Jensen JTA-990 User manual

ALL IN ONE STEREO MUSIC SYSTEM WITH MP3 ENCODING
MODEL: JTA-990
USER MANUAL
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT
AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.

E1
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH
AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The Caution Marking is located at the back enclosure of the apparatus.
The Rating plate is located at the back enclosure of the apparatus.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that product heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table recommended by
the manufacturer, or sold with the product. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for a
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the

E2
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. This appliance shall not be exposed to dripping or splashing water and that no object
filled with liquids such as vases shall be placed on the apparatus.
16. Do not overload wall outlet. Use only power source as indicated.
17. Use replacement part as specified by the manufacturer.
18. Upon completion of any service or repairs to this product, ask the service technician
to perform safety checks.
19. Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instruction.
20. Object and Liquid Entry - Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the product.
21. Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal
operation.
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a
need for service.
22. Mains plug is used as disconnect device and it should remain readily operable during
intended use. In order to disconnect the apparatus from the mains completely, the
mains plug should be disconnected from the mains socket outlet completely.
23. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
24. Excessive sound pressure from earphones and headphone can cause hearing loss.
25. Minimum distances of 10 cm around the apparatus for sufficient ventilation.
26. The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, table-cloths, curtains, etc.
27. No naked flame sources, such as lighted candles, should be placed on the
apparatus.
28. The use of apparatus in moderate climates.
29. Attention should be drawn to the environmental aspects of battery disposal
This symbol indicates that this product incorporates
d o ub le insulation
between hazardous mains voltage and
us er accessible p a r ts.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT. FULLY INSERT THE PLUG TO MAIN
POWER SOCKET.
SAVE THESE INSTRUCTIONS

E3
CAUTION
Follow the advice below for safe operations.
ON PROTECTION AGAINST LASER ENERGY EXPOSURE
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the casing.
Stop operation immediately if any liquid or solid object should fall into the cabinet.
Do not touch the lens or poke at it. If you do, you may damage the lens and the player
may not operate properly.
Do not put anything in the safety slot. If you do, the laser diode will be ON when the CD
door is still open.
If the unit is not to be used for a long period of time, make sure that all power sources
are disconnected from the unit. Remove all batteries from the battery compartment.
This unit employs a laser. The use of controls or adjustment or performance of
procedures other than those specified here may result in exposure to hazardous
radiation.
Caution:
- Any use of the controls or performing any of the procedures in a way other than those specified
herein may result in hazardous radiation exposure.
- This unit should not be adjusted or repaired by anyone except qualified service personnel.
ON PLACEMENT
Do not use the unit in places which are extremely hot, cold, dusty or humid.
Place the unit on a flat and even surface.
Do not restrict the air-flow of the unit by placing it in a place with poor ventilation, by covering it
with a cloth or by placing it on a carpet.
ON CONDENSATION
When left in a heated room where it is warm and damp, water droplets or condensation may
form inside the unit.
When there is condensation inside the unit, the unit may not function normally. Let it stand for
1 to 2 hours before turning the power on, or gradually heat the room up and dry the unit before
use.
PRECAUTION FOR USE
UNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.
DO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAINS
VOLTAGE AND ALL OTHER CONNECTIONS HAVE BEEN MADE.
DO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF
SEVERAL CENTIMETERS AROUND THE UNIT FOR VENTILATION.

E4
IMPORTANT NOTES
Avoid installing the unit in locations described below:
Places exposed to direct sunlight or close to heat radiating appliances such as electric
heaters.
Places subject to constant vibration.
Dusty, humid or moist places.
COMPLIANCE WITH FCC REGULATIONS
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
NOTE : This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
PROTECT YOUR FURNITURE!!
This system is equipped with non-skid rubber ‘feet’ to prevent the product from moving when you
operate the controls. These ‘feet’ are made from non-migrating rubber material specially
formulated to avoid leaving any marks or stains on your furniture. However certain types of oil
based furniture polishes, wood preservatives, or cleaning sprays may cause the rubber ‘feet’ to
soften, and leave marks or a rubber residue on the furniture.
To prevent any damage to your furniture we strongly recommend that you purchase small
self-adhesive felt pads, available at hardware stores and home improvement centers everywhere,
and apply these pads to the bottom of the rubber ‘feet’ before you place the product on fine
wooden furniture.

