Jacuzzi PowerActive Swim Spa Series User manual

PowerActiveTM Swim Spa
PowerProTM Swim Spa
PowerActiveTM Swim Spa 50A
240VAC
60A
60Hz
4
NORTH AMERICAN MODELS (60 Hz)
PowerProTM Swim Spa
Terminal Block Connections
1. Neutral wire connection (blue)
2. Hot wire connection (brown)
3. Bonding Lug / GroundingTerminal
4. Power wires entrance
(Electrical tting and conduit
must be installed)

240 VOLT 60 HZ THREE PHASE GFCI WIRING
240 VOLT 60 HZ SINGLE PHASE GFCI WIRING
240 VOLT 60 HZ DUAL PHASE GFCI WIRING

230 VOLT 50 HZ THREE PHASE RCD WIRING
230 VOLT 50 HZ SINGLE PHASE RCD WIRING
230 VOLT 50 HZ DUAL PHASE RCD WIRING

(5.59 m) 558.8 cm. (220 inches) Length of the Jacuzzi
®
PowerActive
TM
Swim Spa
Sono Tube** with re-bar and
poured concrete in cavity space.
Ground
Level
Ground
Level
134 cm. (52.75 inches)
Height of the 2020 Jacuzzi
®
PowerActive
TM
Swim Spa
Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone
(1.8542 cm to 2.54 cm stone size)
11.43 cm
(4.5 inches)

(5.59 m) 558.8 cm. (220 inches) Length of the
Jacuzzi®PowerActiveTM Swim Spa
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®PowerActiveTM Swim Spa
Concrete Pad
Electrical Conduit Electrical Conduit
Electrical Conduit
24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)24 inches (60.96 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)
16 inches
(40.64 cm)

(5.59 m) 558.8 cm. (220 inches)s
Length of the Jacuzzi®PowerActiveTM Swim Spa
60.96 cm.
(24 inches)
Wide
Crawl Way
60.96 cm.
(24 inches)
Wide
Crawl Way
Sump Pump
with Float Hollow concrete block with re-bar and
poured concrete in cavity space
French Drain or
Gravel Drain
Pit Access
or Servicec
Area
91.44 cm.
(36 inches)
Wide
Crawl Way
91.44 cm.
(36 inches)
Wide
Crawl Way
260.96 cm.
(24 inches)
Wide
Crawl Way
60.96 cm.
(36 inches)
Wide
Crawl Way
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®
PowerActiveTM Swim Spa

60.96 cm.
(24 inches) Wide
Crawl Way
60.96 cm.
(24 inches) Wide
Crawl Way
60.96 cm.
(24 inches) Wide
Crawl Way
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
60.96 cm.
(24 inches) Wide
Crawl Way
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®PowerActiveTM Swim Spa
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®PowerActiveTM Swim Spa
Ground
Level
Ground Level
(1.34 m)134 cm. (52.75 inches)
Height of the 2020 Jacuzzi®
PowerActiveTM Swim Spa
(1.34 m)134 cm. (52.75 inches)
Height of the 2020 Jacuzzi®
PowerActiveTM Swim Spa
Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone
1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size
Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone
1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size
11.43 cm
(4.5 inches)
11.43 cm
(4.5 inches)
60.96 cm.
(24 inches) Wide
Crawl Way
60.96 cm.
(24 inches) Wide
Crawl Way
60.96 cm.
(24 inches) Wide
Crawl Way
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
Steel
Frame
Support
60.96 cm.
(24 inches) Wide
Crawl Way
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®PowerActiveTM Swim Spa
(2.36 m) 236 cm. (93 inches)
Width of the Jacuzzi®PowerActiveTM Swim Spa
Ground
Level
Ground Level
(1.34 m)134 cm. (52.75 inches)
Height of the 2020 Jacuzzi
®
PowerActiveTM Swim Spa
(1.34 m)134 cm. (52.75 inches)
Height of the 2020 Jacuzzi®
PowerActiveTM Swim Spa
Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone
1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size
Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of crushed stone
1.8542 cm. to 2.54 cm. (.75 to 1 inch) stone size
11.43 cm
(4.5 inches)
11.43 cm
(4.5 inches)

Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of
crushed stone 1.8542 cm to 2.54 cm (.75 to 1 inch)
stone size
(5.59 m) 558.8 cm. (220 inches)
Length of the Jacuzzi®PowerActiveTM Swim Spa
134 cm. (52.75 inches)
Height of the Jacuzzi®
PowerActiveTM Swim Spa
2ft.*
(60.96 cm)
Wide
Crawl Way
3ft.*
(91.44 cm)
Wide Service Area
11.43 cm
(4.5 inches)

Minimum 10.16 cm (4 inches) thick concrete slab
with reinforced wire mesh
Minimum 20.3 cm - 25.4 cm (8-10 inches) of
crushed stone 1.8542 cm to 2.54 cm (.75 to 1 inch)
stone size
(5.59 m) 558.8 cm. (220 inches)
Length of the Jacuzzi®PowerActiveTM Swim Spa
134 cm. (52.75 inches)
Height of the Jacuzzi®
PowerActiveTM Swim Spa
2ft.*
(60.96 cm)
Wide
Crawl Way
3ft.*
(91.44 cm)
Wide Service Area
11.43 cm
(4.5 inches)
