JEFFANDRM30-110
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com 3
• A high-velocity two-speed drum fan capable of moving large volumes of air.
• Durable and robust design with heavy-duty gauge steel casing, guard, handle, wheels and frame.
• Cradle stand with tilt function allows exible control of airow when required.
• Balanced and fully guarded blades provide quiet and safe operation.
• Suitable for use in industrial, commercial, agricultural, automotive workshop and on-site applications.
• Energy efciency tested according to EU 206/2012 regulations and standards (ERP 206 Compliant)
•
SPECIFICATIONS
Model Number: JEFFANDRM30-110
Voltage ~ Frequency: 110V ~ 50Hz (16A)
Fan Diameter: 30” • 760mm
Power: 123W
Speed: High 1400rpm
Low 1295rpm
Air Flow: High 179.2cmm • 6328cfm
Low 154cmm • 5720cfm
Net Weight: 20.4kg
Energy Efficiency (According To EU 206/2012 - ERP 206)
Item Symbol Unit Value
Maximum Fan Flow Rate F m3 /min 179.2
Fan Power Input P W 120.67
Service Value SV (m 3 /min)/W 1.49
Standby Power Consumption PSB W 0.00
Seasonal Electricity Consumption Q kWh/a 38.6
Fan Sound Power Level LWA dB(A) 84.5
Maximum Air Velocity C meters / sec 2.15
INTRODUCTION
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com
4
UNPACKING & ASSEMBLY
Upon receipt of the equipment, ensure all components are present and have remained undamaged in transit. Retain the packing materials and
packaging in case future transportation of the fan is necessary.
We recommend that the packaging is kept, at least within the period of the guarantee.
The diagram (Fig.1) and table shown below show the main components of the fan and how they are assembled for maintenance and servicing.
Part # Part Description Quantity
1 Front Guard 1
2 Fan Blade 1
3 Drum Body 1
4 Rear Guard 1
5 Motor 1
6 Switch Box 1
7 Switch 1
8 Power Cable /
Plug
1
9 Frame 1
10 Wheels 2
SAFETY GUIDELINES
Please read and ensure that you understand all of the operating instructions, safety precautions and warnings
in this Instruction Manual before operating or maintaining this equipment. An accident can often be avoided by
recognizing a potentially hazardous situation before it occurs, and by observing appropriate safety procedures.
Hazards that must be avoided to prevent bodily injury or machine damage are identied by warnings on the
equipment and in this Instruction Manual.
Never use this equipment or modify it in any way that has not been specically recommended by the manufacturer.
Contact Jefferson Tools for all information relating to the repair and maintenance of this equipment.
Contact a qualied electrician for advice on any issues relating to electrical safety in your working environment.
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com 5
SAFETY GUIDELINES
ELECTRICAL SAFETY
Ensure that you check the equipment thoroughly to ensure it is safe and t for purpose before each use. It is important that
you inspect all plugs, sockets, power cables and electrical ttings for wear and damage and repair or replace any defective
components. The risk of electric shock can be minimised by the correct use of the appropriate electrical safety devices.
• We recommend that you t a Residual Current Circuit Breaker (RCCB) in the main
distribution board and that a Residual Current Device (RCD) is used when operating
this equipment.
• The Electricity at Work Act 1989 includes legislation that places legal implications
on employers to ensure the safety of electrical devices in the workplace. The
regulations dictate that all portable equipment must be inspected regularly and tested
to ensure that it is safe for use. 'Portable equipment' means any electrical item that
can be moved and this is often referred to as Portable Appliance Testing (PAT).
PAT testing should be carried out regularly on this equipment by trained, authorised
personnel, as required by the legislation.
• The Health and Safety at Work Act 1974 states that it is the responsibility of the
owner of electrical appliances to ensure that both the equipment and working
environments are maintained to ensure safe operation at all times.
• Check that all equipment cables are secure, correctly insulated, free from damage,
and protected against short circuit and overload before connecting to the power
supply. Do not use worn or damaged cables, plugs, sockets or other ttings.
• Ensure that the power supply matches voltage requirements specied on the equipment and that the plug is wired correctly and tted with a
16A fuse (See Fig.2).