E5
DEAR JENSEN® CUSTOMER
Selecting fine audio equipment such as the unit you've just purchased is only the start of your
musical enjoyment. Now it's time to consider how you can maximize the fun and excitement
your equipment offers. This manufacturer and the Electronic Industries Association's
Consumer Electronics Group want you to get the most out of your equipment by playing it at a
safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion and, most importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing "comfort level" adapts to higher volumes of
sound. So what sounds "normal" can actually be loud and harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After
all, we want you listening for a lifetime.
We Want You Listening For a Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often undetectable until it is too late, this manufacturer and
the Electronic Industries Association's Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise.
Customer's Record:
The serial number of this product is found on its back cover. You should note the serial
number of this unit in the space provided as a permanent record of your purchase to aid in
identification in the event of theft of loss.
Model Number: JTA-990 Serial Number: ____________________

E6
GETTING STARTED
SPEAKER CONNECTION
1. Insert the speaker cable ends (exposed wires) into the terminals located on the back of the
main unit by pushing down the lever of the left speaker terminal and then the right speaker
terminal
2. Connect the left speaker to the left speaker terminals with the red wire to L+ and the black wire
to L -.
3. Connect the right speaker to the right speaker terminals with the red wire to R+ and the black
wire to R -.
NOTE:
Make sure that the power is turned off when connecting or disconnecting the speakers.
Make sure that the speakers are connected to the correct terminals.
CONNECTING THE AC POWER CORD
After connecting the speakers unwind the AC power cord fully and
connect it to any convenient household 120V~ 60Hz AC outlet.
NOTE:
The product is designed to operate on normal 120V~ 60Hz AC only.
Connecting this system to any other power supply could result in
damage to the unit which is not covered by your warranty. You will
noted that this system is equipped with a polarized AC power plug
having one blade wider than the other. This is a safety feature.
If this plug does not fit into your existing AC outlet, do not try to defeat this safety feature by filling
the wide blade to make it fit into your outlet. If this plug will not fit into your outlet, you probably
have an outdated non-polarized AC outlet. You should have your outlet changed by a qualified
licensed electrician.

E7
LOCATION OF CONTROLS
MAIN UNIT
1. Turntable Dust Cover
2. LCD Display
3. Remote Sensor
4. Standby LED Indicator
5. Power Button
6. Erase Button
7. Finalize Button
8. Record 1/All button for encoding
from CD to USB
9. USB Port
10. Display Button
11. Random Button
12. Repeat Button
13. Program Button
14. Folder/Preset Up / Down Button
15. Skip /Tuning Up /Down Button
16. Stop / FM Stereo/Mono button
17. 3.5mm Aux-in Jack
18. 3.5mm Headphone Jack
19. Manual Track Separation (TS) Button
20. Tape Mode button
21. Record Button
22. Play/Pause button
23. Rotary Volume Control Knob
24. Aux/Phono Mode Button
25. CD/USB Mode Button
26. Tuner (AM/FM) Mode Button
27. CD Door open/close Button
28. Enhance Bass effect On/Off button
29. Cassette Door Cover
30. Tape Forward / Eject Button
31. CD Tray
32. CD Tray eject hole
33. 45 Rpm Record Adaptor
34. 33/45/78 RPM Speed Selector
35. Auto-Stop Switch
36. Tone Arm Rest with Clip
37. Pitch Adjust Knob
38. RCA Line Out Jack
39. L/R Speaker Wire Terminals
40. FM Wire Antenna
41. AC Power cord
CAUTION:
Usage of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service personnel.

E8
REMOTE CONTROL
Buttondescription
1. Repeat In CD/USB mode: Press to activate CD Repeat 1/all
2. Random In CD/USB mode: Press to activate shuffle play function
3. Program In CD/USB mode: Press to activate programming function
4. Play/pause In CD/USB mode: Press to Start/Pause CD/USB playback
In Recording/Encoding mode: Press to confirm function.
5. Skip/Tuning
Up /Down In CD/USB mode: Press to select next/previous Track
In Radio mode: Press to tune frequency up/down
6. Stop /FM Mono/St In CD/USB mode: press to stop playback
In FM Radio mode: Press to Select FM Stereo/Mono Mode
7. Folder/Preset
Up /Down In Radio mode: Press to recall radio preset channel
upward/downward
In USB mode: Press to select Music Folder up/down
8. Volume +/- Press to adjust the volume level Up (+) and Down (-)
9. Record Press to active Record/Encode function
10. Rec Level+/- Press to increase/decrease recording level in recording mode.

