jcb JZ140 T4i User manual

OPERATOR'S MANUAL
EXCAVATOR
JZ140 [T4i], JZ141 [T4F]
EN - 9831/4300
ISSUE 1 - 05/2017
THIS MANUAL SHOULD ALWAYS STAY WITH THE MACHINE

OPERATOR'S
MANUAL
EXCAVATOR
JZ140 [T4i], JZ141 [T4F]
EN - 9831/4300
ISSUE 1 - 05/2017
This manual contains original instructions, verified by
the manufacturer (or their authorized representative).
Copyright 2016 © JCB SERVICE
All rights reserved. No part of this publication may
be reproduced, stored in a retrieval system, or
transmitted in any form or by any other means,
electronic, mechanical, photocopying or otherwise,
without prior permission from JCB SERVICE.
www.jcb.com
Foreword
The Operator's Manual
You and others can be killed or seriously injured
if you operate or maintain the machine without
first studying the Operator's Manual. You must
understand and follow the instructions in the
Operator's Manual. If you do not understand
anything, ask your employer or JCB dealer to
explain it.
Do not operate the machine without an Operator's
Manual, or if there is anything on the machine you
do not understand.
Treat the Operator's Manual as part of the machine.
Keep it clean and in good condition. Replace the
Operator's Manual immediately if it is lost, damaged
or becomes unreadable.
Machine Delivery and Installation
Even if you have operated this type of equipment
before, it is very important that your new machines
operations and functions are explained to you by
a JCB Dealer Representative following delivery of
your new machine.
Following the installation you will know how to gain
maximum productivity and performance from your
new product.
Please contact your local JCB dealer if the
Installation Form (included in this manual) has not
yet been completed with you.
Your local JCB Dealer is
