Jenoptik JD 1300F User manual

2
Thank you for purchasing the Digital camera
JENDIGITAL JD 1300f as simple operation and easy to
carry out.
Please be sure to carefully read this manual and follow
the caution and operating instruction. If you follow the
manual carefully and fully understand how to use the
camera, you will enjoy years digital images with this
camera.
JD 1300f User's Manual

3
Product introduction
Systems Requirement
1. Powerful storage module to easily acquire pictures.
2. Plug & Play USB interface.
3. NTSC and PAL Video Out
4. Natural and graceful image quality
5. Simple and easy-to-use LCD panel.
6. Friendly interface.
7. Automatic power off on 60 seconds.
8. Lightly and easy to carry out
1. System: Win98/98SE/ME/2000, Mac: OS9 or above.
2. Pentium level CPU or above.
3. 16 MB RAM or above
4. 110MB Free Disk Min.
5. CD-ROM

4
Package contents
Package contents:
1. Digital Camera
2. Storage Driver for win98
3. Adobe PhotoDeluxe for Mac
4. Adobe PhotoDeluxer for PC
5. Vido cable
6. USB cable
7. Strap
8. Pouch
9. 2 x "AA" Batteries
10. User's manual
1
2
3
75
6
8
10
9
4

5
Nomenclature
1
3
4
6
18 17
10
9
12 11 13
2
8
57
1. Power , Macro switch
2. Shutter release button
3. Ready lamp (green)
4. Busy lamp (orange)
5. View finder
6. LCD Panel
7. Flash
8. Lens
9. Card-slot door
10.Strap eyelet
11. Enter / Confirm button
12. Left selecting button
13. Right selecting button
14. Video-out terminal
15. DC terminal
16. USB connector
17. Tripod socket
18. Battery-chamber door
16
14
15

6
Loading the battery
Loading the CF card
1. To load the battery: (As shown by figure below)
2. Please note the correct positive (+) and negative (-) polarity
as shown in figure below
3. Close the battery cover.
1. Open the card-slot door as shown in the figure.
2. Insert the CF card into the card slot.
(+)
(-)

7
Press the key
Press the key
LCD Panel Display
A. Mode button setting
B. Select button setting
(a.) Flash Selection
RED Fill-in
Flash-off Auto Flash
(c.) Quality Selection
Normal Best
(b.)Image size Selection
1280X960 640X480
(d.) TV Selection
NTSC PAL

8
(e.) Digital zoom Selection
2x digital zoom on 2x digital zoom off
(f.) Self-Timer Selection
on off
(g.) Delete Selection
Del.All Last One
no no
Del.All Last One
yes yes
C.Other
(h) Macro
on off
Rotate the function dial to
(i.) Card / Format
Format
no yes
No Card
(j)Battery
Full Warning Dangerous
LCD Panel Display

9
Basic Operations
Taking pictures:
1. Turn on the power.
2. Select the image size (1280 /640) and the quality (Best/ Normal)
3. Frame the subject in the viewfinder.
4. Make sure the green (shooting-ready) lamp lighted.
5. Press the shutter release button gently.
Please keep the lens clean to ensure better quality of image.
Delete pictures:
1. Delete the certain picture: In Menu mode, set the mode to "DELETE
ONE", press the menu button. Use the Right/Left button to select
YES/NO to insure Delete or Cancel Image; in TV mode, by connect-
ing this camera to your TV with the supplied video cable, you can
watching the captured images on TV, delete the last picture, press
the menu button, use the Right/Left button to select YES/NO to
insure Delete or Cancel images, or press the SB button to cancel it.
2. Delete all pictures: In menu mode, set the mode to "DELETE ALL",
press the menu button. And use the Right/Left button to select
YES/NO to insure Delete or Cancel images, all of the pictures in the
memory will be deleted. Or press the SB button to cancel it.
flash mode:
The camera has four flash shooting modes:
(1)Auto flash-Flash will automatically fire under dim light setting.
(2)Fill-in flash-The flash will always fire whenever you take pictures. In
low-light conditions or back light situations, it is recommended to
use this mode.
(3)Flash off-Flash will not function under this mode.
(4)RER mode-Red eye effect on human being will be reduced under
this mode.

