Anchor AN-Mini User manual

AN-MINI Speaker Monitor
Portable Speaker Monitor Specifications
Advancing Technology
The AN-Mini speaker monitor is the most powerful, smallest system in the market.
The AN-Mini is battery-operated so you can take it anywhere. Just switch it on and
you are ready for indoor or outdoor assemblies anywhere. You can also connect
your ipod, MP3 player or CD Player to the AN-Mini’s convenient Line In jack.
Anchor Audio, Inc. 888/444-6077
Portable Sound Systems • Torrance, California www.anchoraudio.com
S-ANMINI/0708
AN-MINI FEATURES
6-YEAR WARRANTY!
REACH CROWDS OF 50+
DELIVERS 109 dB OF CLEAR SOUND
BUILT-IN UHF WIRELESS RECEIVER AVAILABLE
LIGHTWEIGHT AT ONLY 2.5 POUNDS
LINE IN JACK FOR IPOD, MP3 & CD PLAYER
16 CHANNEL UHF DIVERSITY WIRELESS
BY ANCHOR AUDIO
OPERATES UP TO 12 HOURS
ON FULLY CHARGED BATTERIES
4.5” NEODYMIUM WOOFER & 30W AMPLIFIER
PHANTOM-POWERED INPUT FOR
ELECTRET-TYPE MICROPHONE
HANDHELD WIRED MICROPHONE AVAILABLE
OPTIONAL RECHARGEABLE KIT
MADE IN THE USA!
ACCESSORIES
MIC-50 Dynamic handheld wired microphone
SOFT-30 Soft case – custom colors available
SS-300 Speaker stand
RC-30 Battery charging kit
(FEATURES & SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
UHF WIRELESS
WH-6000 Wireless Handheld mic/transmitter
WB-6000 Wireless body-pack transmitter
w/ handsfree microphone. Mic options include:
Over-the-Ear/EM-60T, Lapel/LM-60,
Collar/CM-60, Headband/HBM-TA4F
AN-MINI TECHNICAL SPECIFICATIONS
Rated Power Output 30 Watts
Max SPL@Rated Power 109 dB @ 1 meter
Frequency Response 100Hz - 15KHz ±3dB
Speaker Type 4.5” Neodymium woofer
Battery Type 10 ‘AA’ alkaline
Dimensions (HWD) 5.5 x 5.5 x 6.5” / 14 x 14 x 16.5 cm
Weight 2.5 pounds / 1.13 Kg
Output
Line line level, 3.5 mm
Inputs
Line line level, 3.5 mm
Powered Mic Lo-Z phantom power, 3.5 mm jack
Mic Lo-Z, 1/4” phone
RC-30 – Recharge Kit (optional)
Battery Type 10 ‘AA’ size, NiMH 2.5 Ah
Charger AC-30
AC-30 Input 120 VAC, 60Hz, 24 watt max
AC-30/220 Input 220 VAC, 50Hz, 24 watt max
Shipping Weight 2.1 pounds / 1.0 Kg
AN-MINI MODELS
AN-MINI AC/DC powered speaker monitor
AN-MINIU1 AN-MINI w/ 1 built-in wireless receiver
(AN-MINIU1 Control Panel Shown)
