Jaeger-leCoultre Reverso Grande Taille User manual

English
TABLE OF CONTENTS
Introduction
Accuracy
Water resistance
“1000 Hours Control” test
Adjusting the bracelet
Use
International Guarantee
Limited Warranty
(United States of America and Canada)
23
23
23
24
24
28
30
32

22
1 2
3
4
1Hour hand
2Minute hand
3Crown
4Small seconds hand

23
English
Introduction
We congratulate you on the acquisition of your Jaeger-LeCoultre watch, and
thank you for your confidence.
We invite you to consult the operating instructions and hope your Jaeger-
LeCoultre timepiece brings you great enjoyment.
Accuracy
Mechanical manually-wound or automatic watches
The precision of watch models with mechanical movements is determined by
the balance.The latter oscillates at a rate of 21,600 or 28,800 vibrations per hour.
Despite all the care that the master-watchmakers of the Manufacture Jaeger-
LeCoultre have lavished on building and assembling your watch, its accuracy is
subject to the influence of gravity, magnetic fields, impacts, as well as ageing of
the oils.The precision of a watch is measured by its regularity of rate in various
positions.
Your individual temperament and your activities may result in slight irregularities.
If you were to observe a discrepancy in the running of your watch, we advise
you to entrust it to an authorised Jaeger-LeCoultre retailers who will perform
the necessary adjustments.
Water resistance
Your Jaeger-LeCoultre watch is water-resistant to 3 atm. The water resistance
of your watch is identifiable by a symbol engraved on the back.This
means that your timepiece has been tested at an immersion pressure corre-
sponding to 30 metres, according to the number of atmospheres appearing next
to the above-mentioned symbol (1 atm = approx. 10 metres).
You may use your watch during short swims and when jumping in from the
edge of a swimming pool, but not from a diving board. Your watch must not
be used for scuba diving, nor for sports involving significant risk of impact, such
as windsurfing or water-skiing. Also note that leather straps are not suited to
aquatic activities.
It is vital to have the water resistance of your watch checked by an authorised
Jaeger-LeCoultre retailer before any period during which it is liable to undergo
prolonged and/or regular immersions.

24
“1000 Hours Control” test
Jaeger-LeCoultre submits all its watches to the stringent “1000 Hours Control”, a
unique battery of comprehensive and rigorous tests lasting a full 1000 hours.
The“1000 Hours Control” seal or legend placed or engraved on the back of your
watch certifies that the latter has undergone this programme of observation in
our laboratories and has successfully passed all the tests relating to regularity
of rate, temperature, atmospheric pressure, resistance to shocks and magnetic
fields, as well as water-resistance trials.Your watch is thus capable of withstanding
the daily stresses and strains that await it when worn on your wrist.
The criteria of the “1000 Hours Control” programme considerably exceed the
standards of official timing tests, which deal only with part of the movement.
Jaeger-LeCoultre tests not only the movement prior to its being cased up in the
watch, but also the watch as a whole.
Adjusting the bracelet
You can adjust your steel bracelet yourself. However, if you have a gold model,
we advise you to entrust it to the nearest approved Jaeger-LeCoultre retailer,
or to contact one of our official Service Centres listed at the end of this user
manual.
Adjusting the steel bracelet
Place the watch on your wrist. You can thus see how many links need to be
added or removed.
Remove your watch by simultaneously pressing the push-pieces on either side
of the clasp.
Hold the bracelet near the clasp. Using the adjustment tool, press the end of
the bar (fig. 1) and lift up the link (fig. 2). Avoid the 2 links on either side of the
clasp.

25
English
Proceed in the same way for the following link (fig. 3) if you want to remove
a single row of links (or the 2nd, 3rd, etc. if you want to remove 2, 3... rows of
links).
Take out the two bars (fig. 4).
Remove the row(s) of links (fig. 5).
Place the 2 ends of the bracelet back together and insert a bar (fig. 6).
Tip over the link, press on the end of the bar pivot and push your link down
until it clicks (fig. 7).
Fig. 5 Fig. 6
Fig. 3 Fig. 4
Fig. 1 Fig. 2

26
Adjusting the clasp
The clasp of your watch is fitted with a length-change system enabling you to
lengthen or shorten your bracelet by 4 mm on each side, for enhanced wearer
comfort.
Using the fine adjustment system
Transition from the long position to the short position:
Remove your watch.
Hold your clasp open between the thumb and forefinger of one hand, with the
bracelet section in your other hand (fig. 1).
Fig. 1
Fig. 7

27
Lift up the clasp cover so as
to release the tip-over part
of the bracelet section from
its groove (fig. 2).
Fig. 2 Long position
Push the tip-over part of
your bracelet section and
place it in its groove, facing
the opposite way to its ini-
tial position (fig. 3).
Fig. 3 Shortened position
The transition from the
short to the long position
is done in the same manner,
but in the opposite direc-
tion (fig. 4).
Fig. 4 Extended position
English

28
Technical characteristics
- Manually-wound mechanical movement, Calibre 822.
- 21,600 vibrations/hour.
- Power reserve: approximately 45 hours.
- Accuracy adjusted and tested in 5 positions.
Movement
Jaeger-LeCoultre Calibre 822.
Use
Winding
Crown in position 1.
Winding is performed by turning the crown clockwise.The watch is fully wound
when the crown locks.
Do not attempt to wind a manually-wound watch beyond the locking point.
To ensure good operating accuracy, it is advisable to wind your watch regularly,
at least once a day.

