JCM Technologies ACCESS-5K User manual

EN
ACCESS-5K
ACCESS CONTROL UNIT
instruction manual
jcmtechnologies

Introduction 3
General description 3
Installation 4
Fixing 4
Wiring 5
Power supply + relays 5
Proximity readers 6
Configuration 7
Verification 8
LED Indicators 8
Maintenance 9
Firmware update 9
Cell battery replacement for time/date loss 9
Technical Data 10
Electrical parameters 10
Physical parameters 10
Radiofrequency parameters 10
Solving problems 11
FAQs 11
Safety instructions 13
Use of the system 13
EC Declaration of conformity 13
ACCESS-5K
Contents
2 - jcmtechnologies

COMMUNICATIONS
CARD CONNECTOR
Optionally, if a GSM-CARD
is connected, the
ACCESS-5K can be remote
managed in real time.
3 - jcmtechnologies
ACCESS-5K
Introduction
The ACCESS-5K is an autonomous access control unit with time scheduling for small installations up
to 2 doors.
User management is only via Soft Assistant, it is secured against transmitter copies.
It completes the ACCESS family with advanced features:
• 5000 users and events
• Scheduling for groups and relays
• 12/24 Vac/dc power supply
• 2 independent Bus L / Wiegand26 inputs
• Improved events management
• Firmware update
General description
ANT
COMMS. CARD ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
POWER
SUPPLY
OUPUT
RELAYS
(R1/R2)
PROXIMITY
READERS
RD1/RD2
MEMORY
SLOT
MICRO SD
Button cell CR2032
Memorises data and time
OPERATION LEDS
12/24V
ac/dc

ACCESS-5K
Installation
4 - jcmtechnologies
Installation with support
Installation without support
Fixing
DRILL
HANG DEVICE
4
UNSCREW
1
SCREW
5
REMOVE SUPPORT
2
UNSCREW
3
ANT
COMMS. CARD ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
DRILL
3
OPEN TOP COVER
21

Installation
ACCESS-5K
5 - jcmtechnologies
Wiring
Power supply and relays
R1 R2
POWER SUPPLY
Connect the power
supply cables
12/24
Vac/dc RELAYS
Connect the R1/R2 relay outputs (Normally
Open Contact) to the existing elements of
the installation
ELECTROLOCK
Check power supply
value for electrolock
CONTROL
PANEL
POWER
Check the power supply led
is lighted when power
is turned on
ANT
COMMS. CARD ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
ANT
COMMS. CARD ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
12/24V
ac/dc
Example of installation in control panel.

ACCESS-5K
Installation
6 - jcmtechnologies
Wiring
Proximity readers
LED D0 12Vdc L
D1
PROXIMITY READERS
Connect the desired readers to the
RD1/RD2 connectors
RD1 RD2
WIEGAND26
Channel 1 for RD1 reader
Channel 2 for RD2 reader
BUS L
Channel is defined in
EVOPROX configuration
See the EVOPROX user manual for protocol and channel
configuration.
ANT
COMMS. CARD ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
12/24V
ac/dc
Example of installation in EVOPROX readers.

Configuration
ACCESS-5K
7 - jcmtechnologies
MICRO SD CARD
Insert into the computer
and configure the system
using SoftAssistant
SD CARD ADAPTER
Use the SD adapter if
necessary
This device can be only configured by the software
SoftAssitant.
Check its user manual and the ACCESS-5K specific annex for
details of creating an installation, adding devices, creating user
groups etc...
For more information, visit:
www.jcm-tech.com/en/MAESTRO-PROGMAN-ASSISTANT/
Keep the plastic cover of micro SD memory in a safe place as it
contains the label with the data for remote management.

