janitza JPC70 Instruction manual

Doc no. 2.100.011.1a 08/2018
Smart Energy Panel
JPC70
User Manual and Technical Data
Janitza electronics GmbH
Vor dem Polstück 6
35633 Lahnau, Germany
Support tel. [phone]
Fax [phone]
Email: [email protected]
www.janitza.com
www.janitza.com

JPC70
www.janitza.com
2
Content
1. General information 4
1. 1 Disclaimer 4
1. 2 Copyright notice 4
1. 3 Technical changes 4
1. 4 Declaration of Conformity 4
1. 5 Comments on the manual 4
2. Safety 5
2. 1 Safety instructions 5
2. 2 Safety measures 6
2. 3 Qualified personnel 6
3. Intended use 7
3. 1 Incoming goods inspection 7
3. 2 Intended use 7
2. 4 Scope of delivery 7
4. Product description 8
4. 1 Operating concept 8
4. 2 Performance features 9
4. 3 Product overview 10
5. Assembly 12
5. 1 Installation location 12
5. 2 Installation position 12
5. 3 Fastening 12
5. 4 Ground 13
6. Installation 14
6. 1 Connection to a master device 14
6. 2 Disconnectors 14
6. 3 Supply voltage 14
6. 4 Bus structure 15
7. Configuration 16
7. 1 Start screen 16
7. 2 Show bus system 17
7. 2. 1 Integrating the master device: 17
7. 2. 2 Integrating slave devices 18
7. 2. 3 Starting communication 18
7. 3 Slave devices 19
7. 3. 1 Measured values 19
7. 3. 2 Configuration 19
7. 3. 3 Alarm configuration 22

www.janitza.com
JPC70
3
7. 4 Master devices 23
7. 4. 1 Configuration 23
7. 4. 2 Alarm configuration 23
7. 5 Alarm management 24
7. 5. 1 Alarm history 24
7. 6 User management 25
7. 6. 1 User settings 25
7. 7 System 27
7. 7. 1 Device settings 27
7. 7. 2 Modbus TCP 27
7. 7. 4 Time setting 28
7. 7. 5 Display 28
7. 7. 3 TCP/IP settings 28
7. 8 Email configuration 29
8. Service and maintenance 30
8. 1 Repair and calibration 30
8. 2 Front foil 30
8. 3 Disposal 30
8. 4 Service 30
9. Technical data 31
9. 1 Dimensional drawings 32

JPC70
www.janitza.com
4
1. 1 Disclaimer
It is essential that the information products
for the devices are observed to ensure
safe operation and achieve the specified
performance characteristics and product
features. Janitza electronics GmbH assumes
no liability for personal injuries, property
damage and financial losses resulting
from the failure to observe the information
products.
Make sure that your information products are
legible and accessible.
1. 2 Copyright notice
© 2018 - Janitza electronics GmbH - Lahnau.
All rights reserved.
Any duplication, processing, distribution
and any other kind of use, even in part,
is prohibited.
All trademarks and any resulting rights belong
to the respective holders of these rights.
1. 3 Technical changes
• Make sure that the installation instructions
match your device.
• First, make sure you have read and
understood the document accompanying
the product.
• Keep the documents accompanying the
product accessible through its service life
and hand them over to the subsequent
owner where applicable.
• Refer to www.janitza.com for information
concerning device revisions and
the associated adjustments to the
documentation accompanying the
product.
1. 4 Declaration of Conformity
Please refer to the Declaration of Conformity
on our web site www.janitza.com for the
laws, standards and directives applied by
Janitza electronics GmbH.
1. General information
1. 5 Comments on the manual
We welcome your comments. If anything
in this manual seems unclear, please let us
know and send us an email at:
[email protected]

