Jensen SCR-90 User manual

Stereo USB Cassette Player with Encoding to Computer
MODEL: SCR 90
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE

E-1
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B Digital Device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Dear JENSEN Customer
Selecting fine audio equipment such as the unit you've just purchased is only the
start of your musical enjoyment. Now it's time to consider how you can maximize the
fun and excitement your equipment offers. This manufacturer and the Electronic
Industries Association's Consumer Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that lets the sound come through loud
and clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing. Sound can be deceiving. Over time your hearing "comfort level"
adapts to higher volumes of sound. So what sounds "normal" can actually be loud and
harmful to your hearing. Guard against this by setting your equipment at a safe level
BEFORE your hearing adapts.
To establish a safe level:
 Start your volume control at a low setting.
 Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
 Once you have established a comfortable sound level Set the dial and leave it there.
Take a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.

E-2
We Want You Listening for a Lifetime
Used wisely, your new sound equipment will provide a lifetime
of fun and enjoyment. Since hearing damage from loud noise
is often undetectable until it is too late, this manufacturer and
the Electronic Industries Association's Consumer Electronics
Group recommend you avoid prolonged exposure to excessive
noise.
Customer's Record:
The serial number of this product is found on its bottom. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to aid in
identification in the event of theft of loss.
Model Number SCR-90 Serial Number ____________________
LOCATION OF CONTROLS
1. PLAY BUTTON
2. STOP BUTTON
3. FAST FORWARD BUTTON
4. BATTERY LED INDICATOR
5. EARPHONE JACK
6. SPEAKER ON/OFF SWITCH
7. VOLUME CONTROL
8. MINI USB JACK
9. DC IN JACK
10. SPEAKER
11. BELT CLIP
12. BATTERY DOOR

E-3
POWER SOURCE
BATTERY OPERATION
Notes If you are using an external AC adapter (not included) for powering the unit,
disconnect it before installing batteries.
For best performance and longer operating time, we recommend using alkaline batteries.
1. Remove the BATTERY DOOR (#12) on the back of the unit.
2. Follow the polarity diagram shown beside the BATTERY DOOR (#12) to insert 2 X
‘AA’ size (UM-3) batteries and close the BATTERY DOOR (#12).
BATTERY WARNING
1 . Be sure the batteries are installed correctly. Wrong polarity may damage the unit.
2. Use only the size and type of batteries specified.
3. Do not mix old and new batteries.
4. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
5. If the unit is not to be used for an extended period of time, remove the batteries. Old
or leaking batteries can cause damage to the unit and may void the warranty.
6. Do not try to recharge batteries not intended to be recharged; they can overheat and
rupture. (Follow battery manufacturer’s directions).
7. Do not dispose of batteries in fire, batteries may leak or explode.
AC ADAPTER OPERATION (adapter not included)
This unit can also be powered using an AC adapter (not included) with an input voltage of
AC 120V ~ 60Hz, and output voltage of DC 3V 300mA.
1. Plug the AC adapter (not included) into a household AC power outlet.
2. Insert the DC plug of the AC adapter cord into the DC IN JACK (#9).
3. If batteries are installed in the SCR-90, they will automatically be disconnected when
using an AC adapter.
NOTE Only use adaptor with an output voltage
rated at DC 3V 300mA with a
center positive plug.
WARNING: Before connecting to the power supply, ensure that the supply corresponds
to the information on the rating label located on the back of the unit.
USB POWER
- This unit can also be powered using the built-in MINI USB JACK (#8) and the included
USB cable.
- A USB power supply (not included) like a cell phone charger, computer USB port or
USB power bank with a minimum output of DC 5V 500mA is required.
- Plug the mini USB connector on the cable into the MINI USB JACK (#8) located on the
SCR-90. Plug the other end of the USB cable into the USB charger, power bank or
computer (not included).
- If batteries are installed in the SCR-90, they will automatically be disconnected when
using the USB port for powering the unit.

E-4
CASSETTE PLAYER OPERATION
1. Open the cassette door and insert a pre-recorded cassette tape with the exposed tape
facing out. Close the cassette door.
2. Select the playback output.
• SPEAKER Slide the SPEAKER ON/OFF SWITCH (#6) to ON position to select
speaker output.
• EARPHONE Slide SPEAKER ON/OFF SWITCH to OFF position to select
earphone output.
3. Press the PLAY BUTTON (#1) and adjust the VOLUME CONTROL (#7) to obtain
the desired sound level.
4. Press the FAST FORWARD BUTTON (#3) when you wish to rapidly advance the
tape.
5. Press the STOP BUTTON (#2) to switch off.
AUTO STOP
To protect your cassette tapes and prevent unnecessary wear to the pinch roller of the
cassette mechanism, this unit is equipped with an Automatic Stop System. When the
tape ends during play or fast forwarding, it will automatically release to stop the cassette
from running.
CASSETTE TAPE OPERATING TIPS
1. High quality tapes are recommended to obtain maximum quality reproduction from
recordings.
2. Tapes with playing time of 120 minutes (C-120) are not recommended because they
contain thinner and longer tape that has a greater chance to malfunction and jam,
which may damage the cassette mechanism.
3. To obtain good reproduction, the head should be cleaned after every 10 to 20 hours of
use. It is also recommended that the cassette be kept away from excessive heat or
cold.
4. If there is slack in the tape, remove the slack prior
to inserting the cassette. To remove the slack,
insert a pencil into the hub and rotate clockwise as
shown
5. A leader tape is provided at the beginning on each
cassette. There is no recording on this area, so it
is necessary to let the tape run for about five
seconds to clear the head.
6. Keep the tape head clean since a dirty head
can cause distorted sound or improper tape
speed. Depress the PLAY BUTTON (#1)
and use a small cotton swab with tape head
cleaner or alcohol to clean the tape head,
capstan and pinch roller as shown

