jcb JZ140 User manual

Copyright © 2004 JCB SERVICE. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any other means,
electronic, mechanical, photocopying or otherwise, without prior permission from JCB SERVICE.
World Class
Customer Support
9803/9910-3
Publication No.
Issued by JCB Technical Publications, JCB Aftermarket Training, Woodseat, Rocester, Staffordshire, ST14 5BW, England. Tel [phone] Fax [phone]
Service Manual
JZ140
Service Manual - JZ140
Section 1 - General Information
Section 2 - Care & Safety
Section 3 - Maintenance
Section B - Body & Framework
Section C - Electrics
Section E - Hydraulics
Section F - Transmission
Section J - Track & Running Gear
Section K - Engine

Copyright © 2004 JCB SERVICE. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any other means,
electronic, mechanical, photocopying or otherwise, without prior permission from JCB SERVICE.
World Class
Customer Support
9803/9910-2
Publication No.
Issued by JCB Technical Publications, JCB Aftermarket Training, Woodseat, Rocester, Staffordshire, ST14 5BW, England. Tel [phone] Fax [phone]
Section 2
Care & Safety
Service Manual - JZ140
Section 1 - General Information
Section 2 - Care & Safety
Section 3 - Maintenance
Section B - Body & Framework
Section C - Electrics
Section E - Hydraulics
Section F - Transmission
Section J - Track & Running Gear
Section K - Engine

Page No.Contents
Section 2 - Care and Saftey
2-i 2-i
Safety Notices
Important Information ................................................................................ 2-1
Safety Check List ....................................................................................... 2-2
Safety Labels ........................................................................................... 2-12

Section 2 - Care and Saftey
2-1 2-1
9803/9910-2
Safety Notices
Important Information
T1-042
The Operator Manual
!MWARNING
You and others can be killed or seriously injured if you
operate or maintain the machine without first studying
the Operator Manual. You must understand and follow
the instructions in the Operator Manual. If you do not
understand anything, ask your employer or JCB
dealer to explain it.
INT-1-4-2
Do not operate the machine without an Operator Manual,
or if there is anything on the machine you do not
understand.
Treat the Operator Manual as part of the machine. Keep it
clean and in good condition. Replace the Operator Manual
immediately if it is lost, damaged or becomes unreadable.
Safety Warnings
In this publication and on the machine, there are safety
notices. Each notice starts with a signal word. The signal
word meanings are given below.
!MDANGER
Denotes an extreme hazard exists. If proper
precautions are not taken, it is highly probable that the
operator (or others) could be killed or seriously
injured.
INT-1-2-1
!MWARNING
Denotes a hazard exists. If proper precautions are not
taken, the operator (or others) could be killed or
seriously injured.
INT-1-2-2
!MCAUTION
Denotes a reminder of safety practices. Failure to
follow these safety practices could result in injury to
the operator (or others) and possible damage to the
machine.
INT-1-2-3
This safety alert system identifies
important safety messages in this
manual. When you see this symbol, be
alert, your safety is involved, carefuly
read the message that follows, and inform
other operators.