29
Setting the hour and minutes
Pull the crown out to position 2.
Move the hands clockwise until the desired time is displayed.
When the operation is completed, push the crown back to position 1.
English
1 2

30
International Guarantee
This International Guarantee applies to Jaeger-LeCoultre products sold or
presented for guarantee repairs in all countries except the United States of
America and Canada (for those two countries, see the Limited Warranty on
pages 32 to 34).
The manufacturer’s International Guarantee applies only to Jaeger-LeCoultre
products purchased from authorised Jaeger-LeCoultre retailers. In addition, all
maintenance and repair works must be carried out either by an authorised
Jaeger-LeCoultre retailer or by an official Jaeger-LeCoultre Service Centre. If
these conditions are not met, the manufacturer’s guarantee does not apply.
For a list of authorised Jaeger-LeCoultre retailers worldwide, please contact
Jaeger-LeCoultre or its Distributors.
Jaeger-LeCoultre watches
The terms and conditions of the Jaeger-LeCoultre International
Guarantee
The following terms and conditions of the Jaeger-LeCoultre International Guar-
antee apply to watches sold or presented for guarantee repairs in all countries
except the United States of America and Canada (for those two countries, see
the Limited Warranty on pages 32 to 34).
Your Jaeger-LeCoultre watch is guaranteed against all manufacturing defects for
two years from the date of purchase, subject to the following conditions.
Any part found by our technical services to be defective as a result of a manufac-
turing defect will, at the sole discretion of Jaeger-LeCoultre, be repaired or replaced
free of charge. Jaeger-LeCoultre International Guarantee is valid only if the guaran-
tee certificate enclosed with this booklet has been duly completed,dated, stamped
and signed by the authorised Jaeger-LeCoultre retailer who sold your watch.
This International Guarantee does not cover defects resulting from accidents,
mishandling or incorrect or abusive use (for example, knocks, dents, crushing,
excessive temperatures, powerful magnetic fields), the use of or effect of using
batteries other than those designated by Jaeger-LeCoultre, unauthorised altera-
tion or repair or the consequences of normal wear and ageing of the watch, the
strap or the glass, the loss of water resistance after two years after the date of
purchase if your watch is water-resistant, and any defect resulting from the con-
tact with water if your watch is not water-resistant.

31
Jaeger-LeCoultre water-resistant watches may be identified by the symbol
engraved on the back. Their water resistance is guaranteed for two
years from the date of purchase, provided that the glass, the bezel, the back,
the middle part and the crown have not been damaged. It is essential to have
the water resistance checked by an authorised Jaeger-LeCoultre retailer or an
official Jaeger-LeCoultre Service Centre at least once a year, and in any event,
prior to any period of intensive use. Please refer to the operating instructions
for further details.
For quartz watches, this guarantee does not cover the battery life.
As a consumer, you may have legal rights under applicable national legislation
governing the sale of consumer goods; those rights are not affected by this
guarantee.
Customer service at Jaeger-LeCoultre
The movement of a mechanical watch requires regular maintenance (servic-
ing, lubrication, etc.) to ensure a long operating life. Should your watch need
servicing or repairs, please send it, together with its guarantee certificate, to the
authorised Jaeger-LeCoultre retailer who sold it to you.
Alternatively, you may send it to one of the official Jaeger-LeCoultre Service
Centres listed at the end of this booklet, or to any authorised Jaeger-LeCoultre
retailer – a list is available on the “www.jaeger-lecoultre.com” website.
Our official Service Centres employ watchmakers trained at the Jaeger-LeCoultre
Manufacture and possess the tools and parts necessary to repair and maintain all
Jaeger-LeCoultre watches and clocks.
In certain cases, especially for operations requiring special tools and parts, the
Service Centres will send your watch to the Jaeger-LeCoultre Manufacture in
Switzerland to have the necessary work carried out.
In any case, or if you live in a country which is not indicated in our lists, please do
not hesitate to contact Manufacture Jaeger-LeCoultre in Switzerland, Rue de la
Golisse 8, 1347 Le Sentier, telephone [phone], fax [phone],
which will inform you of the procedure to follow.We also invite you to visit our
website“www.jaeger-lecoultre.com” for an updated list of official Jaeger-LeCoultre
Service Centres.
English

