Javad HPT404BT JL User manual

All contents in this manual are copyrighted by JAVAD GNSS.
All rights reserved.The information contained herein may not be used, accessed, copied,
stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express written
consent from JAVAD GNSS
HPT404BT with GSM
Operator’s Manual
Version 1.0
Last Revised March 19, 2013

www.javad.com
© JAVAD GNSS Inc., 2012

3www.javad.com
TABLE OF CONTENTS
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Terms and Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Manual Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Screen Captures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Technical Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1. Getting Acquainted. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1. LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.2. Data and Power Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
1.3. External Antenna and GSM Antenna Connectors . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.4. Mounting Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.5. Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.6. Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
1.7. External GSM Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.8. External RF Antenna (not included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
1.9. Storage Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Chapter 2. Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1. Powering HPT404BT with GSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1. Power supply requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2. RF Antenna Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3. GSM Antenna Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Installing ModemVU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5. Connecting HPT404BT and Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
5.1. Connecting through serial port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.2. Connecting through USB port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3. Connecting through Bluetooth® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
5.4. Connecting HPT404BT and TRIUMPH-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6. Configuring HPT404BT with GSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
7. Loading New Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
8. Bluetooth Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Chapter 3. Internet services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
1. TCP client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

4www.javad.com
2. TCP server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.1. RTN corrections uploading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.2. Remote CLI support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3. NTRIP client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Chapter 4. Command Line Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1. Command Line Interface Convention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
1.1. Software Switching to Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
1.2. Hardware Switching to Maintenance Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1.3. Switching to Data Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2. Networking Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
2.1. LINK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3. Serial Interfacing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.1. DPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.2. MPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4. Special Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.1. BOOT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2. HELP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.3. SAVE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.4. SLEEP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5. Diagnostics and Identification Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.1. INFO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.2. STATE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6. RTN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7. GSM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Appendix A. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1. HPT404BT with GSM Modem Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.1. General Radio Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
1.2. Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
1.3. Transmitter Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
1.4. Receiver Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
2. Internet Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3. Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4. Connector Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Appendix B. UHF Radio Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Appendix C. Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
1. General Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Appendix D. Warranty Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5www.javad.com
PREFACE
Thank you for purchasing this product. The materials available in this Manual (the “Manual”) have been
prepared by JAVAD GNSS, Inc. (“JAVAD GNSS”) for owners of JAVAD GNSS products. It is designed
to assist owners with the use of HPT404BT with GSM modem and its use is subject to these terms and
conditions (the “Terms and Conditions”).
Note: Please read these Terms and Conditions carefully.
Terms and Conditions
USE – JAVAD GNSS modems are designed to be used by a professional. The user is expected to have a
good knowledge and understanding of the user and safety instructions before operating, inspecting or
adjusting.
COPYRIGHT – All information contained in this Manual is the intellectual property of, and copyrighted
material of JAVAD GNSS. All rights are reserved. You may not use, access, copy, store, display, create
derivative works of, sell, modify, publish, distribute, or allow any third party access to, any graphics,
content, information or data in this Manual without JAVAD GNSS’ express written consent and may only
use such information for the care and operation of your HPT404BT with GSM. The information and data
in this Manual are a valuable asset of JAVAD GNSS and are developed by the expenditure of considerable
work, time and money, and are the result of original selection, coordination and arrangement by JAVAD
GNSS.
TRADEMARKS – HPT404BT with GSM™, ModemVU™, JAVAD GNSS®are trademarks or
registered trademarks of JAVAD GNSS. Windows®is a registered trademark of Microsoft Corporation;
Bluetooth®word mark is owned by the Bluetooth SIG, Inc. Product and company names mentioned
herein may be trademarks of their respective owners.
DISCLAIMER OF WARRANTY – EXCEPT FOR ANY WARRANTIES IN THIS MANUAL OR A
WARRANTY CARD ACCOMPANYING THE PRODUCT, THIS MANUAL AND THE HPT404BT
WITH GSM MODEM ARE PROVIDED “AS-IS.” THERE ARE NO OTHER WARRANTIES. JAVAD
GNSS DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR USE OR PURPOSE. JAVAD GNSS AND ITS DISTRIBUTORS SHALL NOT BE
LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN;
NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
FURNISHING, PERFORMANCE OR USE OF THIS MATERIAL OR THE HPT404BT with GSM
MODEM. SUCH DISCLAIMED DAMAGES INCLUDE BUT ARE NOT LIMITED TO LOSS OF
TIME, LOSS OR DESTRUCTION OF DATA, LOSS OF PROFIT, SAVINGS OR REVENUE, OR
LOSS OF THE PRODUCT'S USE. IN ADDITION, JAVAD GNSS IS NOT RESPONSIBLE OR
LIABLE FOR DAMAGES OR COSTS INCURRED IN CONNECTION WITH OBTAINING