Ensure the power cable is kept away from heat, oil and sharp edges.
• Always disconnect the equipment from the power source before servicing, inspecting, maintaining, cleaning, replacing or checking any parts.
• Do not carry the equipment while it is connected to its power source.
• Do not use this equipment in damp or wet conditions or areas with high condensation such as showers, pools etc.
GENERAL EQUIPMENT SAFETY
• Do not touch the fan until it has been disconnected from the mains power supply.
• Always disconnect the fan from the power supply when moving it from one location to another.
• Ensure fan is stood on a rm, level surface during operation.
• The air ow generated from this equipment is powerful. Before use ensure that there is nothing nearby that can be damaged or displaced by
the stream of air. Be careful that there are no naked ames or embers that can be blown by the air ow, even remotely.
• Keep the fan clean and maintained in good condition. For motor service contact an authorised service agent.
• Use only Jefferson approved replacement parts when repairing this equipment. Unapproved parts may be dangerous, and will invalidate your
warranty. Speak to your nearest Jefferson dealer for advice.
• Never operate the fan in environments containing explosive or ammable gases, fumes or other hazardous substances.
• Never allow the fan to be placed on top of the power cable.
• Do not insert any objects through the fan guard.
• Do not cover the fan when in use.
• Never immerse the fan in water or any other liquid.
• Never allow children to operate the fan - keep children and animals away from the equipment during operation.
• Never operate the fan in a position where it can be knocked over or off a surface, or where the lead may cause a person to trip.
• This equipment is not suitable for outdoor use.
• Do not modify the speed control or attempt to t any additional external speed control devices to the fan.
• When not in use place the fan in its original box, or otherwise cover, to protect from dust and store in a safe, dry, childproof environment.
• Always keep the user manual with the equipment for future reference.
Fig.2
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com
6
OPERATION
Please ensure that you read, understand and apply safety instructions in before attempting to use this equipment.
Check that the speed control is set to “0” (OFF) and then plug into the mains power supply and switch the power on.
The fan is equipped with 2 speed settings ("1" = Low "2" = High) to control the rate of air ow delivered. Select the speed setting you require us-
ing the switch located at the back of the fan, above the motor.
Adjust the direction of the air ow by moving from side to side and tilting the fan up or down, as required.
When you have nished using the fan ensure you turn the speed control switch back to "0” (OFF) and disconnect the fan from the mains
power.
MAINTENANCE
Equipment - General Cleaning:
• Use a soft, damp cloth to clean the fan after use .
• Never use solvents, petroleum, paint thinner or other chemicals to clean the fan.
Cleaning The Fan Blade:
• Undo the cross headed screws around the circumference, remove the grille and clean the blade with a slightly damp cloth.
• Replace the grille as required and ret the cross headed screws.
Servicing:
Should the motor, switch or the power lead require service or maintenance contact your local service agent.
Storage:
When not in use place the fan in its original box or otherwise cover to protect from dust, and store in a safe, dry, environment and safe from
children and animals.
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com 7
WEEE Waste Electrical and Electronic Equipment Statement
Information on Disposal for Users of Waste Electrical & Electronic Equipment
This symbol on the product(s) and / or accompanying documents means that used electrical and electronic products should
not be mixed with general household waste. For proper treatment, recovery and recycling, please take this product(s) to
designated collection points where it will be accepted free of charge.
For private households:
Dispose of this product at the end of its working life and in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). Contact your local solid waste authority for recycling information for this equipment.
Disposing of this product correctly will help save valuable resources and prevent any potential negative effects on human health and the
environment, which could otherwise arise from inappropriate waste handling.
Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with you national legislation.
For business users in the European Union:
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.
Information on Disposal in other Countries outside the European Union:
This symbol is only valid in the European Union. If you wish to discard this product please contact your local authorities or dealer and ask for the
correct method of disposal.
RoHS Directive 2011/65/EU
We hereby declare that this equipment has been tested and found to be compliant to RoHS Directive 2011/65/EU of the European Parliament and
the Council from 08/06/2011 on restriction of the use of certain hazardous substances in electrical and electronic appliances.