32
Limited Warranty (United States and Canada)
The following Limited Warranty applies to Jaeger-LeCoultre products sold or
presented for warranty repairs in the United States of America and Canada
only.
The manufacturer’s Limited Warranty applies only to Jaeger-LeCoultre products
purchased from authorised Jaeger-LeCoultre retailers. In addition,all maintenance
and repair works must be carried out either by an authorised Jaeger-LeCoultre
retailer or by an official Jaeger-LeCoultre Service Centre. If these conditions are
not met, the manufacturer’s Limited Warranty does not apply. For a list of au-
thorised Jaeger-LeCoultre retailers worldwide, please contact Jaeger-LeCoultre
or its Distributors.
Jaeger-LeCoultre watches
The terms and conditions of the Jaeger-LeCoultre Limited
Warranty
The following terms and conditions of the Jaeger-LeCoultre Limited Warranty
apply only to watches sold or presented for warranty repairs in the United
States of America and Canada.
Your Jaeger-LeCoultre watch is guaranteed against all manufacturing defects for
two years from the date of purchase, subject to the following conditions.
Any part found by our technical services to be defective as a result of a manu-
facturing defect will, at the sole discretion of Jaeger-LeCoultre, be repaired or
replaced free of charge.The Jaeger-LeCoultre Limited Warranty is valid only if
the warranty certificate enclosed with this booklet has been duly completed,
dated, stamped and signed by the authorised Jaeger-LeCoultre retailer who sold
your watch.
This Limited Warranty does not cover defects resulting from accidents, mishan-
dling or incorrect or abusive use (for example, knocks, dents, crushing, excessive
temperatures, powerful magnetic fields), the use of or effect of using batteries
other than those designated by Jaeger-LeCoultre, unauthorised alteration or re-
pair or the consequences of normal wear and ageing of the watch, the strap or
the glass, the loss of water resistance after two years from the date of purchase if
your watch is water-resistant, or any defect resulting from the contact with water
if your watch is not water-resistant.

33
Jaeger-LeCoultre water-resistant watches may be identified by the symbol
engraved on the back. Their water resistance is guaranteed for two
years from the date of purchase, provided that the glass, the bezel, the back,
the middle part and the crown have not been damaged. It is essential to have
the water resistance checked by an authorised Jaeger-LeCoultre retailer or an
official Jaeger-LeCoultre Service Centre at least once a year, and in any event,
prior to any period of intensive use. Please refer to the operating instructions
for further details.
For quartz watches, this guarantee does not cover the battery life.
Except insofar as prohibited by applicable law, this Limited Warranty shall be
the exclusive manufacturer’s warranty. Neither this Limited Warranty nor any
other warranties, whether express or implied, including, but not limited to, any
implied warranty of merchantability or of fitness for any particular purpose,
shall extend beyond the period of two years from the date of purchase.
The liability of Jaeger-LeCoultre is limited solely and exclusively to repair or
replacement under the terms and conditions stated herein. Jaeger-LeCoultre
shall not be liable, by virtue of this LimitedWarranty or otherwise, for any loss
or damage arising out of the use of or inability to use this watch nor for any
incidental or consequential damages relating in any way to this watch.
Some States, Provinces and Territories do not allow limitations on how long
an implied warranty lasts or the exclusion or limitation of incidental or con-
sequential damages, so the above limitations or exclusions may not apply to
you.
This Limited Warranty grants you specific legal rights, in addition to which you
may have other legal rights which vary from one Country, State, Province or
Territory to another.
Customer service at Jaeger-LeCoultre
The movement of a mechanical watch requires regular maintenance (servic-
ing, lubrication, etc.) to ensure a long operating life. Should your watch need
servicing or repairs, please send it, together with its warranty certificate, to the
authorised Jaeger-LeCoultre retailer who sold it to you.
Alternatively, you may send it to one of the official Jaeger-LeCoultre Service
Centres listed at the end of this booklet, or to any authorised Jaeger-LeCoultre
retailer – a list is available on the “www.jaeger-lecoultre.com” website.
English

34
Our official Service Centres employ watchmakers trained at the Jaeger-LeCoultre
Manufacture and possess the tools and parts necessary to repair and maintain all
Jaeger-LeCoultre watches and clocks.
In certain cases, especially for operations requiring special tools and parts, the
Service Centres will send your watch to the Jaeger-LeCoultre Manufacture in
Switzerland to have the necessary work carried out.
In any case, or if you live in a country which is not indicated in our lists, please
do not hesitate to contact Manufacture Jaeger-LeCoultre in Switzerland, Rue de
la Golisse 8, 1347 Le Sentier, telephone [phone], fax [phone]
50, which will inform you of the procedure to follow.We also invite you to visit
our website “www.jaeger-lecoultre.com” for an updated list of official Jaeger-
LeCoultre Service Centres.
