Jantex FN975 User manual

Manual size A4: Front page
FN975 Liquid automatic sanitiser dispenser
FN976 Spray automatic sanitiser dispenser
• All recommended fixings are supplied. Do not use less substantial fittings.
• Ensure the wall surface provides sufficient support for the product before proceeding to drill and install
fixings.
• For cleaning, wipe the exterior surface with a soft, wet cloth occasionally.
• For step 7: For power supply, you can use either 4x1.5V batteries (Size C, not included) OR a DC
adaptor (6V/1A, not included). Remove the batteries if using the adaptor or if the unit is not to be used
for an extended period of time. Always unplug the adaptor when not in use to prevent overheating.
• For step 10: Before use, slide the ON/OFF switch downward (ON position) first.
1
Pack Contents
x 1
x 1
x 4
x 4
3
5
A
B
2
A
B
9
B
A
6
4
108
Technical Specifications
Model Power Capacity Sensing
distance
FN975 Adaptor, or
4x1.5V
Batteries
1000ml 8-12 cm
FN976
Troubleshooting
LED light Indications Description and solution
Flashing green Working normally
Flashing red x 2 Obstacle under the sensor,
remove the obstacle
Flashing red x 5 Low battery, replace batteries
or check the adaptor
Compliance
Dispose of depleted batteries in accordance with local regulations, within the EC there are nominated disposal
points for batteries.
The WEEE logo on this product or its documentation indicates that the product must not be disposed
of as household waste. To help prevent possible harm to human health and/or the environment, the
product must be disposed of in an approved and environmentally safe recycling process. For further
information on how to dispose of this product correctly, contact the product supplier, or the local
authority responsible for waste disposal in your area.
Jantex parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
Jantex products have been approved to carry the following symbol:
7
6V, 1A
4x1.5V,
Size C
FN975-FN976_A4_v2_20201201.indd 1FN975-FN976_A4_v2_20201201.indd 1 2020/12/1 09:502020/12/1 09:50

FN975-FN976_A4_v2_20201201
DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Liquid Automatic Sanitiser Dispenser
Spray Automatic Sanitiser Dispenser
FN975
FN976
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare
EU-Richtlinie(n) • Applicazione delle
Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Electro-Magnetic Compatibility (EMC)
Directive 2014/30/EU - recast of 2004/108/EC
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to
Directive 2011/65/EU
Electromagnetic Compatibility
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Jantex
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)
and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y
estándar(es) arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Date • Data • Date • Datum • Data •
Fecha • Data
22nd October 2020
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma • Assinatura
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
• Nome por extenso
Ashley Hooper
Eoghan Donnellan
Josie Holt
Position • Functie • Fonction •
Position • Qualifica • Posición •
Função
Technical & Quality
Manager
Commercial
Manager/ Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
• Morada do fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 727D552F-6FF6-4A5D-8D2B-AA4ECA8C1563
UK 0845 146 2887
Eire
NL 040 – 2628080
FR 01 60 34 28 80
BE-NL 0800-29129
BE-FR 0800-29229
DE 0800 – 1860806
ES 901-100 133
PT [email protected]
AU 1300 225 960