10
Basic Operations
Self-timer mode:
Under this mode, the shutter will be delayed for about 10 seconds to
release after pressing the shutter release button, to allow you to join
the picture.
(1) Press the mode button to self-timer mode.
(2) Using a tripod or a steady support to hold the camera firmly.
(3) Compose the picture and reserve a space for yourself later.
(4) Press the shutter release button.
(5) Red self-timer lamp light will blink for about 10 seconds before
shutter is released.
Go to the reserved space within this time to take the picture.
TV mode:
1. After turn on the power, plug in Video Cable.
2. There are three options on TV Screen. Selecting by using
Left/Right button, then press the menu button.
2.1 Live view: Instant image, you can look for the picture you want to
capture by TV on this mode. Photographing is as same as before.
Viewing the picture, please go into the selecting mode, choose TV
mode (NTSC/PAL), then you can select Show one or Slide Show.
Please using Left/Right Select button to back the TV mode.
2.2 Show One: Show the pictures on TV from CF card or interior mem-
ory. Please use the Left/Right Selecting button to see the previous
and following pictures. Pressing the menu button or SB button to
back the TV mode
2.3 Slide show: One by one to show the pictures on TV from CF card
or interior memory automatically. Pressing the menu button or SB
button to back the TV mode.

11
Software operations
Driver installation:
1.For Win 98 / 98SE
(1) Start Window 98 / 98SE
(2) Insert the CD into the CD-ROM Driver
(3) Use the USB cable to connect computer and camera, plug
one end into the computer USB port and the other end into
camera USB jack.
(4) Please follow the instruction shown on the screen.
(5) Pull out the USB cable, and restart the computer.
2.For Win 2000 / ME
Just plug in the USB cable and directly use the camera.

12
INSTALLING
Adobe PhotoDeluxe
To use the supplied image editing application Adobe Photo Deluxe
Home Edition 4.0 (Windows® version) or Adobe Photo Deluxe 2.0
(Macintosh version), the following systems are required.
For the IBM-PC/AT and the compatible unit
CPU
OS
Memory
Hard disk
space
Monitor
CD-ROM
drive
Intel Pentium II processor of 233 MHz or more, or the
computer equipped with the fully compatible processor.
Windows®95, Windows®98 Windows2000.
Windows® NT 4.0 (Service Pack 5)
16 MB or more of built-in memory (For Windows® NT,
32 MB or more of built-in memory).
110 MB or more of available hard disk space.
Resolution 800 x 600/th color monitor for 16-bit color
video display
Necessary (when installing and using the software).
CPU
OS
Memory
Hard disk
space
Monitor
CD-ROM
drive
68040 or later processor or better, or Macintosh or
Power Macintosh
Mac OS 8.6, OS9
32MB RAM or higher
110 MB or more of available hard disk space.
The color monitor capable of displaying 256 colors
Necessary (when installing and using the software).
For Apple Macintosh

13
INSTALLING
Adobe PhotoDeluxe
Installing to the IBM-PC/AT and the compatible unit
1. Turn on the computer and start up Windows®.
2. Insert the Adobe PhotoDeluxe 4.0 CD-ROM into the CD-ROM drive.
3. When the setup program starts up automatically displayed on the
screen.
• When the setup program does not start up automatically, select
"Start" "Run" and input "D:\ENGLISH\NSTALL\SETUP.EXE"
in the box of "Open" (when your CD-ROM drive is the D drive) and
click [OK].
Installing to the Apple Macintosh
1. Turn on the computer and start up Mac OS.
2. Insert the Adobe PhotoDeluxe 2.0 CD-ROM into the CD-ROM drive.
3. When the icon of Adobe PhotoDeluxe 2.0 CD-ROM is displayed on
the desktop, double-click its icon.
4. Double-click "English" folder to open it.
5. Double-click "PhotoDeluxeTM Installer" icon.
After that, follow the operations according to the indication displayed
on the screen.