Determination of levels of regulated substances in electrotechnical products, elements of Cadmium (Cd), Lead (Pb), Mercury (Hg), Chromium (Cr)
and Bromine (Br) contents were measured by XRF Spectroscopy and chemical conrmation test for RoHS restricted substances.
ENVIRONMENTAL PROTECTION
Recycle any packaging and unwanted materials instead of disposing of them as waste. All tools, accessories and packaging
should be sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable, reaches the end of its working life and requires disposal, drain off any
uids (if applicable) into approved containers and dispose of the product and the uids according to local regulations.
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com
8
EC DECLARATION OF CONFORMITY
We, Jefferson Tools as the authorised European Community representative of the manufacturer, declare that the
following equipment conforms to the requirements of the following directives, standards and regulations:
Directive / Standard: Description: Notified Body:
IEC 60335-2-80:2015 Household and similar electrical appliances -
Safety - Part 2-80: Particular requirements for
fans
Intertek Testing Services
Shenzhen Ltd.
2011/65/EU (as amended) RoHS Directive
Regulation (EC) No 1907/2006 Registration, Evaluation, Authorisation and
Restriction of Chemicals (REACH)
EU 206/2012 (ERP 206) Energy Related Products:
Test Standards:
IEC 60879:1986/COR1:1992
EN 50564:2011
EN 60704-1:2010+A11:2012
EN 60704-2-7:1998
Equipment Category: Electric Fan
Model Number • Description: JEFFANDRM30-110 • 30" - HIGH VELOCITY DRUM FAN 110V - 50Hz - 123W
Signed by: Stephen McIntyre
Position in the company: Operations Director
Date: 07 January 2020
Name and address of manufacturer
or authorised representative:
Jefferson Tools, Herons Way, Chester Business
Park, Chester, United Kingdom, CH4 9QR
Telephone: +44 (0)1244 646 048
Fax: +44 (0)1244 241 191
Email: [email protected]
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com 9
Jefferson Professional Tools & Equipment, or hereafter "Jefferson" warrants its customers that its products will be free of defects in workmanship
or material. Jefferson shall, upon suitable notication, correct any defects, by repair or replacement, of any parts or components of this product
that are determined by Jefferson to be faulty or defective.
This warranty is void if the equipment has been subjected to improper installation, storage, alteration, abnormal
operations, improper care, service or repair.
Warranty Period
Jefferson will assume both the parts and labour expense of correcting defects during the stated warranty periods below.
All warranty periods start from the date of purchase from an authorised Jefferson dealer. If proof of purchase is unavailable from the end user, then
the date of purchase will be deemed to be 3 months after the initial sale to the distributor.
1 Year:
JEFFANDRM30-110 • 30" HIGH VELOCITY DRUM FAN 110V - 50Hz - 123W
90 Days
• All replacement parts purchased outside of the warranty period
Important: All parts used in the repair or replacement of warranty covered equipment will be subject to a minimum of 90 days cover or the
remaining duration of the warranty period from the original date of purchase.
Warranty Registration / Activation
You can register and activate your warranty by visiting the Jefferson Tools website using the following address:
www.jeffersontools.com/warranty and completing the online form. Online warranty registration is recommended as it eliminates the need to
provide proof of purchase should a warranty claim be necessary.
Warranty Repair
Should Jefferson confirm the existence of any defect covered by this warranty the defect will be corrected by repair or replacement at an
authorized Jefferson dealer or repair centre.
Packaging & Freight Costs
The customer is responsible for the packaging of the equipment and making it ready for collection. Jefferson will arrange collection and
transportation of any equipment returned under warranty. Upon inspection of the equipment, if no defect can be found or the equipment is not
covered under the terms of the Jefferson warranty, the customer will be liable for any labour and return transportation costs incurred.
These costs will be agreed with the customer before the machine is returned.
*Jefferson reserve the right to void any warranty for damages identified as being caused through misuse
Warranty Limitations
Jefferson will not accept responsibility or liability for repairs made by unauthorised technicians or engineers. Jefferson's liability under this
warranty will not exceed the cost of correcting the defect of the Jefferson products.