Preface
Terms and Conditions
6www.javad.com
SUBSTITUTE PRODUCTS OR SOFTWARE, CLAIMS BY OTHERS, INCONVENIENCE, OR ANY
OTHER COSTS. IN ANY EVENT, JAVAD GNSS SHALL HAVE NO LIABILITY FOR DAMAGES
OR OTHERWISE TO YOU OR ANY OTHER PERSON OR ENTITY IN EXCESS OF THE
PURCHASE PRICE FOR HPT404BT WITH GSM.
LICENSE AGREEMENT – Use of any computer programs or software supplied by JAVAD GNSS or
downloaded from a JAVAD GNSS website (the “Software”) in connection with HPT404BT with GSM
constitutes acceptance of these Terms and Conditions in this Manual and an agreement to abide by these
Terms and Conditions. The user is granted a personal, non-exclusive, non-transferable license to use such
Software under the terms stated herein and in any case only with a single HPT404BT with GSM or single
computer. You may not assign or transfer the Software or this license without the express written consent
of JAVAD GNSS. This license is effective until terminated. You may terminate the license at any time by
destroying the Software and Manual. JAVAD GNSS may terminate the license if you fail to comply with
any of the Terms or Conditions. You agree to destroy the Software and manual upon termination of your
use of HPT404BT with GSM. All ownership, copyright and other intellectual property rights in and to the
Software belong to JAVAD GNSS. If these license terms are not acceptable, return any unused software
and manual.
CONFIDENTIALITY – This Manual, its contents and the Software (collectively, the “Confidential
Information”) are the confidential and proprietary information of JAVAD GNSS. You agree to treat
JAVAD GNSS' Confidential Information with a degree of care no less stringent that the degree of care you
would use in safeguarding your own most valuable trade secrets. Nothing in this paragraph shall restrict
you from disclosing Confidential Information to your employees as may be necessary or appropriate to
operate or care for HPT404BT with GSM. Such employees must also keep the Confidentiality
Information confidential. In the event you become legally compelled to disclose any of the Confidential
Information, you shall give JAVAD GNSS immediate notice so that it may seek a protective order or other
appropriate remedy.
WEBSITE; OTHER STATEMENTS – No statement contained at the JAVAD GNSS website (or any
other website) or in any other advertisements or JAVAD GNSS literature or made by an employee or
independent contractor of JAVAD GNSS modifies these Terms and Conditions (including the Software
license, warranty and limitation of liability).
SAFETY – Improper use of HPT404BT with GSM can lead to injury to persons or property and/or
malfunction of the product. The HPT404BT with GSM modem should only be repaired by authorized
JAVAD GNSS warranty service centers. Users should review and heed the safety warnings in Appendix
C.
MISCELLANEOUS – The above Terms and Conditions may be amended, modified, superseded, or
canceled, at any time by JAVAD GNSS. The above Terms and Conditions will be governed by, and
construed in accordance with, the laws of the State of California, without reference to conflict of laws.