E9
11. Erase Press to erase file in USB thumb drive or CD-RW
12. Record 1/All
from CD to USB Press to Record One/All tracks for encoding from CD to USB
13. Finalize Press to Finalize the CD-R/RW disc after recording
14. Clear Press to delete the latest track of programmed tracks
15. TS (Track Separation) Press to activate the Manual Track Separation function
16. Display Press to change CD/USB playback time information on LCD
17. CD/USB Press to select the CD or USB mode.
18. Phono/Aux Press to select Phono mode, plug in 3.5 mm AUX IN cable to
change to Aux mode.
19. FM/AM Press to select AM or FM radio
20. Tape Press to select cassette player mode
BATTERY INSTALLATION
The battery compartment is located on the back of the remote control.
1. Remove the battery compartment door by pressing in on the tab
and lifting it off.
2. Insert two (2) AAA size batteries (included) into the battery
compartment following the polarity markings inside the battery
compartment.
3. Replace the battery compartment door.
Battery Precautions
Replacement of batteries must be done by an adult.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable
(nickel-cadmium) batteries.
The supply terminals are not to be short-circuited.
Non-rechargeable batteries are not to be recharged.
Exhausted batteries are to be removed.
Only batteries of the equivalent type are to be used.
Batteries are to be inserted with the correct polarity.
Dispose of batteries properly. Do not dispose of batteries in fire. The
batteries may explode or leak.

E10
RADIO OPERATION
MANUAL TUNING
1. Press the POWER button on main unit to turn on the unit. The display will show “HELLO” and
then “---bUSY” for few seconds. Wait until the display shows FM frequency. The unit is in FM
mode.
2. Tap the “FM/AM” button to select AM Radio mode if necessary.
3. To manually tune to a specific radio station, tap the “ /TUNE” or “TUNE/ ” button on
either the main unit or the remote control repeatedly. Use the manual tuning method to tune
in weaker stations that are bypassed during Automatic Tuning.
4. To automatically tune to the next available radio station, press and hold the “ /TUNE” or
“TUNE/ ”button for 1-2 seconds until frequency readout on the display begins to scan and
then release the button. The tuner will stop scanning when it receives the next broadcasting
station of adequate signal strength.
5. Rotate the VOLUME control knob on main unit or press the “VOL+/-“ button on the remote
control to adjust the volume to the desired volume level.
FM & FM-STEREO RECEPTION
Tap the “FM/AM” button to select FM radio mode if unit is in AM mode. When listening to the
FM radio, press the “ /ST./MONO” button to switch between stereo mode and mono mode.
The FM stereo icon “ ” will appear on the display if unit is in stereo mode.
We recommend leaving the unit in mono mode if you are receiving a weak FM station.
HINTS FOR BEST RECEPTION:
AM - The AM antenna is located inside the cabinet of the unit. If AM reception is weak,
change the position of unit until the internal antenna picks up the strongest signal.
FM - For best FM reception, the FM lead wire antenna located on the back of the set
should be fully unwrapped and extended.
NOTE: Automatic tuning depends on the signal strength of the broadcasting station, so weak
stations may be skipped. You can manually tune to find the weak stations if a station gets
skipped. With strong signals, the tuner may stop before it reaches the actual broadcast
frequency, so you may need to manually tune for the best reception.
PRESET RADIO STATIONS
You can store up to 30 FM + 30 AM radio stations in the memory.
1. Press the POWER button to turn on the unit, wait until the display shows the FM frequency.
2. Tap the “FM/AM” button to select AM band if necessary.
3. Tune to a desired radio station by using either the “manual” or “automatic” tuning method.
4. Tap the “PROGRAM” button to enable the program mode and the “PROGRAM” indicator and
“P - -01” appear on the LCD display.
5. Tap the “ /”button on remote control or main unit repeatedly to select the desired station
memory for storage.
6. Tap the “PROGRAM” button again to confirm the setting.
7. Repeat steps 3 through 6 to preset other stations if necessary.
NOTES:
1.) The unit will remain in program mode for about 40 seconds if no buttons are pressed. After
the 40 seconds expires, the unit will return to normal tuner mode automatically.
2.) You can overwrite a present station by storing another frequency in its place.
RECALLING PRESET MEMORY CHANNELS
In AM or FM radio mode, recall the pre-set channels by repeatedly pressing the
“FOLDER/PRESET UP/DOWN” button on the remote control or on the main unit.

