Jaeger-leCoultre MASTER CONTROL CHRONOGRAPH CALENDAR User manual

Contents
Introduction 21
Accuracy and precautions for use 21
Water resistance 22
“1000 Hours Control” test 24
Technical specifications 25
Movement 26
Use 26
International Guarantee 32
Limited Warranty 36
(United States of America and Canada)
Guarantee for Australia 40
Jaeger-LeCoultre Customer Service 44
ENGLISH

20
1Month
2Minute hand
3Push-piece A: chronograph start/stop
4Corrector A: Setting the month
5Crown: Setting the time
6Corrector B: Setting the date
7Push-piece B: Chronograph resetting
8Chronograph minute counter
9Date
10 Moon Phases
11 Corrector C: Setting the moon phase
12 Seconds display
13 Pulsometric scale
14 Hour hand
15 Day
16 Corrector D: Setting the day
17 Chronograph seconds hand
1
2
3
4
5
6
7
8
9
16
17
14
13
12
11
10
15

21
Introduction
We would like to thank you for the confidence
you have placed in Jaeger-LeCoultre. Our Mai-
son has applied all its expertise and exacting
standards to the creation of this model.
We invite you to consult the operating instruc-
tions and hope your Jaeger-LeCoultre time-
piece brings you great joy.
Accuracy and precautions for use
MANUALLY-WOUND OR AUTOMATIC
MECHANICAL WATCHES
The accuracy of watch models with mechan-
ical movements is determined by the balance
wheel. This oscillates at a rate of 28,800 vi-
brations per hour. Despite all the care that the
master watchmakers of the Jaeger-LeCoultre
Manufacture have lavished on building and as-
sembling your watch, its accuracy is subject to
the influence of gravity, magnetic fields, acci-
dental impacts, and the ageing of the oils. The
accuracy of a watch is measured by its regular-
ity of rate in various positions.
ENGLISH

22
Your individual activities could be the cause of
slight irregularities in the working of your time-
piece. If you observe a discrepancy in the way
your watch runs, we advise you to entrust it to
an authorised Jaeger-LeCoultre retailer who
will make the necessary adjustments. Watches
with mechanical movements must not be used
for sports involving significant risk of impact or
abrupt actions, such as golf or tennis.
Water resistance
Your Jaeger-LeCoultre watch is water resistant
up to 5 bar. Its water resistance can be identi-
fied by the symbol and/or the engraving:
“5 bar” on the case-back. This means that your
model has been tested at an overpressure of 5
bar, corresponding to an immersion pressure of
50 metres (1 bar = ±10 metres).
In accordance with the ISO 22810/NIHS 92-20
standard, in order to guarantee the durability
of the watch’s characteristics over time, and as
water resistance may be aected by certain ac-
tivities, it is recommended that you:

23
- have the watch’s water resistance checked
by an authorised Jaeger-LeCoultre retailer
at least once every two years. It is essential
to have such a check carried out each time
your watch is opened, and before any period
in which it is liable to undergo prolonged and/
or regular immersions.
- check when making the purchase that the
bracelet is suitable for the intended use.
- avoid subjecting the watch to excessively
abrupt temperature changes.
- protect the watch from being dropped or suf-
fering other accidental impacts, and have the
water resistance checked after any severe im-
pact.
- avoid using the controls, push-piece, or
time-setting crown while under water, or out-
side the water, if the watch is not yet dry after
immersion.
- restore the time-setting crown and the
push-pieces to their normal positions, or
where applicable, close the compression keys,
after every manipulation.
ENGLISH

24
- rinse the watch with fresh water after use in
sea water.
You may use your watch while swimming as
long as you do not exceed the immersion pres-
sure and do not engage in any water sports
that could cause impacts. This watch is not a
piece of diving equipment and should not be
used as such. Also, note that leather straps are
not suited for aquatic activities.
“1000 Hours Control” test
The Jaeger-LeCoultre Manufacture pays close
attention to the quality and to the final checks
of its watches.
The 1000 Hours Control is a series of internal
qualification tests for each of the models in our
collection, as well as internal tests on the pro-
duction of your watch, which go beyond ocial
timing tests. These tests include checks of the
movement before and after being cased up in
the watch and cover the whole watch once it
has been assembled, in the conditions closest
to daily wear.

