Jabra FreeSpeak FS258 User manual

JABRA FS258
USER MANUAL

2

English
1. Check phone compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Charge JABRA
®
FS258 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Read the glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. “Pair” to your Bluetooth
™
phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. Turning headset on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. Choosing wearing preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7. Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
8. Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
9. Answering a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
10. Call-waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
11. Resetting the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
12. Tips for Nokia Bluetooth phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
13. Enhanced features (for Bluetooth phones with hands-free profiles) . . 10
14. Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
15. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
16. Storage of headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
17. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
18. Warranty and parts replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
19. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3
English

English
1Blue Indicator Light
2Multi-Function Button
3Volume Control Button
4Charging Cradle
5MiniGel
™
4
5
3
2
1
4
STOP: BEFORE USING YOUR HEADSET
The JABRA FS258 is compatible with most Bluetooth
1
(see Glossary)phones
that are compliant with Bluetooth version 1.1 or higher specification and
support the headset and/or hands-free profile(s)
2
.Ensure that your phone has
Bluetooth capability by either visiting your phone manufacturer’s web site or
JABRA’s web site at www.jabra.com
JABRA also provides Bluetooth headsets for most non-Bluetooth phones.
JABRA FS258 uses a rechargeable battery that must be charged fully before
you use the headset for the first time.
1. Fully insert the headset into the charging cradle.
2. Plug the JABRA FS258 AC adaptor into the headset’s charging cradle.
3. Plug the AC adaptor into the electrical outlet.
4. Charge your headset until the blue light on JABRA FS258 turns off. The unit
will be fully charged in approximately 2 hours.
Charge JABRA FS258
2
4
Check phone compatibility
1

5
5. Unplug the AC adaptor from the charging cradle.
6. Remove the headset from the charging cradle. You are now ready to “pair”
JABRA FS258 to your mobile phone. If the headset has already been paired
to your phone, then you can begin using it.
WARNING: Do not attempt to charge JABRA FS258 with anything other
than the AC adaptor provided. Using another AC adaptor may damage or
destroy the headset.
IMPORTANT: The blue indicator light will be on while charging and will turn
off when charging is complete. Removing the headset from the charging
cradle while it’s charging will put the headset into standby mode and stop the
charging sequence.
IMPORTANT: JABRA FS258 cannot be used while charging.
Read the glossary at the end of this document to familiarize yourself with
important terms used in this User Manual.
Once JABRA FS258 is fully charged,continue with these instructions.
Read the glossary
3
1
2
3
4
5
6
Fig. 1
English

6
English
Pairing
3
will create a unique and encrypted wireless link between
two Bluetooth-enabled devices such as your Bluetooth phone and
JABRA FS258.
1. Ensure the headset is off (see Turning
headset on/off section).
2. Press and hold until you see a solid
blue light (approximately 8 seconds),
then release* (see Fig. 2).
3. Set your Bluetooth phone to “discover”
the headset by following your phone’s
instruction guide. Typically, the steps
involve going to a “setup”,“connect”,
or “Bluetooth” menu on your phone
and then selecting the option to
“discover” a Bluetooth device.
4. Your phone will find the “JABRA 250”
headset and ask if you want to pair
with it. Confirm this by pressing “yes”
or “ok”.
5. Enter passkey or PIN
4
= 0000 (4 zeros),then press “yes” or “ok”.
IMPORTANT: If pairing was successful, the blue indicator light will briefly flash
rapidly before going back to flashing every 3 seconds.If unsuccessful, the light
remains solid, and you’ll need to reattempt pairing (see steps 3–5 above).
* If you have a Bluetooth phone that supports the hands-free Bluetooth
profile, see Enhanced features section for alternative pairing
instructions. Phone-specific pairing instructions can be found online at
www.jabra.com/fscs
“Pair” to your Bluetooth phone
4
Fig. 2
Fig. 3

