................ 17
6.3 Wiring diagram...................................................................18
6.4 Motor protection PTC 130°C..........................................21
6.5 Tool change monitoring .................................................21
6.6 Speed and position sensor (MiniCoder) ....................22
6.6.1 Technical data (TTL, x8) ..................................... 22
6.7 Air-borne noise emissions ..............................................22
7 Operating location 23
8 Installation 24
8.1 Installing the HF spindle...................................................24
8.2 Diameter of media supply line.......................................25
8.3 Cooling water.......................................................................25
8.3.1 Quality of cooling water.....................................25
8.3.2 Setting the cooling...............................................25
8.4 Compressed air....................................................................26
8.4.1 Air purity classes (ISO 8573-1)..........................26
8.4.2 Setting the sealing air .........................................26
8.4.3 Setting values.........................................................27
9 Commissioning 28
9.1 Running-in schedule..........................................................28
9.2 Daily start-up ........................................................................29
9.3 Shutdown signal .................................................................29
9.4 Commissioning after storage .........................................29
10 Tool change 30
10.1 Clockwise and counter-clockwise.................................30
10.2 pneumatic taper change..................................................30
10.2.1 Automatic hollow shank taper tool clamp
.....................................................................................31
10.3 Tool changing station (optional accessory) ..............32
10.3.1 pneumatic taper change ...................................32
10.3.2 Installing the changing station........................32
10.3.3 Maintenance...........................................................32
11 Tools for high speed cutting 33
12 Maintenance 34
12.1 Ball bearings .........................................................................34
12.2 Daily cleaning.......................................................................34
12.2.1 Before commencing work .................................35
12.2.2 With every tool change ......................................35
12.3 In the case of storage.........................................................35
12.4 Monthly maintenance.......................................................36
12.5 Long periods of storage ...................................................36
12.6 Maximum storage time.....................................................36
13 Dismantling 37
13.1 Disposal and environmental protection ....................37
14 Service and repairs 38
14.1 Service partners...................................................................38
14.2 Malfunctions.........................................................................39
Preliminary information
Item no. 10404084, Revision 00 5 ( 44 )
1 Preliminary information
The high frequency spindle (HF spindle) is a high quality precision tool for
high speed machining.
1.1 Purpose of the manual
The manual is an important component of the HF spindle.
ÜStore the manual carefully.
ÜMake the manual available to all persons who work with the HF spindle.
ÜRead the documentation supplied in full.
ÜBefore carrying out any work, read the corresponding section of the man-
ual carefully again.
1.2 Explanation of symbols used
To enable quick classification of information, this manual uses visual aids in
the form of symbols and text markings.
Notes are marked with a signal word and a colored box:
DANGER
Dangerous situation!
Results in serious injury or death.
uMeasure to avert the danger.
WARNING
Dangerous situation!
May result in serious injury or death.
uMeasure to avert the danger.
CAUTION
Dangerous situation!
May result in minor to moderate injury.
uMeasure to avert the danger.
Note
May result in material damage. This warning symbol is not a warning for per-
sonal injury.
Tip
Tips indicate useful information for users.
Transport and packaging
Item no. 10404084, Revision 006 ( 44 )
2 Transport and packaging
Avoid strong vibrations or impacts during transportation, as these could dam-
age the ball bearings of the HF spindle.
ÜAny damage reduces the accuracy of the HF spindle.
ÜAny damage restricts the functionality of the HF spindle.
ÜAny damage shortens the service life of the HF spindle.
2.1 Scope of supply of HF spindle
The following parts are supplied with the HF spindle:
qHigh Frequency Spindle
qFelt cleaning taper
qTransport packaging
ÜCheck the high frequency spindle for completeness upon delivery.
2.1.1 Optional accessories
Available on request:
qSpindle holder
qFrequency converter
qChiller
qCollet grease
qHose connections
qFurther accessories on request.
Only approved accessories have been tested for operational safety and func-
tionality.
ÜDo not use any other accessories – this may invalidate any warranty claims
and compensation claims for damages.
ÜIf the spindle holder is to be produced in-house, it is essential to contact
Alfred Jäger GmbH before starting production to request the tolerances
and production plan for the spindle holder.
2.1.2 Documentation supplied
The documents listed below are supplied with the HF spindle:
qManual
qThe declaration of incorporation is part of the manual.
qInspection protocol
ÜCheck that the documentation supplied is complete when the spindle is
delivered. If necessary, request a new copy.
Designated use
Item no. 10404084, Revision 00 7 ( 44 )
2.2 Packaging of HF spindle
All transport packaging materials can be recycled in appropriate disposal facil-
ities.