25
The “1000 Hours Control” legend, or the “ ”
seal engraved on the back of the watch certi-
fies that each of the models from our collection
has successfully undergone all of the qualifica-
tion tests, and that your watch has successful-
ly undergone all of the production tests. These
ensure regularity of rate, resistance to varia-
tions in temperature and atmospheric pressure,
ability to withstand shocks and magnetic fields,
as well as water resistance.
Technical specications
- Automatic mechanical movement,
Jaeger-LeCoultre Calibre 759.
- 28,800 vibrations/hour.
- Power reserve: approximately 65 hours.
- Water-resistant to 5 bar.
ENGLISH

26
Movement
Jaeger-LeCoultre Calibre 759
Use
0
A
B
D
C
1
STARTING THE WATCH
Crown in position 0.

27
A few clockwise turns of the crown are enough
to start your watch.
It will then automatically wind up when you
wear it. Please note that the crown does not
lock when winding, even when the watch is
fully wound.
SETTING THE TIME
Pull the crown out to position 1.
The movement is then locked ("stop seconds"
function). To enable precise time-setting to
the nearest second, stop the seconds hand at
60. Move the hands forward clockwise to the
desired time and, on the hour signal, push the
crown back to position 0. The watch starts
running again.
SETTING THE DAY, DATE, MONTH, AND
MOON PHASE
The day, date, month, and moon-phase
adjustments can be carried out by pressing
the correctors A, B, C and D using the stylus
provided with your watch.
ENGLISH

28
SETTING THE DAY
Press corrector D at 10 o’clock.
Each press moves the disc one day forward.
SETTING THE DATE
Press corrector B at 4 o’clock.
Each press moves the date hand one day
forward.
For months with fewer than 31 days, repeat this
process to reach the 1st of the following month.
SETTING THE MONTH
Press corrector A at 2 o’clock.
Each press moves the disc one month forward.
SETTING THE MOON PHASE
Press corrector C at 8 o’clock.
Each press moves the disc one day forward.
To ensure correct adjustment, calculate the
number of days that have elapsed since the last
full moon using the calendar at the end of this
user manual. Centre the moon in the aperture,
then move the disc forwards according to the
number of days that have elapsed since the last
full moon.

29
Note: date, day, month or moon phase cor-
rections should not be performed between
10 p.m. and 2 a.m. This is because the auto-
matic date-change mechanism is already in
action between these times.
OPERATING THE CHRONOGRAPH
The central seconds hand on the Master
Control Chronograph Calendar displays the
chronograph seconds to the nearest quarter of
a second.
The counter located at 3 o’clock tallies the
minutes up to 30 minutes (after 1 revolution it
will start counting another 30 minutes).
- Push-piece at 2 o’clock: this push-piece starts
and stops the chronograph function.
- Push-piece at 4 o’clock: This push-piece
resets the 30 minute counter and the central
seconds hand.
Note: When timing is in progress, resetting
is not possible. This push-piece is locked
and forcing it may harm the mechanism’s
functioning.
ENGLISH

30
To safely reset the chronograph, timing must
be stopped first using the push-piece at 2
o’clock.
TIMING
- The chronograph is activated by pressing
the push-piece at 2 o’clock once. The central
seconds hand will turn, and the minute counter
will run. Pressing the push-piece at 2 o’clock
again will stop the chronograph, enabling the
time measurement to be read.
- Reset by pressing the push-piece at 4
o’clock to be ready to perform another time
measurement.
- It is possible to add up several timing
operations by pressing on the push-piece at
2 o’clock again (without having to reset the
counter). Timing starts again and is added to
the previous measurement.
PULSOMETER
The pulsometer is an instrument for measuring
heartbeat frequency. The Master Control

31
Chronograph Calendar watch’s internal flange is
equipped with a pulsometric scale which allows
you to measure the frequency of heartbeats
per minute.
Use:
- Reset the seconds hand by pressing the push-
piece at 4 o’clock to be ready to perform the
measurement.
- Press once on the push-piece at 2 o’clock to
measure 30 heartbeats. The seconds hand
turns (the minute counter is also in operation
but is not used for pulsometer measurement).
- After 30 heartbeats, press the push-piece at 2
o’clock again to stop the chronograph.
- Read the frequency of heartbeats per minute
indicated by the seconds hand on the
pulsometric scale on the flange.
ENGLISH

32
Jaeger-LeCoultre watches
In order to benefit from the International Guar-
antee and/or the Limited Warranty and/or the
Manufacturer’s Guarantee for Australia, Jaeger-
LeCoultre products must be purchased exclu-
sively from authorised Jaeger-LeCoultre retail-
ers or from Jaeger-LeCoultre Boutiques. Main-
tenance and repair work must be entrusted
to an authorised Jaeger-LeCoultre retailer, a
Jaeger-LeCoultre Boutique, or an authorised
Jaeger-LeCoultre Service Centre. If these con-
ditions are not met, the manufacturer’s guar-
antee does not apply. Please contact Jaeger-
LeCoultre to obtain the list of authorised Jaeger-
LeCoultre retailers across the world.
International Guarantee
The International Guarantee applies to Jaeger-
LeCoultre products sold or presented for
guarantee repairs in all countries, except the
United States of America and Canada (for
these two countries, see the Limited Warranty)