ACCESS-5K
Verification
8 - jcmtechnologies
LED Indicators
ANT
COMMS. CARD
ANT
COMMS. CARD
R1 R2
LED D0 12Vdc L
D1
RD1
RD2
12/24V
ac/dc
WARNING (only A5K+)
1 Flash
Anti-passback input A activation
2 Flashes
Anti-passback input B activation
3 Flashes
Radio programming trial
4 Flashes
Anti-panic activation
Continous flashing
Tamper input activation
ERROR
1 Flash
Forbiden access
2 Flashes
Out-of-schedule access
3 Flashes
Anti-passback violation
(only A5K+)
4 Flashes
Firmware update needed
hardware reset
5 Flashes
Transmitters code file not found
Continous flashing
No memory or bad memory format
OK
1 Flash
Access garanted
Continous flashing
Reading memoy
MEMORY
ERROR
Continous flashing
Wrong customer
code
POWER SUPPLY
R1 ACTIVATED
R2 ACTIVATED

Maintenance
ACCESS-5K
9 - jcmtechnologies
Firmware update
Replacement of the cell battery
You can also check the current APP version in generated
A5KInfo.txt file in SD memory.
Steps to update the firmware in the ACCESS-5K:
• Insert the SD memory in your computer.
• COPY FILE ACCESS5K_AABBCCDD_bin.a5k (AABBCCDD = version) to the uSD memory.
• RENAME FILE copied in the SD to bin.a5k.
• Extract the SD memory from the computer.
• Power off your ACCESS-5K.
• Insert the SD memory in your ACCESS-5K.
• Power on your ACCESS-5K.
• If the OK led flashes fast, slowly and then fast once again. Then:
- The update has finished properly.
- The bin.a5k file has been deleted from SD memory.
• If the ERROR led keeps flashing slowly, an error has occurred:
- Check the file in the SD memory.
- Delete the firmware file manually in order to allow the device to boot normally.
In case the ACCESS-5K events lose the date, the button cell battery CR2032 must be changed.

ACCESS-5K
Technical Data
10 - jcmtechnologies
Electrical parameters
Power Supply 12 / 24V dc/ac
Standby / operating consumption <50 mA / 100 mA
Maximum power consumption 5W
Relay power (R1 / R2) 3A
Physical parameters
Operating temperature -20ºC … +55ºC
Size 180 x 150 x 85 mm
IP Rating IP65
Radiofrequency parameters
Motion Frequency 868 MHz
Motion Codification High-security rolling-code

11 - jcmtechnologies
Solving problems
ACCESS-5K
FAQs
Q: How many users can Access 5k unit handle?
A: Up to 5000 users.
Q: How many codes can be added manually?
A: Codes cannot be added manually, they can only be added using SoftAssistant.
Q: Can the unit be blocked so that no one can delete or program more transmitters?
A: It is not necessary to block the unit as the codes can only be managed with the SoftAssistant.
Q: Can any SoftAssistant read the conguration of my unit?
A: ACCESS-5K can be protected through the customer code and the password.
Q: How can the events be read?
A: Connecting the SD card at the computer and opening the events le through SoftAssistant
Q: Can we power the unit at 230 V?
A: No, we can only supply low voltage, 12/24 Vac / dc.
Q: How many relay outputs does the unit have?
A: It has 2 relay outputs.
Q: Are the relays potential free?
A: Yes, also the relays can be used to switch power to an electric lock, for example.
Q: Which sort of readers can be connected?
A: It has 2 relays outputs.
Q: The relays are potential free?
A: There can be connected readers with Bus-L and Wiegand 26 protocol.
Q: How can I know there is an error if the door does not open?
A: A LED indicates the error. Identied by the number of flashes.

ACCESS-5K
Safety instructions
Use of the system
EC Declaration of conformity
12 - jcmtechnologies
Disconnect the power supply whenever you proceed to the installation
or repair of the control panel.
In accordance with the European low voltage directive, you are infor-
med of the following requirements:
• For permanently connected equipment, an easily accessible connec-
tion device must be incorporated into the cabling.
• This system must only be installed by a qualified person that has
experience with automatic doors/gates and knowledge of the relevant
EU standards.
• The instructions for use of this equipment must always remain in the
possession of the user.
This equipment is designed for applications where pedestrian doors
installed on garage doors. It is not guaranteed for directly activating
equipment other than that specified.
The manufacturer reserves the right to change the specification of the
equipment without prior warning.
JCM TECHNOLOGIES, S.A. declares herewith that the product AC-
CESS-5K complies with the requirements of the 1999/5/ CEE R&T-
TE Directive, and complies with the fundamental requirements of the
2004/108/EC Directive on electromagnetic compatibility and 2006/95/
EC on low voltage, insofar as the product is used correctly.
See web www.jcm-tech.com/en/declarations
UM_3200401_EN_Rev00.pdf
