JDV JBSM Installation and operating instructions

1 of 18
JDV CONTROL VALVES CO.,LTD.
Installation, Operation and Maintenance
3-PC Floating Type Threaded /
Welded Metal Seat Ball Valve
VERSON: V 1.0
ISSUING DATE: 2015/11/02

2 of 18
JBSM
3-PC Floating Type Threaded /Welded Metal Seat Ball Valve
Instructions for Installation, Operation and Maintenance
Contents
Overview -------------------------------------------------------------------------2、3
Notes prior to Use --------------------------------------------------------------4、5
Warning Banners
Safety Notification
Product Transportation/Storage/Maintenance --------------------------6、7、8
Notes for Preparation of Installation ----------------------------------------9、10
Notes prior to Operation ----------------------------------------------10、11、12
Routine Maintenance and Troubleshooting ------------------------------13、14
JBSM Structure Diagram / Procedure of Disassembling and Assemblag-15、16
JBSM-EXTENDED Structure Diagram / Procedure of Disassembling and
Assemblag--------------------------------------------------------------------17、18

3 of 18
Overview:
JBSM is a 3-PC Floating Type Threaded /Welded Metal Seat Ball Valve
of JDV. Features of the product comprise:
1. Anti-static device: Static is generated by valve ball due to friction
with fluid flow, and the static cannot be conducted to exterior of
the body. With the design of anti-static device, static may be
conducted to the exterior of the valve rapidly without explosion or
fire event due to spark generated by static.
2. Valve stem anti-fly device: Old stem is installed in valve from outside.
As there is pressure in the valve, and screw is loosened exceptionally,
the stem would fly out due to the pressure from the valve and result
in industrial accident. The new stem anti-fly design has the stem
penetrates from the interior of the valve without flying out due to
blocking of the valve.
3. Bi-directional sealing seat: The upstream and downstream end have
leakproof seal design, can play a fluid backflow prevention effect,
use INCONEL X-750 shrapnel can reach from the seat tightly sealed.
4. Padlock design: The orientation of the ball valve may be locked to
on or off position as a safety design to avoid hazard because of
careless opening or closing.
5. Balanced pressure relief hole: The ball top is designed with pressure
relief hole to balance the pressure in the inner chamber of the valve,
and prolong the life of ball pad.

4 of 18
Notes prior to Use:
1. Read the instructions for installation, operation, maintenance carefully before
operating the product.
2. Identify the warning banners and descriptions mentioned in this document.
3.Do not use in excess of the design pressure of the valve case.
4.Do not use in case of over temperature valve designs.
5. Please put the instructions for installation, operation, maintenance in an easy
access site in order for query in use.

5 of 18
Warning Banners:
Banner
Description
This indicates a dangerous situation. Slight or moderate
injury might be resulted if it is not averted.
Death or severe injury might be resulted if such potential
dangerous situation is not averted.
Safety Notification:
Design engineers or product users identify basic product specifications
and check the compliance of valve and installation equipment in order
to guarantee safe use.
Prior to installation of valve, the compliance of operating conditions
(temperature, pressure, fluid characteristics, ambient conditions,
installation gauges etc.) with the service conditions set for valve has
to be checked and identified.
Warning:
Do not get beyond the limitation indicated by valve specification or
technical parameters, or otherwise, death or severe injury might be
resulted.
Warning:
Valve may be used indoors or outdoors. If it is exposed to atmospheric
environment, erosion of valve has to be cared, or otherwise, slight or
moderate injury might be resulted.
Product Transportation/Storage/Maintenance

6 of 18
Warning:
1. In moving or transportation, suitable tools have to be
selected for correct equipments and accessories (sling,
fastener, hook and so forth) in terms of size with
consideration of individual weights of details in the package
and the complete total weight.
2. Ball valve lifting and handling should be operated by
qualified operators. Inappropriate lifting would result in
deformation or dropping of valve to damage the valve.
3. Do not lift the valve using the suspending point or bracket
arranged on cylinder to prevent from danger.
4. Do not use the handle of the manual valve to take or lift
ball valve. In such a way, the handle of the manual valve would
fractured or depart from the valve, such that damage or human
injury might be resulted.
※The product has to be packed well to avoid unnecessary damage when
transportation to and storage in warehouse. Particularly, the
following precautionary measures have to be cared:
Transportation
1. The openings on two sides of the ball valve have to be protected well
using appropriate sealing cover in order to guarantee clean interior of
the valve and prevent foreign objects from entry.
2. The packaging has to guarantee safe transportation to storage site.
As arrival to the storage site, please identify that the covering material
or packing paper or wooden case keeps in a complete status.
Storage & Maintenance