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-2 2-2
9803/9910-2
Safety Check List
P11-1007_3
Safety - Yours and Others
INT-1-3-1_3
All machinery can be hazardous. When a machine is
correctly operated and properly maintained, it is a safe
machine to work with. But when it is carelessly operated or
poorly maintained it can become a danger to you (the
operator) and others.
In this manual and on the machine you will find warning
messages. Read and understand them. They tell you of
potential hazards and how to avoid them. If you do not fully
understand the warning messages, ask your employer or
JCB distributor to explain them.
But safety is not just a matter of responding to the
warnings. All the time you are working on or with the
machine you must be thinking what hazards there might be
and how to avoid them.
Do not work with the machine until you are sure that you
can control it.
Do not start any job until you are sure that you and those
around you will be safe.
If you are unsure of anything, about the machine or the job,
ask someone who knows. Do not assume anything.
Remember
BE CAREFUL
BE ALERT
BE SAFE
General Safety
T1-043
!MWARNING
To operate the machine safely you must know the
machine and have the skill to use it. You must abide by
all relevant laws, health and safety regulations that
apply to the country you are operating in. The
Operator Manual instructs you on the machine, its
controls and its safe operation; it is not a training
manual. If you are a new operator, get yourself trained
in the skills of using a machine before trying to work
with it. If you don't, you will not do your job well, and
you will be a danger to yourself and others.
INT-1-4-1
!MWARNING
Care and Alertness
All the time you are working with or on the machine,
take care and stay alert. Always be careful. Always be
alert for hazards.
INT-1-3-5
!MWARNING
Clothing
You can be injured if you do not wear the proper
clothing. Loose clothing can get caught in the
machinery. Wear protective clothing to suit the job.
Examples of protective clothing are: a hard hat, safety
shoes, safety glasses, a well fitting overall, ear-
protectors and industrial gloves. Keep cuffs fastened.
Do not wear a necktie or scarf. Keep long hair
restrained. Remove rings, watches and personal
jewellery.
INT-1-3-6_2
!MWARNING
Alcohol and Drugs
It is extremely dangerous to operate machinery when
under the influence of alcohol or drugs. Do not
consume alcoholic drinks or take drugs before or
while operating the machine or attachments. Be aware
of medicines which can cause drowsiness.
INT-1-3-9_2

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-3 2-3
9803/9910-2
!MWARNING
Feeling Unwell
Do not attempt to operate the machine if you are
feeling unwell. By doing so you could be a danger to
yourself and those you work with.
8-1-2-4
!MWARNING
Mobile Phones
Switch off your mobile phone before entering an area
with a potentially explosive atmosphere. Sparks in
such an area could cause an explosion or fire
resulting in death or serious injury.
Switch off and do not use your mobile phone when
refuelling the machine.
INT-3-3-9
!MWARNING
Lifting Equipment
You can be injured if you use incorrect or faulty lifting
equipment. You must identify the weight of the item to
be lifted then choose lifting equipment that is strong
enough and suitable for the job. Make sure that lifting
equipment is in good condition and complies with all
local regulations.
INT-1-3-7_2
!MWARNING
Raised Equipment
Never walk or work under raised equipment unless it
is supported by a mechanical device. Equipment
which is supported only by a hydraulic device can
drop and injure you if the hydraulic system fails or if
the control is operated (even with the engine stopped).
Make sure that no-one goes near the machine while
you install or remove the mechanical device.
13-2-3-7_3
!MWARNING
Raised Machine
NEVER position yourself or any part of your body
under a raised machine which is not properly
supported. If the machine moves unexpectedly you
could become trapped and suffer serious injury or be
killed.
INT-3-3-7_1
!MDANGER
Lightning
Lightning can kill you. Do not use the machine if there
is lightning in your area.
5-1-1-2
!MWARNING
Machine Modifications
This machine is manufactured in compliance with
legislative and other requirements. It should not be
altered in any way which could affect or invalidate any
of these requirements. For advice consult your JCB
Distributor.
INT-1-3-10_2

