Jeanneau SUN FAST 3200 User manual

SUN FAST 3200
OWNER'S MANUAL
COURSE &CROISIÈRE
087862
Index F

-1/102
WELCOME ABOARD
Madam, Sir,
You have just taken delivery of your new JEANNEAU boat and we thank you for the
confidence you have shown us in ordering a vessel of our brand. The whole JEANNEAU team
welcomes you aboard.
A JEANNEAU is made to last, in order to bring you all the pleasure you expect from a vessel
over a period of many years. Each boat is subject to the utmost attention to detail from the
design stage right through to launching.
This manual is meant to help you to enjoy your boat comfortably and safely. It includes the boat
specifications, the equipment provided or installed, the systems and tips on her operation and
maintenance. Some of the equipment described in this manual may be optional.
Your JEANNEAU dealer will be able to help and advise you in the use and maintenance of
your boat.
Read this user's guide/owner's manual carefully and get to know your boat before using it.
The better you know your vessel the more pleasure you will get from being at the helm.
The sea is a source for learning. Caution based on a knowledge of one's own limits and those
of the boat is the pre-requisite for an accomplished sailor.
Even when your boat has been adapted for them, the sea and wind conditions corresponding
to the design categories A, B, C and D may vary, ranging from severe conditions to strong
storms subject to the risks of exceptional waves and gusts of wind, this meaning they are
dangerous conditions in which only an experienced, fit and well trained crew manoeuvring a
well maintained boat can sail in a satisfactory manner.
This user's guide/owner's manual is not a course in safety at sea or about sailing sense. If this
is your first boat or if you change to a new type of boat which you are not used to, get some
training in boat control and sailing to ensure your safety and comfort. Your dealer, your
international sailing association or your yacht club will be very happy to recommend local
sailing schools or professional instructors.
Make sure the sea and wind conditions will correspond to the category of your boat and you
and your crew are able to handle the boat in these conditions.
Always listen to the weather forecast before you put out to sea.
Keep this user's guide/owner's manual in a safe place and hand it over to the new owner if
you sell your boat.
You are advised to keep all the instructions and manuals provided by the boat equipment
manufacturers (accessories...) in the same place as this manual

1/102
INTRODUCTION
We share a common passion for the sea: we, JEANNEAU as shipbuilders and you who want
to live your passion on the Seven Seas.
We are delighted to welcome you to the great family of JEANNEAU boat owners and we
congratulate you on it.
This manual is meant to help you to enjoy your boat comfortably and safely. It includes the boat
specifications, the equipment provided or installed, the systems and tips on her operation and
maintenance.
Read this manual carefully before you put out to sea so that you can make the most of her and
avoid any damage and any trouble. Get to know your boat before you sail.
We keep improving our boats as we want you to benefit from the technological developments,
new equipment or materials and our own experience. That is the reason why the specifications
and information given are not contractual, they may be modified without prior notice or up
dates.
This owner's manual is designed in accordance with the ISO 10 240 standard requirements, it
has a general purpose and it may sometimes list some equipment or accessories or deal with
some points or questions that are not relevant to your own boat. In case of doubt refer to the
inventory list you were given when you bought your boat.
Our network of JEANNEAU authorized dealers will be at your disposal to help you get
acquainted with your boat and will be the most qualified to take care of her maintenance.
If this is your first boat or if you change to a new type of boat which you are not used to, get
some training in boat control and sailing to ensure your safety and comfort. Your dealer, your
international sailing association or your yacht club will be very happy to recommend local
sailing schools or professional instructors.
Even if everything has been provided for and designed for the safety of the boat and the safety
of her users, don't forget that sailing highly depends on the weather conditions, the sea
condition, and that only an experienced and very fit crew, handling a well-maintained boat can
sail satisfactorily.
The sea and wind conditions that correspond to the design categories A, B or C are
changeable and are dependent on the hazards of unusually strong waves or gusty winds.
Therefore total safety cannot be guaranteed, even if your boat meets the requirements of a
category.
Always listen to the weather forecast before you put out to sea.
Make sure the sea and wind conditions will correspond to the category of your boat and you
and your crew are able to handle the boat in these conditions.