Preface
Regulatory Information
7www.javad.com
Regulatory Information
FCC Class A Compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
C AUTION : Any changes or modifications to the equipment not expressly approved by the party responsible for
compliance could void your authority to operate such equipment.
Canadian Emissions Labeling Requirements
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Réglement sur le matériel
brouilleur du Canada.
Industry Canada
The term “IC:” before the equipment certification number only signifies that the Industry Canada
technical specifications were met.
WEEE Directive
The following information is for EU-member states only: The use of the symbol indicates that this
product may not be treated as household waste. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information about
the take-back and recycling of this product, please contact your supplier where you purchased the product
or consult.

Preface
Manual Conventions
8www.javad.com
Manual Conventions
This manual uses the following conventions:
Screen Captures
This manual includes sample screen captures. Your actual screen can look slightly different from the
sample screen due to the modem you have connected, operating system used and settings you have
specified. This is normal and not a cause for concern.
Technical Assistance
If you have a problem and cannot find the information you need in the product documentation, contact
your local dealer.
Example Description
FileExit Click the File menu and click Exit
Link Space This format represents titles of dialog windows/boxes, names of menu options, identifies
program interface objects, such as checkboxes, edit boxes, radio buttons, etc.
Temp
This format is used to enter various string information (e.g., file and directory names) as
well as operator commands.

Chapter 1
9www.javad.com
INTRODUCTION
HPT404BT with GSM is the up-to-date unsurpassed 4 W UHF radio transceiver with USB and
Bluetooth® capacity, and built-in quad band GSM/GPRS module. HPT404BT accesses Real Time
Network (RTN) via GPRS, takes incoming data from the network, modulates it with GMSK, FSK, PSK
or most spectrum efficient QAM modulation and transmits it at RF power output levels from 15 dBm up
to 36 dBm operating in UHF frequency band (406 to 470 MHz). The data taken from RTN can be routed
to the UART, USB or Bluetooth communication ports as well. HPT404BT is also capable of receiving RF
signal from remote UHF transmitter or data from communication ports (UART, USB or Bluetooth) and
sending it over the cellular network using built-in GSM/GPRS module if such operation mode is selected.
Figure 1. HPT404BT with GSM
The HPT404BT with GSM radio transceiver provides a high-speed point-to-point and point-to-multipoint
wireless data transfer at up to 38.4 kbps. The firmware supports user selectable modulation techniques,
which allows the user achieving the highest data speed for a given range. It also includes a selectable
error correction, which improves the functioning of the radio modem under interference. The
sophisticated features of HPT404BT with GSM include data scrambling, frequency hopping, user
selectable transmit output power level, low power consumption sleep modes, autoscanning for base and
plug-and-play installation for remote terminals.
The firmware of the HPT404BT with GSM radio modem resides in a flash memory. The updating of the
radio modem programs is entirely software-based. The flash memory is re-programmable through an RS-
232 interface, USB, Bluetooth. By accessing to the internet via GPRS the HPT404BT with GSM
provides remote CLI access and can be configured remotely (through the internet) if corresponding
operation mode is selected.
1. Getting Acquainted
The HPT404BT with GSM is a rugged and very powerful external radio transceiver 146 mm wide 75 mm
deep 44 mm high, weighs 488 g.

Introduction
Getting Acquainted
10 www.javad.com
1.1. LEDs
External LED's (see Figure 2) are used for Link and Line status indication:
1.2. Data and Power Port
The HPT404BT with GSM data and power port is placed on the front of the unit (Figure 2).
Figure 2. HPT404BT with GSM front side
Through the DB15 port the HPT404BT with GSM can be connected to PC with Accessory Data-Ser-Pwr
Cable, DB9/DB15/SAE (6ft/1.8m) p/n 14-578108-02, or with JAVAD GNSS receiver with Accessory
Data-Ser-Pwr Cable, ODU-7/DB15/SAE (6ft/1,8m) p/n 14-578110-02 and can be powered.
Positio
nLED Name Description
1 PWR Solid Green if external power connected.
2 UHF Blinking if radio receives or transmits data over UHF.
3 GSM Blinking if radio receives or transmits data over GSM.
4 BT Blinking if radio receives or transmits Data over Bluetooth.
LEDs
Data and
power port