Jefferson will not be liable for incidental or consequential damages (such as loss of business or hire of substitute equipment etc.) caused by
the defect or the time involved to correct the defect. This written warranty is the only express warranty provided by Jefferson with respect to its
products.
Any warranties of merchantability are limited to the duration of this limited warranty for the equipment involved.
Jefferson is not responsible for cable wear due to flexing and abrasion. The end user is responsible for routine inspection of cables for possible
wear and to correct any issues prior to cable failure.
LIMITED WARRANTY STATEMENT
USER MANUAL v1.2
JEFFANDRM30-110
30"HIGH VELOCITY DRUM FAN • 123W • 110V~50Hz
www.jeffersontools.com
10
Claiming Warranty Coverage
The end user must contact Jefferson Professional Tools & Equipment (Tel: +44 (0) 1244 646 048) or their nearest authorised Jefferson dealer where
final determination of the warranty coverage can be ascertained.
Step 1 - Reporting the Defect
Online Method:
• Visit our website www.jeffersontools.com/warranty and complete the Warranty Returns form. You can complete the form online and submit it
to us directly or download the form to print out and return by post.
Telephone Method:
Contact your Jefferson dealer or sales representative with the following information:
• Model number
• Serial number (usually located on the specification plate)
• Date of purchase
A Warranty Returns form will be sent to you for completion and return by post or fax, together with details of your nearest authorised Jefferson
repair centre. On receipt of this form Jefferson will arrange to collect the equipment from you at the earliest convenience.
Step 2 - Returning the Equipment
It is the customer's responsibility to ensure that the equipment is appropriately and securely packaged for collection, together with a copy of
the original proof of purchase. Please note that Jefferson cannot assume any responsibility for any damage incurred to equipment during
transit. Any claims against a third party courier will be dealt with under the terms & conditions of their road haulage association directives.
Please note: Jefferson will be unable to collect or process any warranty requests without a copy of the original proof of purchase.
Step 3 - Assessment and Repair
On receipt, the equipment will be assessed by an authorised Jefferson engineer and it will be determined if the equipment is defective and in need
of repair and any repairs needed are covered by the warranty policy. In order to qualify for warranty cover all equipment presented must have been
used, serviced and maintained as instructed in the user manual.
Where repair is not covered by the warranty a quotation for repair, labour costs and return delivery will be sent to the customer (normally within 7
working days).
Note: If the repair quotation is not accepted Jefferson Professional Tools & Equipment will invoice 1 hour labour time at £30 per hour plus return
carriage costs (plus VAT).
In cases where no fault can be found with the equipment, or, if incorrect operation of the equipment is identified as the cause of the problem, a
minimum of 1 hour labour at £30 per hour plus carriage costs will be required before the equipment will be despatched back to the customer.
Any equipment repaired or replaced under warranty will normally be ready for shipment back to the customer within 7 working days upon receipt
of the equipment at an authorised Jefferson Repair centre (subject to part availability). Where parts are not immediately available Jefferson will
contact you with a revised date for completion of the repair.
General Warranty Enquiries
For any further information relating to Jefferson warranty cover please call +44 (0) 1244 646 048 or send your enquiry via email to warranty@
jeffersontools.com
Disclaimer:
The information in this document is to the best of our knowledge true and accurate, but all recommendations or suggestions are made without
guarantee. Since the conditions of use are beyond their control, Jefferson Tools® disclaim any liability for loss or damage suffered from the use of
this data or suggestions. Furthermore, no liability is accepted if use of any product in accordance with this data or suggestions infringes any patent.
Jefferson Tools® reserve the right to change product specifications and warranty statements without further notification. All images are for
illustration purposes only.
Jefferson Tools,
Herons Way,
Chester Business Park,
Chester,
United Kingdom,
CH4 9QR
Tel. +44 (0)1244 646 048
Email: [email protected]
IMPORTANT! SAFETY FIRST!
Before attempting to use this product please read
all the safety precautions and operating instructions
outlined in this manual to reduce the risk of fire,
electric shock or personal injury.
www.jeffersontools.com
www.jeffersontools.com
Table of contents
Other Jefferson Fan manuals