BASIC OPERATIONS
Turning headset on/off
5
What you hear
Quick series of 2tones –
low to high pitch (when
active mode starts)
Quick series of 2tones –
high to low pitch (when
standby mode starts)
3 beeps every 30 seconds
3 beeps every 5 minutes
Status
Active Mode5
•Call in progress
•Up to 8 hours of talk-time*
Standby Mode6
•Waiting for call
•Up to 240 hours of
standby time*
Low Battery
(in active mode)
•3–5 minutes of talk time left
Low Battery
(in standby mode)
•3–5 minutes of talk time left
What you see
Flashes every
second
Flashes every
3 seconds
3 flashes every
second
3 flashes every 3
seconds
What you do
Press and hold for
3 to 5 seconds until you
see a burst of flashes on
the blue indicator light,
then release
Press and hold for
3 to 5 seconds until you
see a burst of flashes on
the blue indicator light,
then release
What you hear
Ascending
(low-to-high)
tones
Descending
(high-to-low)
tones
Turning
headset
on
Turning
headset
off
What you see
The blue indicator
light will flash
while the power is
on (see Status
indicators table
below)
The blue indicator
light will stop
flashing
Status indicators
* Depending on phone type and usage.
7
English

IMPORTANT: Do not hold the button down for more than 3 to 5 seconds
when turning the headset on or else it may go into pairing mode, and the blue
indicator light will turn solid.If that happens, turn off the headset, wait 3 to 5
seconds, and repeat process for turning the headset on.
FS258 is ready to wear on the right ear. If
you prefer the left, gently rotate the
MiniGel 180°.
For optimal performance, wear FS258
and your Bluetooth phone on the same
side of your body. In general, you will
get better performance when there are
no obstructions (including parts of your
body) between the headset and the
phone.
If JABRA FS258 is off, turn it on now (see Turning headset on/off section).
Using phone’s keypad
1. Dial number on keypad.
2. Press phone’s “send” key.
Using voice-activated dialing (after you’ve set up voice tags on your phone)
1. Press and release once.You’ll hear 1short beep while doing this.
2. You’ll then hear the voice-activation tone; say the name of the person you
wish to call.
NOTE: Record voice tag from headset for better reception.
8
English
Making a call
7
Choosing wearing preference
6
Fig. 4

•Press and release once.
OR
•End call from phone’s keypad.
•After you hear the ring tone, press and release once.
OR
•Answer the call with your phone’s keypad.You may then need to transfer the
call to the headset by pressing and releasing once (depending on your
phone).
•(Recommended) Use standard method from your phone’s keypad which
typically involves pressing the “send” button
OR
•Press and release once to answer the incoming call and toggle between
calls (some phones do not support this headset feature).
IMPORTANT: Do not hold the button down too long when making, ending,
or answering a call.This should only be a quick tap, so you don’t put the
headset into pairing mode by accident.
Call-waiting*
10
Answering a call
9
* See Enhanced features section for alternative call-waiting instructions
for phones that support the hands-free profile.
9
Ending a call
8
English

10
English
TIPS AND SOLUTIONS
If the headset is not responding or the blue light will not turn on or off
after pairing, you may need to RESET your headset.
1. Fully insert the headset into the charging cradle.
2. Plug the JABRA FS258 AC adaptor into the headset’s charging cradle.
3. Plug the AC adaptor into the electrical outlet.
4. Leave the headset in the charging cradle for about 3 seconds, then remove
the headset (see Fig. 1).
5. Unplug the AC adaptor from the charging cradle.
(Such as Nokia 6310 and 8910 series)
Please ensure that the headset is allowed by the phone to connect without
authorization. To do this, you must adjust your phone’s settings.
Set the following menu options:
•Menu > Bluetooth > View Paired Devices > select your headset,
press “Options” > Request conn. authorization? — No
Tips for Nokia Bluetooth phones
12
Enhanced features (for Bluetooth phones
with hands-free profiles)
13
Enhanced features are available for phones that support the hands-free
Bluetooth profile such as Nokia 3600, 3650, 6310, 6310i, 8910, 8910i,
Siemens S55 and S56.Check your phone’s instruction guide or contact
the phone manufacturer if you are not sure if your phone supports the
hands-free Bluetooth profile.
Resetting the headset
11

