JBL Reference 610 Installation and operation manual

Bring home theater to life
Turn your flat panel TV into a full home theater with the JBL Cinema 610. Easily connectable
to any audio/video receiver, the JBL Cinema 610 delivers a box office experience that can’t
be matched anywhere else. Sink into pure JBL bliss with an 8” bass reflex, 100W powered
subwoofer with 5 identical voice-matched satellite speakers, and a dedicated center speaker
to ensure you receive flawless sound reproduction and perfect dialogue reproduction
from all your music and movie sources. With customized wall-mount options and an easy
plug-and-play format, you’re headed to the movies in no time.
CINEMA 610
Advanced 5.1 Home Theater System with Powered Subwoofer
Easy-to-install system
Voice matched satellites for detailed listening
Dedicated center channel for vocal clarity
8” (200mm) powered subwoofer for deep
rich bass
Wall brackets (built-in) and loudspeaker
cable included
Key specifications:

HARMAN International Industries, Incorporated
8500 Balboa Boulevard, Northridge, CA 91329 USA
www.jbl.com
CINEMA 610
Advanced 5.1 Home Theater System with Powered Subwoofer
What’s in the box:
5 voice-matching satellite speakers
1 powered subwoofer
Wall mounts
Speaker cables
Subwoofer LFE cable
Quick-start guide
Product specifications:
Type: speaker system
Frequency response: 38Hz – 20kHz
Maximum SPL: 109dB @ 1m
Power output (sub): 100W
© 2013 Harman International Industries, Incorporated. All rights reserved. JBL is a trademark of Harman International
Industries, Incorporated, registered in the United States and/or other countries. Features, specifications and
appearance are subject to change without notice.
Features
Satellites
Recommended Amplifier Power: 10 - 100 Watts
Power Handling (Continuous/Peak): 60W
Impedance: 8 ohms
Sensitivity: 86dB @ 2.83V/1 meter
Frequency Response: 130Hz – 20kHz (-6dB)
Midrange: 75mm (3”) cones
Tweeter: 32mm (1.25”)
Dimensions (H x W x D):
(7.87” x 3.8” x 3.92”)
200mm x 96.8mm x 99.5mm
Weight: 0.8kg (1.76lb)
Subwoofer
Amplifier: 100 Watts RMS
Frequency Response: 38Hz – 250Hz (–6dB)
Woofer: 200mm (8”)
Enclosure: Bass reflex
Dimensions (H x W x D): 357mm x 320mm x 324mm (14” x 12.6” x 12.7”)
Weight: 8.12kg (17.9lb)
Center
Impedance: 8 ohms nominal
Sensitivity: 89dB @ 2.83V/1 meter
Frequency Response:
150 Hz - 20kHz (-6dB)
Midrange: Dual 75mm (3”) cones
Tweeter: 32mm (1.25”)
Dimensions (H x W x D):
(3.92” x 9.4” x 3.78”)
99.5mm x 239mm x 96mm
Weight: 1.23kg (2.7lb)