7 of 18
Preserving of Packed Ball Valve
1. Protect the pack adequately to prevent the pack from damage.
2. There should be warning banners for packs to guarantee that the moving
of product would not result in unnecessary damage, such as suspending
center of gravity
3. Flange surface and channel opening have to be protected on the surfaces
of two sides of the ball valve using adequate sealing patch or cover to
guarantee clean interior in the valve and prevent foreign objects from
entry.
4. If the used material of the valve is prone to rust, the flange surface
and the channel opening have to be coated with antirust oil in order for
preventing rust spots from appearing.
5. The storage site has to keep clean and dry.
6. Do not let the product to be exposed to wind/rain or to be sunned.
7. Please check preserving status regularly if the product is to be stored
for a period of time.

8 of 18
Preserving of non-packed/unpacked ball valve
1. Please guarantee appropriate protection of the product in order to
prevent it from damage.
2. In treating large valve, the product has to be fixed safely and stably.
Suitable tools (bracket, hook, fastener, cable) should be used in
transportation. In moving, balance has to be kept in order to prevent
product from damage due to dropping or shaking in transportation process.
Notes for Preparation of Installation
Please follow the following instruction guidelines to guarantee and
prolong product life.
1. Please disassemble the pack (wooden case or pallet) carefully in order
to prevent the product and cylinder and other components from damage.
2. Before installation, remove the seal from flange opening for the air
pipeline containing air filter to clean the interior of the ball valve.
Make sure the clearance of foreign object inside.
3. Make sure that the mark on the nameplate is compliant with service
condition.
4. Make sure that the flow direction on the body meets the direction of
equipment pressure.
5. Make sure that all screws and nuts are secured.

9 of 18
6. In valve installation, please use wrench and follow diagonal sequence
(Figure 1) to lock screws in order to prevent flange from deformation.
Notes prior to Operation
Manual Valve:
1.In manual operation, over or inadequate operation would damage handle
or components, or result in indirect leakage.
2. Please identify that the opened or closed position
※Opened position of ball valve –please identify that the notch
direction on top of stem on the ball valve is parallel to the direction
of the handle and channel, and the ball valve is in opened status.(Figure
2)
圖一
Notch for Stem
(Figure 2)

10 of 18
※Closed position of ball valve –please identify that the notch direction on top of
stem on the ball valve is vertical to the direction of the handle and channel, and the
ball valve is in closed status. (Figure 3)
Pneumatic Ball Valve:
1. Please operate according to the instructions in the user manual of
the cylinder manufacturer for the action valve to be opened or closed
pneumatically.
Notch for Stem
(Figure 3)

11 of 18
Maintenance and Troubleshooting
Routine Maintenance
* Maintain routine maintenance and check to guarantee good operability.
For fastening torque, refer to the torque tables for each specification.
ANSI 600LB / DIN PN100
Size
Joint Bolt
Size
Torque
Unit :N.m
JBSM
JBSM-EXTENDED
Nut Size
Torque
Unit :N.m
Gland Bolt
Size
Torque
Unit :N.m
1/2"
M8
20
M12
> 5
M8
> 7
3/4"
M8
20
M12
> 5
M8
> 7
1"
M10
40
M14
> 8
M8
> 8
1-1/4"
M12
70
M14
> 8
M8
> 8
1-1/2"
M14
80
M22
> 10
M10
> 16
2"
M14
80
M22
> 10
M10
> 16
(Table 1)

12 of 18
Troubleshooting
Area
Problem Description
Solution
Internal
Leaks
Leak at the surface
of the ball
1. Please check whether the surface of
BALL(3) and SEAT(4) have scratches or any
damage.
2. Replace the SEAT GASKET(5) when the
surface of ball and valve seat have not
scratches or any damage.
3. Replace the BALL(3) or SEAT(4) when the
surface of BALL(3) and SEAT(4) have
scratches or any damage.
4. Disassemble it each time, need to
replace the SEAT GASKET(5).
External
Leaks
Leak at the mouth of
the stem
1. Fastening the NUT(16), please refer to
the torque tables 1 for each
specification.
2. Replace the GLAND PACKING(12) if
leakage can not stanch.
Leak occurred in the
junction surface.
1. Fastening the BOLT & NUT(10), please
refer to the torque table 1 for each
specification.
2. Disassemble it each time, need to
replace the BODY GASKET (8).
PS. Refer to the instruction of the number of the structure.