14
* Sensor Resolution : 1.3M Pixel CCD
* Image Resolution : 1280 x 960 pixels , 24 bit color
: 640 x 480 pixels , 24 bit color
* Image Compression : Best(1/5), Normal(1/10) - External
: Best(1/25), Normal(1/50) - Internal
* File Format : DCF
* Image Storage : External 8M CF card - 16 Pic.
( Best mode) , 32Pic. ( Normal mode)
: Internal - 16 Pic. ( Best mode ) ,
33 Pic. ( Normal mode)
* LCD Display : B/W LCD for functions.
* View Finder : Optical Reflective style View finder.
* Zoom : 2 x digital.
* Lens : Fixed Focus.
* Focal Length : f = 5 mm ( 33mm of 135 Camera)
* Focus Range : Normal-0.7M to infinity,
Macro-Up to 0.17M
* Exposure : Auto ( EV 2-15 )
* Shutter Speed : 1 - 1/250
* Aperture Range : F3.6/11
* ISO Equivalent : 100-400
* Flash : Strobe flash (Auto, Fill, Off, Red-eye),
range up to 9.8' (3 M).
* Self-Timer : 10 seconds
* Tripod Mount : Standard
Basic Operations

15
1. Do not use socket that is in excess of the voltage range of
the AC adapter specified for the camera to prevent from fire
or electrical shock.
2. Before pulling out or connecting the cord, please turn off the
power first.
3. After use, please turn off the camera, and pull out the AC
adapter from the socket.
4. Avoid heavy force on the power cord and keep away from
heat to ensure the safe use of the cord.
5. Remove the batteries if the camera will not be used for long
period of time.
Caution
* Interface : USB , CF card
* Video Out : NTSC / PAL
* Auto power off : 60 seconds
* Power Sources : a) 2 x "AA" Batteries.
b) USB power
c) AC Adaptor (optional)
* Certification : CE, FCC class B
* System requirment : Win 98 /98SE /ME /2000 ,
16M RAM Min.
, 110M Free Disk.CD-ROM
: Mac OS 9.0 or above
Basic Operations

16
JD 1300f Bedienungsanleitung
Wir danken lhnen für der Kauf der JENDITAL JD 1300f.
Sie haben damit eine einfach zu bedienende und
zuverlässige Kamera erworben. Bitte lesen Sie die
Bedienungsanleitung sorgfältig durch, bevor Sie die
Kamera zum ersten Mal benutzen. Bei genauer
Kenntnis der Funktionsweise und sorgfältigem Umgang
mit der Kamera Können Sie sich für viele Jahre an den
digitalen Bildern erfreuen, die Sie damit aufnehmen.

17
Produktmerkmale
Systemvoraussetzungen
1. Hohe Speicherkapazitäten möglich
2. Plug-und-Play über USB-Schnittstelle
3. Videoausgang für NTSC und PAL
4. Natürliche Bildqualität
5. Einfache und leicht zu handhabende LCD-Anzeige
6. Automatische Abschaltung nach 60 Sekunden
7. Geringes Gewicht
1. System: Windows 98/98SE/ME/2000, Mac: OS9 oder höher
2. Pentium PC mit 166 MHz oder höher
3. mindestens 32 MB Arbeitsspeicher
4. mindestens 110 MB freier Speicherkapazität
5. CD-ROM-Laufwerk

18
Lieferumfang
1. Digitalkamera inclusive 8 MB CF-Karte
2. Treibersoftware
3. Software Adobe PhotoDeluxe für Mac
4. Software Adobe PhotoDeluxe für PC
5. Videokabel
6. USB-Kabel
7. Kameratragschlaufe
8. Kameratasche
9. 2 Stck. Batterien Typ "AA"
10. Bedienungsanleitung
1
2
3
75
6
8
10
9
4

19
Teile der Kamera
1
3
4
6
18 17
10
9
12 11 13
2
8
57
1. Ein-/Aus-Schalter /
Schalter für Nahaufnahme
2. Auslöser
3. Bereitschaftsanzeige (grün)
4. Betriebsanzeige (rot)
5. Sucher
6. LCD-Anzeige
7. Blitz
8. Objektiv
9. Speicherkartenfach
10. Öse für Tragschlaufe
11. Taste Enter/Bestätigung
12. Wahlschalter, links
13. Wahlschalter, rechts
14. Videoausgangsbuchse
15. DC-Buchse
16. USB-Anschluss
17. Stativaufnahme
18. Batteriefachdeckel
16
14
15

20
1. Speicherkartenfach entsprechend Abbildung öffnen.
2. Speicherkarte einschieben.
3. Speicherkartenfach schließen
Einlegen der Batterien
Speicherkarte einlegen
1. Einlegen der Batterien entsprechend Abbildung.
2. Beim Einlegen der Batterien auf richtige Polung
entsprechend der Abbildung achten.
3. Batteriefach schließen.
(+)
(-)
