GRAVITY WAGON
OPERATOR’S MANUAL
MODEL
Manual

3
Table Of Contents
4....................................................................................To the Dealer
5.............................................................................General Information
5......................................................................... Serial Number Location
6.....................................................................................Safety Rules
7.................................................................. Specications and Dimensions
8..........................................................................................Decals
10 ......................................................................Bolt Torque Specications
11 ................................................................Initial Operation & Maintenance
12 .................................................................................... Lubrication
13 ....................................................................... Bleeding the Brake Lines
15 ........................................................................................Fenders
16 ..................................................................Tongue Assembly with Brakes
18 ...........................................................................24 Ton Running Gear
20 .................................................................................Shell Assembly
21 ..........................................................................Door Wheel Assembly
22 .................................................................................Door Assembly
24 .......................................................................................Roll Tarp
26 ....................................................13” Brake Assembly for 24 Ton Running Gear

4
TO THE DEALER
Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists are completed
before releasing equipment to the owner.
The dealer must complete the Warranty Registration found on the Dealer Portal website located at dealer.jm-inc.com and return it to J&M
Mfg. Co., Inc. at the address indicated on the form. Warranty claims will be denied if the Warranty Registration has not been submitted.
EXPRESS WARRANTY:
J&M Mfg. Co. Inc. warrants against defects in construction or materials for a period of ONE year. We reserve the right to inspect and
decide whether material or construction was faulty or whether abuse or accident voids our guarantee.
Warranty service must be performed by a dealer or service center authorized by J&M Mfg. Co., Inc. to sell and/or service the type of
product involved, which will use only new or remanufactured parts or components furnished by J&M Mfg. Co., Inc. Warranty service will
be performed without charge to the purchaser for parts or labor based on the Warranty Labor Times schedule. Under no circumstance
will allowable labor times extend beyond the maximum hours indicated in the Warranty Labor Times schedule for each warranty
procedure. The purchaser will be responsible, however, for any service call and/or transportation of the product to and from the dealer
or service center’s place of business, for any premium charged for overtime labor requested by the purchaser, and for any service and/or
maintenance not directly related to any defect covered under the warranty. Costs associated with equipment rental, product down time,
or product disposal are not warrantable and will not be accepted under any circumstance.
Each warranty term begins on the date of product delivery to the purchaser. Under no circumstance will warranty be approved unless (i)
the product warranty registration card has been properly completed and submitted to the equipment manufacturer, and (ii) a warranty
authorization number has been issued by the equipment manufacturer. This Warranty is eective only if the warranty registration card is
returned within 30 days of purchase.
This warranty does not cover a component which fails, malfunctions or is damaged as a result of (i) improper modication or repair, (ii)
accident, abuse or improper use, (iii) improper or insucient maintenance, or (iv) normal wear or tear. This warranty does not cover
products that are previously owned and extends solely to the original purchaser of the product. Should the original purchaser sell or
otherwise transfer this product to a third party, this warranty does not transfer to the third party purchaser in any way. J&M Mfg. Co.,
Inc. makes no Warranty, express or implied, with respect to tires or other parts or accessories not manufactured by J&M Mfg. Co., Inc.
Warranties for these items, if any, are provided separately by their respective manufacturers.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS, IMPLIED OR STATUTORY, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE.
In no event shall J&M Mfg. Co., Inc. be liable for special, direct, incidental or consequential damages of any kind. The exclusive
remedy under this Warranty shall be repair or replacement of the defective component at J&M Mfg. Co., Inc’s. option. This is the entire
agreement between J&M Mfg. Co., Inc. and the Owner about warranty and no J&M Mfg. Co., Inc. employee or dealer is authorized to
make any additional warranty on behalf of J&M Mfg. Co., Inc.
The manufacturer reserves the right to make product design and material changes at any time without notice. They shall not incur any
obligation or liability to incorporate such changes and improvements in products previously sold to any customer, nor shall they be
obligated or liable for the replacement of previously sold products with products or parts incorporating such changes.
SERVICE:
The equipment you have purchased has been carefully manufactured to provide dependable and satisfactory use. Like all mechanical
products, it will require cleaning and maintenance. Lubricate the unit as specied. Observe all safety information in this manual and
safety signs on the equipment.
For service, your authorized J&M dealer has trained mechanics, genuine J&M service parts, and the necessary tools and equipment to
handle all your needs.
Use only genuine J&M service parts. Substitute parts may void warranty and may not meet standards required for safety and satisfactory
operation. Record the model number and serial number of your equipment in the spaces provided:
Model No: 655/755 Gravity Wagon Serial No: ________________________ Date of Purchase: ______________________
Purchased From: ________________________________________________________________________________
Provide this information to your dealer to obtain correct repair parts.
To the Dealer