www.janitza.com
JPC70
5
Please read the present user manual and
all other publications that are applicable
for working with this product. This applies
in particular for installation, operation and
maintenance.
In the process, observe all safety
requirements and warning notices. Failure
to observe the notices can result in personal
injury and/or property damage.
Any impermissible modification or use of this
device exceeding the specified mechanical,
electrical or other operating limits can result
in personal injury and/or property damage.
Any associated impermissible use applies as
"misuse" and/or "negligence" with respect
to the product warranty and thus voids
the guarantee for coverage of potentially
resulting damages.
The user manual:
• must be read the manual before using the
device.
• must be kept and remain available
for reference during the entire service life
of the product.
Also observe the applicable legal and safety
requirements for the respective application
when using the device.
2. 1 Safety instructions
NOTE
Points out procedures during which
a danger of injuries or property damage
does not exist.
ATTENTION
Indicates an imminently dangerous situation
that can result in property damage
or environmental damage in the event
of noncompliance.
Safety instructions are highlighted by
a warning triangle and are presented as
follows depending on the level of risk:
DANGER
Indicates an imminent danger that will result
in serious and/or fatal injuries.
WARNING
Indicates a potentially dangerous situation
that can result in serious injuries or death.
CAUTION
Indicates a potentially dangerous situation
that can result in minor injuries or property
damage.
2. Safety

JPC70
www.janitza.com
6
2. 2 Safety measures
When operating electrical devices, specific
parts of these devices inevitably carry
dangerous voltage. As a result, serious bodily
harm or property damage can occur if they
are not handled correctly.
WARNING
Electrical voltage!
Dangerous voltages can cause serious
bodily harm or death.
Therefore, please note the following:
• Before connecting the device, ground
it at the ground wire connection if
available.
• Dangerous voltages may be present
in all circuit parts connected to the
voltage supply.
• There may still be dangerous voltages
present in the device even after it is
disconnected from the supply voltage.
• Fit wire end ferrules on the conductors
made of individual wires.
• Only connect screw-type terminals
with matching numbers of poles and
of the same type.
• De-energize the system before
starting work.
WARNING
Risk of injury due to improper use
If the device is not operated according to
the documentation, protection is no longer
guaranteed and danger can emanate from
the device.
2. 3 Qualified personnel
This device must only be operated and
maintained by qualified experts.
Qualified experts are persons who, based
on their appropriate training and experience,
are capable of recognizing risks and avoiding
potential hazards which can arise during
operation or maintenance of the device.

www.janitza.com
JPC70
7
3. 1 Incoming goods inspection
The prerequisites for smooth and safe
operation of the device include proper
transport, storage, setup and assembly,
as well as proper operation and maintenance.
Exercise caution when unpacking the device
without using force and only using suitable
tools.
Perform a visual inspection of the device to
ensure the fault-free mechanical condition.
Please check the scope of delivery for
completeness before beginning with the
installation of the device.
If you assume that safe operation is no
longer possible, the device must be shut
down immediately and prevented from
unintended re-commissioning. If you assume
that safe operation is no longer possible,
when, for example, the device:
• has visible damage,
• no longer functions despite an intact
power supply,
• was subjected to extended periods
of unfavorable conditions (e.g. storage
outside of the permissible climate
thresholds without adjustment to the room
climate, condensation, etc.) or transport
stress (e.g. falling from an elevated
position, even without visible external
damage, etc.).
3. Intended use
3. 2 Intended use
The device is:
• intended for installation in switch cabinets
and small installation distributors.
• not intended for installation in vehicles!
Using the device in mobile equipment
is considered an unusual environmental
condition and is only permissible by
special agreement.
• not intended for installation in areas
exposed to harmful oils, acids, gases,
vapors, dust and radiation, etc.
2. 4 Scope of delivery
Number Item no. Designation
1 15.06.356 JPC70
1 33.03.373 Installation instructions
1 Fastener set

JPC70
www.janitza.com
8
4. Product description
The device is intended for:
• visualization of current and voltage
measuring devices in a bus system.
• monitoring of measured values and
settings of connected measurement
devices.
• configuration of the connected slave
devices.
• installation in permanently installed switch
cabinets or small installation distributors.
4. 1 Operating concept
You can program the device in several
different ways and/or display
measured values:
• Directly on the device via the display
with touch screen.
• Via the Ethernet interface with
a connected PC.
Only the operation of the device via touch
screen is described in this operating manual.
NOTE
An input aid is recommended for operation
on the touch screen.

