JBL Control Control 1X User manual

CONTROL 1X
Personal-Size Monitor Loudspeaker
Control 1X OM 11/12/99 10:59 AM Page 1

• Rugged, high-impact
molded-plastic cabinet
• Video-shielded
• Optional adjustable wall-
mount brackets available
thank you for choosing J L. For more than 50 years, J L has been
involved in every aspect of music and film recording and reproduction, from
live performances to the recordings you play in your home, car or office.
We’re confident that the J L loudspeakers you have chosen will provide
every note of enjoyment that you expected – and that when you think about
purchasing additional audio equipment for your home, car or office, you will
once again choose J L.
Please take a moment to complete the enclosed profile card. It enables us to
keep you posted on our latest advancements, and helps us to better understand
our customers and build products that meet their needs and expectations.
J L Consumer Products
features
one. Speaker Placement
As front speakers
As rear speakers
5 – 6 ft.
included
Control 1X OM 11/12/99 10:59 AM Page 2

connection tips
two. Speaker Connections
– +– +
Front or Rear Speaker Outputs
LEFT RIGHT
LEFT RIGHT
–+–+
Speakers and electronics
terminals have correspond-
ing (+) and (–) terminals.
It is important to connect
both speakers identically:
(+) on the speaker to (+) on
the amplifier and (–) on
the speaker to (–) on the
amplifier. Wiring “out of
phase” results in thin
sound, weak bass and a
poor stereo image.
The Control 1X loud-
speakers may be wall-
mounted. This product is
not intended for ceiling
mounting. Optional
adjustable wall-mount
brackets are available from
J L. Contact your dealer or
call 800-336-4J L for a
dealer near you.
three. Wall-Mounting
Control 1X OM 11/12/99 10:59 AM Page 3

Troubleshooting
If there is no sound from any
of the speakers:
• Check that receiver/
amplifier is on and a source
is playing.
• Review proper operation of
your receiver/amplifier.
If there is no sound coming
from one speaker:
• Check the “ alance”
control on your receiver/
amplifier.
• Check all wires and con-
nections between receiver/
amplifier and speakers.
• Make sure all wires are
connected. Make sure none
of the speaker wires are
frayed, cut or punctured.
If the system plays at low
volumes but shuts off as
volume is increased:
• Check all wires and con-
nections between receiver/
amplifier and speakers.
• Make sure all wires are
connected. Make sure none
of the speaker wires are
frayed, cut or punctured.
• If more than one pair of
main speakers is being used,
check the minimum imped-
ance requirements of your
receiver/amplifier.
If there is no (or low) bass
output:
• Make sure the polarities
(+ and –) of the left and
right “Speaker Inputs” are
connected properly.
Notice to Purchaser:
J L assumes no responsibility or lia-
bility for injuries or property damage –
direct, indirect or consequential –
resulting from the improper installa-
tion of Control 1X loudspeakers.
High-Frequency Driver 1/2" Titanium-laminate, shielded
Low-Frequency Driver 4", Shielded
Crossover Frequency 4,000Hz
Frequency Response 80Hz – 20kHz
Sensitivity 89d
Nominal Impedance 8 Ohms
Recommended Amplifier
Power Range 10 – 80 Watts
Dimensions (H x W x D) 9 x 6-1/16 x 5-7/16"
228 x 155 x 139mm
Weight (each) 5.2 lbs/2.4 kg
Specifications
J L Consumer Products
250 Crossways Park Drive, Woodbury, NY 11797
8500 alboa oulevard, Northridge, CA 91329
1-800-336-4J L (4525) (USA only)
www.jbl.com
©1999 J L, Incorporated.
J L is a registered trademark of J L, Incorporated.
8/99 Part No. 1111-CTRL1XOM
A Harman International Company
Declaration of Conformity
We,JBL Europe A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the product described
in this owner’s manual is in compliance with technical
standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
JBL Europe A/S
Birkerød. DENMARK. 8/99