5
General Information
TO THE OWNER:
The purpose of this manual is to assist you in operating and maintaining your gravity wagon in a safe manner. Read it carefully. It furnishes
information and instructions that will help you achieve years of dependable performance and help maintain safe operating conditions. If
this machine is used by an employee or is loaned or rented, make certain that the operator(s), prior to operating:
1. Is instructed in safe and proper use.
2. Reviews and understands the manual(s) pertaining to this machine.
Throughout this manual, the term IMPORTANT is used to indicate that failure to observe can cause damage to equipment. The terms
CAUTION, WARNING and DANGER are used in conjunction with the Safety-Alert Symbol, (a triangle with an exclamation mark), to indicate
the degree of hazard for items of personal safety. When you see this symbol, carefully read the message that follows and be alert to the
possibility of personal injury or death.
DANGER
WARNING
CAUTION
This Safety-Alert symbol indicates a hazard and means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury,
and includes hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates that failure to observe can cause damage to equipment.
Indicates helpful information.
IMPORTANT
NOTE
Serial Number Location
Serial Number Location
Serial Number:________________________________
Model Number: 655/755 Gravity Wagon
Standard practice when ordering parts or obtaining information from your dealer requires the serial number and model number. Have
numbers available before making contact.

6
Safety Rules
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Safety is a primary concern in the design and manufacture of our products. Unfortunately, our eorts to provide safe equipment can
be erased by an operator’s single careless act. In addition, hazard control and accident prevention are dependent upon the awareness,
concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
Make certain that the operator(s), prior to operating is instructed in safe and proper use and reviews and understands the manual(s)
pertaining to this machine. Also make certain that the operator(s) reviews and understands the operator’s manual of the tow vehicle
prior to hooking up or operating the gravity wagon.
Read this manual before you operate this machine. If you do not understand any part of this manual, or need more information, contact
the manufacturer or your authorized dealer. COMPLY WITH ALL SAFETY WARNINGS AND CAUTIONS IN THIS MANUAL AND IN THE
COMBINE OPERATOR’S MANUAL
1. Understand that your safety and the safety of other persons are measured by how you service and operate this machine. Know the
positions and functions of all controls before you try to operate them. Check all controls in a safe area before starting your work.
2. The safety information given in this manual does not replace safety codes, federal, state, or local laws. Ensure your machine has the
proper equipment as designated by local laws and regulations.
3. A frequent cause of personal injury or death is from persons falling o equipment and being run over. Do not permit persons to ride
on this machine.
4. Travel speeds should be such that complete control and machine stability is maintained at all times. Where possible, avoid operating
near ditches, embankments and holes. Reduce speed when turning, crossing slopes and rough, slick or muddy surfaces.
5. Collision of high speed road trac and slow moving machines can cause personal injury or death. On roads, use asher lights according to
local laws. Keep slow-moving-vehicle emblem visible. Pull over to let faster trac pass.
6. Fasten the gravity wagon securely to the pulling vehicle using the proper hitch pin, clip, and safety chains.
7. Before unhooking the implement from the towing unit, be sure to properly block the wheels to prevent the implement from moving.
8. Never overload the wagon. Overloading the wagon is dangerous and can cause extensive damage. Never add more sideboards to the
gravity box than what is recomended, as the box is not designed to carry the additional weight. Do NOT exceed speeds in excess of 20
MPH. Rims, hubs and bearings are designed for heavy loads at slow speeds. Also ensure slow moving vehicle emblem is attached to the
rear of the wagon.
9. IMPORTANT: Use caution when transporting. Be alert of the transport unit’s overall width when approaching obstacles, such as post
signs and poles, along the road. Check the transport width of the unit to ensure clearance before entering bridges.
10. Do not allow anyone to stand between tongue or hitch and towing vehicle when backing up.
11. Choose the most level route possible when transporting across elds.
12. Never adjust, service, clean, or lubricate gravity wagon until all power is shut o.
13. Keep all safety shields in place. Keep hands, feet, hair, and clothing away from the moving parts while the unit is in operation.
14. The service ladder is for service work only. If you must climb into the grain tank, be certain all power is o and use extreme caution.
Never allow anyone in, near or on the gravity box during transporting or unloading grain. Moving grain is dangerous and can cause
entrapment, resulting in severe injury or death by suocation.
15. Make sure that everyone is clear of equipment before applying power or moving the machine.
16. WARNING: BE SURE ALL LIGHTS ARE WORKING PROPERLY BEFORE HIGHWAY TRAVEL.

