JBL BOOST TV User manual

JBL BOOST TV
OWNER'S MANUAL
ENGLISH

2
JBL BOOST TV
INTRODUCTION
Thank you for choosing this JBL product!
Thank you for purchasing the JBL Boost TV. The JBL Boost TV is designed to bring fun
and excitement to your home entertainment system. We urge you to take a few minutes
to read through this manual, which describes the product and includes step-by-step
instructions to help you set up and get started.
CONTACT US: If you have any questions about JBL Boost TV, its installation or its
operation, please contact your retailer or custom installer, or visit our website at:
www.JBL.com.
Included items
•1 x JBL Boost TV
•1 x Remote Control
•1 x Optical Cable
•1 x Analog Aux Cable
•1 x Power Cable
•1 x Quick Start Guide
•1 x Safety Sheet
TOP PANEL CONTROLS
Harman Display
Surround
Power
JBL Connect
Volume
Down
Volume
Up
TV Input /
JBL SoundShift
Bluetooth
• Bluetooth (see Bluetooth section)
Switches to Bluetooth source
Adds a new Bluetooth device
• Harman Display Surround (see Virtual Surround Section)
Toggles virtual surround on/off
• Volume Down
Reduces the speaker volume
• Power
Toggles between power ON and STANDBY mode
• Volume Up
Increases the speaker volume
• JBL Connect (See JBL Connect section)
Engages the speaker in JBL Connect pairing mode
• TV Input/SoundShift™ (see JBL SoundShift section)
Switches to TV input
Toggles JBL SoundShift ON/OFF
NOTE: To MUTE press both Volume Up and Volume Down at the same time.
REAR PANEL CONNECTIONS
Service / Updates only
OR
• Optical
Digital audio input
• Aux
Analog audio input
• Power
Connection for JBL Boost TV power supply
• Software
Mini USB connection for manual software updates only. If a new software update
is released, JBL will notify you if your product is registered at www.JBL.com
NOTE: JBL Boost TV is designed to support one audio connection at a time, see
the “Connecting to your TV” section for more information.
REMOTE CONTROL FUNCTIONS
Power
Bluetooth
TV Input /
JBL SoundShift
Audio FeedbackJBL Connect
Volume Down Volume Up
Mute
Harman Display
Surround
BLUETOOTH TV
• Power
Toggles between power ON and STANDBY mode

3
JBL BOOST TV
ENGLISH
• Bluetooth (see Bluetooth section)
Switches to Bluetooth source
Adds a new Bluetooth device
• TV/SoundShift™ (see JBL SoundShift section)
Switches to TV input
Toggles JBL SoundShift ON/OFF
• JBL Connect (See JBL Connect section)
Engages the speaker in JBL Connect pairing mode
• Audio Feedback (see Audio Feedback section)
Enables audible tones for certain functions
• Volume Up
Increases the speaker volume
• Volume Down
Reduces the speaker volume
• Mute
Mutes the speaker volume
• Harman Display Surround (see Virtual Surround Section)
Toggles virtual surround on/off
OPERATION
Connecting to your TV
Follow these instructions to properly connect your system.
Audio/Video
sources
JBL Boost TV
1. Connect directly each of your source devices such as your cable box or gaming
system directly to your TV. These may be HDMI connections on most HDTVs.
2. Observe your TV audio output connections—there may be an AUX (also called analog
or headphone) or Optical (also called digital) connection, or both. According to what
is available on your television, connect ONLY the AUX or Optical cable provided with
the JBL Boost TV directly from your TV to the product.
NOTE: JBL Boost TV is designed to support a single audio connection from your
TV. If there is an option for Optical or Aux, select the Optical connection—this
supports Dolby®Digital for HDTV movies.
3. Connect the provided power JBL Boost TV power cable to a power outlet.
4. Turn on your TV JBL Boost TV using your remote control.
NOTE: Your TV may have settings to disable the internal TV speakers, or enable an
external speaker like JBL Boost TV. Please refer to your TV user manual or settings
menu.
USING BLUETOOTH
Bluetooth is a wireless connection that will help you to wirelessly stream any music from your
mobile device to your JBL Boost TV. You can pair up to 3 Bluetooth devices at the same time.
JBL BOOST TV
or BLUETOOTH TV
1. Press the Bluetooth button on the top-panel or remote control. The button light will
blink slowly, indicating that there is no connected Bluetooth device. If you have never
paired a Bluetooth device before, the JBL BOOST TV will enter pairing mode directly,
which indicated by the button light fast blinking. Skip step 2 for the first time you
pair a Bluetooth device.
2. Press the Bluetooth button again to enter pairing mode. This is indicated by a fast
blinking button light.
3. Open your Bluetooth settings on your mobile device, then locate and select JBL
BOOST TV.
4. Test the connection by streaming music from your device to your JBL Boost TV.
5. To add an additional Bluetooth device (up to 3), repeat steps 2 & 4.
6. To clear all connections, press and hold the Bluetooth button for 5 seconds.
NOTE: If you have more than one Bluetooth device paired at one time, one device
may interrupt/override another device simply by pressing “PLAY”.
USING JBL SOUNDSHIFT™
JBL SoundShift is a new technology that allows you to seamlessly switch between
your TV and your wireless Bluetooth device. This helps to you watch TV and use your
Bluetooth device at the same time without reaching for the remote control to switch
between the two devices.
BLUETOOTH TV
OR