13 of 18
Structure/disassembly/assembly
1/2"~2" JBSM
Structure
NO
1
BODY
2
CAP
3
BALL
4
SEAT
5
SEATGASKET
6
SEAT RETAINER
7
SEAT SPRING
8
BODY GASKET
9
STOPPER
10
BOLT & NUT
11
THRUST WASHER
12
GLAND PACKING
13
STEM
14
RING
15
BEVEL WASHER
16
NUT
17
PACKING LOCK
WASHER
18
HANDLE
19
HANDLE NUT

14 of 18
●Disassembly
1. Turn BALL (3) to full “closed”position.
2. Remove HANDLE NUT (19), HANDLE(18) and STOPPER(9).
3. Remove PACKING LOCK WASHER (17), loose NUT (16), then take
BEVEL WASHER (15) out.
4. Loose BOLT & NUT (10), remove CAP (2) and BODY GASKET (8).
5. After remove CAP (2), take out SEAT (4), SEAT SPRING (7), SEAT
RETAINER (6), and SEAT GASKET (5) orderly.
6. Take out BALL (3), after Knock lightly STEM (13) and push it from GLAND
PACKING (12), than remove STEM (13), THRUST WASHER (11) AND
GLAND PACKING (12).
PS. In order to prevent leakage after reinstall, carefully take out and place
BALL (3) and SEAT (4) to prevent possible damage.

15 of 18
●Assembly
1. Put THRUST WASHER(11) on STEM(13), than install STEM(13) into BODY(1).
註:
2. Insert BALL into BODY (1).
PS. Be careful to assemble, in order to avoid collision and damage the sealing
surface.
3. Put SEAT GASKET (5), SEAT RETAINER (6), SPRING (7), SEAT (4) on CAP
(2) orderly.
4. Put BODY GASKET (8), CAP (2) on BODY (1), and Screw BOLT& NUT (10)
to tighten.
5. After cycle the valve several times to assure smooth operation and check
stem packing area to confirm there is no leakage from stem packing, put
PACKING LOCK WASHER on NUT (16). Please refer to Table 1.

16 of 18
1/2"~2" JBSM-EXTENDED
structure
NO
1
BODY
2
CAP
3
BALL
4
SEAT
5
SEATGASKET
6
SEAT RETAINER
7
SEAT SPRING
8
BODY GASKET
9
BOLT & NUT
10
THRUST WASHER
11
GLAND PACKING
12
STEM
13
GLAND
14
GLAND BOLT
15
GLAND BEARING
16
BONNET
17
BONNET GASKET
18
BONNET BOLT

17 of 18
●Disassembly
1. Turn BALL (3) to close position.
2. Loose GLAND BOLT (14), remove GLAND (13) and GLAND BEARING (15)
3. Loose BOLT & NUT (9) and take out CAP (2) and BODY GASKET (8).
4. After remove CAP (2), take out SEAT (4), SEAT SPRING (7), SEAT
RETAINER (6) and SEAT GASKET (5)
5. Take out BALL (3).
6. Loose BONNET BOLT (18), and take BONNET (16) and BONNET
GASKET (17) off.
7. Remove STEM (12), THRUST WASHER (10) and GLAND PACKING (11)
orderly.
PS. In order to prevent leakage after reinstall, carefully take out and place
BALL (3) and SEAT (4) to prevent possible damage.

18 of 18
●Assembly
1. Put THRUST WASHER (10) on STEM (12), install STEM (12) into BODY (1).
2. Install GLAND PACKING (11), BONNET GASKET (17), BONNET (16) to BODY
(1) orderly, and Screw BONNET BOLT (18) to tighten.
3. Put BALL (3) into BODY (1).
PS. Be careful to install to avoid collision and damage the sealing surface.
4. Install SEAT GASKET (5), SEAT RETAINER (6), SEAT SPRING (7), and SEAT
(4) into CAP (2) orderly.
5. Install BODY GASKET (8) and CAP (2) to BODY (1), then SCREW BOLT &
NUT (9) to tighten.
6. Install GLAND PACKING (11) and GLAND (13) to BONNET (16) orderly,
than SCREW GLAND BOLT to tighten.