7
Specications and Dimensions
655 755
A 17’-7” 17’-7”
B 7’-11” 8’-7”
C 10’-5” 11’-2”
D 7’-8” 7’-8”
E 11’-5” 11’-5”
F 9’-6” 9’-6”
G 25’-4” 25’-4”
H 1’-5” 1’-5”
655 755
Capacity - Box 660 Bushels 760 Bushels
Door Width 60” 60”
Chute Height Adjustable 14”-19” Adjustable 14”-19”
Hopper Steel 12 & 9 Gauge 12 & 9 Gauge
Understructure 3” x 6” Runners 3” x 6” Runners
Taillights Standard Standard
Front Ladder Standard Standard
Center Dump Deector Optional Optional
Capacity - Running Gear 24 Tons 24 Tons
Spindles 3-3/8” Diameter 3-3/8” Diameter
Wheels 22.5 x 13 - 10 Bolt 22.5 x 13 - 10 Bolt
Tires 16-22.5 or 18-22.5 16-22.5 or 18-22.5
Hydraulic Brakes Optional 4-Wheel Drum Optional 4-Wheel Drum
Weight 6,800 lbs 7,050 lbs

8
Decals
Description Part No.
1 J&M Oval Decal (Large) 9-1/2” x 15” JM0015151
2 www.jm-inc.com Decal JM0019239
3 Red Reective Decal 2” x 9” JM0009945
4 Orange Reective Decal 2” x 9” JM0009944
5 Check All Wheel Nuts Decal JM0018043
6 Check Tire Ination Decal JM0018041
7 Amber Reective Decal 2” x 9” JM0009946
8 Danger, Flowing Grain Traps GW Decal JM0019223
9 655 Driver’s Side Decal JM0036548
9 755 Driver’s Side Decal JM0036554
10 For Farm Use Only Decal JM0018038
11 Caution, Fasten Box Securely Decal JM0019228
12 Gravity Box Door Light Decal JM0036562
13 Warning, Keep Lug Nuts Tightened Decal JM0024420
14 J&M Oval Decal (Medium) 5-1/2” x 8-1/2” JM0010179
15 655 Passenger’s Side Decal JM0036549
15 755 Passenger’s Side Decal JM0036553
16 Caution, Keep Lug Nuts and Lug Bolts Tightened Decal JM0019220
17 Caution, Check Fluid Level in Master Cylinder Decal JM0019229
2
1
3
4
2
1
5
6
7
7
8

9
Decals
550+ Bushel Capacity
CAUTION
FASTENBOXSECURELYTO WAGON GEAR.
KEEPAWAYFROMMOVING PARTS.
DONOTCLIMB INTO GRAVITY TANK.
BEFOREHIGHWAYTRAVEL,SECURE A
SLOW-MOVINGVEHICLEEMBLEM TO THE
REAROFTHE BOX IN ACCORDANCE WITH
STATEANDLOCALLAWS.
MAKESUREALL FLASHER ANDTURN
INDICATOR/BRAKELIGHTSARE WORKING
PROPERLYBEFOREINCIDENTAL HIGHWAY
TRAVEL.
11
9
12
13
14
15 13
17
16
14
10