“Pairing” to a Bluetooth phone with hands-free profile:
1. Ensure headset is off (see Turning
headset on/off section).
2. Press and hold plus the volume up
button until you see a solid blue light
(approximately 8 seconds), then
release (see Fig. 5).
3. Set your Bluetooth phone to “discover”
the headset by following your phone’s
instruction guide. Typically, the steps
involve going to a “setup”,“connect”,or
“Bluetooth” menu on your phone and
then selecting the option to “discover”
a Bluetooth device*.
4. Your phone will find the “JABRA 250”
headset and ask if you want to pair with
it. Confirm this by pressing “yes” or “ok”.
5. Enter passkey or PIN = 0000 (4 zeros),then press “yes” or “ok”.
IMPORTANT: If pairing was successful, the blue indicator light will briefly flash
rapidly before going back to flashing every 3 seconds.If unsuccessful, the light
remains solid, and you’ll need to reattempt pairing (see steps 3–5 above).
* Phone-specific pairing instructions and the most current list of phones
with hands-free profile can be found online at www.jabra.com/fscs
Fig. 6
11
Fig. 5
English
You can enable these enhanced features by using the following
alternative pairing sequence.

Once you’re done pairing, the following new headset features will be available:
•Last number redial (when not on a call)
While the headset is on, press and hold until you hear 2short beeps,
release immediately.
•Rejecting an incoming call (when not on a call)
When your phone rings, press and hold until you hear 2short beeps,
release immediately.
•Call-waiting (swapping between 2 calls)
When your phone notifies you of another incoming call while you’re on a
call, press and hold until you hear 2short beeps, release immediately.
•Putting a call on hold
While you’re on a call, press and hold until you hear 2short beeps, release
immediately. Repeat to retrieve the call.
1. How far away from my phone will my JABRA FS258 work?
The operating range is typically up to 30 feet (10 metres).
2. Will JABRA FS258 work with my cordless phone at home?
JABRA FS258 is not designed for use with cordless phones.
3. Will JABRA FS258 work with laptops, PCs, and PDAs?
JABRA FS258 will work with devices that are compliant with Bluetooth version
1.1 or higher specifications and support the headset and/or hands-free
profile(s).
4. Will anything cause interference with my conversation when I’m using
my JABRA FS258?
Appliances such as cordless phones and wireless networking equipment
may cause interference with your conversation, usually adding a crackling
noise. To reduce any interference, keep the headset away from other
devices that use or produce radio waves.
12
English
Frequently asked questions
14

5. Will my JABRA FS258 interfere with my car’s electronics, radio, or
computer?
JABRA FS258 produces significantly less power than a typical mobile
phone. It also only emits signals that are in compliance with the
international Bluetooth standard. Therefore, you should not expect any
interference with standard consumer-grade electronics equipment.
6. Can other Bluetooth phone users hear my conversation?
When you pair your headset to your Bluetooth phone, you are creating a
private link between only these two Bluetooth devices. The wireless
Bluetooth technology used in your headset is not easily monitored by third
parties because Bluetooth wireless signals are significantly lower in radio
frequency power than those produced by a typical mobile phone.
7. What material is the headset made of?
The MiniGel is made of PVC (polyvinyl chloride), a form of plastic.The
headset itself is primarily made of thermoplastic polyurethane, which is a
soft plastic. The face of the headset, where the buttons are located, is made
of polycarbonate, a very strong, hard plastic. Neither the MiniGel nor the
headset contains latex.
8. How do I take care of JABRA FS258?
•To clean the headset, use a clean, soft cloth that is slightly damp.
•To clean the MiniGel, remove it from the headset by gently lifting and
pulling it off the speaker housing.Then, wash it in warm, soapy water.
1. Web: www.jabra.com/fscs (for the latest support info and online User Manuals)
2. E-mail: [email protected]
Need more help?
15
13
English

