Jensen Ms3artl User manual

MS30BT

Owner’s Manual

MS30BT

CONTENTS

Introduction.................................................................................................................................................................................1

Features..............................................................................................................................................................................1

Box Content.........................................................................................................................................................................1

Compliance .........................................................................................................................................................................1

Safety Information ...............................................................................................................................................................2

Installation..................................................................................................................................................................................3

Mounting the Radio..............................................................................................................................................................3

Auxiliary Input......................................................................................................................................................................4

Line Output..........................................................................................................................................................................4

Wiring Diagram....................................................................................................................................................................5

Operation....................................................................................................................................................................................6

Basic Functions...................................................................................................................................................................6

Audio Menu.........................................................................................................................................................................6

Radio Mode.........................................................................................................................................................................6

USB Mode...........................................................................................................................................................................7

Auxiliary Input Mode............................................................................................................................................................7

Bluetooth Operation.............................................................................................................................................................8

Troubleshooting........................................................................................................................................................................10

Specifications ........................................................................................................................................................................... 11

MS30BT

INTRODUCTION

Thank for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If

you take a few minutes to look through it, you’ll learn how to use all the features of your new Jensen receiver for maximum

enjoyment.

Features

Waterproof iPx6

UV and Corrosion Resistant

AM/FM Tuner

12 Programmable Presets (6AM, 6 FM)

USB MP3/WMA Player

Rear Auxiliary Audio Output

4-Channel Amplified Audio Output

Bluetooth (Supports A2DP and AVRCP)

Box Content

MS30BT Radio

Radio Mounting Bracket

Screw Posts (x2)

Locking Hex Nuts (x2)

Washers (x2)

Compliance

Compliance with FCC Rules (U.S.A. Only)

This device complies with Part 15 of the FCC rules. Operation is subjected to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept any interference received), including interference that may cause

undesired operation.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not used in accordance with the instructions, may

cause harmful interference to radio communications

FCC WARNING

Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

Proper connections must be used for connection to a host computer and/or peripherals in order to meet FCC emission

limits.

MS30BT

Safety Information

To ensure full satisfaction with the product, please read the entire instruction manual.

Keep instructions for future reference.

Follow all operation guidelines and adhere to all safety warnings and cautions to ensure safe use.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that

produce heat.

Only use attachments/accessories specified by the manufacturer.

Never use harsh cleaning agents. Clean only with a dry cloth.

When Driving

Keep the volume level low enough to be aware of the road and traffic conditions.

Protect from Water

Do not submerge, as this can cause electrical shorts, fire or other damage.

Protect from High Temperatures

Exposure to direct sunlight for an extended period of time can produce very high temperatures inside your vehicle. Give the

interior a chance to cool down before starting playback. Do not mount the radio within close proximity of the engine

compartment.

Use the Proper Power Supply

This product is designed to operate with a 12 volt DC negative ground battery system.

WARNING:

DO NOT OPEN, DISASSEMBLE OR ALTER THE UNIT INANYWAY. Doing so may result in fire, electric shock or product

damage.

USE THE CORRECTAMPERE RATINGWHEN REPLACING FUSE. Failure to do so may result in fire, electric shock or

product damage.

DO NOT INSTALL IN LOCATIONS THAT MIGHT HINDER VEHICLE OPERATION. Doing so may obstruct vision or

hamper movement which can result in a serious accident.

INSTALL THE WIRING SO THAT IT IS NOT CRIMPED OR PINCHED BY SCREWS OR SHARP METAL EDGES. Route

the cables away from moving parts or sharp pointed edges. This will prevent crimping and damage to the wiring. If the

wiring must pass through a metal hole, be sure to use a rubber grommet to prevent the wire's insulation from being cut by

the metal edge of the hole. It is also recommended to apply sealing caulk to any opening that may potentially allow water

to enter.

Be sure to choose a location that is flat and has clearance above the unit to prevent any damage, as well as allow for

ventilation.