www.janitza.com
JPC70
9
4. 2 Performance features
General information
• Integrated front panel unit with the dimensions 197 x 140 mm
• Connection via Ethernet to the Janitza gateway devices: UMG
512/509/605/604/96RM-E and ProData
• Representation of up to 10 Janitza UMG 20CM devices
• TFT display 800 x 480 pixels
• Operation via touch screen
• 2 x USB 2.0 type A interfaces
• Ethernet interface
• Operating temperature range -20 °C – +60 °C
Visualization
• Representation of all current and energy values
• Display of the last maximum value of the connected devices
• Topology view of the bus system
• Visualization of the main and auxiliary measurement
• Monitoring of up to 200 current channels
Configuration
• Dynamic topology configuration with freely selectable number of devices
• Group transfer of configuration of up to several devices
• Import and export of device configurations via USB
• Labeling of individual current circuits
• Threshold value can be set per channel

JPC70 www.janitza.com
10
4. 3 Product overview
Fig. 1: Front view JPC70
2
1
3
Touch area
2
3
Display
Home button
1
NOTE
Since the analogue-resistive touch screen
is not multi-touch capable, a mean value is
generated when the screen is touched in
multiple places simultaneously.
This averaged position value is evaluated by
the application. Therefore, since the entire
touch area is larger than the display itself,
multiple touches (including outside of the
display) can trigger undesired commands.
This can take place when the operator
holds the JPC70 in their hands.

www.janitza.com
JPC70
11
Fig. 2: Rear view JPC70 with connections
1
2
Ground conductor:
The connection to the ground potential must be made as short
as possible and adequately strong (≥4 mm²) via the provided flat
plug connection (Faston 6.3 mm).
2Unshielded conductors:
All unshielded conductors must be relieved of tensile stress with
cable ties on the ground plate.
1

JPC70
www.janitza.com
12
5. Assembly
5. 1 Installation location
The device is suitable for indoor installation
in a stationary and weather-protected switch
board.
Ensure that grounding is provided for
switchboards.
5. 2 Installation position
The cut-out size in the switchboard is
186+0.8 mm x 129+0.8 mm with a wall thickness
of 2 to 6 mm.
In order to achieve adequate ventilation,
the following must be observed:
• Install the device vertically.
• Observe a minimum clearance of 60 mm
above and below.
• Observe a minimum clearance of 40 mm
to the sides.
Fig. 3: Installation position of the JPC70
5. 3 Fastening
The device must be installed using the
supplied retaining clamps (see Fig. 6)
on a level, clean and burr-free surface.
Unevenness can cause damage to the
display and result in the penetration of dust
and water.
Fig. 4: Rear view with retaining clamps
1. Insert the front side of the device in the
provided installation cut-out.
2. Insert the retaining clamps in the
recesses provided on the device.
Fig. 5: Inserting the retaining clamps
3. Slide the retaining clamps towards the
rear until they are flush with the back side
of the recess.
Fig. 6: Sliding the retaining clamps towards the rear
4. Fix the retaining clamps by tightening the
fastening screws on the wall and/or the
switch cabinet sheet metal.
Fig. 7: Fixing the retaining clamps
CAUTION
Property damage due to noncompliance
with the assembly instructions!
Noncompliance with the assembly
instructions can result in damage or
destruction of your device.
Observe the specifications for the
installation position in the sections
"Assembly" and "Technical data".

www.janitza.com
JPC70
13
5. 4 Ground
Faults are discharged effectively via
a grounding lug. The cable shield
(e.g. Ethernet) is discharged via the
ground plate.
Ground
connection
WARNING
The ground potential (ground lug on the
device) and the GND connection of the
voltage supply are connected internally.
Use at least one PELV power supply unit.
≥4 mm²
Fig. 8: Ground in the switch cabinet