English
14
1. Always store the JABRA FS258 with power off and safely protected.
2. Avoid storage at high temperatures (above 60°C / 134°F) – such as in a hot
vehicle or in direct sunlight. (Storage at high temperatures can degrade
performance and reduce battery life).
3. Do not expose the headset or any of its supplied parts to rain or other liquids.
This product is CE marked according to the provisions of the R & TTE
Directive (99/5/EC).
Hereby, GN Netcom, declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
For further information please consult http://www.gnnetcom.com
Users are not permitted to make changes or modify the device in any way.
Changes or modifications not expressly approved by JABRA (GN Netcom)
will void the user’s authority to operate the equipment.
Bluetooth is a trademark owned by the Bluetooth SIG, Inc.
JABRA (GN Netcom) warrants this product against all defects in material
and workmanship for a period of one year from the date of original purchase.
Warranty and parts replacement
18
Storage of headset
16
Certification and safety approvals
17

The conditions of this warranty and our responsibilities under this warranty
are as follows:
•The warranty is limited to the original purchaser.
•A copy of your receipt or other proof of purchase is required.Without proof
of purchase, your warranty is defined as beginning on the date of
manufacture as labeled on the product.
•The warranty is void if the serial number, date code label or product label is
removed, or if the product has been subject to physical abuse, improper
installation, modification, or repair by unauthorized third parties.
•The responsibility of JABRA (GN Netcom) products shall be limited to the
repair or replacement of the product at its sole discretion.
•Any implied warranty on JABRA (GN Netcom) products is limited to one year
from the date of purchase on all parts, including any cords and connectors.
•Specifically exempt from any warranty are limited-life consumable
components subject to normal wear and tear, such as microphone
windscreens, ear cushions, decorative finishes, batteries, and other accessories.
•JABRA (GN Netcom) is not liable for any incidental or consequential
damages arising from the use or misuse of any JABRA (GN Netcom) product.
•This warranty gives you specific rights and you may have other rights which
vary from area to area.
•Unless otherwise instructed in the User Manual, the user may not, under any
circumstances, attempt to perform service, adjustments or repairs on this
unit, whether in or out of warranty. It must be returned to the purchase
point, factory or authorized service agency for all such work.
•JABRA (GN Netcom) will not assume any responsibility for any loss or
damage incurred in shipping. Any repair work on JABRA (GN Netcom)
products by unauthorized third parties voids any warranty.
15
English

16
English
1Bluetooth is a radio technology developed to connect devices, such as mobile
phones and headsets, without wires or cords over a short distance of
approximately 10 metres. More information is available at www.bluetooth.com
2Bluetooth profiles are protocols through which Bluetooth devices
communicate with other devices. Bluetooth phones support different sets
of profiles – most support the headset profile but some support the hands-
free profile and others support both profiles. In order to support a certain
profile, a phone manufacturer has to implement certain mandatory features
within the phone’s software.
3Pairing creates a unique and encrypted communication link between two
Bluetooth-enabled devices and allows them to communicate with each
other. Bluetooth devices will not work if the devices have not been paired
with each other.
4Passkey or PIN is a secret code that needs to be entered on the phone in
order to pair the mobile phone with FS258. When you have already paired
your mobile phone with FS258, the phone and headset will recognize each
other and the phone will bypass the discovery and authentication process
and automatically accept the transmission.
5Active mode is when the headset has an active call in progress. FS258 will
go from standby mode into active mode when you receive a call or when
you make a call. When FS258 is in active mode, the blue light will flash every
second.
6Standby mode is when the headset is passively waiting for a call. When
you “end” the call on your mobile phone, FS258 will go into standby mode.
When FS258 is in standby mode, the blue light will flash every three
seconds.
Glossary
19

17

4
5
3
2
1
4
18
1

19
1
2
3
4
5
6

20
