Jensen PA500 Quick start guide

ASA ELECTRONICS
2602 Marina Drive
Elkhart, IN 46514
1-800-688-3135
www.asaelectronics.com

The JENSEN PA500 is a universal public address system
that can be utilized as a stand alone PA (when connected
to speakers) or operate in conjunction with any existing
radio/speaker set up.
The PA500 system amplifier connects in line between the
vehicle's radio and the installed speakers.
The installed radio will operate normally. When
the microphone is activated by the "Push to Talk" (PTT)
switch on the microphone, the speakers are electrically
disconnected from the radio and engaged with the PA.
The microphone triggers activation of the PA through
the same speakers (muting/overriding the radio source).
There is no need to adjust PA volume at the radio since
the PA volume can be set using the volume/gain control
on the PA500 itself. If the PA500 is installed in an enclosure
the volume level can be pre-set by the installer.

1
1
2
3
4-5
6-7
8-9
10
11
11
12
Manual Contents...............................................................
Package Contents ............................................................
Panel Cutout(Optional Installation) .................................
Optional Flange Mount Installation..................................
Typical Wiring Connections.............................................
PA500 Wiring ....................................................................
PA500 Applications
Speaker Connections .......................................................
Troubleshooting ...............................................................
Specifications ...................................................................
Installation Notes .............................................................
(Extensions and Microphone compatibility).....
12

25

5 Pair- 4Ohm Speakers
4 Pair- 4Ohm Speakers
3 Pair- 4Ohm Speakers
4.8 Ohm
4.8 Ohm

Boom Microphone
P/N JMICBOM
Boom Microphone with
Foot Pedal
P/N JMICBOMFP
※ The PA500 is also compatible with older VOYAGER and
JENSEN Microphones such as the BVMH01 and BVMH01M

20 Ft Extension Cable
P/N 1401003
3 Ft Extension Cable
P/N 1401020
Hand Held Microphone
P/N JMICHND
Hostess Microphone
P/N JMICHST
Description
Hand held Microphone
Part Number
JENSEN PA500 Applications
Boom Microphone with foot pedal
8