2/102
The sea and the water are not the natural environment of Man and one has to respect their laws
and strength.
Adapt the use of your boat to her condition that wears out with time and use.
Any boat, however solid she may be, may be severely damaged if badly used. This is not
compatible with safe navigation. Always adapt the speed and direction of your boat to the
conditions of the sea.
The 'COLREG', an international regulation in order to prevent collision at sea, published by the
International Maritime Organization, specifies the steering and course regulations, the
navigation lights etc. throughout the world Make sure you know these regulations and you have
on board a manual that explains them.
In numerous countries, a licence, an authorization or a training course is requested. Make sure
you have this legal authorization before you use your boat.
Always use an experienced technician for the maintenance of your boat, the fitting of
accessories and the carrying out of small modifications. The written authorization of the builder
or his legal representative is compulsory for modifications that alter the specifications of the
boat, in particular the vertical layout of the grounds (putting up of a radar, modification of the
mast, change of the engine etc.).
The different warnings used throughout this guide are broken down as follows
For the essential or optional equipment (engine, electronics etc.) refer to their respective
manual delivered with your boat.
DANGER
Indicates the existence of a serious inherent danger with a high risk of death
or serious injury if the appropriate precautions are not taken.
WARNING
Indicates the existence of a danger which could lead to injury or death if the
appropriate precautions are not taken.
PRECAUTION
Indicates a reminder of safety practice or draws attention to dangerous practices which could
cause injury to persons or damage to the vessel or to its components.

3/102
The users of the boat are informed of the following:
- The entire crew must be trained properly.
- The boat shall not be loaded more with than the maximum load recommended by the
builder, in particular the total weight of the food supplies, of the different equipment that
are not supplied by the builder and of the persons on board. The weight of the boat shall
be properly distributed.
- The water in the bilge shall be kept at its minimum.
- The stability is reduced when you add weight in the upper parts.
- In case of heavy weather, the hatches, lockers and doors shall be closed in order to
minimize the risk of water coming in.
- The stability may be reduced when you tow a boat or when you lift heavy weights with the
davits or the boom.
- Breaking waves are a serious threat to stability.
- If your boat is equipped with a liferaft, carefully read the instructions. In the boat there shall
be all the proper safety equipment (harness, flares, liferaft etc.) depending on the type of
boat, the country, the weather
- The crew must be familiar with the use of all the safety equipment and the emergency
safety procedures (MOB, towing etc.).
- Anyone on the deck shall wear a life jacket or a buoyancy aid. Please note that in some
countries it is compulsory to wear an homologated buoyancy aid permanently.
- Some of the data is shown on the manufacturer's plate fixed to the boat. The explanation
of the data is given in the appropriate chapters of this manual.
PRECAUTION BEFORE ANY REPAIR
Contact your seller who will give you the best advice and the suitable parts or materials for the
repairs you can carry out yourself.
It would be better to have important repairs of the hull or engine done by a professional. Your
seller can carry out these repairs or appoint a skilled person to carry them out.
Some of the equipment described in this manual may be optional.
ADVICE - RECOMMENDATION
Indicates a recommendation or advice for carrying out manoeuvres appropriate for the
planned manoeuvres.
Keep this manual in a safe place and hand it over to the new owner if you sell your boat.
DANGER
Contact your seller to find out what is possible for you to repair and above
all what you must not do !
You could endanger your safety and lose your warranty.