E11
PHONO OPERATION
Note, Before Use:
-Lift up the turntable dust cover.
-Lift up the stylus protector as shown to the right.
-Be sure that the tone arm is unlocked from the tone arm rest before
operating, and replace again when finished.
1. Press the POWER button to turn on the unit, press the PHONO/AUX button to select
PHONO mode, LCD display will show “PHONO”. Wait for few seconds until busy message
disappear from display.
2. Place the record on the platter, over the center spindle (use the 45 RPM record adaptor when
playing 45 RPM record).
3. Set the Speed selector to 33, 45 or 78 RPM according to the record you are playing.
4. Lift the tone arm from the rest and slowly move it over the record. The platter will turn.
5. Move the tone arm to the beginning of the record, or to the start of a particular track. Gently
lower the tone arm onto the record to start playing.
6. Adjust the volume to the desired level.
7. When the record is played to the end of the record, the platter will automatically stop rotating.
Lift the tone arm and return it to the rest position.
8. To stop the record manually when playing, lift up the tone arm and return it to the rest
position.
Note:
Some types of records may have an auto-stop area outside the preset limit, so the turntable may
stop before the last track finishes. In this case, set the auto-stop switch to the “OFF” position.
This allows the record to play to the end, but it will not stop automatically. You must manually
raise the tone arm and place it back in the rest to stop the turntable from spinning and turn it off.
PITCH ADJUST
The PITCH ADJUST allows you to fine tune the playing speed of the record once the correct
speed (33/45/78 RPM) is chosen. Turn the Pitch Adjust Control to slightly increase or decrease
the speed of the turntable if necessary.
CD OPERATION
NOTE: This player will not only play commercial CDs, but also self-complied CD-R/RW discs.
Do not attempt to play CD-ROM, CDI, VCD, DVD or computer CDs.
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs. They will
also read self-compiled CD-R/CD-RW discs but it may take up to 15 seconds for playback to
start. If playback does not start, it is likely due to the quality of the CD-R/RW disc and/or the
compatibility of the CD compilation software. Manufacturer is not responsible for the playback
quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a malfunction
GETTING STARTED
1. Press the POWER button to turn on the power, press the CD/USB Function button to select
“ CD “ mode. The LCD display will show “---bUSY” and then “NO Cd” if the CD compartment
is empty.
2. Press the “Open/Close ” button on the main unit front panel to open the CD tray.
3. Place an audio CD with the printed side facing up inside the tray and then press the
button to close the CD tray. Wait for “---bUSY” message disappears form display and reading
the CD.

E12
4. After the CD is read, the LCD display shows the total number and time of the tracks. If a CD
is not recognized by the player or if no disc is loaded, the display will show “NO Cd”.
NOTES:
- Keep the CD disc tray closed when the system is not in use to prevent dirt and dust
from entering the CD mechanism.
- Never place more than one CD in the CD tray. If two discs are loaded at the same
time, the CD mechanism may jam and / or the discs themselves may be damaged.
- Never push on the CD door to close it. Always press the ”OPEN/CLOSE ”button on the
unit front panel to open and close the CD tray.
Play / Pause mode
1. Press the CD Play/Pause button to start playback, the first track will start playback, play
indicator “ “ and elapsed time will show on the LCD display.
2. Press the DISPLAY button, elapsed time will change to count down time of CD.
3. To interrupt, press the Play/Pause button once, the playing time will be freeze and pause
indicator “ II “ will show on the LCD display. Press again to resume normal playback.
Stop mode
If Stop button is pressed during play or pause mode. It will go to stop mode and display
total number of track on the LCD display.
Skip mode (skip up / skip down )
1. During CD Stop mode, if Skip up or down button is pressed. It will go to next or
previous track and remain in Stop mode. Press Play/Pause button to start music
playback
2. During play or pause mode, if Skip up or down button is pressed. It will go to next or
previous track and start playing the track.
NOTES:
- Always press the “STOP ” button to stop CD playback and return the LCD to the original
information before pressing the “OPEN/CLOSE ” button for disc changing.
- The reaction time of the CD burner is longer than normal CD player due to the complicacy
system.
- Keep pressing with all difference function within a short time may cause mal-function of the
system. Please re-start the unit if this is happened.
- The reading and playback time of CD-R/RW disc is various from brand to brand. It depends
on the compatibility of the used disc.
- CD player/recorder only designed for normal compact disc format. It is not support any
MP3/WMA format.
Repeat Play mode
Press the Repeat button before or during playback, a single track or all the tracks can be played
in difference mode as following:
(1) Repeat all tracks (2) Repeat 1 track (3) Off mode
Random Play mode
Press the RANDOM button and “ RAN “ will display on LCD, and now the track will playback in
random order by this function. Press again to cancel it.