33
and Australia (for this country, refer to the
Guarantee for Australia).
TERMS AND CONDITIONS OF
THE J AEGER-LE C OULTRE
INTERNATIONAL GUARANTEE
Your Jaeger-LeCoultre watch is guaranteed to
protect against all manufacturing defects for
two years from the date of purchase, subject
to the following conditions. Any part found by
our technical services to be defective as a re-
sult of a manufacturing defect will, at the sole
discretion of Jaeger-LeCoultre, be repaired or
replaced free of charge. The Jaeger-LeCoultre
International Guarantee is valid only if the guar-
antee certificate enclosed with this booklet
has been duly completed, dated, stamped, and
signed by the authorised Jaeger-LeCoultre re-
tailer or the Jaeger-LeCoultre Boutique, which
sold you your watch.
The Jaeger-LeCoultre International Guaran-
tee does not cover defects resulting from ac-
cidents, mishandling, or incorrect, abusive use
(for example, knocks, dents, crushing, excessive
ENGLISH

34
temperatures, powerful magnetic fields), the
use of or eect of using batteries other than
those designated by Jaeger-LeCoultre, unau-
thorised alteration or repair, the consequences
of normal wear and ageing of the watch, strap,
or glass, the loss of water resistance after two
years from the date of purchase, if your watch
is water-resistant, or any defect resulting from
contact with water, if your watch is not water-
resistant.
Jaeger-LeCoultre water-resistant watches can
be identified by the symbol and/or by
“3, 5, 10, or 20 bar” (or another number de-
pending on the model) engraved on the case-
back. Their water resistance is guaranteed for
two years from the date of purchase, provid-
ed that the glass, bezel, back, middle part, and
crown have not been damaged. It is neverthe-
less essential to have the water resistance of
your watch checked at least once every two
years, and in any event, prior to any period of
intensive use, either by an authorised Jaeger-
LeCoultre retailer, a Jaeger-LeCoultre Bou-
tique, or authorised Jaeger-LeCoultre Service

35
Centre (for further information please see your
User Manual).
For quartz watches, this guarantee does not
cover the battery life.
As a consumer, you may have legal rights un-
der applicable national legislation governing
the sale of consumer goods; those rights are
not aected by this guarantee.
ENGLISH

36
Limited Warranty (United States of
America and Canada)
The following Limited Warranty applies to
Jaeger-LeCoultre products sold or present-
ed for warranty repairs in the United States of
America and Canada only.
TERMS AND CONDITIONS OF THE J AEGER-
LE C OULTRE LIMITED WARRANTY
Your Jaeger-LeCoultre watch is guaranteed
against all manufacturing defects for two years
from the date of purchase, subject to the fol-
lowing conditions. Any part found by our tech-
nical services to be defective as a result of a
manufacturing defect will, at the sole discretion
of Jaeger-LeCoultre, be repaired or replaced
free of charge. The Jaeger-LeCoultre Limited
Warranty is valid only if the warranty certificate
enclosed with this booklet has been duly com-
pleted, dated, stamped, and signed by the au-
thorised Jaeger-LeCoultre retailer or the Jaeger-
LeCoultre Boutique, which sold you your watch.
This Jaeger-LeCoultre Limited Warranty does

37
not cover defects resulting from accidents,
mishandling, or incorrect, abusive use (for ex-
ample, knocks, dents, crushing, excessive tem-
peratures, powerful magnetic fields), the use
of or eect of using batteries other than those
designated by Jaeger-LeCoultre, unauthorised
alteration or repair, the consequences of nor-
mal wear and ageing of the watch, strap, or
glass, the loss of water resistance after two
years from the date of purchase, if your watch
is water-resistant, or any defect resulting from
contact with water, if your watch is not water-
resistant.
Jaeger-LeCoultre water-resistant watches can
be identified by the symbol and/or by
“3, 5, 10, or 20 bar” (or another number de-
pending on the model) engraved on the case-
back. Their water resistance is guaranteed for
two years from the date of purchase, provid-
ed that the glass, bezel, back, middle part, and
crown have not been damaged. It is neverthe-
less essential to have the water resistance of
your watch checked at least once every two
years, and in any event, prior to any period of
ENGLISH

38
intensive use, either by an authorised Jaeger-
LeCoultre retailer, a Jaeger-LeCoultre Boutique,
or authorised Jaeger-LeCoultre Service Centre
(for further information please see your User
Manual).
For quartz watches, this guarantee does not
cover the battery life.
Except insofar as prohibited by applicable law,
this Limited Warranty shall be the exclusive
manufacturer warranty. Neither this Limited
Warranty nor any other warranties, whether
expressed or implied, including, but not limit-
ed to, any implied warranty of merchantability
or of fitness for any particular purpose, shall
extend beyond the period of two years from
the date of purchase.
The liability of Jaeger-LeCoultre is limited
solely and exclusively to repair or replacement
under the terms and conditions stated herein.
Jaeger-LeCoultre shall not be liable, by virtue
of this Limited Warranty or otherwise, for any
loss or damage arising out of the use of or in-
ability to use this watch nor for any incidental