5/102
HISTORY OF UPDATES
• Index A ...................................................................................................... 07/2007
• Index B ...................................................................................................... 10/2007
• Index C ...................................................................................................... 05/2008
• Index D ...................................................................................................... 11/2009
• Index E ...................................................................................................... 09/2010
• Index F....................................................................................................... 08/2012

7/102
CONTENTS
INTRODUCTION
Chapter 1 .................................................................................................................Page 9
SPECIFICATIONS AND WARRANTY
Chapter 2 ...............................................................................................................Page 15
SAFETY
Chapter 3 ...............................................................................................................Page 25
HULL
Chapter 4 ...............................................................................................................Page 29
DECK
Chapter 5 ...............................................................................................................Page 35
STEERING SYSTEM
Chapter 6 ...............................................................................................................Page 39
RIGGING AND SAILS
Chapter 7 ...............................................................................................................Page 53
INTERIOR
Chapter 8 ...............................................................................................................Page 57
WATER AND SEWAGE WATER
Chapter 9 ...............................................................................................................Page 69
GAS
Chapter 10 .............................................................................................................Page 71
ELECTRICAL EQUIPMENT
Chapter 11 .............................................................................................................Page 81
ENGINE
Chapter 12 .............................................................................................................Page 93
LAUNCHING
Chapter 13 .............................................................................................................Page 97
WINTER STORAGE
PERSONAL NOTES
At the end of the manual
DINGHIES AND OTHER EQUIPMENT
At the end of the manual
SUN FAST 3200 Anglais
Update 08/2012
Index F
Code: 087862 Total number of pages: 102

9/102
SPECIFICATIONS AND WARRANTY
TECHNICAL SPECIFICATIONS
CERTIFICATION
CONSTRUCTION
YOUR BOAT
1

10/102
TECHNICAL SPECIFICATIONS
L.O.A .................................................................................................................. 10,10 m/33’ 1’’
Hull length ............................................................................................................. 9,78 m/32’ 1’’
L.W.L..................................................................................................................... 8,55 m/28’ 0’’
Overall width ......................................................................................................... 3,48 m/11’ 5’’
Beam..................................................................................................................... 3,48 m/11’ 5’’
Waterline beam....................................................................................................... 2,67 m/8’ 9’’
Air draught - Empty vessel ...................................................................................... 15 m/49’ 2’’
Draught ................................................................................................................... 1,90 m/6’ 2’’
Ballast weight ............................................................................................... 1 300 kg/2 866 lbs
Light displacement ........................................................................................ 3 400 kg/7 496 lbs
Maximum load recommended by the builder .............................................. 4 688 kg/10 335 lbs
Including the mass of the persons who are authorized on board (75 kg/16 lbs per adult), the
supplies, the liquids that can be used (fresh water and fuel) in fixed completely full tanks, the
additional loads, the optional equipments, the liferaft and the scope for load.
Total mass of liquids (all tanks full) ..................................................................................140 kg
Freshwater capacity............................................................................................. 80 l/21 US gal
Fuel oil tank capacity ........................................................................................... 75 l/20 US gal
Refrigeration unit capacity ................................................................................... 60 l/16 US gal
Recommended maximum power ........................................................................ 11 kW (15 HP)
Maximum motorisation mass ............................................................................. 145 kg/320 lbs
Battery capacity ............................................................................ 1 x 50 Ah (House 2 x 50 Ah)
Cabins.......................................................................................................................................2
Sleeping capacity......................................................................................................................6
Note: The capacities indicated are maximum (including options).
Architect ...................................................................................................Andrieu Yacht Design
SAILS
Mainsail (classic)............................................... 33,5 m2/361 sq.ft
Genoa ............................................................... 28,5 m2/307 sq.ft
Spinnaker.......................................................... 83,0 m2/893 sq.ft
I ...........................................................................12,80 m/41’ 11’’
J ..............................................................................3,85 m/12’ 7’’
P ...........................................................................11,80 m/38’ 8’’
E..............................................................................4,25 m/13’ 7’’
The sails are the main propulsion means of the SUN FAST 3200.