E13
Play mode Indicator on LCD display
Repeat all
Repeat 1 1
Random RAN
Off mode --------------
CD disc programming
Up to 32 tacks can be programmed for CD playback. Before programming tracks, be sure the CD
system is in stop mode:
1. Select CD mode and stop the disc playback.
2. Press the PROGRAM button on remote control or main unit, “ PROGRAM “ indicator will
appear on LCD display. Moreover, it will show program number and digits of track number to
be programmed (001P-01).
3. Select a desired track by tapping the TUNE/ or /TUNE buttons.
4. Press the PROGRAM button to store the track into memory. Program counter advanced to
“P02”.
5. Repeat steps 3 and 4 to enter additional tracks into the memory if necessary.
6. When all the desired tracks have been programmed, press the Play/Pause button to play
the disc in assigned order.
7. To cancel the programmed selections, press Stop button twice until “PROGRAM”
indicator is disappeared from LCD display.
DELETING PROGRAMMED CD TRACKS (Remote Control Only)
After a programmed played, you can delete the programmed tracks in the order from the last one
to the first one by pressing the “CLEAR” button on the remote control. This function allows you to
re-program the memory half way through if necessary.
1. Tap the STOP button once to stop programmed track playback, “PROGRAM” icon still
showing in LCD display.
2. Press the CLEAR button on remote control once to start deleting the last programmed track.
3. Press the CLEAR button once by once, the programmed tracks will be deleted one by one
from the memory.
NOTES:
- The reaction time of the CD Recorder is longer than that of a normal CD player due to the
complexity of the system, so there may be a slight delay when using the CD player.
- Pressing the different function buttons within a short time of one another may cause
malfunction of the system.
- If this happens, please disconnect the unit from the mains, let it rest for about 15 minutes and
then re-start it. This should hopefully re-set the unit.
- The reading and playback time of a CD-R/RW disc may vary from brand to brand. There may
be issues caused by the incompatibility of the used disc. Recommended using good brands
of CD-R/RW disc for recording.
- This device is designed for recording to normal Audio CD Format. It does not record to
MP3-CD format.
Display Information
During CD playback, press the “DISPLAY” button on main unit or remote control to toggle
between elapsed time or time remaining for the track being played.