10
Bolt Torque Specications
TIGHTENING WHEEL NUTS: Torque 9/16”-18 lug nuts on wheels to 170 ft-lbs after the rst 10, 25, and 50 miles of driving, then recheck
torque every 50 hours or every year, whichever comes rst. Failure to do so may damage wheel nut seats. Once seats are damaged it
will become impossible to keep nuts tight.
Always tighten hardware to these values unless a dierent torque or tightening procedure is listed for specic application. Fasteners must
always be replaced with the same grade as specied in the manual parts list. Always use the proper tool for tightening hardware. Make
sure fastener threads are clean and you start thread engagement properly. Use these values when tightening all bolts and nuts with
the exception of wheel nuts.
Stud and Wheel Nut Torque Specications
Always tighten hardware to these values unless a dierent torque or tightening procedure is listed for specic application. Fasteners must
always be replaced with the same grade as specied in the manual parts list. Always use the proper tool for tightening hardware. Make
sure fastener threads are clean and you start thread engagement properly. Use these values when tightening all studs and wheel
nuts.
Stud Tightening Torque
1/2”-20 120 ft-lbs
9/16”-18 170 ft-lbs
5/8”-18 300 ft-lbs
3/4”-16 400 ft-lbs
20mm 475 ft-lbs
22mm 640 ft-lbs
SAE Fasteners
Coarse Thread Series
Grade 5 Grade 8
Diameter and Pitch (Inches) Dry Oiled Dry Oiled
1/4”-20 8 ft-lbs 6 ft-lbs 12 ft-lbs 9 ft-lbs
5/16”-18 17 13 25 18
3/8”-16 31 23 44 33
7/16”-14 49 37 70 52
1/2”-13 75 57 106 80
9/16”-12 109 82 154 115
5/8”-11 150 113 212 159
3/4”-10 267 200 376 282
7/8”-9 429 322 606 455
1”-8 644 483 909 681
Fine Thread Series
Diameter and Pitch (Inches) Dry Oiled Dry Oiled
1/4”-28 10 ft-lbs 7 ft-lbs 14 ft-lbs 10 ft-lbs
5/16”-24 19 15 27 20
3/8”-24 35 26 49 37
7/16”-20 55 41 78 58
1/2”-20 85 64 120 90
9/16”-18 121 91 171 128
5/8”-18 170 127 240 180
3/4”-16 297 223 420 315
7/8”-14 474 355 669 502

11
Initial Operation & Maintenance
Initial Operation
WARNING: Ensure all power is shut o before servicing the gravity wagon.
Before the gravity wagon is put into service, check the following items for safe operation:
• The track assembly for the door has proper lubrication for less wear on the sprocket and track and easier door operation.
• The SMV (Slow Moving Vehicle) sign is positioned with a point of the triangle upward and as near to the rear and centered or as near
to the left of center of the unit as practicable. The lower edge of the sign should be located 2-10 feet above the ground.
• The gravity wagon is properly attached to the running gear. If no rocking bolster is used, bolt all four corners (use 1/2”bolts
provided) of the gravity wagon runners to the running gear. (If the box is used in rough terrain, bolt a minimum of two corners and
chain (or cable) the remaining corners to allow more box exibility.
• Check all braces, bolts, nuts, lug bolts, and lug nuts been checked to ensure they are properly fastened. The proper torque for the
wheel lug nuts is 350 ft lbs.
• All operators of this machine have read and clearly understand the safety instructions.
• All lights must work properly. All reective decals are clean, visible, and positioned correctly.
• Tires are properly inated. The following is to be used as a general guide for tire ination for cyclic use. Figures can vary depending
on specic brand of tire used. It is important that tires are inspected before and after the unit is loaded. The tire should stand
up with no side wall buckling or distress as the tire rolls. Do not exceed the tire pressure indicated below:
WARNING: Tow loads safely
Stopping distance increases with speed and weight of towed loads, and on slopes. Towed loads with or without brakes that are too
heavy for the tractor or are too fast can cause loss of control. Consider the total weight of the equipment and its load.
For towed equipment WITHOUT brakes, the following is recommended:
Do NOT tow equipment that does not have brakes at speeds over 32 km/h (20 mph); or that, when fully loaded, has a mass (weight) over
1.5t (3300 lb) and more than 1.5 times the mass (weight) of the towing unit.
For towed equipment WITH brakes, the following is recommended:
Do NOT tow equipment that has brakes at speeds over 40 km/h (25 mph); or that, when fully loaded, has a mass (weight) more that 4.5
times the mass (weight) of the towing unit.
Ensure the load does not exceed the recommended weight ratio. Use additional caution when towing loads under adverse conditions,
when turning and on inclines.
WARNING: Before lling the gravity wagon, make certain that no one is inside the grain tank. Never allow children or
anyone in, near, or on the gravity wagon during transport or during loading or unloading of grain. Be aware that moving grain
is dangerous and can cause entrapment, resulting in severe injury or death by suocation.
After hauling corrosive materials such as fertilizers, be sure to wash out the grain tank to prevent premature rusting. Bare spots on
metal should be primer coated before applying the outer surface paint.
Check the box periodically for cracks in welds and for other structural damage. Have cracked welds fixed immediately. Failure to
do so could result in extensive damage and greatly reduce the life of the gravity wagon.
Tire Size psi
425/65R22.5 85
445/65R22.5 85