Introduction
Getting Acquainted
11www.javad.com
1.3. External Antenna and GSM Antenna Connectors
The external antenna connects to the BNC external antenna connector and GSM antenna connects to the
SMA connector which are placed on the back panel of HPT404BT with GSM.
Figure 3. RF and GSM Antenna Connectors
1.4. Mounting Bracket
The mounting bracket (optional) connects the modem to a standard pole/adapter (Figure 4).
Figure 4. Optional mounting bracket (p/n 10-587302-21)
1.5. Cables
The HPT404BT with GSM package includes standard communication and power cable DB9/DB15/SAE
(p/n 14-578110-02) for configuring the modem and providing a power source to the modem.
Figure 5. Cable DB9/DB15/SAE (p/n 14-578110-02)
1.6. Literature
HPT404BT with GSM literature, including manuals and other product information are available on the
JAVAD GNSS website (http://www.JAVAD GNSScom.com):
RF Antenna
AntennaBluetooth GSM Antenna

Introduction
Getting Acquainted
12 www.javad.com
• HPT404BT with GSM Operator’s Manual
• Functional specifications
1.7. External GSM Antenna
GSM/GPRS Antenna 850/900/1800/1900MHZ, SMA (p/n 30-587314-01):
Figure 6. GSM Antenna
1.8. External RF Antenna (not included)
Antenna type depends on the site requirements, and may be directional or omni-directional.
Warning: Do not use HPT404BT with GSM without antenna to avoid serious damage of your device.
1.9. Storage Precautions
1. Always clean the instrument after use. Wipe off dust with a cleaning brush, then wipe off dirt with
a soft cloth.
2. Store in a location with a temperature of -40°... +85°C, and no exposure to direct sunlight.
3. Use a clean cloth, moistened with a neutral detergent or water, to clean the modem. Never use an
abrasive cleaner, ether, thinner benzene, or other solvents.
Always make sure the instrument is completely dry before storing. Dry the modem with a soft, clean
cloth.

Chapter 2
13www.javad.com
CONFIGURATION
1. Powering HPT404BT with GSM
To power HPT404BT with GSM use the Battery kit 1 (p/n 99-587300-10).
Figure 1. Battery Kit 1
1.1. Power supply requirements
A single external power supply is necessary to operate HPT404BT with GSM. The external power supply
needs to be Listed for US and Certified for EU countries, it needs also to be a Limited Power Source and
rated for Outdoor Use and have an output rated for +9... +36V, 4A. This may not be the same range as
other JAVAD GNSS products with which you are familiar.
C AUTION : To avoid the introduction of hazards when operating and installing, before connecting of the equip-
ment to the supply, make sure that the supply meets local and national safety ordinances and
matches the equipment’s voltage and current requirements.
C AUTION : Never attempt any maintenance or cleaning of the supply while plugged in. Always remove supply
from AC power before attempting service or cleaning.
Warning: If the voltage supplied is below the minimum specification, the modem will suspend operation. If the voltage
supplied is above the maximum specification, the modem may be permanently damaged, voiding your
warranty.
Make sure cords are located so that will not be stepped on, tripped over, or otherwise subjected to
damage or stress. Do not operate equipment with a damaged cord or plug – replace immediately.