11/102
CERTIFICATION
DEFINITION OF DESIGN CATEGORIES:
The SUN FAST 3200 model conforms to the directive 2003/44/CE.
CONSTRUCTION
Your boat is built of stratified balsa.
The inner moulding that is stuck and laminated to the hull distributes the stresses over the
whole bottom surface. The cast iron/lead ballast is attached to the hull with bolts and backing
plates.
The deck is stratified and has hardwood inserts at the points of fixtures and fastenings. The
deck to hull joint is obtained with methacrylate glue.
CE Category Persons Maximum
A 6 persons
B 8 persons
C 10 persons
D 10 persons
Design category Wind force
(Beaufort scale)
Significant height of waves
to be considered
(,in metres H 1/3)
Vessel designed for navigation:
A - "At high sea"
B - "In open sea"
C - "Near to the coast"
D - "In sheltered waters"
Over 8
Up to and including 8
Up to and including 6
Up to and including 4
Over 4 m
Up to and including 4 m
Up to and including 2 m
Up to and including 0,5 m
1
SPECIFICATIONS AND WARRANTY

12/102
Category A: At high sea
This craft is designed to operate in winds that may exceed wind force 8 (Beaufort scale) and in
significant wave heights of 4 m and above.
This craft is largely self-sufficient. Abnormal conditions such as hurricanes are excluded.
Such conditions may be encountered on extended voyages, for example across oceans, or
inshore when unsheltered from the wind and waves for several hundred nautical miles.
Category B: In open sea
This craft is designed to operate in winds up to Beaufort force 8 and the associated wave
heights (significant wave height up to 4 m, see Note 1 below).
Such conditions may be encountered on offshore voyages of sufficient length, or on coastal
waters when unsheltered from the wind and waves for several dozens of nautical miles.
These conditions may also be experienced on inland seas of sufficient size for the wave height
to be generated.
Category C: Near to the coast
This craft is designed to operate in winds up to Beaufort force 6 and the associated wave
heights (significant wave height up to 2 m, see Note 1 below). You may meet with such
conditions in exposed inland waters, in estuaries and in coastal waters with moderate weather
conditions.
Category D: In sheltered waters
This craft is designed to operate in winds up to Beaufort force 4 and the associated wave
heights (occasional maximum waves of 0,5 m height).
Such conditions may be encountered in sheltered inland waters, and in coastal waters in fine
weather.
NOTE:
- The significant wave height is the mean height of the highest one-third of the waves, which
approximately corresponds to the wave height estimated by an experienced observer. Some
waves will be double this height.
- The creation of different design categories results from the need to distinguish between
different levels of risk according to the construction of the boats.
The parameters for the characteristics are established to define the conditions of navigation
which each category may encounter; they serve purely to evaluate the boat designs and are
not to be used to limit the geographical areas in which these boats may operate..
- One boat may be classed in several design categories at the same time, each with their
different maximum capabilities.

13/102
YOUR BOAT
Version
NAME OF THE BOAT .............................................................
NAME OF THE OWNER .............................................................
ADDRESS .............................................................
.............................................................
.............................................................
HULL NUMBER .............................................................
SERIAL NUMBER .............................................................
REGISTRATION NUMBER .............................................................
DELIVERY DATE .............................................................
DOOR KEY NUMBER .............................................................
MAKE OF ENGINE .............................................................
ENGINE SERIAL NUMBER .............................................................
ENGINE KEY NUMBER .............................................................
JEANNEAU (Establishment of the company SPBI)
BP 529 - 85505 LES HERBIERS cedex - FRANCE
Tel. [phone] - Fax [phone]
Internet : http://www.jeanneau.com(fr).
Your agent
1
SPECIFICATIONS AND WARRANTY

15/102
SAFETY
SAFETY EQUIPMENT
GENERAL INFORMATION
VALVES
RECOMMENDATIONS FOR GAS
FIGHT AGAINST FIRE
BILGE PUMP SYSTEM
2

16/102
GENERAL INFORMATION
DANGERS
The main dangers concern the gas and electrical systems as well as the motorisation.
Please refer to the relevant paragraphs.
SAFETY EQUIPMENT
Raft in the cockpit locker
Note: If over 10 persons on board:
2 liferafts compulsory.