12
Lubrication
Your gravity wagon has grease ttings at all critical points. These should be serviced before the gravity wagon is put into
operation each season.
HOW TO FLUSH OLD OIL OUT OF THE OIL BATH HUBS
Your gravity wagon is equipped oil bath hubs. Follow these steps to ush the oil bath hubs once per year.
1. Check the hub for leaks and wear. Replace components as necessary.
2. Roll the hub until the ll plug is on top.
3. Drain the hub by removing the cap.
4. After draining the old oil, use light weight motor oil to ush out remaining oil. There is no need to tilt the hub, the oil will ow
through the bearing easily.
5. Replace cap. Torque cap to 30-40 ft-lbs.
6. Replace oil with 80-90WT Sta-Lube from NAPA. This oil has a rust inhibitor additive.
HOW TO ADD OIL TO OIL BATH HUBS
IMPORTANT: Use Napa STA-Lube - GL5 80/90 WT with Rust Inhibitors FL2472 for the Oil Bath Hubs.
1. Use a 3/4”wrench to remove breather plug.
2. Add 80-90WT Sta-Lube oil from NAPA with an oiler hand pump. The recommended oil capacity in the hubs is 8 ounces.
3. Replace breather plug. First hand tighten, then use 3/4” wrench to make a 1/4”of a turn.
Routine Maintenance
WARNING: Ensure all power is shut o before servicing the gravity wagon.
• Check the gravity wagon periodically for cracks in welds and for other structural damage. Fix cracked welds immediately. Failure to
do so could result in extensive damage to the gravity wagon and greatly reduce the life of the unit.
• If equipped with uni-swivel auger, check all hydraulic hoses for wear and replace as necessary.
• Ensure all tires are properly inated. Refer to“Initial Operation & Maintenance” on page 11 for recommended tire pressures. It is
important that tires are inspected before and after unit loaded.
• Ensure all grease ttings have proper lubrication.
• Properly torque all lug nuts to 350 ft-lbs.
Your local, authorized dealer can supply genuine replacement parts. Substitute parts not provided by J&M Manufacturing may not meet
original equipment specications and may be dangerous.
When performing maintenance work, wear sturdy, rough-soled work shoes and protective equipment for eyes, hair, hands, hearing and
head. Follow instructions in this manual to ensure safe and proper maintenance and repair.
Store the gravity wagon in a dry, protected place. Leaving your gravity wagon outside, open to the weather will shorten its life.
Follow the procedure below when your gravity wagon is placed in storage for periods up to six months:
1. Remove all grain from inside the grain tank.
2. Wash or clean and completely lubricate the gravity wagon.
3. Touch up areas where paint may have worn away. Use a good quality primer paint, especially before re-applying graphite paint to the
interior slopes of the grain tank.
4. Clean the tires before storage. Inate the tires at regular intervals.
Storage Preparation

13
Bleeding the Brake Lines
METHOD ONE (requires two people)
1. Close all bleed screws
2. Start with the wheel furthest from the master cylilnder. Slip a transparent bleed hose on the bleeder stem and place the other end of
the hose in a clean container which is partially lled with uid at all times.
3. The rst person depresses the brake plunger SLOWLY. This should take 3-5 seconds. Next, the second person opens the bleed screw.
He then closes the bleed screw BEFORE the rst person SLOWLY releases the plunger. This should again take 3-5 seconds. Continue
process until there is no evidence of air in the bleed hose.
4. Repeat for remaining wheels working from the longest to the shortest distance from the master cylinder. Top o master cylinder as
needed to prevent reintroducing air into the lines.
METHOD TWO (one person)
1. Attach bleed hose to rear wheel as in method one. Open bleed screw. SLOWLY depress plunger (3-5 seconds). Repeat until line is air
free. Close bleed screw. Top o master cylinder as needed to prevent reintroducing air into the lines.
Repeat with remaining wheels.
DANGER: Contamination with dirt, water, petroleum products or other materials may result in brake failure or costly repairs.
Adjusting the Brake Master Cylinder
1. Use a 9/16”wrench to remove the (2) 3/8” x 1” serrated hex head bolts and
shield.
2. Loosen the 1/2”nut on the plunger pin. Use a 3/4” wrench.
3. Rotate the plunger rod to adjust. The braking plunger system should have
approximately a 1/4” of play when adjusted for level road travel. For more
aggressive braking action turn the plunger rod counterclockwise. This will
lengthen the assembly. For less aggressive braking action turn the plunger rod
clockwise. This will shorten the assembly.
DANGER: Do not adjust all the play out of the plunger system. This will
cause the brakes to be activated at all times and overheat the drums,
causing failure.
NOTE: This braking system is designed to assist the pull vehicle in braking,
not to take the place of it.
4. Tighten the 1/2”hex nut to keep plunger rod in place.
5. Put the shield back on and tighten both 3/8” x 1” SF hex bolts.
3/8” x 1” Hex Bolt
Shield
Plunger Rod
1/2” Hex Nut
Adjusting the Brakes
The brake adjustment nut is located behind a slot at the bottom of the backing plate. Tighten the nut until you cannot rotate the wheel
by hand, then back o the adjustment 18 to 20 notches.
IMPORTANT: When adjusting drum brakes, rotate the wheel and drum in a forward rotation only.