E14
CD RECORDING
RECORDING FUNCTION ON CD
Apart from the CD playback function, this unit can perform the CD recording function either from
PHONOGRAPH, TAPE, AUX or USB modes. All recorded tracks will be stored in “AUDIO-CD”
format.
This unit can only copy a pre-recorded Audio CD to CD via “USB Buffering” method.
IMPORTANT NOTE:
Before starting the CD-to-CD Copying process via USB Buffering, you must insert the
Included 2GB USB thumb drive into the USB port for copying an entire CD.
IMPORTANT NOTICES:
A CD-R disc can only be recorded once and does not support erase or re-record function.
The playback quality of CD-R/RW discs may vary depending on the type of audio CD player
they are used in.
The speed that the CD spins at in CD player/recorder is much higher than a normal CD
mechanism. Some mechanical noise and cabinet vibration may occur during operation. This
is normal and not a malfunction of the system.
Quality and compatibility of CD-R/RW discs on the market varies. Please change to another
brand if you are having problems burning a specific type or brand of disc.
A) RECORDING MODES
Whichever media you choose to record from, please complete the following procedures before
recording onto a CD-R/RW:
1. Press the CD Door open/close button on main unit to open the CD tray.
2. Place a blank CD-R or CD-RW Disc into the CD tray.
3. Press the button to close the tray.
4. The system will perform a search and the LCD display will show ‘---bUSY’.
5. Wait until busy message disappear and LCD display shows ‘NO TOC’ (No Table of
Contents) icon, you can record onto this disc now.
NOTE: If ‘NO TOC’ icon of CD-R/RW does not display, you cannot record onto this disc.
I.) RECORDING FROM PHONOGRAPH/AUX-IN
1. Turn the unit on and press the PHONO/AUX button to select PHONO mode to record
from Phono or AUX-IN.
2. - For Phono: Place the vinyl record you wish to record to CD-R/RW on the turntable
ready for playback.
- For Aux-in: Use a 3.5 mm plugs audio cable (not included) to connect an external audio
device (such as an MP3 player, CD player, etc) via its LINE OUT or
headphone jack to the 3.5mm AUX-IN jack on the main unit.
Note: When in Phono mode, the unit will switch to AUX mode automatically if a 3.5 mm
audio cable is plugged into AUX IN jack. Remember to unplug the AUX cable if
you want to record from a record in Phono mode.

E15
3. Press the REC button on remote control or main unit, the LCD display will show
“---Cd” and icon.
4. Press the Play/Pause button to start recording, the “CD” icon will be flashing and the
elapsed time will start counting. The system is recording now.
5. Now start playback of the record in Phono mode if you are recording from vinyl record. If
you are recording from AUX mode, start playback music on your external device which
connected to AUX-IN jack of the unit.
NOTE: You can only either record from Phone or AUX IN a time during recording.
6. Press the TS (Track Separation) button to manual separate a track during recording if
necessary, a new track number will be generated.
7. When the recording is finished, press the STOP button to stop recording. Stop
playback of the vinyl record or the music in your external audio player which connected to
AUX-IN jack.
8. To listen to the music you have recorded, press the CD/USB button to select CD mode
and then press the Play/Pause button.
9. If the CD is full or if you do not want to add more tracks in the disc, finalize the recorded
CD-R/RW disc by follow the instructions in FINALIZING A CD-R/RW DISC section.
II.) RECORDING FROM CASSETTE
1. Press the TAPE button to select ‘Tape’ mode.
2. Place the Cassette Tape you wish to record into the Cassette Slot. Do not fully insert the
tape.
3. Press the REC button on remote control or main unit, the LCD display will show
“---Cd” and icon
4. Press the Play/Pause button to start recording, the “CD” icon will be flashing and the
elapsed time will start counting, the system is recording now.
5. Now fully insert the Cassette Tape into the Cassette Compartment, It will immediately
begin play.
6. Press the TS button to manual separate a track during recording if necessary, a new
track number will be generated.
7. When recording is complete, press the STOP button to stop recording.
8. To eject your Cassette Tape, press the Tape Forward/Eject button next to the
Cassette Door completely down. Tape will be ejected form cassette compartment.
III.) RECORDING FROM THE USB
1. Insert the USB thumb drive you want to record from into the USB port.
2. Press the CD/USB button twice to select USB mode.
3. Select between recording one track or all tracks or programmed track in a USB:

E16
- Record One Track in USB thumb drive
i) SelectthesongyouwishtorecordbyusingtheTUNE/ or/TUNEbutton
and/orFOLDER/PRE/  buttonoftheremoteandthePlay/Pause
buttontostartplayback.
ii) Press the REC button to start recording, icon appears and CD icon is
flashing.
- Record All Tracks of USB thumb drive
i) Press the Play/Pause button to start playback of the USB
ii) Press the REC 1/ALL button once on the remote control, display will show “AUTO
TRACK”.
Note: If you Record One track, make sure “AUTO TRACK” icon will not show in
display, press the REC 1/ALL button to turn it off if “AUTO TRACK”
showing in display.
iii) Press the REC button to start recording, icon appears and CD icon is
flashing.
- Record Programmed tracks in USB thumb drive
i) Select the desired tracks by following the previous “ CD disc programming
“ procedures and press Play/Pause button at the end of programming.
ii) Press the REC 1/ALL button once on the remote control, display will show “AUTO
TRACK”.
Note: If you Record One track, make sure “AUTO TRACK” icon will not show on
the display, press the REC 1/ALL button to turn it off if “AUTO TRACK”
showing in display.
iii) Press the REC button to start recording, icon appears and CD icon is
flashing.
4. After completion of recording, press the “STOP ” button to stop the playback of the
USB thumb drive.

