4
4
AS/PS
CLK DSP SMART
MOODE SEL
PWR/ILL
327 10
BAND/MENU
11 15 29 12 26
6
D.UP5
D.DN
2423
20
22
21
25 9
ENT
MUTE
OPEN
1
DOLBY
6713 2
1
4
RND
3
RPT
2
SCN
SOURCE
4
5
LED 28
AUDIO
Operation:
1. Front Panel / Remote Control
• Controls
1. Power Button: Press the Power button to turn the unit
on. Press and hold for 2 seconds to turn the unit off. Press the
Power button when the unit is on to select 4 different
brightness settings for the panel.
2. SEL: Selects the audio effect. Press the select
button to choose the desired Bass Treble or speaker setting.
Use the VOL+ and VOL- button to adjust the levels.
3. Open: Opens the front panel to allow access to
the CD/DVD slot.
4. Source: Press the source button to toggle
between Radio CD/DVD CDC/DVDC and Aux mode.
(NOTE: CDC/DVDC mode is active only if a changer is
connected. This source will be skipped if a changer is not
installed.) Press and hold the Source button for 2 seconds to
mute the rear speaker and subwoofer. Press and hold for 2
more seconds to re-activate the rear speakers and subwoofer.
5. Enter / Mute: Press the Enter button to select the
highlighted menu bar. Press and hold the Enter button for 2
seconds to mute the speakers.
6. / : Press the to fast forward the
track. Press the to rewind the track.
7. / Press the to skip to the next
track, press the to skip to the previo s track.
8. Slow/Zoom: Activate the slow forward or zoom
f nction.
9. / Pa se/Play b tton. Press once to
pa se the CD/DVD, press again to res me play.
10. Band/Menu: In radio mode, press the
Band/Men b tton to change from AM/FM bands. In
DVD mode, press the Band/Men b tton to activate
the DVD men .
11. /AS/PS: In DVD mode press the /AS/PS to
stop the DVD. In Radio mode press the /AS/PS to
access the Automatic memory storing and preset scanning
mode. Press and hold the button for 2 seconds to scan
through the 6 preset stations.
12. Vol + / Vol - Controls the volume level press the
Vol+ button to increase the volume and the Vol- button to
decrease the volume.
13. Audio/DSP: Chooses the audio soundtrack and the
preset EQ. DVD mode: Press and hold for 2 seconds to
change the language soundtrack. Feature is activated only
if the DVD is recorded with multi language soundtracks.
CD Mode: Press and hold for 2 seconds to change from
Stereo Mono left and Mono right mode. Press once to
