J.S. Technology RGB to Component YUV User manual

WARNING!
The RGB to Component (YUV) converter is powered by 230V mains. All normal
precautions should be observed. Do not spill any liquids on the unit. Do not
attempt to service the unit. Do not cover the unit, do allow for ventilation. Do not
use a higher rating of fuse, and only replace with a like fuse. Do not spray the unit
with any combustable substances.
In the unlikely event the unit falters for any reason, disconnect from the mains
supply and retry after a few minutes. Contact information is provided below.
Input:
RGB input from domestic video equipment, 1V pk-pk.
SCART input connector.
Output:
Y video at 1V pk-pk with colour difference signals, U & V, at appropriate levels.
Left and right audio available via phono connectors.
Copy Protection Compatibility:
Computer control to enhance compatibility with copy protected sources while still
maintaning accuracy of unit. This will not allow copies to be made from this unit.
Power:
Standard fused (3A) UK mains plug, 230V and 50/60Hz ac. Power consumption
1W. LED power indicator.
Dimensions:
150x85x48mm.
TechnicalSpecification.
J.S. Technology,
APL Centre,
Stevenston Ind. Est.,
Stevenston.
Ayrshire
KA20 3LR
© 2002-2003.
E-mail: [email protected] Tel: [phone] Fax: [phone]
RGB to Component (YUV).
http://www.rgbtosvideo.com
Instruction Manual.
•Input of RGB from a DVD player, Sky Digibox, On/ITV/Freeview Digital box, Digi-
tal Cable or any other RGB video source.
•Output of high quality Component video via three phono connectors. YUV is also
known as Y, Pb, Pr and Y, Cb, Cr.
•Broadcast quality synchronisation extraction-built on Plasma VGA technology.
•Convenient connections to existing equipment -SCART input, Phono connectors for
component video and audio output.
•Computer enhancement for compatibility with copy protected sources.
•Compatible with both NTSC and PAL formatted RGB video pictures.
•Audio is passed through without modification to ensure optimum audio quality.
The Converter unit should be connected to the RGB source via a FULLY CONNECTED
SCART lead, or one that has at least the RGB, audio and composite connections. Fully
connected SCART leads are available at most retailers. The unit requires 230V a.c. 50-
60Hz mains supply to operate.
2002-
2003.
Designed & manufactured in UK/Europe.

Configuration of Single Monitor with the
RGB to Component Converter.
Connect the digital set-top box (or DVD player) to the RGB to Component’s SCART
input, then the output directly to the display device with audio. In some systems the
audio may be routed to an external amplifier rather than the display.
Configuration of the Digital Set-top Box and DVD Player.
For Sky Digital, press the "Services" button on the remote control to bring up the
services menu. Go to option 4 -System Set-up. Then to 1 -Picture Settings. Ensure
that Video Output is RGB, not PAL. Do not press the "TV" button as this switches off
the RGB output, in this case depressing the “Sky” button will restore RGB output.
On/ITV Digital select menu, "4", then "2" and the TV Output option toggles between
RGB and Composite. The timer function with On/ITV Digital switches off the RGB
output, therefore if recording via the converter leave the unit on the desired channel.
Digital Cable normally has an options menu inside the TV guide where RGB output
can be found.
Please refer to the DVD player’s user manual for options for RGB output and ensure
that it is active.
Connect the digital set-top box (or DVD player) to the RGB to Component’s SCART
input, then the output directly to the A/V amplifierwith audio. This will enable the A/
V amplifier to switch both video and audio.
Configuration of Home-Cinema with the
RGB to Component Converter.