14
L1
L1
L3
L2
L2 L4
Gravity Wagon Trail Adjustment
• Ensure the tongue bolt is as tight as possible without over restricting the vertical motion of the hitch.
• An extra washer (shown below) can be added if the nut is tightened so far that it runs out of threads before the tongue bolt is as tight as
possible.
• Ensure all tires are properly inated. Refer to“Initial Operation & Maintenance” on page 11 for recommended tire pressures.
• If either of the front tires look to be excessively worn or unevenly worn they should be rotated with a less worn rear tire, if possible.
• Toe the front tires inward 3/16” on front from rim to rim (acceptable range for tired to be toed insward is 1/8” to 1/4”). For directions
on how to adjust the toe-in, follow the steps below.
• Ensure the inner tongue bolt (shown below) is tightened enough to mitigate slop but still allow the inner tongue to slide in and out of
the outer tongue. It is acceptable to see the outer tongue squeezed inward by the inner tongue bolt for a slop-free t.
Hitch
Tongue Ear
Inner Tongue Bolt
Outer Tongue
Adjusting Running Gear Toe-In
1. Position the tongue in the straight and horizontal position. Measure both“L1”locations. Once both locations are the same length, move
to the next step.
2. Measure both“L2”locations. Adjust both tie-rods to ensure both measurements are equal.
3. Measure“L3”and“L4”distances. L3 should be set 3/16”smaller than L4 by adjusting the tie-rods in equal amounts.
4. Measure both“L2”locations again to ensure they are the same. If L2 lengths are dierent, repeat the process.

15
Fenders
Wheels and Tires
Description Part No.
1 3/8”-16 x 1-1/2” Gr5 Z SF Hex Bolt JM0001633
2 3/8” ID, 1”OD Z Flat Washer JM0003061
3 3/8”-16 Gr2 Z Centerlock Hex Nut JM0001512
4 55 Series Mud Flap JM0033494
5 Front Lower Left Fender Bracket (655, 755) JM0034359
6 3/8”-16 x 6” x 4-5/8” Square U-Bolt JM0033399
7 3/8”-16 Gr5 Z SF Hex Nut JM0002152
8 Fender (55 Series) JM0033393
9 3/8”-16 x 1” Gr5 Z SF Hex Bolt JM0002092
10 Front Upper Left Fender Bracket (55 Series) JM0033395
11 Front Upper Right Fender Bracket (55 Series) JM0033435
12 Front Lower Right Fender Bracket (655, 755) JM0034362
13 Rear Lower Left Fender Bracket (655, 755) JM0034376
14 Rear Lower Right Fender Bracket (655, 755) JM0034372
15 1/2”-13 x 5-1/2” Gr5 Z Hex Bolt JM0001498
16 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
17 7/16” ID x 2-1/2” OD x 1/8” Z USS Flat Washer JM0018982
Description Part No.
1 Wheel Rim, 8 hole 22.5” x 13.5” (WR-22.5-13.5) JM0019398
2 16.5-22.5 Used Tire (425 Metric) JM0019399
3 8 Hole, 22.5”x 13.5”Wheel Rim and Used 16.5-22.5 Tire JM0036257