JPC70 www.janitza.com
14
6. 1 Connection to a master device
The device is connected via Ethernet to the
gateway device / master device of a bus
system:
6. Installation
6. 2 Disconnectors
Provide a suitable disconnector for the
supply voltage in the building installation in
order to de-energize the device from current
and voltage.
• Install the disconnector near the device in
a location that is easily reachable for the
user.
• Mark the switch as a disconnecting device
for this device.
6. 3 Supply voltage
A supply voltage is required for operation of
the device. Refer to the technical data for the
type and level of the supply voltage for your
device.
The connection of the supply voltage is made
via the plug-type terminals on the rear side of
the device.
Before connecting the supply voltage,
ensure that the supply voltage matches the
specifications form the technical data.
(See section 9 on Page 31)
Fig. 9: Bus topology with a UMG 605 as a master and con-
nected JPC70
JPC70
UMG 605-PRO
as a master
Slave 1 Slave 2 Slave n
Ethernet
ModbusModbus Modbus
Ethernet
Connect the supply voltage via
a UL/IEC-approved fuse.
After connecting the supply voltage,
a display appears. If no display appears,
check whether the supply voltage is within
the rated voltage range.
WARNING
Risk of injury due to electric voltage!
It may result in serious bodily harm or death
due to:
• Touching live exposed or stripped cores.
• Device inputs that are dangerous to
touch.
Therefore, please note the following:
• The inputs for the supply voltage are
dangerous to touch.
• De-energize your system before
beginning to work!

www.janitza.com
JPC70
15
6. 4 Bus structure
• All devices are connected in a bus
structure (line).
• Each device has a dedicated address
within the bus.
• Up to 32 participants can be connected
in a segment.
• The cable is terminated with resistors
(bus terminator, 120 Ohm, 1/4 W) at the
start and end of a segment.
• Repeaters (regenerative repeaters) must
be used for more than 32 participants in
order to connect the individual segments.
Slave
Fig. 10: Bus structure representation
Slave Slave Slave Repeater
Slave Slave Slave
Master Speisung notwendig / power supply necessary
Busabschluss eingeschaltet / bus terminator on
T
T
T
T
T
• Devices with an activated bus terminator
must be supplied with power.
• We recommend only placing the master
at the end of a segment.
• If the master is replaced with bus
terminator activated, the bus is
deactivated.
• If a slave is replaced with bus terminator
activated or is de-energized, the bus can
become unstable.
• Devices which do not participate in the
bus terminator can be replaced without
making the bus unstable.

JPC70
www.janitza.com
16
7. Configuration
Operation of the device takes place either
on the device itself via touch screen or via
remote access with the PC connected to the
device in the network.
7. 1 Start screen
A topology overview of the integrated bus
system is represented on the main screen of
the device.
An overview of the current voltage values of
the integrated slave devices is shown on the
start screen.
By touching the values in the overview of
a slave device, you open its other values,
the configuration menu and the alarm
configuration for this device.
1Selected slave device
2Save button
3Selected master device
4Home button
5Active user role
6Software version
7Current date
Fig. 11: Start screen
1
2
3
4 5 6 7 8 9
11
10
12
13
8Current time
9Warnings/alarms
10 Status bar
11 Number of slave devices
12 Representation of a slave device
13 Legend

www.janitza.com
JPC70
17
7. 2 Show bus system
In order to be able to manage a bus system
via the JPC70, the IP and Modbus address of
the master device and the Modbus address
of the slave devices must be configured in
the device.
Before beginning with configuration of the
JPC70, you must accept the device settings.
1. Touch the display of the current role in
the status bar to open the login mask.
2. Log in as an administrator. The user name
and password of the administrator are
pre-configured in the factory as "Admin".
3. Switch back to the system settings by
pressing the System tab.
4. Press the ACK button in the Device
menu.
• A fixed standard IP address is loaded.
We recommend only correcting the TCP/
IP settings at first, because assigning a
permanent IP address can cause problems
in networks. (See 7. 7. 3 on Page 28)
7. 2. 1 Integrating the master device:
Proceed as follows to connect the device to
a master:
1. Log in as an administrator.
2. Press the Home button to switch to the
start screen.
3. Select the type of your master device in
the selection list.
4. Touch the miniature representation of the
master device (see Fig. 11) in order to
open these settings.
5. Enter the IP address of the master device
in the TCP/IP address input field.
6. Enter the Modbus address of the master
device in the Modbus UnitID input field.
7. Press the Save button to save the
changes.
8. Proceed with the configuration of the
slave devices.
You can display additional measured values
with the Show L4, L5 and L6 selection boxes.
Activate/deactivate the representation of the
measured values on the start screen with the
Show values on startpage selection box.
Fig. 12: Master device configuration