E-5
READ THIS IMPORTANT INFORMATION BEFORE USING YOUR EARBUDS
1. Avoid extended play at very high volume as it may impair your hearing.
2. If you experience ringing in your ears, reduce the volume or shut off your unit.
3. Do not use while driving a motorized vehicle. This is dangerous and also illegal in
some states.
4. Keep the volume at a reasonable level even if your headset is an open-air type
designed to allow you to hear outside sounds. Please note excessively high volume
may still block outside sounds.
RECORDING TO YOUR COMPUTER
Record audio from the tape directly to your computer using the included USB cable and
Audacity Software included on the enclosed CD.
The Audacity program manual can be accessed from the programs pull down menu once
installed on your computer.
For more information on compatibility, updates or the Audacity program, please visit
https //www.audacityteam.org
CARE AND MAINTENANCE
1. Clean your unit with a damp (never wet) cloth. Solvent or detergent should never be
used.
2. Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
3. Keep your unit away from heating appliances and sources of electrical noise such as
fluorescent lamps or motors.

E-6
TROUBLE SHOOTING GUIDE
If you experience difficulties in the use of this Cassette Player with AM/FM Radio, please
check the following or call 1-800-777-5331 for Customer Service and support
SYMPTOM POSSIBLE SOLUTION
Low or no power Replace all batteries with
new ones. No sound
Volume set at minimum Increase Volume.
Sound appears
distorted at high volume
setting
Volume control is set to
maximum
Adjust Volume control to a
lower comfortable level
Speaker no sound
The Speaker is OFF
Volume at minimum
Slide the Speaker On/Off
switch to ON
Increase volume
Tape Sound distorted Defective tape or dirty tape
head
Replace tape or clean tape
head
Speed varies Tape old or worn
Dirty roller and capstan
Replace the tape
Clean roller and capstan
SPECIFICATION
Power Requirement Battery 2 x "AA"(UM-3) batteries (not included)
AC Adaptor (not included) Input AC 120V ~ 60Hz
Output DC 3V 300mA
USB Power DC 5V 500mA
SPECTRA GREEN NOTICE
At Spectra, environmental and social responsibility
is a core value of our business. We are dedicated
to continuous implementation of responsible
initiatives with an aim to conserve and maintain the
environment through responsible recycling.
Please visit us at
http://www.spectraintl.com/green.htm for more information on Spectra’s green
initiatives or to find a recycler in your area.

E-7
90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A. ONLY
SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from
defective materials or factory workmanship for a period of 90 days from the date of original
customer purchase and provided the product is utilized within the U.S.A. This warranty is not
assignable or transferable. Our obligation under this warranty is the repair or replacement of
the defective unit or any part thereof, except batteries, when it is returned to the SPECTRA
Service Department, accompanied by proof of the date of original consumer purchase, such as a
duplicate copy of a sales receipt.
You must pay all shipping charges required to ship the product to SPECTRA for warranty service.
If the product is repaired or replaced under warranty, the return charges will be at SPECTRA’s
expense. There are no other express warranties other than those stated herein.
This warranty is valid only in accordance with the conditions set forth below
1. The warranty applies to the SPECTRA product only while
a. It remains in the possession of the original purchaser and proof of purchase is
demonstrated.
b. It has not been subjected to accident, misuse, abuse, improper service, usage outside
the descriptions and warnings covered within the user manual or non-SPECTRA
approved modifications.
c. Claims are made within the warranty period.
2. This warranty does not cover damage or equipment failure caused by electrical wiring not in
compliance with electrical codes or SPECTRA user manual specifications, or failure to
provide reasonable care and necessary maintenance as outlined in the user manual.
3. Warranty of all SPECTRA products applies to residential use only and is void when
products are used in nonresidential environment or installed outside the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state. TO OBTAIN SERVICE please remove all batteries (if any) and pack the unit
carefully and send it freight prepaid to SPECTRA at the address shown below. IF THE UNIT IS
RETURNED WITHIN THE WARRANTY PERIOD shown above, please include a proof of
purchase (dated cash register receipt) so that we may establish your eligibility for warranty
service and repair of the unit without cost. Also include a note with a description explaining how
the unit is defective. A customer service representative may need to contact you regarding the
status of your repair, so please include your name, address, phone number and email address
to expedite the process.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $10.00 to
cover the cost of repair, handling and return postage. All out of warranty returns must be sent
prepaid.
It is recommended that you contact SPECTRA first at 1-800-777-5331 or by email at
[email protected] for updated information on the unit requiring service. In some cases,
the model you have may be discontinued, and SPECTRA reserves the right to offer alternative
options for repair or replacement.
SPECTRA MERCHANDISING INTERNATIONAL, INC.
4230 North Normandy Avenue,
Chicago, IL60634, USA. 1-800-777-5331
To register your product, visit the link on the website below to enter your information.
http //www.spectraintl.com/wform.htm
0619 Printed in China