16
Tongue Assembly with Brakes

17
Description Part No.
1 3/8”-16 x 1” Gr5 Z SF Hex Bolt JM0002092
2 Shield for Master Cylinder (SMC-1) JM0019273
3 5/16”-18 x 3” Gr5 Z Hex Bolt JM0019359
4 Rubber Boot for Master Cylinder (RB-1415) JM0019358
5 51-1/8” Long Plunger Pole (655/755) JM0035044
6 Spindle Bolt 1-1/4” x 10-1/4” (SB-114) JM0019324
7 1/2”-13 Gr5 Z SF Hex Nut JM0002153
8 1/4”-20 x 1/2” Gr5 Z Hex Bolt JM0001481
9 1/4” ID, 3/4” OD Z Flat Washer JM0003090
10 Mounting Bracket with Springs for Master Cylinder (2 Pieces) (MBMC-DR2) JM0019340
11 1/2”-13 x 6” Gr5 Z J-Bolt JM0002168
12 1/4”-20 Gr2 Z Centerlock Hex Nut JM0001505
13 1-1/4” USS Flat Washer JM0010112
14 1-1/4”-7 Gr2 Z Centerlock Hex Nut JM0002150
15 1-3/4” x 11-3/4” King Pin Vertical Hitch Bolt JM0029375
16 Hitch Weldment, 24 Ton Running Gear (HW-24) JM0029107
17 7/8” ID x 1” OD x 7/8” LG Bronze Bushing (BB-78) JM0029185
18 Tongue Spring 3/8”x 1-3/4” x 12-1/2” (TS-615H) JM0014200
19 1/4”-20 x 3/4” Gr5 Z Hex Bolt JM0001507
20 5/16”-18 Gr5 Z Star Washer Hex Nut JM0019361
21 1/64” Orice Restrictor Fitting for Drum Brake Master Cylinder JM0027857
22 Master Cylinder with Spring Bracket (MCA-DR1) JM0019356
23 Master Cylinder Cap (RCMC-1324) JM0019357
24 Master Cylinder Plunger Rod End (PRE-1) JM0019341
25 1/2”-13 Gr2 Z Hex Nut JM0002124
26 Seal Kit for Master Cylinder (SKMC-1324) JM0036060
27 Tongue Latch for Gravity Wagon (TL-1324) JM0019289
28 1”-8 Gr2 Z Centerlock Hex Nut JM0002149
29 3/8”Wire x 1-5/16” Diameter x 7” Long Compression Spring (CM1516112) JM0019293
30 Compression Spring (1” x 1-3/4”) for Door Assembly & Tongue Latch JM0001688
31 1”-8 x 7” Gr5 Z Hex Bolt JM0016689
32 1”-8 x 9” Gr8 Z Hex Bolt JM0001708
33 Brake Limiter on Gravity Wagon (BL-58) JM0019306
34 7/8”-9 x 6” Gr8 Z Hex Bolt JM0032815
35 1”-8 x 7-1/2” Gr8 YZ Hex Bolt JM0017944
36 7/8”-9 Gr2 Z Centerlock Hex Nut JM0002148
37 Rubber Bar for Running Gear Inner Tongue (3-15/16” x 3-1/8” x 1-1/4”) JM0032331
38 Front of Cushion Hitch (55 Series Running Gear) JM0032324
39 Tongue Hitch Insert (55 Series) JM0033959
40 24 Ton Outer Tongue Cushion Hitch Assembly (55 Series) JM0029536
Tongue Assembly with Brakes