Before drilling any holes, carefully inspect the area underneath and behind the mounting surface where the device will be

mounted to make sure it will not interfere with existing wires, fuel lines, the fuel tank or any other objects that could be

damaged.

Always disconnect the vehicle negative battery terminal during installation to prevent accidental shorting.

MS30BT

INSTALLATION

Mounting the Radio

1. Choose a mounting location on the dash board or instrument panel that will allow room behind to run radio cables to the

power source. Consider how you will use the AUX IN, LINE OUT and USB connectors and route the appropriate extension

cables to an accessible area.

2. Cut a hole in the dash board usingthe template provided in the back of this manual.At least 3 ¾” depth is needed to mount

the radio.

IMPORTANT! Do not mount this unit where it can be submerged in water.

3. Slide the included spring washers (B) over the screw posts (A) and attach the screw posts to the back of the radio.

4. Place the radio in front of the dashboard opening so the wiring can be brought through the opening.

5. After completing the wiring connections, turn the radio on to confirm operation (vehicle accessory switch must be on). If the

radio does not operate, recheck all wiring until the problem is corrected. Once proper operation is achieved, turn the

accessory switch off and proceed with final mounting of the radio. Refer to the “Wiring Diagram” on page 5.

NOTE: Before final installation, test the wiring connections to make sure the unit is connected properly and the system

works.

6. Insert the radio into the mounting hole.

7. Place the “U” bracket (C) over the screw posts and secure the radio to the dash using the included hex nuts (D). If

necessary, cut the score marks (E) on either side of the mounting bracket to custom fit the bracket length for your

application. See FigureA.

Figure A - Installation

MS30BT

Auxiliary Input

Connect a portable audio device to the Audio Input (AUX IN RIGHT/LEFT) on the back of the unit using RCA cables.

Line Output

The Line Out connectors (LINE OUT RIGHT/LEFT) on the back of the unit output a line-level analog signal. Use this output to

connect to an external amplifier

MS30BT

Wiring Diagram

WIRE COLOR

DESCRIPTION

PURPLE

RIGHT REAR SPEAKER (+)

PURPLE/BLACK

RIGHT REAR SPEAKER ()

GRAY

RIGHT FRONT SPEAKER (+)

GRAY/BLACK

RIGHT FRONT SPEAKER ()

WHITE

LEFT FRONT SPEAKER (+)

WHITE/BLACK

LEFT FRONT SPEAKER ()

GREEN

LEFT REAR SPEAKER (+)

GREEN/BLACK

LEFT REAR SPEAKER ()

RED

ACC +12V

BLACK

GROUND

Note: Do not connect the red wire to a

constant power connection. The red wire

should be connected to a vehicle connection

with switched power such as IGN or ACC.

MS30BT

OPERATION

Basic Functions

Power

Press the JENSEN power button (1) to turn the unit on/off.

Restore Factory Settings

Perform the following steps to reset the radio to factory default settings:

1. Press and hold the power button (1) to display the software version.

2. Press the VOL + button (3) to display “RESET”

3. Press the power button to confirm factory default restore. After reset, the unit will default to FM mode.

Volume

Press the VOL + button (3) to increase the volume.

Press the VOL - button (2) to increase the volume.

Press and hold either button to change the volume level quickly.

Mute

Press the MUTE button (9) to silence the audio output in tuner, AUX or USB mode. Press again to restore the previous volume

level.

Mode

Press the MODE button (8) to select a mode of operation: FM, AM,AUX, USB and Bluetooth.

Audio Menu

Press and hold the MODE button (8) to access the audio menu. Press the MODE button repeatedly to adjust the following

settings: BASS, TREBLE, BALANCE, FADER, AS and PS. Use the VOL +/- buttons (3, 2) to choose a value for each setting.

See “Radio Mode” for instructions regarding the Auto Store (AS) and Preset Scan (PS) features.