3 Designated use
The HF spindle is an “incomplete machine” in accordance with the Machinery
Directive and cannot perform any function independently. The HF spindle can
only be operated in conjunction with a machine tool and a frequency con-
verter.
3.1 Permissible types of machining
The HF spindle has been developed only for the following types of machining.
qCutting
qDrilling
qEngraving
qGrinding
ÜContact Alfred Jäger GmbH if other types of machining are required.
3.2 Permissible materials
The HF spindle has been developed only for the following materials.
qMetals (such as alloys, cast metals etc.)
qSintered materials
qPlastics
qWood
qGraphite
qStone (marble, etc.)
qPaper and cardboard
qCircuit boards
qGlass and ceramic
ÜContact Alfred Jäger GmbH if other materials are to be machined.
Safety instructions
Item no. 10404084, Revision 008 ( 44 )
4 Safety instructions
The high frequency spindle is a state of the art product and is safe to operate.
However, the HF spindle may pose a risk in the following cases:
qIf it is installed by untrained personnel.
qIf it is used incorrectly.
qIf it is not used in accordance with its intended use.
The high frequency spindle may only be installed, commissioned, and main-
tained by specialist personnel.
Definition: Specialist personnel are persons who are familiar with the assem-
bly, installation, commissioning, and operation of the product and have the
relevant qualifications for their area of activity. The operator must closely con-
trol the responsibility, training, and monitoring of these personnel.
DANGER: Due to explosion.
HF spindles are not approved for use in areas at risk of explosion. Use in such
areas may result in explosions.
uDo not use the HF spindle in potentially explosive atmospheres.
DANGER: Due to flying parts.
The HF spindle operates at high speeds and may therefore be flung away by
these.
uOperate the HF spindle only if it is installed in the machine or system in a
fixed manner.
Note: Adhere to the limit values.
uObserve the limit values specified in the technical data.
Note: Take account of the machine.
uObserve the manual of the machine in which the HF spindle is installed.
uObserve all safety instructions specified by the machine manufacturer.
uEnsure that the machine does not cause any hazards (e.g. uncontrolled
movements). Do not install the HF spindle in the machine until this has
been done.
Note. Do not damage the HF spindle.
uAny damage reduces the accuracy of the HF spindle.
uAny damage restricts the functionality of the HF spindle.
uAny damage shortens the service life of the HF spindle.
Safety instructions
Item no. 10404084, Revision 00 9 ( 44 )
4.1 Safe working
Observe all safety instructions set out in the manual, the applicable national
accident prevention regulations, and the valid company work, operation, and
safety guidelines.
DANGER: Due to flying parts.
Tools that are not clamped correctly will be flung away by the centrifugal
forces that occur during machining.
uUse the full clamping depth of the clamping system.
uClamp the tool securely.
DANGER: Due to flying parts.
If the wrong rotational direction is used, the clamping system releases and
the tool is flung away.
uIt is essential to adhere to the rotational direction of the HF spindle.
WARNING: Risk of injury due to flying parts.
The HF spindle operates at high speeds which may cause chips to fly out
with great force.
uNever remove the protective devices of the machine or system.
uAlways wear protective goggles during work.
Exampleofdesign: Inserting the
shank
Note: Ensure functionality.
uNever operate the HF spindle without a clamped tool shank.
If no tool shank is clamped:
qThe clamping system is damaged by the centrifugal forces.
qThe clamping system is shifted.
qThe balance of the HF spindle is affected.
qThe bearing is damaged.
ÜTake the relevant measures to protect against splashes and spray accord-
ing to the type of machining, the type of material being machined, and the
type of tool selected.
ÄObserve the manual of the machine in which the HF spindle is installed.
ÜObtain the maximum circumferential speeds of the tools used from the
tool supplier.
Single-point tools are not suitable for high speed cutting.
If they are required for production reasons:
ÜOnly use a balanced tool.
ÄDIN ISO 1940
ÄBalance grade 2,5
Safety instructions
Item no. 10404084, Revision 0010 ( 44 )
The tool cutting diameter (X) must not be greater than the maximum
clamping range (Y).
ÜAlways clamp the tool so that it is as short as possible.
ÜKeep the dimension (Z) small.
Ä(Y) See section: Technical Specifications [}14].
4.2 Shutdown of HF spindle
The procedure for shutting down the high frequency spindle for installation
and maintenance work is as follows:
ÜCompletely disconnect the power supply.
ÜCompletely disconnect the media supply (air and liquid).