18
24 Ton Running Gear
45

19
Description Part No.
1 55 Series 24 Ton Front Right A-Frame Arm JM0035128
2 Hitch Weldment, 24 Ton Running Gear JM0029107
3 7/8” ID x 1” OD x 7/8” LG Bronze Bushing (BB-78) JM0029185
4 1-3/4” x 11-3/4” King Pin Vertical Hitch Bolt JM0029375
5 Spindle Bolt (1-3/4” x 13-1/2”) (12-15 Ton) (SPB-134) JM0019321
6 873 Hub with Studs, Lugs & Races (Brakes) (W-871B) JM0029503
7 Drum Brake Cluster Assembly (Left) (DRBA-L) JM0027922
7 Drum Brake Cluster Assembly (Right) (DRBA-R) JM0027931
8 55 Series 24 Ton Front Left A-Frame Arm JM0035126
9 1-3/4” USS Flat Washer JM0029723
10 1-3/4”-5 Gr5 Z Hex Nut JM0019334
11 1”-8 Gr2 Z Centerlock Hex Nut JM0002149
12 55 Series 24 Ton Front Axle Weldment JM0033950
13 1”-8 x 6-3/4” Gr5 Z Hex Bolt JM0029381
14 55 Series 24 Ton Rear Axle Weldment JM0033953
15 1/2”-20 Gr2 Z Centerlock Hex Nut JM0009858
16 Rubber Damper (1/2”-13 x 1-1/4” Stud) JM0031630
17 1/8” NPT Male x 11/16” Straight Grease Fitting JM0009756
18 4-1/2” Collar to Coupling Pole (CL-412) JM0015724
19 1-3/4” ID Bronze Bushing (2”OD x 1”Length) (EB-134) JM0002244
20 Oil Seal for 873 Hub (G873OB) (24T-OB) JM0035243
21 Large Bearing (4T-33275) JM0025687
22 Large Race (4T-33462) JM0025689
23 3/4”-16 x 1-3/4”Wheel Stud JM0018957
24 873 Hub with Studs, Lugs & Races (Brakes) (W-871B) JM0029503
25 Wheel Nut 3/4”-16 JM0018958
26 Small Race (4T-453A) JM0025695
27 Small Bearing (4T-460) JM0025688
28 1-3/10” ID x 3-1/4” OD x 3/16” Spindle Washer JM0029511
29 873 Oil Bath Hub Dust Cap JM0035157
30 5/16”-18 x 1/2” Gr5 Z Hex Bolt JM0016674
31 1-1/4”-12 Gr2 Castle Hex Nut JM0010113
32 3/16” x 2-1/2” Cotter Pin JM0027684
33 5/8”-11 Nut for Shoulder Bolt JM0003184
34 7/8” Shoulder Dia x 1-3/8” Shoulder Length x 5/8”-11 Shoulder Bolt and Nut (SB-78) JM0029199
35 1-1/4” Left Tie Rod End (Clevis) (TRE-114L) JM0029192
36 1-1/4”-12 Gr5 PN LH Hex Nut JM0019931
37 1-1/4” x 24” 24 Ton Tie Rod (TR-24A) JM0029187
38 1-1/4”-12 Gr5 PN RH Hex Nut JM0019930
39 24 Ton Right Clevis Weldment (TRE-114R) JM0029191
40 7/8”-9 Gr2 Z Centerlock Hex Nut JM0002148
41 7/8” USS Flat Washer (2-1/4” OD) JM0014395
42 24 Ton Back Rocking Bolster - Spacer JM0032503
43 24 Ton Back Rocking Bolster JM0032500
44 7/8”-9 x 8” Gr8 YZ Hex Bolt JM0019392
45 Coupling Pole (144” x 4” OD Pipe) (655, 755) JM0033947
24 Ton Running Gear

20
Shell Assembly
Description Part No.
1 755 Sideboard Corner (9-1/2”) JM0034351
2755 Front Passenger or Rear Driver Sideboard (105-1/2” Length) JM0034313
3 3/8”-16 x 1”Gr5 Z SF Hex Bolt JM0002092
4 755 Sideboard Splice Plate (8-1/2” x 4-5/8”) JM0034319
5755 Front Driver or Rear Passenger Sideboard (105-1/2” Length) JM0034317
6 755 Endboard (114-1/2”Length) JM0034315
7 755 Sideboard Brace End JM0034320
8 755 Sideboard Brace JM0034321
9 3/8”-16 Gr5 Z SF Hex Nut JM0002152
10 1/4”ID, 3/4” OD Z Flat Washer JM0003090
11 1/4”-20 x 3/4”Gr5 Z Hex Bolt JM0001507
12 1/4”-20 x 1”Gr5 Z Hex Bolt JM0002095
13 Wire Harness Storage Bracket (WHB-1) JM0001438
14 1/4”-20 Gr5 Z SF Hex Nut JM0001630
15 55 Series Ladder Brace JM0034491
16 1/4”-20 Gr2 Z Centerlock Hex Nut JM0001505
17 Operator’s Manual Canister JM0010115
18 Ladder Weldment (655, 755) JM0034378
19 755 Passenger Side Divider End JM0036017
20 755 Divider Sideboard JM0036015
21 755 Driver Side Divider End JM0036024
555 Divider Option Only