Radio Mode

USA/Europe (EURO) Tuning Mode Selection

To change from USA to European tuning mode, perform the following steps:

1. Press and hold the MODE button (8) for 2 seconds to access the system menu.

2. Press the MODE button repeatedly to move through the menu options (BASS > TREBLE > BALANCE > FADER > AS/PS

> USA/EURO). The unit will display USA (if set to USA frequency tuning mode) or EURO (if set to European frequency

mode).

3. With the display showing the current tuning mode, press the VOL - or VOL+ button (2, 3) to change between USA/EURO.

4. Press the JENSEN power button (1) to confirm your selection.

MS30BT

Frequency Tuning

Press the l<< or >>l button (6, 7) to fine tune the radio frequency.

Channel Seek

Press and hold the l<< or >>l button to seek strong radio frequencies.

Preset Channel Store

To manually store a favorite channel to one of the six preset channels, perform the following steps:

1. Press the l<< or >>l button (6, 7) to tune to the radio frequency you want to store.

2. Press and hold the FOLDER + or -button (4, 5) to access the preset channel list.

3. Press the l<< or >>l button to select the desired preset channel number (1-6).

4. Wait three seconds and the unit will save the station to the chosen preset channel and display “SAVED” on the screen.

Auto Store

Press and hold the MODE button (8) to access the audio menu. Press the MODE button repeatedly until “AS” appears on the

display. Press the >>l button to begin theAuto Store function and store the strongest stations to the preset tuning channels. The

unit will automatically perform a Preset Scan once the Auto Store is complete.

Preset Scan

Press and hold the MODE button to access the audio menu. Press the MODE button repeatedly until “PS” appears on the

display. Press the >>l button to begin the Preset Scan function and listen to a preview of each stored station.

Preset Channel select

Press the FOLDER +/- buttons (4, 5) to select available preset channels.

USB Mode

Insert/Remove USB Device

You can connect a USB device directly to the USB interface at the rear of the radio for playback of compatible files. Playback

begins automatically.

Press the MODE button (8) to switch to USB mode from another source.

Play/Pause (USB)

During USB playback, press the MUTE button (9) to play or pause the selected track.

Next/Previous File

Press the l<< or >>l button (6, 7) to select the previous or next track.

Folder Navigation

Press the FOLDER +/- buttons (4, 5) to select the next/previous folder. Playback will begin with the first song file in the selected

folder.

Fast Forward/Fast Reverse

Press and hold the l<< or >>l button to fast forward or fast reverse.

Auxiliary Input Mode

Press the MODE button (8) to directly access auxiliary input mode (AUX IN) from any other mode when a portable audio device

is connected to the unit.

MS30BT

Bluetooth Operation

The MS30BT includes built-in Bluetooth technology that allows you to connect this unit to Bluetooth devices for streaming audio

playback.

About Bluetooth Technology

Bluetooth is a short-range wireless radio connectivity technology developed as a cable replacement for various electronic

devices. Bluetooth operates in 2.4 GHz frequency range and transmits voice and data at speeds up to 1 megabit per second.

Bluetooth was launched by a special interest group (SIG) comprised of Ericsson Inc., Intel Corp., Nokia Corp., Toshiba and IBM

in 1998, and it is currently developed by nearly 2,000 companies worldwide. The Bluetooth word mark and logos are owned by

the Bluetooth SIG, Inc. and any use of such marks is under license. Other trademarks and trade names are those of their

respective owners.

Bluetooth Menu Options

NOTE: Please note that some Bluetooth menu options are only available while the unit is in Bluetooth Audio mode.

Press and hold the MODE button (8) to enter the menu adjustment mode. Then repeatedly press the MODE button to access the

following Bluetooth Menu options:

BT ON/OFF: Press the VOL+ (ON) or VOL- (OFF) button to turn the Bluetooth function on or off.

BT Pair: On the BT Pair screen press the ||/MUTE (9) button to make pairing available for 120 seconds then connect

using your Bluetooth enabled device

DEVICE: Press the ||/MUTE button to view a list of previously paired mobile phone devices. Press the VOL+ or VOL-

buttons (2, 3) to view devices in the list. When viewing a specific device press ||/MUTE again to enable the following

LOCK/UNLOCK, DISCONNECT, and DELETE functions and VOL+ or VOL- to cycle through them.