4
JBL BOOST TV
1. Confirm that you have paired at least one Bluetooth device to JBL Boost TV (See
“Using Bluetooth” section).
2. Press the TV button on the Remote Control or Top-panel buttons until the LED turns
BLUE. This color indicates that JBL SoundShift is ON.
3. Play sound from your TV through your JBL Boost TV in a normal manner.
4. Press PLAY on your mobile device to stream music. You will hear the Bluetooth audio
“break in” over your TV sound.
5. Press PAUSE on your mobile device. You will hear the audio automatically switch
back to your TV.
USING JBL CONNECT
JBL Connect lets you wirelessly daisy chain multiple speakers. JBL Connect requires
an additional compatible speaker like JBL Flip 3, JBL Xtreme, or JBL Pulse 2. For more
information, please visit our website at www.jbl.com
1. Confirm that you have paired at least one Bluetooth device to JBL Boost TV
2. Press the JBL Connect button on the remote control or the top-panel button on JBL
Boost TV.
3. Press the JBL Connect button on your other JBL speaker.
4. Stream music from your wireless device. You will hear sound on both speakers
5. The volume is synchronized between the two devices—turning the volume up or
down on one device will affect the other.
6. To disable JBL Connect, turn off the second device.
NOTE: JBL Connect supports Bluetooth audio streaming only. Audio from the wired
TV input will not stream to the second JBL device.
USING AUDIO FEEDBACK
Audio feedback enables audible tones indicate certain product features. When Audio
feedback is ON, you will hear tones for specific actions on the JBL Boost TV:
1. Bluetooth Pairing is ON.
2. Bluetooth device is connected
3. JBL Connect paring is ON
4. JBL Connect device is connected
5. JBL SoundShift On/Off
USING VIRTUAL SURROUND
Harman Display Surround brings rich virtual surround sound to your home entertainment
experience. Turn Harman Display Surround ON when you are watching movies for a wide,
spacious sound effect.
1. To turn Harman Display Surround ON, press
the button on the remote control or the top-
panel.
2. The button light is off for Harman Display
Surround OFF, White for ON.
USING YOUR OWN TV REMOTE CONTROL (TV REMOTE
LEARNING)
TV
SOURCE
1. Press button on device
2. Press button on remote
Command is learned
LED BEHAVIOR
You can use your own TV remote control to command JBL Boost TV. For example, when
you press POWER ON, you will turn on your TV and JBL Boost TV at the same time. This
simplifies your system helps you keep your TV and speaker in sync.
1. Confirm that JBL Boost TV is ON
2. Press and hold the top-panel Harman Display Surround Button for 5 seconds until
the LED flashes amber. If the LED does not flash, release the button and try again.
3. Press the JBL Boost TV top-panel VOLUME UP button
4. Aim the TV remote at the front of the JBL boost TV and slowly press the VOLUME UP
button on the TV remote until the Harman Display Surround button flashes white for
one second. This indicates that the programming operation has been successful.
5. Repeat steps 3 and 4 for VOLUME DOWN, POWER, and MUTE (to mute the JBL Boost
TV, press VOLUME UP and VOLUME DOWN buttons at the same time).
6. To exit the learning mode (at any time or when the learning is complete), press and
hold the Harman Display Surround button until the amber LED stops flashing.
TROUBLESHOOTING
If your JBL Boost TV does not perform the way you think it should, check whether the
problem is covered in this section before contacting you dealer or a JBL representative.
Problems Solutions
If the speaker does not turn ON Check if the speaker power supply's AC
cord is plugged into a working AC outlet
and that the power supply is plugged
into the speaker.
If there is no sound coming from the
speaker
Check the power is set to ON, then
check to see if the volume is turned up.
Check if your TV has certain settings to
enable the audio connection.
If there is NO sound from the system,
even when the speaker's volume is
turned all the way up
If the TV or source component is
connected via a variable output, check
its instructions if the output is not turned
down too low.
HARMAN International Industries,
Incorporated 8500 Balboa Boulevard,
Northridge, CA 91329 USA
www.jbl.com TR01354_A
© 2015 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of
HARMAN International Industries, Incorporated, registered in the United States and/or other countries.
All Rights Reserved. Features, specifications and appearance are subject to change without notice.
Harman Display Surround ON.
Harman Display Surround OFF.

Торговая марка : JBL
Назначение товара : АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
Изготовитель : ХАРМАН ИНТЕРНЕШНЛ ИНДАСТРИЗ ИНКОРПОРЕЙТЕД, США, 06901 КОННЕКТИКУТ, г.СТЭМФОРД,
АТЛАНТИК СТРИТ 400, ОФИС 1500
Страна происхождения : Китай
Импортер в Россию : OOO «ХАРМАН РУС СиАйЭс», РОССИЯ, 123317, МОСКВА, ПРЕСНЕНСКАЯ НАБ, Д.10
Гарантийный период : 1 год
Информация о сервисных центрах : www.harman.com/ru тел. [phone]
Срок службы : 5 лет
Срок хранения : не ограничен
Условия хранения : Cтандартные при нормальных значениях климатических факторов внешней среды
Номер документа соответствия :
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы символов серийного
номера изделия, следующих после разделительного знака «-». Кодировка соответствует порядку букв латинского
алфавита, начиная с января 2010 года: 000000-MY0000000, где «M» - месяц производства (А - январь, B - февраль, C - март и
т.д.) и «Y» - год производства (A - 2010, B - 2011, C - 2012 и т.д.).
5
JBL BOOST TV
ENGLISH
