GT5 AMPS
GT5 SERIES AMPLIFIERS
THE JBL
®GT5 AMPLIFIER LINE
includes a dedicated Class D subwoofer
amplifier and two full-range amplifiers that
have been engineered to deliver low distortion
and optimum system tuning at a great value.
Each model includes a 12dB-per-octave variable
electronic crossover, with the subwoofer
amplifier offering a variable bass EQ and the
full-range amplifiers offering a selectable bass
EQ. All three models feature full-range preamp
outputs to facilitate easy system-building and
wiring architecture. The GT5 amps also feature
common-dimension footprints for all three
models, which minimizes the amount of space
occupied, thus optimizing multiple-amplifier
mounting applications.
Andrew Shandro – Team Trek/Volkswagen/JBL. Photo by Sterling Lorence.

SPECS
GT5 SERIES AMPLIFIERS
GT5-A402
120-Watt 2-Channel Full-Range Amplifier
• 40W RMS x 2 channels at
4ohms and ≤1% THD + N*
• 60W RMS x 2 channels at
2ohms and ≤1% THD + N*
• Signal-to-noise ratio: 85dBA
(reference 1W into 4 ohms)*
• Signal-to-noise ratio: 101dBA
(reference rated power into 4 ohms)
• THD + N: 0.05%
(rated power @ 4 ohms)
• Built-in variable electronic crossover
• Selectable bass EQ
• Frequency response:
10Hz – 100kHz (–3dB)
• Total peak power: 240 Watts
• RCA low-level preamp inputs
• RCA low-level preamp outputs
• Dimensions (L x W x H):
7-1/2" x 9-1/4" x 2-1/8"
* CEA-2006A compliant
GT5-A604
320-Watt 4-Channel Full-Range Amplifier
• 60W RMS x 4 channels at
4ohms and ≤1% THD + N*
• 80W RMS x 4 channels at
2ohms and ≤1% THD + N*
• Signal-to-noise ratio: 85dBA
(reference 1W into 4 ohms)*
• Signal-to-noise ratio: 102dBA
(reference rated power into 4 ohms)
• THD + N: 0.05%
(rated power @ 4 ohms)
• Built-in variable electronic crossover
• Variable bass EQ on rear channel
• Frequency response:
10Hz – 100kHz (–3dB)
• Total peak power: 640 Watts
• RCA low-level preamp inputs
• RCA low-level preamp outputs
• Dimensions (L x W x H):
12" x 9-1/4" x 2-1/8"
* CEA-2006A compliant
GT5-A3001
300-Watt Mono Subwoofer Amplifier
• 175W RMS x 1 channel at
4ohms and ≤1% THD + N*
• 225W RMS x 1 channel at
2ohms and ≤1% THD + N*
• 300W RMS x 1 channel at 1 ohm
and ≤1% THD + N
• Signal-to-noise ratio: 95dBA
(reference 1W into 4 ohms)*
• Signal-to-noise ratio: 120dBA
(reference rated power into 4 ohms)
• THD + N: 0.05%
(rated power @ 4 ohms)
• Built-in variable electronic crossover
•Frequency response:
10Hz – 330Hz (–3dB)
• Total peak power: 600 Watts
•RCA low-level preamp inputs
• RCA low-level preamp outputs
• Remote bass-level control included
• Dimensions (L x W x H):
12" x 9-1/4" x 2-1/8"
* CEA-2006A compliant