JPC70
www.janitza.com
18
7. 2. 2 Integrating slave devices
1. Open the start screen as an administrator.
(See 7. 2. 1)
2. Select the type of your slave devices in
the selection list.
3. Enter the number of slave devices
connected in the bus in the window next
to the selection list. (max. 10)
4. Open the view of the respective slave
device by touching the corresponding
tabular representation.
5. Switch to the configuration menu by
pressing the Configuration tab.
6. Enter a name for the corresponding slave
device in the Name input field.
7. Enter the Modbus address of the device
in the Modbus address input field.
(Refer to the documentation of the
corresponding slave device to determine
the Modbus address).
8. Configure the addresses of all connected
slave devices in this manner.
9. Save the settings by pressing the Save
button.
10. Touch the version number, date or time
in the status bar to open the JPC70
settings.
11. Press the Reboot button in the Device
section to restart the JPC70.
7. 2. 3 Starting communication
After the bus system has been configured
completely in the JPC70, you can start
communication via Modbus/TCP:
1. Log in as an administrator.
2. Navigate to the system settings.
3. Activate the Overwrite all selection box if
you want to overwrite the configuration
of the connected devices with the
configuration from the JPC70.
4. Press the Start button under Modbus
TCP.
• The update symbol appears next to the
Modbus TCP menu item and displays an
active transmission.
Fig. 13: Slave device configuration
Fig. 14:Modbus TCP system settings

www.janitza.com
JPC70
19
7. 3 Slave devices
With the JPC70, you can
• configure the integrated slave devices.
• View measured values of the slave
devices.
• Create alarms for the slave devices.
7. 3. 1 Measured values
You can have an overview of the measured
values of all channels of the slave device with
the Measurement and Currents tabs.
You can switch between the slave devices
with the << and >> buttons.
7. 3. 2 Configuration
You enter the configuration menu of the slave
device via the Configuration tab.
You must be logged in as an administrator to
make configurations on the devices
(see „7. 2 Show bus system“).
The measuring inputs of all integrated slave
devices can be configured with the JPC70.
For this purpose, open the configuration
menu of a slave device as described
in 7. 2. 2.
Fig. 15: Measured values overview
You switch between the available measuring
channels of the device with the arrow buttons.
Name
You can assign a name for the measuring
channel in the Name input field.
Fault current measurement
You can specify whether the device should
measure fault current or operating current
with the Fault current meter selection box.
This configuration option is only available if
the measurement device is suitable for fault
current measurement.
Transformer settings
Configure the current transformers with the
Transformer type selection list.
The primary side and apparent power input
fields must be filled in manually for the
transformer type setting User-defined.
Voltage channel
You can assign a voltage channel to the
measurement channel with the Related
voltage channel selection list.

JPC70
www.janitza.com
20
Actions for this UMG
Additional configuration options to facilitate
the handling of multiple slave devices are
available with the Actions for this UMG
button (see Fig. 17).
Here, you can:
• Reset energy meters and minimum/
accident current values of individual
channels.
• Reset energy meters and minimum/
accident current values of all channels
of the selected device.
• Carry out configuration of a channel for all
channels of the device.
Fig. 16: Actions for this UMG in the JPC70
Overcurrent warning level and alarm level
The warning level and alarm level for
overcurrent can be configured with the
JPC70.
With the Set IO selection box, you can define
whether outputs should be activated when
the warning level or alarm level is exceeded.
Low-pass filter
You can activate the low-pass filter as
necessary by activating the Low-pass filter
selection box. For more information about the
low-pass filter function, refer to the device
documentation for the respective device.
Delay time
Messages of temporary threshold violations
are hidden with parameterization of delay
times for warning and alarm messages.
They are displayed when the delay time
has elapsed and the current path increases
further above the upper threshold. The delay
times can be adjusted separately for each
measuring channel.
Fig. 17: Configuration interface of the slave devices in the JPC70
Button
Actions for this
UMG