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-4 2-4
9803/9910-2
Operating Safety
!MWARNING
Machine Condition
A defective machine can injure you or others. Do not
operate a machine which is defective or has missing
parts. Make sure the maintenance procedures in this
manual are completed before using the machine.
INT-2-1-2_2
!MWARNING
Machine Limits
Operating the machine beyond its design limits can
damage the machine, it can also be dangerous. Do not
operate the machine outside its limits. Do not try to
upgrade the machine performance with unapproved
modifications.
INT-2-1-4
!MWARNING
Engine/Steering Failure
If the engine or steering fails, stop the machine as
quickly as possible. Do not operate the machine until
the fault has been corrected.
INT-2-1-5
!MWARNING
Exhaust Gases
Breathing the machine exhaust gases can harm and
possibly kill you. Do not operate the machine in closed
spaces without making sure there is good ventilation.
If possible, fit an exhaust extension. If you begin to
feel drowsy, stop the machine at once and get into
fresh air.
INT-2-1-10_2
!MWARNING
Work Sites
Work sites can be hazardous. Inspect the site before
working on it. You could be killed or injured if the
ground gives way under your machine or if piled
material collapses onto it. Check for potholes and
hidden debris, logs, ironwork etc. Any of these could
cause you to lose control of your machine. Check for
utilities such as electric cables (overhead and
underground), gas and water pipes etc. Mark the
positions of the underground cables and pipes. Make
sure that you have enough clearance beneath
overhead cables and structures.
INT-2-2-1_2
!MWARNING
Communications
Bad communications can cause accidents. Keep
people around you informed of what you will be doing.
If you will be working with other people, make sure any
hand signals that may be used are understood by
everybody. Work sites can be noisy, do not rely on
spoken commands.
INT-2-2-3
!MWARNING
Parking
An incorrectly parked machine can move without an
operator. Follow the instructions in the Operator
Manual to park the machine correctly.
INT-2-2-4_2
!MWARNING
Banks and Trenches
Banked material and trenches can collapse. Do not
work or drive too close to banks and trenches where
there is danger of collapse.
INT-2-2-5
!MWARNING
Safety Barriers
Unguarded machines in public places can be
dangerous. In public places, or where your visibility is
reduced, place barriers around the work area to keep
people away.
INT-2-2-8

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-5 2-5
9803/9910-2
!MDANGER
Sparks
Explosions and fire can be caused by sparks from the
exhaust or the electrical system. Do not use the
machine in closed areas where there is flammable
material, vapour or dust.
INT-2-2-10
!MWARNING
Hazardous Atmospheres
This machine is designed for use in normal out door
atmospheric conditions. It should not be used in an
enclosed area without adequate ventilation. Do not
use the machine in a potentially explosive
atmosphere, i.e. combustible vapours, gas or dust,
without first consulting your JCB Distributor.
INT-2-1-14
!MCAUTION
Regulations
Obey all laws, work site and local regulations which
affect you and your machine.
INT-1-3-3
!MWARNING
Practice
You or others can be killed or seriously injured if you
do unfamiliar operations without first practising them.
Practise away from the work site on a clear area. Keep
other people away. Do not perform new operations
until you are sure you can do them safely.
INT-2-1-1
!MWARNING
Airborne particles of light combustible material such
as straw, grass, wood shavings, etc. must not be
allowed to accumulate within the engine compartment
or in the propshaft guards (when fitted). Inspect these
areas frequently and clean at the beginning of each
work shift or more often if required. Before opening
the engine cover, ensure that the top is clear of debris.
5-3-1-12_3
!MWARNING
Keep the machine controls clean and dry. Your hands
and feet could slide off slippery controls. If that
happens you could lose control of the machine.
2-2-3-6
!MWARNING
Electrical Power Cables
You could be electrocuted or badly burned if you get
the machine or its attachments too close to electrical
power cables.
You are strongly advised to make sure that the safety
arrangements on site comply with the local laws and
regulations concerning work near electric power lines.
Before you start using the machine, check with your
electricity supplier if there are any buried power
cables on the site.
There is a minimum clearance required for working
beneath overhead power cables. You must obtain
details from your local electricity supplier.
2-2-5-4
!MCAUTION
If you have an attachment which is not covered in the
Operator Manual do not install it, use it or remove it
until you have obtained, read and understood the
pertinent information. Install attachments only on the
machines for which they were designed.
5-5-1-1_2
!MWARNING
Use only the JCB approved attachments that are
specified for your machine. Operating with non-
specified attachments can overload the machine,
causing possible damage and machine instability
which could result in injury to yourself or others.
The use of non-approved attachments could invalidate
your warranty.
2-4-5-2_1