LOCK/UNLOCK: The MS30BT can store up to 5 devices for Bluetooth connection. The devices are stored in a

FIFO (First In First Out) order. To prevent a device from being bumped from the list when more than 5 devices are

used, you can lock the device. To Lock/Unlock a device, press ||/MUTE to change between Lock/Unlock.

DISCONNECT: To disconnect a paired device, press the ||/MUTE button to temporarily remove the Bluetooth

connection. The connection can be re-established through your phone menu by selecting the MS30BT for

connection.

DELETE: Deleting a device removes it from the pairing list. To delete a device from the list, press the ||/MUTE

button. To reconnect with a deleted device it must be paired again.

Device 1

Device 2

Device 3

Device 4

Device 5

BT Device

Press ||/MUTE

Device 1

…

Device 5

Lock/Unlock

Connect/Disconnect

Delete

Lock/Unlock

Connect/Disconnect

Delete

Press ||/MUTE

Use VOL +/-

to Navigate

the List

Press ||/MUTE

VOL - / VOL+

MS30BT

Pairing a Bluetooth Device

Before you begin, consult the owner’s manual for the Bluetooth device you want to pair with the MS30BT.

1. Make sure the device is on and ready to receive a signal from the MS30BT. With the MS30BT in “BT MODE”, press and

hold the MODE (8) button.

2. Repeatedly press MODE until the unit displays PAIR ON, then press ||/MUTE. The unit will display PAIR and count down

from 120 to 0. While the unit counts down, use your mobile device Bluetooth function to search for a Bluetooth device.

3. When your mobile device has completed its search, the mobile device will display the Bluetooth device name (MS30BT).

4. Select MS30BT. Once connected the Bluetooth Audio icon ( ) will appear on the radio LCD display.

5. Enter the pairing password (0000), if requested.

After connecting successfully, you will be able to listen to audio stored on your Bluetooth enabled device through the radio.

Answering a Call

When answering a call using the connected phone, Bluetooth audio playback will pause.After hanging up from the call,

Bluetooth audio will continue on some phones. It may be necessary to press the play button to resume Bluetooth audio

playback.

Bluetooth Audio (A2DP)

Selecting Tracks

During playback, press |<< (6) or >>| (7) to play the previous or next track.

Pausing Playback

During playback, press ||/MUTE (9) to pause the Bluetooth audio playback. “BT PAUSE” will appear on the LCD. Press

||/MUTE again to resume playback. If you change to another mode, playback will automatically pause. Press the MODE button

(8) to return to Bluetooth mode and resume audio playback from your Bluetooth enabled device.

NOTE: If a Bluetooth device is disconnected due to the power being turned off or if the device goes out of range, the

unit will automatically search for the matching Bluetooth mobile device when the power is restored.

MS30BT

TROUBLESHOOTING

Table 1: Troubleshooting

Problem

Solution

No power

If the power supply is connected to the vehicle accessory circuits but the engine is not on, switch

the ignition key to “ACC”

Fuse may be blown. Replace with 10AMPATO fuse.

No AM/FM Reception

Antenna cable not connected; insert antenna cable firmly.

No sound

Check volume level; increase volume if necessary.

Check power; make sure device is on.

Check device; press the play/pause button to ensure unit is not in Pause mode.

MS30BT

SPECIFICATIONS

General

Power Supply Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC 12 Volts, Negative Ground

Operating Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-16VDC

Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.0”Diagonal, 3.3”Deep

Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.0”Diagonal, 4”Deep

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 lb.

FM Tuner

Tuning Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87.5 to 107.9 MHz

Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <4μV

Stereo Separation @1 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >25 dB

AM Tuner

Tuning Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 530-1710 KHz

Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <63μV

Amplifier

Max Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 160 Watts Total (40 Watts, 4 Channel)

Output Impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum

Specifications subject to change without notice.
