JBS DPM User manual

INSTRUCTION MANUAL
DPM
Manual Solder Paste Dispenser

2
Syringe
Manual ..................................................... 1 unit
Ref. 0027208
5cc Syringe Barrel, Piston, Cap ... 2 units
Replacement Ref. SB05CC (5 units)
Manual Solder Paste Dispenser .... 1 unit
3cc Syringe Barrel, Piston, Cap ... 2 units
Replacement Ref. SB03CC (5 units)
Adapter for 3cc Syringe ................... 1 unit
The following items are included:
Packing List
This manual corresponds to the following reference:
DPM-B
Piston
Syringe
Piston
Cap
Cap

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
3
Features
Syringe
3cc or 5cc
Piston
Lever
Adapter for 3cc Syringe
(not needed for 5cc
Syringe)
Plunger
Dispensing Needle*
(also Tapered Tips*
available)
References see page
6 and 7.
Grip Pad
The DPM works with 3cc and 5cc Syringes.
* not included

BES
DPM-B
BES
DPM-B
BES
DPM-B
BES
DPM-B
BES
DPM-B
4
For 3cc syringes the adaptor is needed.
Assemble the adapter by clipping onto the
barrel.
4. Adapter Use (for 3cc Syringe only)
Operation
Take the barrel filled with solder paste and
place the corresponding piston into the
barrel.
1. Pay attention to the fact that the plunger
enters with its cylindrical part in the syringe
and the direcction of the teeth angle
corresponds to the upper image. Otherwise,
the DPM does not work properly.
2. Insert the plunger into te piston and
press the piston against the solder paste to
eliminate the air inside the barrel.
Thread the tip onto the syringe barrel.
1. Piston Placement
The DPM works with 3cc and 5cc Syringes. Ask your solder paste supplier for this format or fill the
JBC syringe barrel with solder paste.
2. Plunger Placement
3. Tip Placement
1
2

BES
DPM-B
BES
DPM-B
BES
DPM-B
BES
DPM-B
BES
DPM-B
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
5
1
2
Lower the lever until it fits in with the plunger. Press the DPMs upper part downwards until
solder paste comes out.
Note: When the lever reaches the end of its
stroke, the plunger is reloaded automatically
by lifting and pressing down the DPMs upper
part, the lever automatically jumps into the
next plunger groove and the solder paste
can be dispensed again.
7. Lever Positioning 8. Dispensing
1. Insert the prepared syringe, including the
plunger, into the DPM.
2. Push the syringe down until it snaps
into place and the barrel flange rests in the
opening.
6. Syringe Insertion
Open the DPM by lifting its upper part and
the lever.
5. Lever Lifting

6
BES
DPM-B
JBC offers two different types of dispensing tips, each type with different tip diameters.
Availabel at www.jbctools.com.
6.5 mm
0.26 in
STYLE Ref. COLOR
SOLDER
PASTE
(recomended)
GAUGE ØID
(mm/in)
ØOD
(mm/in)
LENGTH
(mm/in)
TOTAL
LENGTH
(mm/in)
QTY
Stainless
Steel
Needles
ND18S6 Green Type 2 18 0.84/0.050 1.27/0.033
6.5/0.26 24/0.94 10
ND20S6 Pink Type 3 20 0.61/0.036 0.90/0.024
ND21S6 Purple Type 3 21 0.51/0.032 0.82/0.020
ND22S6 Blue Ty pe 3 22 0.41/0.028 0.72/0.016
ND23S6 Orange Type 3 23 0.31/0.025 0.63/0.013
ND25S6 Plan Red Type 4 25 0.25/0.020 0.50/0.010
ND27S6 Clear Type 5 27 0.2/0.016 0.40/0.008
ND30S6 Lavender Type 6 30 0.15/0.012 0.31/0.006
Dispensing Needles* and Tapered Tips*
Despensing Needles with Stainless Steel Tips
24 mm
0.94 in
* not included

40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
7
BES
DPM-B
32 mm
1.26 in
STYLE Ref. COLOR
SOLDER
PASTE
(recomended)
GAUGE ØID
(mm/in)
ØOD
(mm/in)
TOTAL
LENGTH
(mm/in)
QTY
Tapered
Tips
ND18P Green Type 2 18 0.84/0.033 1.27/0.050
32/1.26 10
ND20P Pink Type 3 20 0.64/0.024 1.20/0.048
ND22P Blue Type 3 22 0.41/0.016 0.72/0.028
ND25P Red Type 4 25 0.25/0.010 0.50/0.020
ND27P Clear Type 5 27 0.2/0.008 0.40/0.016
Tapered Tips

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
Specifications
0027208-0521
DPM
Manual Solder Paste Dispenser
Ref.: DPM-B
- Dimensions/Net Weight: 130 x 66 x 16 mm / 0.05 kg
(L x W x H) 5.12 x 2.60 x 0.63 in / 0.11 lb
- Package Dimensions/Weight: 155 x 55 x 45 mm / 0.074 kg
(L x W x H) 6.10 x 2.17 x 1.77 in / 0.16 lb
Complies with CE standards
ESD Safe