ÜMake sure that the shaft of the HF spindle has come to an absolute stand-
still.
If the HF spindle is being shut down to be cleaned:
ÜReconnect only the sealing air and the taper cleaning air.
Tip: Forward the data to the controller.
uUse the option on the frequency converter of detecting the shutdown
signal from the shaft and forwarding this to the machine controller for
evaluation.
4.3 Installation and maintenance
ÜCarry out installation, cleaning, and maintenance work only after shutting
down the HF spindle and after the shaft has come to a standstill.
ÜInstall all safety and protective devices of the machine immediately after
completing work.
4.4 Modification and repair
Modifications or alterations to the HF spindle are only permitted after prior
consultation with Alfred Jäger GmbH.
Only the service partners listed in the “Service and repair [} 38]” section are
authorized to open and repair the HF spindle.
Only approved accessories have been tested for operational safety and func-
tionality.
4.5 Improper operation
The high frequency spindle is only safe to operate for its designated use.
ÜObserve the safety instructions in all sections of the manual to prevent
hazards to persons, the environment, the machine, or the HF spindle itself.
Failure to observe the safety instructions may invalidate any warranty claims
and compensation claims for damages.
Technical description
Item no. 10404084, Revision 00 11 ( 44 )
5 Technical description
5.1 Connections of HF spindle
4
1a
37
2
2
8
1b
1c
1a Electrical connection for: motorphases
1b Electrical connection for: Tool taper monitoring
1c Electrical connection for: Vector control
2Cooling water G 1/8"
3Sealing air G 1/8"
4Taper cleaning G 1/8"
7Pneumatic system for tool change G 1/8"
8Cylinder vent
Sound absorber (may only be removed if necessary!) G 1/8"
Technical description
Item no. 10404084, Revision 0012 ( 44 )
5.2 Electrical connection
The HF spindle may only be operated with a frequency converter (FC).
ÜCheck whether the current, voltage, and frequency data of the HF spindle
match the raw data for the frequency converter.
ÜUse a motor supply line that is as short as possible.
ÜAdjust the speed of the HF spindle using the FC.
ÜRefer to the frequency converter manual for further information.
The FC detects the following operating states of the HF spindle, depending on
the version:
qHF spindle rotating.
qHF spindle too hot.
qHF spindle at a standstill, etc.
The FC forwards the operating states of the HF spindle to the machine con-
troller.
Note: Connect the SpeedTEC quick locking connector.
uFor the combination SpeedTEC connector plug/SpeedTEC cable plug:
uRemove the O ring on the SpeedTEC connector plug.
5.3 Cooling
Liquid cooling keeps the HF spindle at a constant temperature during opera-
tion.
Note: Extension of the service life through heat dissipation.
Heat is produced during operation of the HF spindle. The temperature of the
HF spindle should not exceed + 45° C as this shortens the service life of the
bearing.
uCheck the temperature of the HF spindle on the housing.
Technical description
Item no. 10404084, Revision 00 13 ( 44 )
5.4 Sealing air
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}26]" section.
The sealing air prevents foreign bodies such as chips and liquids (e.g. emul-
sions) from entering the HF spindle.
ÜCheck that air escapes at the front between the housing and the rotating
parts of the HF spindle.
5.5 Taper cleaning
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}26]" section.
Taper cleaning prevents chips and liquids from entering the shaft during a
tool change and causing contamination and damage to the inner taper and
the clamping system.
5.6 Pneumatic tool change
For guidelines on air quality,
see "Air purity classes (ISO
8573-1) [}26]" section.
The tool change or tool taper change is performed pneumatically.
During this, a mechanism is operated inside the HF spindle which clamps, re-
leases, or ejects the tool taper or collet.
5.7 Cylinder vent
The cylinder takes in air when clamping the taper/tool. This air must be clean
and dry.
Only if necessary:
ÜRemove the sound absorber.
ÜFit the relevant hose fitting in place of the sound absorber.
ÜFit the relevant hose to the hose fitting.
ÜSelect the length of the hose so that its free end protrudes out of the hose
fitting far enough that no dirt or moisture can be taken into the hose.
