JAS AUDIO SPEAKERS
ORIOR
OWNER’S MANUAL and Package Contents
For additional requests
If you have any additional questions regarding the installation or
operation of our products, you are welcome to contact us directly via
email: “ [e-mail] “, and please check frequently our JAS
Audio official website: “ http://www.jas-audio.com “.
Page 1 of 7
http://www.jas-audio.com

JAS AUDIO
ORIOR HIGH FIDELITY LOUNDSPEAKERS SYSTEM
Smooth, precise, and punchy!
Never before will a 2-way bookshelf speaker
sound so big and with such details in its
sonic reproduction. The quick and agile bass
region goes below 40Hz, easily outshines
many large floorstanding speakers at higher
price range.
Combined with this state-of-the-arts super
tweeter, plus our selected speedy driver to
push the envelope from our Audiophile’s’
desire: - the absolute sound of the highest
resolution on pinpoint image and
transparency as well.
OWNER’S MANUAL
Introduction
Thank you for purchasing the JAS Audio Orior line of speakers.
JAS Audio speakers are designed and manufactured to the highest quality
standards. The Orior line of speakers combines ribbon and dynamic driver
technologies to produce a line of world-class speaker in performance and
appearance.
The Orior line of speakers features a unique aluminum twin-ribbon tweeter
that produces extremely clean and quick transients as well as enormous
soundstage both in width and depth. The choice of dynamic bass/midrange
drive units for each model is diligently done in effort to allow seamless
integration with the twin-ribbon tweeter. The result is yielding the lowest
coloration and maximum tonal definition.
Page 2 of 7
http://www.jas-audio.com

Unpacking Inspection
The tweeter of JAS Orior speaker is protected with a Transparent-Protective-
Sheet to prevent damaging on the Tweeter Unit
(Dispersion Board + Driver Net)*.
Customers are recommended to remove the
Transparent-Protective-Sheet immediately before
using or installing on your listening system!
Well prepared before Settling
Two caution on your speakers’near placing:
I. Do not place any kinds of metal pieces, such as: keys, needles,
staples... etc. near or closed to the Orior＇s tweeter units, because the
magnetic field can cause a strong attractive force to damage the
speaker.
II. Do not use vacuum cleaner on the speaker drivers; on the other hand,
do not direct coupling the speaker drivers by strong air via
compression gun. Any extreme blowing may damage the speakers.
*If you feel the speakers sounded very muffled and distant (abnormal); as if,
please double check all tweeter unit were covered by the Transparent-
Protective-Sheets or not?
Product Features
Cabinet
•High quality MDF (Medium Density Fiber-board)
•Inner horizontal plane bracing adds extreme rigidity
•Pure natural wool for the best vibration and resonance damping
•Top grade authentic wood veneer with polyester piano finish
•Custom machined, high current binding posts
Page 3 of 7
http://www.jas-audio.com

Unique-Crossover and the switching Key
· Utilizes a 2nd order filter for bass and a
modified 3rd order filter for treble
•Highest quality components have been used,
time aligned of all drivers.
•Two selectable Designer-Precision-modes:
[ Reference ] or [ Dynamic ] operational
crossover network to optimize for your amplifiers.
Find the best setting that fit your own system,
listen to the different carefully by inserting a key at
the back switch and turn to the indicated setting
mark. Pair of switching keys have been attached
in the Orior packing-box already.
Drivers
•Pure aluminum twin-ribbon tweeter
•High quality ceramic cone
midrange/bass drivers
•Computer designed, acoustically
contoured tweeter faceplate
· Precisely machined and
acoustically optimized bass port
Connections – Initial installation
The cables used to connect the speakers to the power amplifier can have a
significant effect on the sound of your audio system. Your authorized JAS
Audio dealer can recommend the appropriate speaker cables for your audio
system setup.
Each speaker has two terminals on the rear panel. The terminals are binding
posts that accept either spade lugs, pins and banana plugs.
Make sure the cables connected to both speakers are in phase with each
other: connect the (+) binding post on the amplifier to the (+) terminal on the
speaker, and the (-) binding post on the amplifier to the (-) terminal on the
speaker.
Page 4 of 7
http://www.jas-audio.com