Configuration
RF Antenna Installation
14 www.javad.com
To reduce the risk of damage to the equipment, pull by the plug body rather than the output cord
when disconnecting the equipment.
Do not operate the supply if it has received a sharp blow, been dropped, or otherwise damaged. Do
not disassemble the supply.
Warning: Before connecting the external power source and the modem, make sure that the power source matches the
modem’s voltage and current requirements.
2. RF Antenna Installation
Warning: To avoid the equipment serious damage, do not switch the modem to transmit mode if RF antenna is not
connected!
Select the type of antenna that best fits your application and the one that offers the highest dB gain. In
addition, setup your system in the highest possible location to minimize obstacles between the
transmitting and receiving systems. Always place the antenna on the highest point available. At a
minimum, set the antenna to at least ten feet above the terrain using an antenna mast.
Some antennas intended to be attached to the pole mount adaptor (p/n 14-578117-01) are designed to be
operated with a ground plane and some without it. Antennas operating without ground plane marked in
our catalogue as NGP, e.g. UHF NGP Antenna 1/2, 2.4 dB gain, NMO:
• p/n 30-587307-01 UHF NGP Antenna 406-430 MHz, 1/2, 2.4 dB, NMO
• p/n 30-587308-01 UHF NGP Antenna 430-450 MHz, 1/2, 2.4 dB, NMO
• p/n 30-587309-01 UHF NGP Antenna 450-470 MHz, 1/2, 2.4 dB, NMO
These antennas are NO GROUND PLANE antennas with gain 2.4 dB and NMO specified connector type
with should match with your antenna adapter (pole mount or magnet mount). Antennas designed to be
operated with ground plane
• p/n 30-587303-01 UHF Antenna 406-430 MHz, 5/8, 5 dB, NMO
• p/n 30-587304-01 UHF Antenna 430-450 MHz, 5/8, 5 dB, NMO
• p/n 30-587305-01 UHF Antenna 450-470 MHz, 5/8, 5 dB, NMO
provide better gain, but to achieve the best performance of your antenna, add a UHF Antenna Ground
Plane Disk (p/n 10-587400-01) to the bottom of the antenna for a ground plane. UHF antenna Ground
Plane disk improves VSWR and as result increase RF power delivered from transmitter to antenna and
system distance range.
To install antenna with ground plane disc (see pictures below):
1. Unscrew the cone-shaped cable part;
2. Place the ground plane disc between cable parts and screw all parts together;
3. Attach cable with ground plane to the UHF antenna;

Configuration
GSM Antenna Installation
15www.javad.com
4. Place the antenna on the pole.
Use coaxial cable and connectors that are impedance-matched with the radio equipment, and make sure
to use the shortest length of cable to move the signal between the radio and the antenna:
• p/n 14-578115-01 Accessory UHF Ant Cable TNC/Magn Mount, 12ft1
• p/n 14-578116-01 Accessory UHF Ant Cable TNC/Mini-Magn Mount, 12ft1
• p/n 14-578117-01 Accessory UHF Ant Cable TNC/Pole Mount, 12ft
3. GSM Antenna Installation
Attach the GSM antenna p/n 30-587314-01 to the SMA connector marked GSM.
Note: The GSM and RF antennas should be separated for about 1 meter to avoid the interference of GSM and
UHF signals.
1. For this type of antenna a metal surface, e.g. car’s roof, serves as ground plane.
1Unscrew the
2 Place the Ground Plane between 3 Attach to the
cone-shaped cable part
cable parts and screw all together
+
UHF Antenna
UHF Antenna
Ground Plane

Configuration
Installing ModemVU
16 www.javad.com
4. Installing ModemVU
ModemVUTM is a Windows® application is a configuration program for the radio modem. ModemVU is
available from the JAVAD GNSS website.
Note: Refer to the ModemVU Software Manual for full details on installing and using ModemVU Software.
ModemVU is JAVAD GNSS’s configuration utility for external modems and modems embedded in
JAVAD GNSS modems. ModemVU provides the following functions:
• Connecting a computer to an UHF modem via a serial port.
• Displaying information about the radio modem installed in the modem.
• Programming the radio modem’s settings.
• Loading the new modem firmware.
To configure the HPT404BT modem, have the following ready:
• Computer running Windows®;
• ModemVU Software installed on the computer;
• A serial cable.
1. If downloading the program from the website, extract the program files into a folder on your hard
drive.
2. Navigate to the location of the ModemVU program and double-click the Setup.exe icon.
3. Follow the on-screen installation instructions. Click Next to continue, Back to get back to previous
step, or Cancel to quit the installation.
4. Keep the default installation location or select a new location.
5. Click Finish to complete the installation.
6. If desired, create a shortcut on the computer’s desktop for quick access to ModemVU.
To uninstall ModemVU use the Start menu on your computer:
1. Navigate to the location of the ModemVU program and double-click the Setup.exe icon.
2. Follow the on-screen installation instructions.
5. Connecting HPT404BT and Computer
Once you have established a connection between the modem and the computer, you will be able to:
• Configure the modem and its components
• Send commands to the modem
Use ModemVU to load new firmware to the modem.