Technical Specifications
Item no. 10404084, Revision 0014 ( 44 )
6 Technical Specifications
Bearings Hybrid ball bearing (pcs) 4
Lifetime lubricated maintenance free
Power values
Liquid cooled
Pmax / 5 s S6-60% S1-100%
Rated power 3,2 2,1 1,8 [kW]
Voltage 185 188 188 [V]
Current 16 10,5 9,1 [A]
Motor data Motor technology 3-phase asynchronous drive
(no brushes or sensors)
Frequency 1.000 Hz
Motor poles (pairs) 1
Rated rotation speed 60.000 rpm
Acceleration/braking value
Per second
10.000 rpm
(other values by consultation)
Characteristics Speed sensor Vector control
TTL, 8x
Toothed wheel Teeth = 64
Module = 0,4
Motor protection PTC 130°C
Optional accessory
Housing Stainless steel
Housing diameter 61,9 mm
Cooling Liquid cooled
Ambient temperature + 10°C … + 45°C
Sealing air
Protection category
(sealing air turned on) IP54
Taper cleaning
Tool change Pneumatic taper change
Tool Holder HSK-E 25
Tool change monitoring inductive
2 positions clamped, ejected
Clamping range up to 8 mm
Clockwise and anticlockwise
Technical Specifications
Item no. 10404084, Revision 00 15 ( 44 )
Coupler plug
Y-TEC
9-pin (motor phases)
12-pin (sensors)
SpeedTEC
17-pin (sensors)
Weight ~ 6,2 kg
Inner taper run out < 1 µ
Axial run-out < 1 µ
6.1 Dimensions
(*) = Clamping range
Technical Specifications
Item no. 10404084, Revision 0016 ( 44 )
6.2 Technical data sheet (KL3702 , AC-Motor)
The power values (S1, S6, S2)
are valid for sinusoidal cur-
rents and voltages.
The power values of the HF
spindle are dependent on the
frequency converter used and
may vary from the indicated
values.
Motor type ACM 48/30/45-2E
Rated power 1,8 kW
Rated rotation speed 60.000 rpm
Cooling Liquid cooled
Motor protection PTC 130°C
Winding resistance 0,85 Ω
Measured values: S1-100%
Rated rotation speed 5.000 10.000 20.000 30.000 40.000 50.000 60.000 rpm
Speed 4.026 8.819 18.770 28.697 38.767 48.775 58.700 rpm
Frequency 84 167 333 500 667 833 1.000 Hz
Rated power 0,128 0,299 0,616 0,93 1,241 1,55 1,826 kW
Torque 0,31 0,323 0,313 0,31 0,306 0,303 0,297 Nm
Voltage 23 40 68 98 129 161 188 V
Current 8,8 9 9 9 9 9,1 9,1 A
Measured values: S6-60%
Rated rotation speed 5.000 10.000 20.000 30.000 40.000 50.000 60.000 rpm
Speed 3.910 8.970 18.900 28.840 38.910 48.754 58.570 rpm
Frequency 84 167 333 500 667 833 1.000 Hz
Rated power 0,137 0,318 0,68 1,035 1,4 1,765 2,117 kW
Torque 0,345 0,345 0,345 0,345 0,344 0,344 0,344 Nm
Voltage 24 39 70 100 133 167 188 V
Current 9,5 9,5 9,7 9,8 9,9 10 10,5 A
Technical Specifications
Item no. 10404084, Revision 00 17 ( 44 )
Measured values: S2-Pmax./5s
Rated rotation speed 5.000 10.000 20.000 30.000 40.000 50.000 60.000 rpm
Speed 3.910 6.960 17.375 27.596 37.818 48.040 57.314 rpm
Frequency 84 167 333 500 667 833 1.000 Hz
Rated power 0,137 0,47 1,14 1,82 2,49 3,17 3,17 kW
Torque 0,345 0,65 0,63 0,63 0,63 0,63 0,53 Nm
Voltage 24 44 75 112 148 185 185 V
Current 9,5 16 16 16 16 15,9 15,5 A
Note on operation with static frequency converters:
For operation with a frequency converter, the effective fundamental voltage
must correspond to the specified motor voltage.
The measured currents may be greater than the specified values due to the
harmonic content.
6.2.1 Performance Diagram
Technical Specifications
Item no. 10404084, Revision 0018 ( 44 )
6.3 Wiring diagram
Note: Do not change the ex-works configuration.
Any change may cause overvoltage on the electrical components (e.g. PTC,
differential magneto resistor).
1
Perschewski
20.10.17
1
29029173
g
f
e
d
c
b
a
4 5 61 32
a
b
c
d
e
f
g
Bl.
Übersetzungen, Vervielfältigungen und die Weitergabe an Dritte, auch nur auszugsweise,
ist ohne schriftliche Gehnehmigung der Fa. Alfred Jäger GmbH untersagt
Datum
Gepr.
Bearb.