Speaker Stands
Some speaker stands are hollow and have access holes that can be used to
fill in with sand, lead shot, or some other heavy material. These filler
material make the speaker stands more stable (because the center of
gravity will be close to the floor) and offer solid reference to the
mechanical moving parts of the speakers, thus provide better vibration
isolation and damping effect. In this general results in overall improved the
sonic performance over the speaker's dynamic range.
Speaker Stands with height ranging from 18
＂ - 26 ＂ is recommended, you
should note that the optimum stand height is the one that places your ears/
seating height approximately 1
＂ above the top edge of speaker.
Many speaker owners use adhesive material; such as, Blu-Tack (Bostik
Brand) / Sticky-Tack to attach the bottom of the speakers to the top of the
stands. This reduces the chances of the speakers being accidentally knocked
off the stands thus damaging the speakers. If adhesive is used, place a
small piece of adhesive under each corner of the speaker where it makes
contact with the speaker platform.
Caution: Removing speaker from the speaker stand or removing adhesive
from the speaker may cause damage to the surface of the speaker. Do so
with great care.
Speaker Placement
The JAS Orior speakers can produce excellent sound in any location.
Therefore you should use these guidelines as a starting point and make
minor adjustments to the position of the speakers and other objects in the
room until you find the combinations that sound best to you.
As a general rule, the distance between the front plane of the speakers and
the front wall of your listening room should be approximately 20% of the
total length of the room; the distance from each speaker to the closest side
wall should be about 20% of the total width of the room. The distance from
the listener＇s chair or couch to the wall behind the listener should be about
the same as the distance between the speakers and the front wall.
Page 5 of 7
http://www.jas-audio.com

This figure shows the relative
position of the two speakers and
the listening position. The front of
each speaker should be angled
toward the listening position.
( Result might vary depending on
the room acoustic conditions,
desirable result can be achieved
by continuous tweaking.)
Running-in Period
The performance of the speaker will change subtly during the initial
listening period. The drive unit suspensions will loosen up during the first
hour of use and continue to loosen up until it reaches its optimal operation
state. The time taken for the speaker to achieve its intended performance will
vary depending on the environment and its previous storage conditions as
well as how it is used. As a guide, allow up to a week for the temperature
effects to stabilize and 15 hours of average use for the mechanical parts to
attain their intended design characteristics. And up to 300 hours of use to
reach its optimal condition.
Aftercare
To prevent damage to the delicate ribbon driver of your JAS speakers, do
not vacuum the front grille cloth panel when it is mounted on the speakers.
Always remove the grille cloth panels before cleaning the grille.
The high quality clear sealed piano finish of the wood cabinet surface only
requires dusting. If needed, a damped cloth can be used for further cleaning.
Avoid use of any abrasive compounds on the cabinet as doing so may
damage the fine finish.
Caution: Do not use vacuum cleaner on the drive units of your speakers.
Doing so may damage your speakers.
Page 6 of 7
http://www.jas-audio.com

JAS Speaker Specifications
Product Model: Orior
Description: 2 way vented, 2 units
Technical Features: Aluminum twin-ribbon tweeter
Dynamic Bass w/ acoustically Bass port
Drive Units: Aluminum Ribbon tweeter with 5
” face-plate
7” ceramic cone Midrange/ BassDriver
Frequency Response: 29Hz - 60kHz ± 3dB
Sensitivity: 88 dB / 1W/ 1M
Nominal Impedance: 8 ohms
Minimal Impedance: 4 ohms
Crossover Frequency: 2200Hz
Min. Amplifier Power: 15 Watts per channel
Speaker Dimensions: W24.5 x H39.5 x D35.5 (cm)
Packing Box Sizes: W42 x H58 x D57 (cm)
Net Speaker Weight: 14kg /pc. x 2 units
Gross/Shipping Weight: 22kg /pc. x2 units
JAS AUDIO is constantly striving new design improvements, we
reserve the right to change or modify product specifications without prior notice or obligation.
Orior Package Contents
1. Each ORIOR’s packing box contains one unit/pc. of speaker, and mostly they
departure in safe as a pair to our dealers. All JAS speakers have their own
serial number (S/N), which have been mark-up at the backside of the speaker
and also written outside the packing box for factory building records. For
example labeling in couple S/N #, such as: ( 12345 A or 12345 B ), which
represents speaker A and B as in a matched pair.
2. When you opening the packing-box A with (S/N xxxxx A) labeling, you can find 2
important items at top easily, those are [ ORIOR’S MANUAL and Package
Contents ] + [ Pair of switching keys].
Happy and Good Listening to all music lovers!
Best Regards,
Set your mind free!
Revised Version 1.1 and Copyright ©March 2006 JAS AUDIO