IV.) RECORDING FROM AN AUDIO CD VIA USB BUFFERING
(A MINIMUM 2GB USB THUMB DRIVE IS REQUIRED)
Although this system has a single CD Player/Recorder it is able to copy and record a
pre-recorded Audio CD via the USB port. The recorded disc will be in AUDIO-CD format.
Note: To copy an entire CD disc, a minimum of 2GB space of USB thumb drive is required
for buffering during copying. Before starting this process, first insert the included
2GB USB thumb drive into the USB port.
a.) RECORDING THE 1ST TRACK OR AN ENTIRE AUDIO CD TO CD (VIA USB)
1. Press the CD/USB button to select the CD mode.
2. In CD STOP mode, press the CD Door open/close button to open the CD tray
and place the audio CD (printed side facing upwards) in the tray.
3. After read, the LCD display will show the TOC (Table of Contents) of the pre-recorded
CD/Audio CD.

E17
4. Select between recording the 1st track or an entire CD:
- Press the REC button, the LCD display will show “ SEL 1” (the 1st track of the CD
Disc).
- Press the REC button again, the LCD display will show “ SEL ALL “ (the entire CD
Disc).
5. Press the Play/Pause button to confirm and start CD recording, the LCD display will
show “ CPY 99 “ and start counting down from 99 to 0.
6. After recording has finished, the CD tray will open automatically. Remove the original CD
and replace it with a blank recordable CD-R or CD-RW disc for CD copying.
7. Close the CD Door with the OPEN/CLOSE button, the LCD will show “ dup 99 “ and
start counting down from 99 to 0.
8. After copying of the disc has finished, the LCD display will go back to show the total
tracks and TOC information on the disc and remain in stop mode.
9. If the disc is full or if you do not want to add more tracks in the disc, finalize the recorded
disc by follow the instructions in FINALIZING A CD-R/RW DISC section.
b.) RECORDING A SELECTED TRACK FROM A CD DISC BY PROGRAM FUNCTION
1. Press the CD OPEN/CLOSE button to open the CD Tray and place the audio CD you
wish to record in the tray, printed side facing upwards.
2. Select the desired tracks by following the previous “ CD Disc Programming “ procedure
and make sure the CD is in stop mode during the procedure.
Note: Do not press the Play/Pause button to play the programmed tracks if you want
to record programmed tracks to a CD-R or CD-RW.
3. Press the REC button directly for the system to start the Recording mode.
4. Repeat procedures 5 – 7 as above IV.) a.) to complete the recording, then “Finalize” the
recorded disc if necessary.
Notes:
- Recording a whole CD involves transferring the CD to the USB flash drive, and then to
the CD-R/RW in real-time. So the process could take over an hour to complete.
- During copying mode, no sound will be coming from the Speakers.
- In general, free memory size needs a minimum of 2GB for copying an entire CD disc
(this varies between different CD formats).
- Press the STOP button to interrupt and abort the Copy function at any time after
starting the procedure.

B) RECORDING SETTINGS
i.) RECORDING LEVEL (REMOTE CONTROL ONLY)
The preset recording level of the system is lower than original music source in order to avoid
distortion during recording except AUX-IN recording mode. If you are recording to a CD-R/RW
via Phono, Tape or AUX mode, you are recommended to try a short recording to determine that
no distortion will occur after adjusted your external MP3 or CD player volume level.
Press the REC+/- button to increase/decrease recording level if necessary.
NOTE: REC LEVEL+/- buttons no function in recording CD to USB or USB to CD-R/RW mode.