Configuration
Connecting HPT404BT and Computer
17www.javad.com
5.1. Connecting through serial port
To configure, or maintain HPT404BT, you need to connect the modem and a computer using an
Accessory Data-Ser-Pwr Cable, DB9/DB15/SAE (1,8m), p/n14-578108-02.
Figure 2. Accessory Data-Ser-Pwr Cables DB9/DB15/SAE
5.2. Connecting through USB port
Make sure the computer has special USB driver installed (available from www.javad.com) before
continuing. To configure, or maintain HPT404BT using USB port, you need to connect the modem and a
computer using special cable (included in the standard kit) Access Data-Ser Cable, USB/DB15/SAE
(1,8m) (p/n 14-578123-02).
Figure 3. Cable p/n 14-578123-01
1. Download the zip-archive with USB driver from www.javad.com;
2. Extract the archive to the new empty folder;
3. Connect the USB port of the computer to the data port of the modem at the switched off power
supply by using of a cable.
4. Turn on your computer.
5. Power HPT404BT.
6. Widows will detect USB driver automatically. Otherwise it will ask to specify driver location.
Select the folder with extracted file.
5.3. Connecting through Bluetooth®
Note: Do not forget to attach the Bluetooth®antenna to Bluetooth antenna connector on the back panel of the
modem.
The HPT404BT modem contains Bluetooth®wireless technology that allows synchronization between
the modem and any other external device that supports Bluetooth®wireless technology; for example, an
IPAQ, or a computer with USB-to-Bluetooth®adapter or PCMCA-to-Bluetooth®adapter installed, etc.

Configuration
Configuring HPT404BT with GSM
18 www.javad.com
HPT404BT and external device connection procedure varies slightly depending on the type of external
device used. In general, the connection procedure is as follows:
Note: Refer to your Bluetooth®-enabled external device documentation for more detailed connection
information.
1. Turn on a Bluetooth®-enabled external device and your receiver. The default external device
mode is Master; the modem’s Bluetooth®module mode is Slave.
2. Instruct the external device (Master) to search for the modem (Slave).
3. Once the Master device detects the modem, use the procedure described in the external device’s
documentation to connect it with the modem.
5.4. Connecting HPT404BT and TRIUMPH-1
Connect the external HPT404BT UHF radio to receiver’s port B with cable Accessory Data-Ser cable,
ODU-7/DB15/SAE (6 ft./1,8m), p/n14-578110-02.
Figure 4. Connecting HPT404BT and TRIUMPH-1
Once you have established a connection between the modem and the TRIUMPH-1, you will be able to:
• Configure the modem and its components through receiver;
• Send commands to the modem trough receiver;
• Use ModemVU to load new firmware to the modem
• Transmit/receive GNSS data.
6. Configuring HPT404BT with GSM
Once you have established a connection between the modem and the computer, you will be able to:
• Configure the modem and its components
• Send commands to the modem
• Use ModemVU to load new firmware to the modem.
1. Ensure the SIM-card is installed in HPT404BT with GSM.
2. Connect the modem to PC, power it.
++

Configuration
Configuring HPT404BT with GSM
19www.javad.com
3. Start ModemVU, select HPT402/ 404BT / 404BT GSM and click Ok.
Figure 5. COM port selecting
4. Select the COM port the modem is connected to and click Connect.
5. In the GSM tab enter the parameters for PIN code, User name, Password, and APN.

Configuration
Configuring HPT404BT with GSM
20 www.javad.com
6. Set the Mode to ON and click Apply.
Figure 6. GSM tab settings
The progress bar appear. Wait the process will be complete.
7. After the modem has been successfully registered in the GSM network, in the RSSI field the signal
level appears. Use Refresh button, to refresh this parameter.
Figure 7. RSSI status displayed