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-6 2-6
9803/9910-2
!MDANGER
Working Platform
Using the machine as a working platform is
hazardous; you can fall off and be killed or injured.
Never use the machine as a working platform.
5-1-5-9
!MWARNING
Machine Safety
Stop work at once if a fault develops. Abnormal
sounds and smells can be signs of trouble. Inspect
and repair before resuming work.
8-1-2-3
!MWARNING
Touching hot surfaces can burn skin. The engine and
machine components will be hot after the unit has
been running. Allow the engine and components to
cool before servicing the unit.
10-1-1-40
!MWARNING
Travelling at High Speeds
Travelling at high speeds can cause accidents. Do not
reverse in a high gear with full throttle. Always travel
at a safe speed to suit working conditions.
INT-5-3-3
!MWARNING
The engine has exposed rotating parts. Switch OFF the
engine before working in the engine compartment. Do
not use the machine with the engine cover open.
5-2-6-5
!MWARNING
You could be killed or seriously injured if you operate
a machine with a damaged or missing ROPS/FOPS. If
the Roll Over Protection Structure (ROPS)/Falling
Objects Protection Structure (FOPS) has been in an
accident, do not use the machine until the structure
has been renewed. Modifications and repairs that are
not approved by the manufacturer may be dangerous
and will invalidate the ROPS/FOPS certification.
INT-2-1-9_6
!MWARNING
Visibility
Accidents can be caused by working in poor visibility.
Use your lights to improve visibility. Keep the road
lights, windows and mirrors clean.
Do not operate the machine if you cannot see clearly.
5-1-4-7
!MWARNING
Keep Your Hands and Feet Inside the Vehicle
When using the machine, keep your hands and feet
clear of moving parts. Keep your hands and feet within
the operator compartment while the vehicle is in
motion.
13-1-1-17
!MWARNING
Controls
You or others can be killed or seriously injured if you
operate the control levers from outside the machine.
Operate the control levers only when you are correctly
seated.
0179_2
!MCAUTION
Passengers
Passengers in or on the machine can cause accidents.
Do not carry passengers.
INT-2-2-2_1
!MWARNING
Fires
If your machine is equipped with a fire extinguisher,
make sure it is checked regularly. Keep it in the correct
machine location until you need to use it.
Do not use water to put out a machine fire, you could
spread an oil fire or get a shock from an electrical fire.
Use carbon dioxide, dry chemical or foam
extinguishers. Contact your nearest fire department as
quickly as possible. Firefighters should use self-
contained breathing apparatus.
INT-3-2-7_2

Section 2 - Care and Saftey
Safety Notices
Safety Check List
2-7 2-7
9803/9910-2
!MWARNING
Should the machine start to roll over, you can be
crushed if you try to leave the cab. If the machine
starts to roll over, do not try and jump from the cab.
Stay in the cab, with your seat belt fastened.
INT-2-1-12
!MWARNING
Seat Belt
Operating the machine without a seat belt can be
dangerous. Before starting the engine, make sure your
seat belt is fastened. Check the tightness and
condition of the seat belt securing bolts regularly (see
maintenance schedules).
INT-2-1-8_1
Maintenance Safety
!MWARNING
Communications
Bad communications can cause accidents. If two or
more people are working on the machine, make sure
each is aware of what the others are doing. Before
starting the engine make sure the others are clear of
the danger areas; examples of danger areas are: the
rotating blades and belt on the engine, the
attachments and linkages, and anywhere beneath or
behind the machine. People can be killed or injured if
these precautions are not taken.
INT-3-1-5
!MWARNING
Repairs
If your machine does not function correctly in any way,
get it repaired straight away. Neglect of necessary
repairs could result in an accident or affect your
health. Do not try to do repairs or any other type of
maintenance work you do not understand. To avoid
injury and/or damage get the work done by a specialist
engineer.
GEN-1-5_2
!MWARNING
Metal Splinters
You can be injured by flying metal splinters when
driving metal pins in or out. Use a soft faced hammer
or copper pin to remove and fit metal pins. Always
wear safety glasses.
INT-3-1-3_2
!MWARNING
Electrical Circuits
Understand the electrical circuit before connecting or
disconnecting an electrical component. A wrong
connection can cause injury and/or damage.
INT-3-1-4

Download the full PDF manual instantly.
Our customer service e-mail:
[e-mail]