E18
ii.) PAUSE / RE-START THE RECORDING PROCESS
1. To pause the recording process at any time, press the Play/Pause button on
Remote Control. ‘---bUSY’ will flash for a second on the LCD display, the system will then
generate a new recording track number and the recording process will pause.
2. To restart recording, press the button again. The play indicator will show on the
LCD display.
Notes: 1.) The Play/Pause button has no function when recording CD to USB or
USB to CD-R/RW mode.
2.)When the CD-R or CD-RW is full, the LCD display will show ‘full’. Press the
Stop button and change to another empty CD-R/RW disc to continue
recording.
iii.) MANUAL SEPARATE TRACKS
You can divide the music being recorded track by track during recording from Phono (vinyl),
Cassette Tape or Aux in play functions. It can be done by pressing Track Separation button
during recording, the system will automatically generate a new track and continue recording. The
word ‘---bUSY’ will briefly show on LCD display.
NOTE: TS (Manual track separation) no function in recording CD to USB or USB to CD-R/RW
mode.
iV.) FINALIZING A CD-R/RW DISC
You must convert the CD-R/RW disc into standard CD before playing at other audio CD player.
This process is knows as finalizing and a table of contents (TOC) will be written to the CD at the
same time:
1. Press the CD/USB button to select the CD mode. ‘CD’ will appear on the LCD display.
2. Press the CD Door open/close button to open the CD tray.
3. Place your Audio CD that you wish to finalize (print side up) inside the CD tray.
4. Press the button to close the CD tray.
5. The system will perform a search and the LCD display will show ‘---bUSY’. Wait until this
message disappears from display.
6. In CD stop mode, press the FINALIZE button on Remote Control or main unit. ‘Fin-dIC’ will
appear on the LCD display on the main unit.
7. Press the Play/Pause button to start the finalizing process.
8. The LCD display will show ‘---bUSY’ during this process.
Note: You can stop CD Finalize mode at any time by pressing the STOP button.
9. When Finalizing is completed, ‘OPEN’ will appear on the LCD display and the CD tray will
open automatically. Your CD-R/RW is now converted into a standard Audio Format CD
and can be played on any other Audio CD player.
IMPORTANT NOTICES:
The time for finalizing is subject to the contents of the recording and it may take up to 15
minutes in some cases.
All button functions are disabled during the finalizing process.
NEVER turn off the Power or un-plug the Power cord during the finalizing process.

E19
The CD-R disc cannot be recorded again after finalizing.
Finalized CD-R discs can be played in ordinary CD players, but finalized CD-RW disc may
not play in ordinary CD players.

Due to the variance of the compatibility of CD-R or CD-RW discs in the market, please
change to other one if you find the recording performance of the existing one unacceptable.
This is not a malfunction of the system.
C) UN-FINALIZE OR ERASING A CD-RW DISC
It is possible to erase the last recorded track or erase a whole recorded disc (CD-RW only).
i.) UN-FINALIZE A CD-RW DISC
1. Press the CD/USB button to select CD mode.
2. Press the CD Door open/close button on main unit to open the CD tray, place the
CD-RW disc you would like to un-finalize into the CD tray.
3. Press the button to close the CD tray. The system will perform a search and the LCD
display will show ‘---bUSY’. Wait for busy message disappear from display.
4. In CD stop mode, press the ERASE button on remote control or main unit, the LCD display
will show ‘UNF-dIC’ message.
5. Press the Play/Pause button to start un-finalizing, ‘---bUSY’ message will appear on the
LCD display.
6. Once the un-finalizing process has finished, the LCD display will show total track numbers,
total playing time and ‘NO TOC’ indicator.
Ii.) ERASE ONE TRACK
1. Press the CD/USB button to select the CD mode.
2. Press the CD Door open/close button on main unit to open the CD tray.
3. Place the un-finalized CD-RW disc from which you would like to delete tracks, into the CD
tray.
4. Press the button to close the CD tray. The system will perform a search and the LCD
display will show ‘---bUSY’. Wait for busy message disappear from display.
5. In CD stop mode, press the ERASE button on remote control or main unit. The LCD display
will show ‘ErS’ (erase) message and the last track number of the disc.
6. Press the Play/Pause button on main unit or remote control to erase the last track from
the disc. ‘---bUSY’ message will appear on the LCD display. Once the erasing process has
finished, the LCD display will show the disc’s total number of tracks and the total playing
time.
7. Repeat steps 5 to 6 to continue erasing more tracks if necessary.
8. The ‘NO TOC’ (No Table of Contents) indicator will appear on the LCD display when ALL
tracks have been deleted.
iii.) ERASE ALL TRACKS
NOTE: This operation cannot be undone. The ‘erase one track only’ function cannot be
