© 2010 Jacuzzi Luxury Bath • For additional information call Customer Service 800-288-4002 • www.jacuzzi.com/technicalspecs
Refer to installation instructions included with xture before beginning installation. Please conrm product availability and specications before commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY ARE SUBJECT TO CHANGE WITHOUT NOTICE.
TECHNICAL SPECIFICATIONS
FEATURES, UPGRADES & ACCESSORIESKEY DIMENSIONS
INSTALLATION NOTES
Refer to installation instructions included with
xture before beginning installation. Please conrm
product availability and specications before
commencing with any installation work.
PRODUCT SPECIFICATIONS AND AVAILABILITY
ARE SUBJECT TO CHANGE WITHOUT NOTICE.
• Right and Left Hand Drain Location
• Accessories / Hardware:
Trip-Lever Drain Kit #X559
Rotary Drain Kit, 26” Cable #8730
TheraPro Jet Trim Kit: #GU44
AccuPro Jet Trim Kit: #GU45
• Trim Kit Finishes Available:
(827) – Chrome
(826) – Brushed Nickel
(845) – Oil Rubbed Bronze
DIMENSIONS
66” L x 34” W x 20” H
(1676 mm) L x (864 mm) W x (508 mm) H
DRAIN/OVERFLOW
A: 15-¼” (387 mm) B: 8-⅜” (213 mm)
CUTOUT
64” x 32”
TOTAL WEIGHT
F946, F947: 823 lb (373 kg) / 53 lb/sq. ft. (258 kg/m2)
F948: 798 lb (362 kg) / 51 lb/sq. ft. (250 kg/m2)
OPERATING GALLONAGE
58 U.S. Gal. (220 Liters)
PRODUCT WEIGHT
F946, F947: 90 lb (41 kg)
F948: 65 lb (29 kg)
SKIRT MOUNTING
Optional, U-Frame: P/N F956
ELECTRICAL SPECIFICATIONS MODELS F946, F947 ONLY
Requires a dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 15 AMP, 60 Hz.
RapidHeat™: 120 VAC, 15 AMP, 60 Hz.
HEATER (OPTIONAL) MODELS F946, F947 ONLY
Requires a dedicated GFCI protected separate circuit.
RapidHeat™: P/N S750000
Product Shown: Luxura 5 Whirlpool Bath Left Hand
Model: F946
* Measurements inside unit represent cutout in
oor to allow for drain/overow.
Luxura® 5.5 Whirlpool Bath
LUX6634 WRL 2XX Luxura 5.5 Whirlpool Bath Right Hand
(F947)
LUX6634 WLR 2XX Luxura 5.5 Whirlpool Bath Left Hand
(F946)
Luxura® 5.5 Bath
LUX6634 BUX XXX Luxura 5.5 Bath (F948)
END VIEW
H
W
SIDE VIEW
L
2"
DRAIN/OVERFLOW
A
B
12" x 5"
2-1/2"
*66"
17"
34"
8-3/8"
Motor
12" H x 18"L
Service Access
Opt. Service Access
2-1/2"
5-3/8"