Norm
Projekt Nr.:
Version Nr.:Zeichn.Nr.:
von
Blatt
DIN 81346
Pinbelegung FSW9 I-Tec (S21)/ Y-Tec (S19)
U
W
V
Stator
*KTY/ **PTC/
***PT1000
PE
A
B
C
1
2
5
3
4
Spindelstecker FSW9 I-Tec (S21)
spindle plug FSW9 I-Tec (S21)
GNYE0,75 mm²
*0,14 mm² BN/ ***0,22 mm² RD**0,14 mm² BU/
*0,14 mm² WH/ ***0,22 mm² WH**0,14 mm² BU/
*BN/ **BN/ ***BN/ ****RD
*BU/ **BU/ ***VT/ ****GN
*BK/ **WH/ ***WH/ ****WH
B
Motorphase V
motor phase V
A
Motorphase U
motor phase U
4
---
3
---
C
Motorphase W
motor phase W
1
*KTY +/ **PTC+/
***PT1000+
2
*KTY -/ **PTC-/
***PT1000-
5
---
PE Schutzleiter
protective earth
* Aderleitung braun (U), blau (V), schwarz (W) bei Jäger Stator 70/40-2pol
* core cable brown (U), blue (V), black (W) at Jäger stator 70/40-2pol
** Aderleitung braun (U), blau (V), weiß (W) bei Jäger Stator 3/7-4pol
** core cable brown (U), blue (V), white (W) at Jäger stator 3/7-4pol
*** Aderleitung braun (U), violett (V), weiß (W) bei Jäger Stator 4/7-2pol
*** core cable brown (U), violett (V), white (W) at Jäger stator 4/7-2pol
**** Aderleitung rot (U), grün (V), weiß (W) bei Jäger Stator 2/4-2pol
**** core cable red (U), green (V), white (W) at Jäger stator 2/4-2pol
hh:mm
~
* Zähler optional
counter optional
2.0
BK0,14 mm²
BK0,14 mm²
Technical Specifications
Item no. 10404084, Revision 00 19 ( 44 )
1
Perschewski
11.10.17
1
29029370
g
f
e
d
c
b
a
4 5 61 32
a
b
c
d
e
f
g
Bl.
Übersetzungen, Vervielfältigungen und die Weitergabe an Dritte, auch nur auszugsweise,
ist ohne schriftliche Gehnehmigung der Fa. Alfred Jäger GmbH untersagt
Datum
Gepr.
Bearb.
Norm
Projekt Nr.:
Version Nr.:Zeichn.Nr.:
von
Blatt
DIN 81346
Pinbelegung FSW9/12 Y-TEC (12) (S19)
1
2
3
4
5
6
7
8
9
10
11
12
PNP
Induktiver Näherungsschalter
Inductive proximity switch
+Us
0V
output
PNP
Induktiver Näherungsschalter
Inductive proximity switch
+Us
0V
output
BN0,14 mm²
BU0,14 mm²
BN0,14 mm²
BU0,14 mm²
Signal HSK clamped BK0,14 mm²
Signal HSK ejected BK0,14 mm²
Spindelstecker FSW9/12 Y-TEC (12) (S19)
male connector FSW9/12 Y-TEC (12) (S19)
Technical Specifications
Item no. 10404084, Revision 0020 ( 44 )
1
Perschewski
17.05.17
1
29031970
g
f
e
d
c
b
a
4 5 61 32
a
b
c
d
e
f
g
Bl.
Übersetzungen, Vervielfältigungen und die Weitergabe an Dritte, auch nur auszugsweise,
ist ohne schriftliche Gehnehmigung der Fa. Alfred Jäger GmbH untersagt
Datum
Gepr.
Bearb.
Norm
Projekt Nr.:
Version Nr.:Zeichn.Nr.:
von
Blatt
DIN 81346
Pinbelegung FS17 (S10) Vektor GS04 S&M
UA-
SIN-
NA
1.Spur
UN+
PZ
N
GND
+5V +/-5%
UB+
COS-
PB
2.Spur
UA+
SIN+
PA
1.Spur
UB-
COS+
NB
2.Spur
UN-
NZ
N
Sense
Zahnradgeber GS04T08 Mis
encoder GS04T08 Mis
11
10
7
3
2
1
12
13
'E'
BU0,25 mm²
BN0,25 mm²
WH0,25 mm²
GY0,25 mm²
YE0,25 mm²
GN0,25 mm²
RD0,25 mm²
PK0,25 mm²
wird nicht benötigt, isoliert hineinlegen
not connected, isolated
Spindelstecker FS17 (S10) Vektor
spindle plug FS17 (S10) Vektor
Table of contents
Other Jäger Controllers manuals
