Javad TRIUMPH-VS Quick guide

All contents in this manual are copyrighted by JAVAD GNSS.
All rights reserved.The information contained herein may not be used, accessed, copied,
stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express written
consent from JAVAD GNSS
External UHF via
TRIUMPH-VS
Configuration Example
Version 1.0
Last Revised: April 28, 2012

2www.javad.com
EXTERNAL UHF MODEM
CONFIGURATION
How to activate and manage Bluetooth on HPT435BT
1. Attach antenna to the HPT435BT.
Warning: Always attach antenna before turning on! Do not use the radio without antenna, to avoid the serious damage of
the equipment.
2. Connect your HPT435BT to PC using serial port. Power the modem.
3. Start ModemVU software.
4. Select HPT435BT from the list, click Ok. Then select the port the modem is connected to and
click Connect:
Figure 1. Connecting to ModemVU

External UHF Modem Configuration
How to activate and manage Bluetooth on HPT435BT
3www.javad.com
5. Check the software version of your HPT435BT in the Identification tab. Ensure the software ver-
sion is 3.1 or newer1:
Figure 2. Identification tab
6. In the BT tab set BT to OFF and click Apply, then set the following parameters:
Figure 3. BT tab
•PIN code - enter the PIN code of the module;
•Mode - set to Slave;
•BT - set to ON to activate the Bluetooth module and click Apply.
1. Starting version 3.1 Bluetooth connection and connection with TRIUMPH-VS is supported.

4www.javad.com
7. In the Serial Interface & Tools tab set the parameters Read data to Transmit from and Write
Received data to to BT, click Apply.
Figure 4. Serial Interface & Tools tab
External UHF Modem Configuring
To configure external UHF modem HPT435BT using TRIUMPH-VS receiver, follow the instructions
below:
1. Attach antenna to the HPT435BT.
Warning: Always attach antenna before turning on! Do not use the radio without antenna, to avoid the serious damage of
the equipment.
2. Power your HPT435BT.
3. Turn on your TRIUMPH-VS.
4. On the Main screen tap SystemConnection Mode.
5. Select External radio.

External UHF Modem Configuration
External UHF Modem Configuring
5www.javad.com
6. Tap Connect using Bluetooth.
Figure 5. Connection Mode
7. Tap Local Settings and ensure that PIN is the same as has been configured in the ModemVU, tap
Apply.
Figure 6. Properties
8. Tap Discover and then select Bluetooth Name of External UHF in the list.

External UHF Modem Configuration
External UHF Modem Configuring
6www.javad.com
9. Tap Connect.
Figure 7. Bluetooth
10. Tap on the Bluetooth icon. Ensure parameters in the right column are not “--”.
Figure 8. BT STATUS
11. On the Main screen tap SettingsCommunicationUHF.

External UHF Modem Configuration
Base Configuration
7www.javad.com
12. Configure parameters such as Frequency, Output Power and Protocol.
Figure 9. HPT435BT
Note: For base station set the output power to 35000 mW, to provide the best transmitting coverage.
Base Configuration
1. On the Main screen tap SettingsActions and select Fixed Base Station:
Figure 10. Actions

External UHF Modem Configuration
Base Configuration
8www.javad.com
2. Press FN button on the front panel of Triumph-VS to switch to Action screen:
Figure 11. Action Screen
3. Tap Yellow Stone 84 on the top of the screen to open the screen with the Fixed Base Station
parameters.
4. Tap Base Station Coordinates and set up the coordinates by choosing them from the list or enter-
ing position manually:
Figure 12. Base Position
5. For transmitting of correction on the Main screen tap SettingsGNSSTransmit Data (Base).
6. Select UHF Modem, Corrections Format and Period.

External UHF Modem Configuration
Rover Configuration
9www.javad.com
7. Click on the UHF icon, check the Sent parameter. Ensure this parameter value is on the increase.
Figure 13. RADIO STATUS (Base)
Rover Configuration
1. To set up the receiving of correction tap on the Main screen SettingsGNSSReceive Data
(Rover).
2. Select UHF and corrections format.
3. Click on the UHF icon and check the LQ, Delay, Received and Lost parameters.
Figure 14. RADIO STATUS (Rover)
